Shiro RCR Installation instructions

S
SH HI IR RO O R RC CR R M MP P3 3 D Di ig gi it ta al l A Au ud di io o P Pl la ay ye er r
Version 1.1
NOTE: Specifications subject to change without prior notice.
31 Ubi Road, Aztech Building #07-00, Singapore 408694.
Visit us: www.shirocorp.com
-
- P PR RO OD DU UC CT T S SP PE EC CI IF FI IC CA AT TI IO ON NS S - -
 OVERVIEW
OVERVIEWOVERVIEW
OVERVIEW
Experience rich and superb sound quality on-the-go in this pocket size, ultra-light
device. SHIR RC MP3 Digital Audio Player is designed to give you the ultimate
skip-free performance with long listening time. You can now download music
seamlessly or use it as a voice recorder. With the SHIR RC MP3 Digital Audio
Player, you can take your entire music collection with you wherever you go.

 MAIN FEATURES
MAIN FEATURESMAIN FEATURES
MAIN FEATURES
Downloading Speed Music download speed via USB 2.0 interface up to 12Mbps
Multi Format Files Supports MP3, audio WMA, WAV music files play back
USB Flash Drive Double up as a USB flash drive
Voice Recorder Built-in microphone for digital voice recording
OLED Screen Blue and Yellow Color OLED for exceptional view
FM Radio & Recording Records your favorite music while listening to FM Radio
Resume Playback Turn off and on your player. It will still continue to play the song you stopped at.
Regulatory Approval FCC, CE

 TECHNICAL/PRODUCT SPECIFICATIONS
TECHNICAL/PRODUCT SPECIFICATIONSTECHNICAL/PRODUCT SPECIFICATIONS
TECHNICAL/PRODUCT SPECIFICATIONS
Chipset Solution SIGMATEL 3504
Audio Support MPEG Audio Layer 3 (MP3), Windows Media™ Audio (WMA), WAV
Downloading Speed
(System Dependent) Up to 12Mbps
Recording Format
(with Built-in Microphone) WAV (IMA ADPCM)
Recording Duration (128MB) Up to 4.4hrs (WAV format)
Voice Recorder External voice through microphone
FM Radio 87.5 MHz – 108 MHz FM Tuning (preset 20 stations)
FM Recording Up to 4.4hrs (WAV format)
USB Flash Drive Capacity 128/256/512/1000 MB
LCD Display • Resolution: 128 x 64 pixel
• Display: 1.1”
OLED Blue and Yellow
ID3 Tag Support Yes
Sound Equalizer Preset sound equalizer to select Normal, Rock, Pop, Classic, Jazz mode
Playback Sequence Select Normal/ Repeat One/ Repeat All/ Shuffle Once / Shuffle Repeat for music
playback sequence
Storage Media On board skip-free Flash
Language 3 (English, Traditional Chinese, Simplified Chinese)
Host Interface Full-Speed USB 2.0
Plug-and-Play Via USB port
Maximum Output 10mW+10mW
Signal to Noise Ratio > 90 dB
Frequency Response 20Hz to 20KHz
Data Retention Period Over 10 years
Erase and Write Cycle Up to 1 million times

S
SH HI IR RO O R RC CR R M MP P3 3 D Di ig gi it ta al l A Au ud di io o P Pl la ay ye er r
Version 1.1
NOTE: Specifications subject to change without prior notice.
31 Ubi Road, Aztech Building #07-00, Singapore 408694.
Visit us: www.shirocorp.com
Power Supply • 1xAAA size 1.5V battery for music listening
• USB bus powered between 4.0V to 5.0V
Playback duration (hr) Up to 17
Size 58mm(L) x 36mm(W) x 16.8mm(H)
Weight 25 gram without battery

 SYSTEM R
SYSTEM RSYSTEM R
SYSTEM REQUIREMENTS
EQUIREMENTSEQUIREMENTS
EQUIREMENTS
Computer/Processor Intel
 Pentium  or AMD 233 MHZ or higher processor
Memory 32 MB or higher
Hard Disk 20 MB or higher hard-disk space available
Drive CD-ROM drive
Host Interface USB port
Operating System •
• Windows® 98/SE/ME/2000/XP
•
• Macintosh OS 10.x or above

 ACCESSORY LISTS
ACCESSORY LISTSACCESSORY LISTS
ACCESSORY LISTS
1
1. . E Ea ar rp ph ho on ne e
2
2. . U US SB B C Ca ab bl le e
3
3. . I In ns st ta al ll la at ti io on n C CD D
4
4. . U Us se er r M Ma an nu ua al l
5
5. . A AA AA A B Ba at tt te er ry y
