HOT-555 User's Manual 1
HOT-555
Pentium™processor
Based PCI MAIN BOARD
User's Manual

FCC Notice:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy. If not installed and used properly, in
strict accordance with the manufacturer’s instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures :
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/television technician for help and for additional suggestions.
The user may find the following booklet prepared by the Federal Communications Commission helpful “How to Identify
and Resolve Radio-TV Interference Problems.” This booklet is available from the U.S. Government Printing Office.
Washington, DC 20402, Stock 004-000-00345-4
FCC Warning
The user is cautioned that changes or modifications not expressly approved by the manufacturer could void the user’s
authority to operate this equipment.
Note : In order for an installation of this product to maintain compliance with the limits for a Class B device, shielded
cables and power cord must be used.
NOTICE
Copyright 1996.
All Right Reserved
Manual Ver 1.1
All information, documentation, and specifications contained in this manual are subject to change without prior
notification by the manufacturer.
The author assumes no responsibility for any errors or omissions which may appear in this document nor does it
make a commitment to update the information contained herein.
TRADEMARKS
Intel is a registered trademark of Intel Corporation
PentiumProcessor is a registered trademark of Intel Corporation
PC/AT is a registered trademark of International Business Machine Corporation.
PS/2 is a registered trademark of IBM Corporation.
All other brand and product names referred to in this manual are trademarks or registered trademarks of their
respective holders.

HOT-555 User's Manual 3
TABLE OF CONTENTS
PREFACE ............................................................................................ 4
CHAPTER 1 INTRODUCTION.................................................................. 5
Specification.......................................................................................................5
CHAPTER 2 HARDWARE INSTALLATION .................................................. 7
Jumpers ...............................................................................................................8
CPU Clock Speed Selection..............................................................................8
Onboard Regulator Output Selection - JP4, 10, 13, 36.................................9
Flash EPROM Jumper - JP18.........................................................................10
Clear CMOS - JP21.........................................................................................10
Clear Password - JP9.......................................................................................10
Connectors & Sockets......................................................................................11
CHAPTER 3 MEMORYCONFIGURATION ............................................... 12
CHAPTER 4 AWARD BIOS SETUP....................................................... 15
The Main Menu................................................................................................16
Standard CMOS Setup....................................................................................18
BIOS Features Setup.......................................................................................20
Chipset Features Setup....................................................................................22
Power Management Setup...............................................................................25
PCI Configuration Setup.................................................................................27
Integrated Peripherals......................................................................................29
Password Setting..............................................................................................31

HOT-555 User's Manual 4
HOT-555 mainboard is a highly integrated IBM PC/AT compatible system
board. The design will accept Intel Pentium, Cyrix 6x86 and AMD5k86
processors and also features high-performance pipeline burst secondary cache
memory support with size of 256KB. The memory subsystem is designed to
support up to 128 MB of EDO RAM, Standard Fast Page DRAM and SDRAM
in standard 72-pin SIMM socket and 168-pin DIMM socket. A type 7 Pentium
processor socket provides access to future processor enhancements.
HOT-555 provides a new level of I/O integration. Intel's 82430VX PCIset
chipset provides increased integration and improved performance over other
chipset designs. The 82430VX PCIset chipset provides an integrated Bus
Mastering IDE controller with two high performance IDE interfaces for up to
four IDE devices.
The onboard Super I/O controller provides the standard PC I/O functions:
floppy interface, two FIFO serial ports, an IrDA device port and a SPP/EPP/
ECP capable parallel port.
Up to three PCI local bus slots provide a high bandwidth data path for data-
movement intensive functions such as graphics, and up to three ISA slots
complete the I/O function.
The HOT-555 provides the foundation for cost effective, high performance,
highly expandable platforms, which deliver the latest in Pentium processor and
I/O standard
Preface

HOT-555 User's Manual 5
Chapter1 Introduction
Specification
CPU Function
Pentium processor clock : 75~200MHz
Cyrix 6x86 CPU clock : 100~133MHz
AMD5k86 CPU clock : 66~100MHz
Chipset
Intel PCISet 82437VX, 82438VX and 82371SB
Memory
Supports two banks of EDO RAM, Fast Page and Sync.
DRAM ranging from 8MB to 128MB
Supports 4MB, 8MB, 16MB, 32MB 72-pins SIMMs and
8MB, 16MB, 32MB 168-pin DIMMs
Cache Memory
Integrated L2 write-back cache controller
- 256KB Direct Mapped Pipeline Burst Cache
Power Management Function
Provides four power management modes : Full on, Doze,
Standby, and Suspend
Supports Microsoft APM
Provides EPMI (External Power Management Interrupt) pin

HOT-555 User's Manual 6
Expansions
32-bit PCI bus slot x 3
16-bit ISA bus slot x 3
2-channel PCI IDE port
- Support up to 4 IDE devices
- PIO Mode 4 transfers up to 16 MB/sec
- Integrated 8 x 32-bit buffer for PCI IDE burst transfers
One floppy port
One parallel port
- Supports SPP (PS/2 compatible bidirectional Parallel
Port), EPP (Enhanced Parallel Port), andECP (Extended
Capabilities Port) high performance parallel port.
Two serial ports
- Supports 16C550 compatible UARTS.
- Supports IrDA (Infra-red) communication.
One PS/2 mouse port
USB (Universal Serial Bus) port
Board Design
Dimension 220mm x 230mm

HOT-555 User's Manual 7
Jumpers
Chapter2Hardware Installation

HOT-555 User's Manual 8
CPU Clock Speed Selection
HOT-555 mainboard features a clock generator to provide adjustable system
clock frequency. Jumpers JP27 and JP28 determine the system clock
frequency from 50MHz to 66MHz.
HOT-555 mainboard also provides Jumpers JP23 and JP24 to figure up
CPU core clock multiplier. By inserting or removing jumper caps on JP23
and JP24, the user can change theHost Bus Clock/CPU Core Clock
ratio from 1 : 1.5 to 1 : 3.
CPU CLOCK SPEED JP27 JP28 SYSTEM
CLOCK JP23 JP24 CPU Bus/Core RATIO
75 MHz
Pentium Processor CLOSE CLOSE 50 MHz OPEN OPEN 1 : 1.5
90 MHz
Pentium Processor CLOSE OPEN 60 MHz OPEN OPEN 1 : 1.5
100 MHz
Pentium Processor OPEN CLOSE 66 MHz OPEN OPEN 1 : 1.5
120 MHz
Pentium Processor CLOSE OPEN 60 MHz CLOSE OPEN 1 : 2
133 MHz
Pentium Processor OPEN CLOSE 66 MHz CLOSE OPEN 1 : 2
150 MHz
Pentium Processor CLOSE CLOSE 50 MHz OPEN CLOSE 1 : 3
180 MHz
Pentium Processor CLOSE OPEN 60 MHz OPEN CLOSE 1 : 3
200 MHz
Pentium Processor OPEN CLOSE 66 MHz OPEN CLOSE 1 : 3
125 MHz
Pentium Processor CLOSE CLOSE 50 MHz CLOSE CLOSE 1 : 2.5
150 MHz
Pentium Processor CLOSE OPEN 60 MHz CLOSE CLOSE 1 : 2.5
166 MHz
Pentium Processor OPEN CLOSE 66 MHz CLOSE CLOSE 1 : 2.5
66 MHz
AMD5k86 - P75 OPEN CLOSE 66 MHz CLOSE OPEN 1 : 1
75 MHz
AMD5k86 - P75 CLOSE CLOSE 50 MHz OPEN OPEN 1 : 1.5
90 MHz
AMD5K86 - P90 CLOSE OPEN 60 MHz OPEN OPEN 1 : 1.5
100 MHz
AMD5k86 - P100 OPEN CLOSE 66 MHz OPEN OPEN 1 : 1.5
100 MHz
Cyrix 6x86 - P120+ CLOSE CLOSE 50 MHz OPEN OPEN 1 : 2
110 MHz
Cyrix 6x86 - P133+ OPEN OPEN 55 MHz OPEN OPEN 1 : 2
120 MHz
Cyrix 6x86 - P150+ CLOSE OPEN 60 MHz OPEN OPEN 1 : 2
133 MHz
Cyrix 6x86 - P166+ OPEN CLOSE 66 MHz OPEN OPEN 1 : 2

HOT-555 User's Manual 9
HOT-555 mainboard is designed an onboard voltage regulator to provide
single 3.3V voltage ranger (VIO=VCORE) for Intel Pentium P54C, Cyrix
6x86 and AMD5k86 processors, and also provide dual 3.3/2.5V voltage
ranger (VIO, VCORE separated) for Intel P55C processors and Cyrix/AMD
future processors.
Single Voltage Output (VIO=VCORE)
Onboard Regulator Output Selection - JP4, 10, 13, 36
Dual Voltage Output (VIO, VCORE separated)
Voltage
Output-Vio JP4 JP13
3.3 V 5 - 6 CLOSE
OPEN
3.45 V 3 - 4 CLOSE
3.6 V 1 - 2 CLOSE
Voltage
Output-Vcore JP10 JP36
2.5 V ALL OPEN 3 - 4, 5 - 6 CLOSE
2.6 V ALL OPEN 3 - 4, 7 - 8 CLOSE
2.7 V 1 - 2 CLOSE 3 - 4 CLOSE
2.8 V 3 - 4 CLOSE 3 - 4 CLOSE
2.9 V 5 - 6 CLOSE 3 - 4 CLOSE
3.0 V 7 - 8 CLOSE 3 - 4 CLOSE
Voltage Output JP4 JP10, JP13, JP36
3.3 V 5 - 6 CLOSE JP10 : All OPEN,
JP13 : CLOSE,
JP36 : 1 - 2 CLOSE
3.45 V 3 - 4 CLOSE
3.6 V 1 - 2 CLOSE
Note :
1. It is highly recommended that a CPU cooling fan is attached
to the CPU to ensure system stability.
2. Make sure none of the CPU cooling fan assembly the heat
sink on the regulator to avoid damage to system.

HOT-555 User's Manual 10
HOT-555 mainboard supports jumperJP21 for discharge mainboard's
CMOS memory. The CMOS memory retains the system configuration
information in the component of R.T.C.
You should short this jumper for a moment when you wish to clear CMOS
memory, and then make sure open this jumper for normal operation to retain
your new CMOS data.
Note: Clear CMOS & R.T.C function available only when "DS12887A"
or "DS12B887" are in use.
There are different ways to discharge CMOS memory between "DS12887A" and
"DS12B887".
DS12887A- Turn off power, close jumper JP21 for 2 to 3 seconds then release and
CMOS will be discharged.
DS12B887- Close jumper JP21, turn on power durning 2 to 3 seconds then release JP21
and turn off power, CMOS will be discharged.
Clear CMOS - JP21
Flash EPROM Jumper - JP18
HOT-555 mainboard supports two types of flash EPROM, 5 volt and 12
volt. By setting up jumper JP18, you can update both types of flash
EPROM with new system BIOS files as they come available.
JP18 Pin 2-3 Closed for 5V, Pin 1-2 Close for 12V.
BIOS UPGRADES
Flash memory makes distributing BIOS upgrades easy. A new version of
the BIOS can be installed from a diskette.
The flash upgrade utility,Awdflash.exe, has two notice for BIOS upgrades:
Flash utility can't work under protected/virtual mode. Memory
manager like QEMM.386, EMM386 should not be loaded. (or
Simply bypass all config.sys and autoexec.bat on system boot
up.
Flash utility supports both 5V and 12V Flash EEPROM.

HOT-555 User's Manual 11
Clear Password - JP9
Allows system password to be cleared by shorting jumper JP9 and turning
the system on, "Password is cleared by jumper, (JCP) !" message will
shown up on power-on screen. The system should then be turned off and
the jumper JP9 should be returned to OPEN to restore normal operation.
The procedure should only be done if the user password has been
forgotten. (This function may not available when Cyrix 6x86 CPU is in
use)
Connectors & Sockets
Connectors & Sockets
ITEM FUNCTION
J2, J3, J4, J5 On-board SIMM sockets
DIM1, DIM2 On-board DIMM sockets
J17, J18, J19 On-board PCI Slots
J20, J21, J22 On-board ISA Slots
J6 On-board PCI Primary IDE Connector
J7 On-board PCI Secondary IDE Connector
CN1 On-board Floppy Controller Connector
CN4 On-board Parallel Port Connector
CN2 On-board Serial port-1 Connector
CN3 On-board Serial Port-2 Connector
J99 On-board PS/2 Mouse Port Connector
J14 Power LED and Keylock Connector
J12 PC Speaker Connector
JP12 Hardware Reset Switch Connector
JP17 Green LED
JP15 EPMI Connector
JP22 On-board Enhanced IDE R/W LED Connector
J10, J11 Universal Serial Bus (USB) Connectors
JP3 IrDA Communication Port Connector
JP1 Cooling Fan Connector
JP7
Display type (Color/Mono) Switcher
Open for Monochrome
Close for EGA/CGA
VGA display card don't care

HOT-555 User's Manual 12
Chapter3Memory Configuration
The HOT-555 mainboard provides four 72-pin SIMM sockets and two 168-
pin DIMM sockets that make it possible to install up to 128MB of RAM.
The SIMM socket support 4MB, 8MB, 16MB, and 32MB single- or double-
side fast page or EDO DRAM modules. Memory timing requires 70 ns fast
page devices or, for optimum performance, 60 ns EDO DRAM or 70 ns
Synchronous DRAM may be used. Both parity and non-parity memory are
supported.
The four SIMM sockets are arranged in two banks of two sockets each and
the two DIMM sockets are arranged in two banks of one socket each. Each
bank provides a 64/72-bit wide data path.
Both SIMMs in a bank must be of the same memory size and type, although
the different types of memory may differ between banks. It is possible to
have 70 ns fast page DRAM in one bank and 60 ns EDO DRAM in the other.
The DIMM socket share the same address lines with SIMM socket, there
have some restriction of memory configuration, please refer to Table 3-1,
Table 3-2, and Table 3-3.
Table 3-1. Restriction of Memory Configuration
SIMM 1, 2
( J2, J3 )
SIMM 3, 4
( J4, J5 )
DIMM 1
( DIM1 )
DIMM 2
( DIM 2) Description
Single-bank Single-bank Single-bank Single-bank Single-bank SIMM include 4 MB and 16 MB.
Double-bank SIMM include 8 MB and 32 MB.
Single-bank DIMM include 8 MB and 32 MB
Double-bank DIMM include 16 MB.
Single-bank Double-bank Single-bank Not Available
Double-bank Single-bank Not Available Single-bank
Empty Empty Double-bank Double-bank
Double-bank Double-bank Not Available Not Available
Single-bank Empty Single-bank Double-bank
Empty Single-bank Double-bank Single-bank

HOT-555 User's Manual 13
Table 3-2. Memory Configuration Table
SIMM 1, 2 SIMM 3, 4 DIMM 1 DIMM 2 TOTAL
4 MB Empty Empty Empty 8 MB
8 MB Empty Empty Empty 16 MB
16 MB Empty Empty Empty 32 MB
32 MB Empty Empty Empty 64 MB
Empty 4 MB Empty Empty 8 MB
Empty 8 MB Empty Empty 16 MB
Empty 16 MB Empty Empty 32 MB
Empty 32 MB Empty Empty 64 MB
Empty Empty 8 MB Empty 8 MB
Empty Empty 16 MB Empty 16 MB
Empty Empty 32 MB Empty 32 MB
Empty Empty Empty 8 MB 8 MB
Empty Empty Empty 16 MB 16 MB
Empty Empty Empty 32 MB 32 MB
Empty Empty 8 MB 8 MB 16 MB
Empty Empty 16 MB 16 MB 32 MB
Empty Empty 32 MB 32 MB 64 MB
4 MB 4 MB Empty Empty 16 MB
4 MB 4 MB 8 MB Empty 24 MB
4 MB 4 MB 8 MB 8 MB 32 MB
4 MB 4 MB 32 MB Empty 48 MB
4 MB 4 MB 32 MB 32 MB 80 MB
4 MB 8 MB Empty Not Available 24 MB
4 MB 8 MB 8 MB Not Available 32 MB
4 MB 8 MB 32 MB Not Available 56 MB
4 MB 16 MB Empty Empty 40 MB
4 MB 16 MB 8 MB Empty 48 MB
4 MB 16 MB 8 MB 8 MB 56 MB
4MB 16 MB 32 MB Empty 72 MB
4 MB 16 MB 32 MB 32 MB 104 MB
4 MB 32 MB Empty Not Available 72 MB
4 MB 32 MB 8 MB Not Available 80 MB
4 MB 32 MB 32 MB Not Available 104 MB

HOT-555 User's Manual 14
Table 3-3. Memory Configuration Table Continued
SIMM 1, 2 SIMM 3, 4 DIMM 1 DIMM 2 TOTAL
8 MB 8 MB Not Available Not Available 32 MB
8 MB 16 MB Not Available Empty 48 MB
8 MB 16 MB Not Available 8 MB 56 MB
8 MB 16 MB Not Available 32 MB 80 MB
8 MB 32 MB Not Available Not Available 80 MB
8 MB Empty Not Available 8 MB 24 MB
8 MB Empty Not Available 16 MB 32 MB
8 MB Empty Not Available 32 MB 48 MB
16 MB 16 MB Empty Empty 64 MB
16 MB 16 MB 8 MB Empty 72 MB
16 MB 16 MB 8 MB 8 MB 80 MB
16 MB 16 MB 32 MB Empty 96 MB
16 MB 16 MB 8 MB 32 MB 104 MB
16 MB 16 MB 32 MB 32 MB 128 MB
16 MB Empty Empty 8 MB 40 MB
16 MB Empty Empty 16 MB 48 MB
16 MB Empty Empty 32 MB 64 MB
16 MB Empty 8 MB 8 MB 48 MB
16 MB Empty 8 MB 16 MB 56 MB
16 MB Empty 8 MB 32 MB 72 MB
16 MB Empty 32 MB 8 MB 72 MB
16 MB Empty 32 MB 16 MB 80 MB
16 MB Empty 32 MB 32 MB 96 MB
32 MB 32 MB Not Available Not Available 128 MB
32 MB Empty Not Available 8 MB 72 MB
32 MB Empty Not Available 16 MB 80 MB
32 MB Empty Not Available 32 MB 96 MB

HOT-555 User's Manual 15
HOT-555's BIOS ROM has a built-in Setup program that allows users to
modify the basic system configuration. This type of information is stored in
battery-backed RAM so that it retains the Setup information when the
power is turned off.
Entering Setup
Power on the computer and press <Del> immediately will allow you to
enter Setup. The other way to enter Setup is to power on the computer,
when the below message appear briefly at the bottom of the screen
during the POST (Power On Self Test), press <Del> key or
simultaneously press <Ctrl>,<Alt>, and <Esc> keys.
TO ENTER SETUP BEFORE BOOT PRESS CTRL-ALT-ESC OR DEL KEY
If the message disappears before you respond and you still wish to enter
Setup, restart the system to try again by turning it OFF the ON or
pressing the "RESET" button on the system case. You may also restart
by simultaneously press <Ctrl>,<Alt>, and <Delete> keys. If you do not
press the keys at the correct time and the system does not boot, an error
message will be displayed and you will again be asked to,
PRESS F1 TO CONTINUE, CTRL-ALT-ESC OR DEL TO ENTER SETUP
Chapter4Award BIOS Setup

HOT-555 User's Manual 16
Standard CMOS setup
This setup page includes all the items in a standard compatible BIOS.
BIOS features setup
This setup page includes all the items of Award special enhanced features.
Chipset features setup
This setup page includes all the items of chipset features.
Power Management Setup
This setup page includes all the items of Power Management features.
PCI Configuration setup
This category specifies the value (in units of PCI bus blocks) of the latency
timer for this PCI bus master and the IRQ level for PCI device. Power-on
with BIOS defaults
Load BIOS Defaults
BIOS defaults loads the values required by the system for the maximum
performance. However, you may change the parameter through the Option
Setup Menu.
The Main Menu

HOT-555 User's Manual 17
Load Setup Defaults
Setup defaults loads the values required by the system for the minimum
performance. However, you may change the parameter through the Setup
Menu.
Integrated Peripherals
This setup page includes all the items of peripheral features.
IDE HDD auto detection
Automatically configure IDE hard disk drive parameters.
Supervisor Password
Change, set, or disable supervisor password. It allows you to limit access to
the system and Setup, or just to Setup.
User Password
Change, set, or disable user password. It allows you to limit access to the
system and Setup, or just to Setup.
Save & Exit setup
Save CMOS value change to CMOS and exit setup
Exit without saving
Abandon all CMOS value changes and exit setup.

HOT-555 User's Manual 18
Standard CMOS Setup
Date
The date format is <day>, <date> <month> <year>. Press <F3> to show the
calendar.
Time
The time format is <hour> <minute> <second>. The time is calculated base
on the 24-hour military-time clock. For example. 5 p.m. is 17:00:00.
Drive C type/Drive D type
The category identify the types of hard disk drive C or drive D that has been
installed in the computer. There are 46 predefined types and a user
definable type. Type 1 to Type 46 are predefined. Type User is user-
definable.
Press PgUp or PgDn to select a numbered hard disk type or type the number
and press <Enter>. Note that the specifications of your drive must match
with the drive table. The hard disk will not work properly if you enter
improper information for this category. If your hard disk drive type is not
matched or listed, you can use Type User to define your own drive type
manually.
If you select Type User, related information is asked to be entered to the
following items. Enter the information directly from the keyboard and press
<Enter>. Those information should be provided in the documentation from
your hard disk vendor or the system manufacturer.

HOT-555 User's Manual 19
The user may also set those items to AUTO to auto configure hard disk
drives parameter when system power-on.
If a hard disk drive has not been installed select NONE and press <Enter>.
Drive A type/Drive B type
The category identify the types of floppy disk drive A or drive B that has
been installed in the computer.
Video
The category selects the type of adapter used for the primary system monitor
that must matches your video display card and monitor. Although secondary
monitors are supported, you do not have to select the type in Setup.
Error halt
The category determines whether the computer will stop off an error is
detected during power up.
Memory
The category is display-only which is determined by POST (Power On Self
Test) of the BIOS.
Base Memory
The POST of the BIOS will determine the amount of base (or conven-
tional) memory installed in the system. The value of the base memory is
typically 512K for systems with 512K memory installed on the
mainboard, or 640K for systems with 640K or more memory installed on
the mainboard.
Extended Memory
The BIOS determines how much extended memory is present during the
POST. This is the amount of memory located above 1MB in the CPU's
memory address map.

HOT-555 User's Manual 20
BIOS Features Setup
CPU Internal Cache
This category enables CPU internal cache to speed up memory access.
External Cache
This category enables external cache to speed up memory access.
Quick Power On Self Test
This category speeds up Power On Self Test (POST) after you power on the
computer. If it is set to Enabled, BIOS will shorten or skip some check
items during POST.
Boot Sequence
This category determines which drive computer searches first for the disk
operating system. Default value is A, C.
Swap Floppy Drive
When this category enables, the BIOS will swap floppy drive assignments
so that Drive A: will function as Drive B: and Drive B: as Drive A:.
Boot Up Floppy Seek
During POST, BIOS will determine if the floppy disk drive installed is 40 or
80 tracks.
