Sharp AR-M161 User manual

Be sure to become thoroughly familiar with this manual to
gain the maximum benefit from the product.
Before installing this product, be sure to read the
cautions and installation requirements sections.
Be sure to keep all operation manuals handy for reference
including this manual, the "Operation manual (for general
information and copier)" and operation manuals for any
optional equipment which has been installed.
MODEL
DIGITAL MULTIFUNCTIONAL
SYSTEM
OPERATION MANUAL
(for general information and copier)
PART 1: GENERAL INFORMATION
• BEFORE USING THE PRODUCT
•TROUBLESHOOTING
AND MAINTENANCE
•PERIPHERAL DEVICES
AND SUPPLIES
PART 2: COPIER OPERATION
•COPY FUNCTIONS
•CONVENIENT COPY
FUNCTIONS
•APPENDIX
•
KEY OPERATOR'S GUIDE
12
24
40
45
64
73
75
Page
AR-M161/AR-M162/AR-M165
AR-M206/AR-M207
With the RSPF installed
AR-M161
AR-M162
AR-M165
AR-M206
AR-M207
HINA
KS1
QSZZ
Pegasus-E_Copy_Ex.book 0 ページ ２００４年９月２５日 土曜日 午前１２時２８分

Warranty
While every effort has been made to make this document as accurate and helpful as possible, SHARP Corporation
makes no warranty of any kind with regard to its content. All information included herein is subject to change without
notice. SHARP is not responsible for any loss or damages, direct or indirect, arising from or related to the use of this
operation manual.
© Copyright SHARP Corporation 2004. All rights reserved. Reproduction, adaptation or translation without prior
written permission is prohibited, except as allowed under copyright laws.
Warning:
This is a Class A product. In a domestic environment this product may cause radio interference in which case
the user may be required to take adequate measures.
In some areas, the "POWER" switch positions are marked "I" and " " on the copier
instead of "ON" and "OFF".
The symbol " " denotes the copier is not completely de-energized but in a stand-by
condition at this "POWER" switch position.
If your copier is so marked, please read "I" for "ON" and " " for "OFF".
Caution!
For a complete electrical disconnection, pull out the main plug.
The socket-outlet shall be installed near the equipment and shall be easily
accessible.
Required in IEC-950 (EN 60 950) - Europe
• The equipment should be installed near an accessible socket outlet for easy disconnection.
Required in Appendix ZB of BS 7002 (En 60 950) — United Kingdom
MAINS PLUG WIRING INSTRUCTIONS
The mains lead of this equipment is already fitted with a mains plug which is either a non-rewireable
(moulded) or a rewireable type. Should the fuse need to be replaced, a BSI or ASTA approved fuse
to BS1362 marked or and of the same rating as the one removed from the plug must
be used.
Always refit the fuse cover after replacing the fuse on the moulded plug. Never use the plug without
the fuse cover fitted.
In the unlikely event of the socket outlet in your home not being compatible with the plug supplied
either cut-off the moulded plug (if this type is fitted) or remove by undoing the screws if a rewireable
plug is fitted and fit an appropriate type observing the wiring code below.
DANGER: The fuse should be removed from the cut-off plug and the plug destroyed immediately
and disposed of in a safe manner. Under no circumstances should the cut-off plug be inserted
elsewhere into a 13A socket outlet as a serious electric shock may occur.
To fit an appropriate plug to the mains lead, follow the instructions below:
IMPORTANT: The wires in this mains lead are coloured in accordance with the following code:
GREEN-AND-YELLOW: Earth
BLUE: Neutral
BROWN: Live
As the colours of the wires in this mains lead may not correspond with coloured markings
identifying the terminals in your plug, proceed as follows:
The wire which is coloured GREEN-AND YELLOW must be connected to the terminal in the plug
which is marked with the letter E, or by the safety earth symbol , or coloured green or green-
and-yellow.
The wire which is coloured BLUE must be connected to the terminal which is marked with the letter
Nor coloured black.
The wire which is coloured BROWN must be connected to the terminal which is marked with the
letter Lor coloured red.
If you have any doubt, consult a qualified electrician.
WARNING: THIS APPARATUS MUST BE EARTHED.
➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢
➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢
➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣
➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢➣➢
Pegasus-E_Copy_Ex.book 1ページ ２００４年９月２３日 木曜日 午前１１時４１分

1
Part 1: General Information
Pegasus-E_Copy_Ex.book 1ページ ２００４年９月２３日 木曜日 午前１１時４１分

2
Pegasus-E_Copy_Ex.book 2 ページ ２００４年９月２３日 木曜日 午前１１時４１分

3
Notes
• Considerable care has been taken in preparing this manual. If you have any comments or concerns about the
manual, please contact your nearest authorised service representative.
• This product has undergone strict quality control and inspection procedures. In the unlikely event that a defect or
other problem is discovered, please contact your dealer or nearest authorised service representative.
• Aside from instances provided for by law, SHARP is not responsible for failures occurring during use of the product
or its options, or failures due to incorrect operation of the product and its options, or other failures, or for any
damage that occurs due to use of the product.
PRODUCT CONFIGURATIONS
This product series consists of the models indicated below. The product configuration varies by model.
The explanations and illustrations in this manual generally use the AR-M206/AR-M207 (with the optional RSPF
installed).
(As of the end of October, 2004)
The "Dual function board" cited in this manual can be installed as an option in some models and is pre-installed standard in
other models. For detailed information, please refer to "PERIPHERAL DEVICES AND SUPPLIES" (page 40).
The display screens, messages, and key names shown in the manual may differ from those on the actual machine due to
product improvements and modifications.
Model Appearance Copying speed Paper trays Optional trays
AR-M161
AR-M162
AR-M165
16 copies/min. One (250 x 1)
250-sheet paper
feed unit (AR-D24)
2 x 250-sheet paper
feed unit (AR-D25)
AR-M206
AR-M207
With the RSPF installed
20 copies/min. Two (250 x 2)
Some models may not be available in some countries.
Note
Chapter00.fm 3 ページ ２００４年１０月１４日 木曜日 午後６時１分

4
CONTENTS
Part 1: General Information
PRODUCT CONFIGURATIONS ................................................................................................................ 3
CAUTIONS................................................................................................................................................. 6
●CAUTIONS ON USING..................................................................................................................................... 6
●LASER INFORMATION .................................................................................................................................... 7
INSTALLATION REQUIREMENTS ........................................................................................................... 8
●ENVIRONMENTAL INFORMATION................................................................................................................. 8
MANUALS PROVIDED WITH THE PRODUCT......................................................................................... 9
MAIN FEATURES .................................................................................................................................... 10
1BEFORE USING THE PRODUCT
PART NAMES AND FUNCTIONS ................... 12
●OPERATION PANEL ......................................14
●OPERATION IN COPY, PRINT, SCAN, AND
FAX MODES...................................................16
TURNING THE POWER ON AND OFF ........... 17
●POWER ON ....................................................17
●POWER OFF ..................................................17
LOADING PAPER............................................ 18
●PAPER............................................................18
●LOADING PAPER...........................................19
●CHANGING THE PAPER SIZE SETTING OF A
TRAY ..............................................................21
●DISABLING (ENABLING) AUTO TRAY
SWITCHING ...................................................22
AUDITING MODE ............................................ 23
●NUMBER OF ACCOUNTS IN AUDITING
MODE .............................................................23
●USING AUDITING MODE...............................23
2
TROUBLESHOOTING AND MAINTENANCE
TROUBLESHOOTING..................................... 25
●MACHINE/COPYING PROBLEMS................ 25
INDICATORS AND DISPLAY MESSAGES .... 28
REMOVING MISFEEDS .................................. 29
●ORIGINAL MISFEED IN THE SPF ................ 29
●MISFEED IN THE BYPASS TRAY ................ 30
●MISFEED IN THE MACHINE......................... 31
●MISFEED IN TRAY 1 ..................................... 33
●MISFEED IN TRAY 2 ..................................... 34
REPLACING THE TONER CARTRIDGE ........ 35
CHECKING THE TOTAL OUTPUT COUNT ... 36
CLEANING THE MACHINE............................. 37
●CLEANING THE DOCUMENT GLASS AND
SPF/DOCUMENT COVER............................. 37
●CLEANING THE BYPASS TRAY PAPER FEED
ROLLER......................................................... 37
●CLEANING THE TRANSFER CHARGER ..... 38
ADJUSTING THE DISPLAY CONTRAST....... 39
3
PERIPHERAL DEVICES AND SUPPLIES
OPTIONAL EQUIPMENT ................................ 40
●REVERSING SINGLE PASS FEEDER /
SINGLE PASS FEEDER................................ 41
●250-SHEET PAPER FEED UNIT / 2 X
250-SHEET PAPER FEED UNIT................... 41
●DUAL FUNCTION BOARD ............................ 42
STORAGE OF SUPPLIES............................... 42
●PROPER STORAGE ..................................... 42
Pegasus-E_Copy_Ex.book 4 ページ ２００４年９月２３日 木曜日 午前１１時４１分

5
CONTENTS
Part 2: Copier Operation
4COPY FUNCTIONS
NORMAL COPYING ........................................ 45
●MAKING A COPY DARKER OR LIGHTER ....48
●SELECTING THE TRAY.................................49
●SETTING THE NUMBER OF COPIES ...........49
●SELECTING THE ORIGINAL SIZE ................50
●USING THE BYPASS TRAY TO COPY A
SPECIAL SIZE ORIGINAL..............................51
REDUCING OR ENLARGING A COPY........... 52
●AUTOMATIC RATIO SELECTION .................52
●MANUAL RATIO SELECTION (PRESET COPY
RATIOS/ZOOM)..............................................52
SELECTING THE VERTICAL AND
HORIZONTAL COPY RATIOS SEPARATELY
(XY zoom copying) ......................................... 54
TWO-SIDED COPYING ................................... 56
●TWO-SIDED COPYING..................................56
●TWO-SIDED COPYING OF ONE-SIDED
ORIGINALS ....................................................57
●
TWO-SIDED COPIES OF TWO-SIDED ORIGINALS
(ONLY WHEN USING THE RSPF)
......................59
●
ONE-SIDED COPIES OF TWO-SIDED ORIGINALS
(ONLY WHEN USING THE RSPF)
......................60
TWO-SIDED COPIES USING THE BYPASS TRAY ... 61
DUAL PAGE COPY (Dual page copy) ........... 62
INTERRUPTING A COPY RUN (Interrupt
copying)........................................................... 63
5
CONVENIENT COPY FUNCTIONS
ROTATING THE IMAGE 90 DEGREES
(Rotation copy) ............................................... 64
SORT MODE.................................................... 64
COPYING MULTIPLE ORIGINALS ONTO A SINGLE
SHEET OF PAPER (2 in 1 / 4 in 1 copy)
............... 66
CREATING MARGINS WHEN COPYING
(Margin shift)................................................... 68
ERASING SHADOWS AROUND THE EDGES
OF A COPY (Erase copy) ............................... 69
CARD SHOT .................................................... 71
6APPENDIX
SPECIFICATIONS ........................................... 73
7KEY OPERATOR'S GUIDE
PURPOSE OF THE KEY OPERATOR
PROGRAMS .................................................... 75
●
PROGRAMS RELATED TO ALL FUNCTIONS OF
THE MACHINE (COPY, FAX, PRINTER, AND
NETWORK SCANNER FUNCTIONS)
.............. 75
●
PROGRAMS FOR COPY MODE ....................... 75
●
PROGRAMMING A KEY OPERATOR CODE ... 75
PROGRAMMING A KEY OPERATOR CODE ... 76
KEY OPERATOR PROGRAM LIST ................ 77
USING THE KEY OPERATOR PROGRAMS.. 78
●
ACCOUNT CONTROL ....................................... 79
●
DEVICE CONTROL............................................ 81
●
OPERATION SETTING...................................... 83
●
ENERGY SAVE.................................................. 85
●
COPY SETTINGS .............................................. 86
MATERIAL SAFETY DATA SHEET................ 89
INDEX .............................................................. 97
KEY OPERATOR CODE NUMBER: FACTORY
SETTING........................................................ 103
Pegasus-E_Copy_Ex.book 5 ページ ２００４年９月２５日 土曜日 午前１２時２１分

6
CAUTIONS
Follow the cautions below when using this machine.
CAUTIONS ON USING
Warning:
• The fusing area is hot. Exercise care in this area when removing misfed paper.
• Do not look directly at the light source. Doing so may damage your eyes.
Caution:
• Do not switch the machine rapidly on and off. After turning the machine off, wait 10
to 15 seconds before turning it back on.
• Place the machine on a firm, level surface.
• When the machine is not used for a long time, for example, during prolonged
holidays, turn the power switch off and remove the power cord from the outlet.
• When moving the machine, be sure to turn the power switch off and remove the
power cord from the outlet.
• Do not cover the machine with a dust cover, cloth or plastic film while the power is
on. Doing so may prevent heat dissipation, damaging the machine.
• Do not make any modifications to this machine. Doing so may result in personal
injury or damage to the machine.
• Do not make copies of anything which is prohibited from copying by law. The
following items are normally prohibited from printing by national law. Other items
may be prohibited by local law.
• Money • Stamps • Bonds • Stocks
• Bank drafts • Checks • Passports • Driver's licences
• Do not touch the photoconductive drum. Scratches or smudges on the drum will
cause dirty prints.
• Store spare toner cartridges in a cool dry place without removing from the package
before use.
• If they are exposed to direct sunlight or excessive heat, poor copies may result.
Fusing unit
Chapter00.fm 6 ページ ２００４年１０月５日 火曜日 午前１１時５７分

7
CAUTIONS
LASER INFORMATION
Wave length 785 nm + 10 nm/- 15 nm
Pulse times (8.141 µs ± 0.1 µs)/7 mm
Output power 0.14 mW - 0.22 mW
At the production line, the output power of the scanner unit is adjusted to 0.8 MILLIWATT PLUS 10 % and is maintained
constant by the operation of the Automatic Power Control (APC).
Caution
Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous
radiation exposure.
For North America:
SAFETY PRECAUTIONS
This Digital Equipment is rated Class 1 and complies with 21 CFR 1040.10 and 1040.11 of the CDRH standards. This means
that the equipment does not produce hazardous laser radiation. For your safety, observe the precautions below.
•Do not remove the cabinet, operation panel or any other covers.
•The equipment's exterior covers contain several safety interlock switches. Do not bypass any safety interlock by inserting
wedges or other items into switch slots.
For Europe:
CLASS 1 LASER PRODUCT
LASER KLASSE 1
LUOKAN 1 LASERLAITE
KLASS 1 LASERAPPARAT
CAUTION
INVISIBLE LASER RADIATION
WHEN OPEN INTERLOCKS
DEFEATED. AVOID EXPOSURE
TO BEAM.
VORSICHT
UNSICHTBARE
LASERSTRAHLUNG WENN
ABDECKUNG GEÖFFNET UND
SICHERHEITSVERRIEGELUNG
ÜBERBRÜCKT. NICHT DEM
STRAHL AUSSETZEN.
ADVARSEL
USYNLIG LASERSTRÅLNING
VED ÅBNING, NÅR
SIKKERHEDSBRYDERE ER
UDE AF FUNKTION. UNDGÅ
UDSAETTELSE FOR
STRÅLNING.
VAROITUS!
LAITTEEN KÄYTTÄMINEN
MUULLA KUIN TÄSSÄ
KÄYTTÖOHJEESSA
MAINITULLA TAVALLA SAATTAA
ALTISTAA KÄYTTÄJÄN
TURVALLISUUSLUOKAN 1
YLITTÄVÄLLE
NÄKYMÄTTÖMÄLLE
LASERSÄTEILYLLE.
VARNING
OM APPARATEN ANVÄNDS PÅ
ANNAT SÄTT ÄN I DENNA
BRUKSANVISNING
SPECIFICERATS, KAN
ANVÄNDAREN UTSÄTTAS FÖR
OSYNLIG LASERSTRÅLNING,
SOM ÖVERSKRIDER GRÄNSEN
FÖR LASERKLASS 1.
CLASS 1
LASER PRODUCT
LASER KLASSE 1
Pegasus-E_Copy_Ex.book 7 ページ ２００４年９月２３日 木曜日 午前１１時４１分

8
INSTALLATION REQUIREMENTS
Improper installation may damage this product. Please note the following during initial installation and whenever the
machine is moved.
1. The machine should be installed near an accessible power outlet for easy connection.
2. Be sure to connect the power cord only to a power outlet that meets the specified voltage and current
requirements. Also make certain the outlet is properly grounded.
•For the power supply requirements, see the name plate on the back of the main unit.
3. Do not install your machine in areas that are:
•damp, humid, or very dusty
•exposed to direct sunlight
•poorly ventilated
•subject to extreme temperature or humidity changes, e.g., near
an air conditioner or heater.
4. Be sure to allow the required space around the machine for
servicing and proper ventilation.
ENVIRONMENTAL INFORMATION
Connect the machine to a power outlet which is not used for other electric appliances. If a lighting fixture is
connected to the same outlet, the light may flicker.
A small amount of ozone is produced within the printer during operation. The emission level is insufficient to cause any health
hazard.
NOTE:
The present recommended long term exposure limit for ozone is 0.2 mg/m3(0.1 ppm) calculated as an 8 hr. time-weighted
average concentration.
However, since the small amount that is emitted may have an objectionable odor, it is advisable to place the copier in a
ventilated area.
As an ENERGY STAR®Partner, SHARP has determined that this product meets the ENERGY
STAR®guidelines for energy efficiency.
Note
20 cm (8")
20 cm
(8")
20 cm
(8")
Pegasus-E_Copy_Ex.book 8 ページ ２００４年９月２３日 木曜日 午前１１時４１分

9
MANUALS PROVIDED WITH THE
PRODUCT
Multiple manuals are provided for use of the machine. Please read each manual as appropriate for the functions that
you wish to use.
Operation manual (for general information and copier) (this manual):
The first half of this manual contains general information on the machine, including safety precautions and the
procedures for loading paper, removing misfeeds, and performing regular maintenance.
The second half of the manual contains explanations of how to use the copy function of the machine.
The manual also includes explanations of key operator programs for management of the machine and for the copy
function. Explanations of key operator programs related to the fax, printer, and network scanner functions can be
found in the respective manuals for those functions.
The key operator programs are used by the administrator of the machine to enable or disable functions to suit the
needs of your workplace.
Software setup guide
This explains how to install and configure the printer driver.
Operation manual (for facsimile)*1:
This explains how to use the fax function of the machine. To use the fax function, the optional facsimile expansion kit
(AR-FR11) must be installed.
Operation manual (for printer and scanner)*2:
This explains how to use the machine as a printer and a scanner when it is connected to a computer.
Operation manual (for network printer)*2:
This explains how to use the machine as a network printer.
To use the machine as a network printer, the optional network expansion kit (AR-NB3) must be installed.
Operation manual (for network scanner)*2:
This explains how to use the machine as a network scanner when it is connected to a computer. To use the machine
as a network scanner, the optional network expansion kit must be installed.
*1 The "Operation manual (for facsimile)" is contained in the optional facsimile expansion kit.
*2 The "Operation manual (for printer and scanner)" is contained in the accompanying CD-ROM in PDF format. The "Operation
manual (for network printer)" and the "Operation manual (for network scanner)" are contained in PDF format in the CD-ROM
that accompanies the network expansion kit. (These manuals are not provided in printed form.)
The meaning of "R" in original and paper size indications
An "R" appearing at the end of an original or paper size (A4R, B5R (8-1/2" x
11"R, 5-1/2" x 8-1/2"R), etc.) indicates that the original or paper is oriented
horizontally as shown below.
Sizes that can be placed only in the horizontal (landscape) orientation (A3,
B4 (11" x 17", 8-1/2" x 14")) do not contain the "R" in their size indication.
Conventions used in this manual
This manual refers to the Reversing single pass feeder as the "RSPF" and the single pass feeder as the "SPF".
Unless specific mention is made, both the RSPF and the SPF are referred to simply as "SPF".
Warns the user that injury may result if the contents of the warning are not properly followed.
Cautions the user that damage to the machine or one of its components may result if the contents
of the caution are not properly followed.
Notes provide information relevant to the machine regarding specifications, functions,
performance, operation and such, that may be useful to the user.
Horizontal (Landscape) orientation
Warning
Caution
Note
Pegasus-E_Copy_Ex.book 9 ページ ２００４年９月２３日 木曜日 午前１１時４１分

10
MAIN FEATURES
High-speed laser copying
•First-copy time*1at 300 dpi*2is only 7.2 seconds.
•Copying speed is 20 (AR-M206/AR-M207) or 16 (AR-M161/AR-M162/AR-M165) copies per minute. This provides
a big boost to workplace productivity.
*1 Measured after the machine has warmed up following power-on, copying using the document glass (A4 (8-1/2" x 11") paper
fed from machine tray 1). The first-copy time may vary depending on machine operating conditions and ambient conditions
such as temperature and power voltage.
*2 "dpi" ("dots per inch") is a unit that is used to measure resolution. Resolution indicates how much detail can be reproduced in
a printed or scanned image.
High-quality digital image
•High-quality copying at 600 dpi is performed.
•In addition to automatic exposure adjustment, two exposure modes can be selected: "TEXT" for text-only originals,
and "PHOTO" for photographs. The exposure can be adjusted to five levels in each mode.
•
Photo mode allows clear copying of originals with delicate halftones such as monochrome photos and colour photos.
Enhanced copying features
•The zoom function can be used to reduce or enlarge copies from 25% to 400% in increments of 1%. (When the
SPF is used, the zoom copy ratio range is 50% to 200%.)
•Up to 999 copies can be made of an original scanned just once. (This can be changed to a maximum of 99 copies
in the key operator programs.)
•The key operator programs allow functions to be selected and managed to meet your specific needs. For example,
access to the machine can be controlled by enabling audit mode.
•The optional dual function board can be installed to enable use of rotation copy and other convenient functions.
* When the dual function board is installed.
Sort function (when the dual function board is installed)
Copies of multiple original pages can sorted into sets.
Laser printer function / colour scanner function
•The machine is equipped standard with a USB port and a parallel port. A computer can be connected to these
ports to use the machine as a printer or a scanner.
•To use the machine as a printer or scanner, the printer driver or scanner driver must first be installed as explained
in the "Software setup guide".
•The scanning feature is only available when the computer is connected to the USB port and is running Windows
98/Me/2000/XP. If the computer is running Windows 95/NT 4.0 or is connected to the parallel port, only printing is
available.
A
AAA CARD CARD
CARD
Erase copy* Margin shift* 2 in 1 copy* 4 in 1 copy*
Dual page copyRotation copy* XY zoom copying Back Card shot*
Front
2
1
3
2
1
3
1
23
2
1
3
Pegasus-E_Copy_Ex.book 10 ページ ２００４年９月２３日 木曜日 午前１１時４１分

11
MAIN FEATURES
Fax function (option)
Installation of the optional facsimile expansion kit enables the plain-paper, Super G3 laser fax function to be used.
Network connection (option)
The optional network expansion kit (AR-NB3) can be installed to enable the machine to be used as a network printer
and network scanner.
Environment and people friendly design
•Preheat and auto power shut-off modes are provided to reduce power consumption when the machine is not in
active use.
•A universal design has been implemented in the product whereby the height of the operation panel and shape of
the keys are designed to be usable by as many people as possible.
Pegasus-E_Copy_Ex.book 11 ページ ２００４年９月２３日 木曜日 午前１１時４１分

12
1BEFORE USING THE PRODUCT
This chapter contains basic information required for use of the machine. Please read this chapter before using the
machine.
PART NAMES AND FUNCTIONS
(1) USB 2.0 port (USB-2) (when the dual function
board is installed)
Connect to your computer to this port to use the
printer and scanner functions.
(2) USB 1.1 port (USB-1)
Connect to your computer to this port to use the
printer and scanner functions.
(3) Parallel port
Connect to your computer to this port to use the
printer function.
(4) Charger cleaner
Use to clean the transfer charger.
(5) Glass cleaner
Use to clean the original scanning glass.
(6) Document glass
Place an original that you wish to scan face down
here. (Page 45)
(7) Handles
Use to move the machine.
(8) Power switch
Press to turn the machine power on and off.
(9) Centre tray
Copies and printed pages are output to this tray.
(10) Top tray (when the job separator tray kit is
installed)
Received faxes (when the fax option is installed)
and print jobs are delivered to this tray.
(11) Operation panel
Contains operation keys and indicator lights.
(12) Front cover
Open to remove paper misfeeds or replace the
toner cartridge.
(13) Tray 1
Tray 1 can hold approximately 250 sheets of
copy paper (80 g/m2(20 lbs.)).
For restrictions on paper types and weights, see
"PAPER" (page 18).
(14) Tray 2
Tray 2 can hold approximately 250 sheets of
copy paper (80 g/m2(20 lbs.)).
For restrictions on paper types and weights, see
"PAPER" (page 18).
(15)
(11)
(12)
(13)(14)
(10)
(9)
(2)
(1)
(3)
(6)
(7)
(8)
(7)
(16)
(17)
(18) (19) (20)
(5)
(4)
Pegasus-E_Copy_Ex.book 12 ページ ２００４年９月２３日 木曜日 午前１１時４１分

13
BEFORE USING THE PRODUCT
1
(15) Document cover (when installed)
Open to make a copy from the document glass.
(16) Side cover
Open to remove misfed paper.
(17) Side cover handle
Pull to open the side cover.
(18) Bypass tray guides
Adjust to the width of the paper when using the
bypass tray.
(19) Bypass tray
Special paper (heavy paper or transparency film)
can be fed from the bypass tray.
(20) Bypass tray extension
Pull out when feeding large paper such as A3 and
B4 (11" x 17" and 8-1/2" x 14").
(21) Toner cartridge lock release lever
To replace the toner cartridge, pull out the toner
cartridge while pushing on this lever.
(22) Toner cartridge
Contains toner.
(23) Document feeder tray (when the SPF is
installed)
Place the original(s) that you wish to scan face up
here. Up to 40 sheets can be placed.
(24) Original guides (when the SPF is installed)
Adjust to the size of the originals.
(25) Feeding roller cover (when the SPF is
installed)
Open to remove misfed originals.
(26) Right side cover (when the SPF is installed)
Open to remove misfed originals.
(27) Fusing unit release levers
To remove the paper misfed in the fusing unit,
push down on these levers and remove the
paper.
(28) Roller rotating knob
Rotate to remove misfed paper.
(29) Exit area (when the SPF is installed)
Originals exit the machine here after
copying/scanning when the SPF is used.
(30) Reversing tray (when the RSPF is installed)
Pull out to remove misfed originals.
(31) Photoconductive drum
Images are formed on the photoconductive drum.
(32) Fusing unit paper guide
Open to remove misfed paper.
(27)(28)
(22)
(21)
(23) (24) (25)
(26)
(31) (32)
(29) (30)
The fusing unit is hot. Do not touch
the fusing unit when removing
misfed paper. Doing so may cause a
burn or injury.
Do not touch the photoconductive drum
(green portion) when removing the misfed
paper. Doing so may damage the drum and
cause smudges on copies.
The model name is on the front cover of the
machine.
Warning
Caution
Note
Pegasus-E_Copy_Ex.book 13 ページ ２００４年９月２３日 木曜日 午前１１時４１分

14
BEFORE USING THE PRODUCT
OPERATION PANEL
(1) Keys for fax function (when the fax option is
installed)
These are used in fax mode. For more
information, see the "Operation manual (for
facsimile)" that accompanies the optional
facsimile expansion kit.
(2) [COPY] key / indicator
Press to select copy mode. If pressed when
"Ready to copy." appears or during warm-up, the
total number of sheets used (page 36) appears
while the key is pressed.
(3) [PRINT] key / indicator
Press to select print mode.
• ONLINE indicator
Print jobs can be received when this indicator is
lit.
• DATA indicator
This lights steadily when there is a print job in
memory that has not been printed, and blinks
during printing.
(4) [SCAN] key / indicator
Press to select scan mode. (To connect a
computer to the USB port on the machine and
use the scanner function, see the "Operation
manual (for printer and scanner)". To use the
machine as a network scanner, see the
"Operation manual (for network scanner)" that
accompanies the optional network expansion kit.)
(5) Display
Shows various messages. For more information
see page 16.
(6) [BACK] key
Press to return the display to the previous screen.
(7) [FAX STATUS] key (when the fax option is
installed)
This key is used in fax mode. For more
information, see the "Operation manual (for
facsimile)" that accompanies the optional
facsimile expansion kit.
(8) [OK] key
Press to enter the selected setting.
(9) Copy number display
The selected number of copies appears. During
copying, this shows the remaining number of
copies.
(10) Numeric keys
Use to select the number of copies.
(11) [INTERRUPT] key ( ) / INTERRUPT indicator
Interrupts a copy run to allow an interrupt copy
job to be performed. (Page 63)
(12) [C] key
Press to clear the set number of copies or stop a
copy run.
ON LINE DATA
LINE DATA
SCAN
FAX
PRINT
26 27 28 29 30
31 32 33 34 35
41 42 43 44 45
46 47 48 49 50
36 37 38 39 40
ABCDE
FGH I J
KLMNO
PQR TS
U V W XYZ SP
SPEAKER
SHIFT
REDIAL/PAUSE SPEED
SYMBOL
COMM. SETTING
SPACE/–
COPY
(13)
(2)
(1) (3) (4)
(14)
The indicators of the
operation panel may
differ depending on the
country and region.
Chapter01.fm 14 ページ ２００４年１０月１４日 木曜日 午後６時７分

15
BEFORE USING THE PRODUCT
1
(13) LINE STATUS indicator (when the fax option
is installed)
This key is used in fax mode. For more
information, see the "Operation manual (for
facsimile)" that accompanies the optional
facsimile expansion kit.
(14) [FAX] key / indicator (when the fax option is
installed)
LINE indicator, DATA indicator
This key is used in fax mode. For more
information, see the "Operation manual (for
facsimile)" that accompanies the optional
facsimile expansion kit.
(15) [EXPOSURE] key
Use to select the exposure mode. "AUTO",
"TEXT", or "PHOTO" can be selected. (Page 48)
(16) [PAPER SELECT] key
Use to manually select a paper tray. (Page 49)
(17) [COPY RATIO] key
Press to select a reduction or enlargement copy
ratio. (Page 52)
(18) [AUTO IMAGE] key
Press to have the copy ratio selected
automatically. (Page 52)
(19) [OUTPUT] key (Only effective when the dual
function board is installed)
Use to select the sort function. (Page 64)
(20) [2-SIDED COPY] key (only on models that
support two-sided printing)
Select the two-sided copying mode. (Page 56)
(21) Arrow keys
Press to move the highlighting (which indicates
that an item is selected) in the display.
(22) [SPECIAL FUNCTION] key
Press to select special functions.
(23) [ACC.#-C] key ( )
Press the end the use of an account and return
the display to the account number entry screen.
(Page 23)
(24) [0] key
Press during a continuous copy run to display the
number of copies completed.
(25) [READ-END] key ( )
When copying in sort mode from the document
glass, press this key when you have finished
scanning the original pages and are ready to start
copying. (Page 64)
(26) [START] key ( ) / indicator
Copying is possible when this indicator is on.
Press the key to start copying.
(27) [CA] key
Clears all selected settings and returns the
machine to the default settings. (Page 18)
ABC DEF
JKLGHI MNO
TUVPQRS WXYZ
@.-
_
COPY
EXPOSURE
PAPER
SELECT
COPY
RATIO
AUTO
IMAGE OUTPUT
2-SIDED
COPY SPECIAL FUNCTION
ACC. #-C READ-END
SCAN
FAX
COLOUR MODE
PROGRAM
FORMAT
BROADCAST
OK BACK
FAX STATUS
RESOLUTION ADDRESS ORIGINAL SIZE DUPLEX SCAN
(5) (9)(6) (7) (8) (10) (11) (12)
(15) (16) (17) (18) (19) (20) (21) (22) (27)(26)(25)(23) (24)
Pegasus-E_Copy_Ex.book 15 ページ ２００４年９月２３日 木曜日 午前１１時４１分

16
BEFORE USING THE PRODUCT
Display (base screen)
Example: Copy mode
* The display shown is the AR-M206/AR-M207 (when the
optional RSPF is installed) display.
Icons appearing in the special function icon display
* These only appear when the dual function board is
installed.
(1) Exposure display
Indicates the selected exposure mode.
(2) Special function icon display
Icons of enabled special functions will appear.
(3) Message display
Messages are displayed regarding machine
status and operation.
(4) Original size display
The size of the placed original and the icon of the
original scanning mode will appear.
: One-sided scanning in the SPF.
: Scanning on the document glass
: Two-sided scanning in the RSPF.
(5) Copy ratio display
Displays the copy ratio for reduction or
enlargement.
(6) Paper size display
Displays the selected paper size. When "AUTO"
appears, the most suitable size of paper is
automatically selected.
(7) Paper tray display
The selected paper tray is highlighted.
OPERATION IN COPY, PRINT, SCAN, AND FAX MODES
Some operations in the various modes of the machine cannot take place simultaneously.
*1 Can be used after pressing the [INTERRUPT] key ( ).
*2 After the page that is currently being printed is output, the job is interrupted.
*3 Only possible when the computer is connected to the USB-2 port.
*4 Only possible when the computer is connected to the parallel port or USB-1 port; the job is interrupted after the page that is
currently being printed is output.
*5 After output of the page that is currently being printed via the parallel port or USB-1 port, the job is interrupted.
Ready to copy.
A4
100%
A4
AUTO
AUTO
(2) (3) (4)
(5)
(1)
(7)(6)
1-sided to 2-sided
copy
Centre erase
copy*
2-sided to 2-sided
copy
Edge + Centre
erase*
2-sided to 1-sided
copy 2 in 1 copy*
Sort function* 4 in 1 copy*
Margin shift copy* Dual page copy
Edge erase copy* Card shot*
Interrupting operation
Copy output Printing Scanning
Faxing
Scanning
originals
Printing
faxes
Interrupted operation
Copying Output Yes*1No No No No
Printing Output Yes*2Yes*4Yes*5No
Scanning Scanning an original
No No No No
Faxing
Scanning an original
No Yes*3No Yes
Output Yes*2No Yes*2Yes
•Printing is not possible when the front or side cover is opened for machine maintenance, or when a misfeed
occurs or the machine runs out of paper or toner, or when the drum cartridge reaches its replacement time.
•If an original misfeed occurs in the SPF, printing will not be possible until the misfed original is removed and
the SPF is ready for use.
Note
Pegasus-E_Copy_Ex.book 16 ページ ２００４年９月２３日 木曜日 午前１１時４１分

17
1
TURNING THE POWER ON AND OFF
The power switch is located on the left side of the machine.
POWER ON
Turn the power switch to the "ON" position
•It will take about 45 seconds
for the machine to warm up.
•When the power switch is
turned to the "ON" position,
the message "System check."
will appear in the message
display and warm-up will start.
Once the copier has finished warming up, the
message display will change to "Ready to copy." and
the START indicator will light up to indicate that
copying is possible. Copy settings can be selected
during warm-up.
•If auditing mode has been enabled (page 79), the
message "Enter your account number." will appear
after warming up. Once a valid account number has
been entered, the message display will change to
"Ready to copy." and copying will be possible.
POWER OFF
Make sure that the machine is not in operation
and then turn the power switch to the "OFF"
position.
If the power switch is turned off
while the machine is in
operation, a misfeed may occur
and the job that was in progress
will be cancelled.
Power save modes
The machine has two power save modes to reduce power consumption, thereby helping to reduce environmental
pollution and conserve resources.
Preheat mode
This function automatically switches the machine to a low power consumption state if the duration of time set in the
key operator programs elapses without the machine being used when the power is on. In preheat mode the display
turns off. Normal operation automatically resumes when a key on the operation panel is pressed, an original is
placed, or a print job or fax is received.
Auto power shut-off mode
This function automatically switches the machine to a state that consumes even less power than preheat mode if the
duration of time set in the key operator programs elapses without the machine being used when the power is on.
During auto power shut-off, only the mode key indicators are lit. To restore the machine to normal operation, press
any one of the mode keys. Normal operation also resumes automatically when a print job or fax is received or
scanning is begun from a computer. While auto power shut-off is in effect, pressing a key other than a mode key will
have no effect.
•If the fax option is installed, be sure to keep the power turned on.
Faxes cannot be received when the power is turned off.
•The machine is set at the factory to return all settings to the default settings one minute after a copy job is
finished (auto clear function). When the settings return to the default settings, any functions that were selected
are cancelled. The auto clear time can be changed in the key operator programs. (Page 83)
The preheat mode activation time and the "Auto power shut-off timer" can be changed in the key operator
programs. (Page 85)
Note
Note
Pegasus-E_Copy_Ex.book 17 ページ ２００４年９月２３日 木曜日 午前１１時４１分

18
BEFORE USING THE PRODUCT
Default settings
The machine is set at the factory to return all settings to the default settings one minute after a copy job is finished
(auto clear function) or when the [CA] key is pressed. When the settings return to the default settings, any functions
that were selected are cancelled.
The auto clear time can be changed in the key operator programs. (Page 83)
In the default state the display shown below appears. The default state of the display may vary depending on
settings in the key operator programs.
* The screen is that of the AR-M206/AR-M207 (when the RSPF is installed).
LOADING PAPER
The message "TRAY< >:Add paper." will be displayed when there is no copy paper in the selected paper tray.
(< > is the tray number.) Load paper in the indicated paper tray.
PAPER
The specifications for the types and sizes of paper that can be loaded in the paper trays are shown below.
*1 A5 (5-1/2" x 8-1/2") can be used in tray 1 but cannot be used in other trays (including trays in optional paper feeding unit).
*2
When making a large number of copies or prints using 90
g
/m
2
(24 lbs.) paper, remove the output from the paper output tray
when about 100 pages have been printed. The output may not stack correctly if more than 100 pages are allowed to accumulate.
*3 The number of sheets of the paper which can be set changes with the weight of a paper. (The indicated numbers are for 80
g
/m
2
(20 lbs.) paper.)
*4 The trays are numbered 1, 2, 3, and 4 from the top.
Paper that can be used for automatic 2-sided printing
Paper used for automatic two-sided printing must meet the following conditions:
Paper type: Plain paper (special paper cannot be used.)
Paper size: Standard sizes (A3, B4, A4, A4R, B5, B5R, A5, 11" x 17", 8-1/2" x 14", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R)
Paper weight: 56 g/m2to 90 g/m2(15 lbs. to 24 lbs.)
Paper tray Tray No.*4Paper type Paper size Weight Capacity
Tray 1 1
Standard paper
Recycled paper
A5*1, B5, B5R, A4, A4R,
B4, A3
(5-1/2" x 8-1/2"*1(Invoice),
8-1/2" x 11" (Letter), 8-1/2"
x 11"R, 8-1/2" x 13"
(Foolscap), 8-1/2" x 14"
(Legal), 11" x 17" (Ledger))
56 g/m2to 90 g/m2*2
(15 lbs. to 24 lbs.)*2
250 sheets (80
g
/m
2
(20 lbs.))*3
(Load paper lower
than the line on
the tray)
Tray 2 2
Tray of
250-sheet
paper feed unit
2 or 3
Tray of 2 x
250-sheet
paper feed unit
2 or 3
3 or 4
Bypass tray
Standard paper
Recycled paper
A6R to A3
(5-1/2" x 8-1/2" (Invoice) to
11" x 17" (Ledger))
56 g/m2to 80 g/m2
(15 lbs. to 20 lbs.) 100 sheets*3
Thick paper Max. 200 g/m2
(54 lbs.)
Load one sheet of
these papers at a
time to the bypass
tray.
Transparency film
Labels
Envelopes
International DL (110 mm x
220 mm), International C5
(162 mm x 229 mm)
Commercial 9 (3-7/8" x
8-7/8"), Commercial 10
(4-1/8" x 9-1/2")
5 sheets
Ready to copy.
