Side-power S-linkcontrol panel pjc211 User manual

Keep this

manual onboard !

Installation and user's manual

Made in Norway

©Sleipner Motor AS 2012

SLEIPNER MOTOR AS

P.O. Box 519

N-1612 Fredrikstad

Norway

Tel: +47 69 30 00 60

Fax: +47 69 30 00 70

www.side-power.com

sidepower@sleipner.no

PJC-211

S-link

Control Panel

SIDE-POWER

Thruster Systems

v 1.1.1

2PJC-211 1.1.1 - 2012

PJC-211

Control panel with S-link™CAN-bus connection

Product features

• ForproportionalthrustercontrolwiththenewPowerControlledDC-thrusters

• Fingertipcontrolspeedcontrolwithpurposedesignedjoysticks

• Back-litLCDdisplaywithinstantfeedback

 - Systemstatus

 - Amountofthrust&directionofthrust

 - Thrustertemperature/remainingruntime

 - Batterysupplyvoltagetothrusters

 - MonitoringofAutomaticMainswitch(informsifthefusehasblown

 orthemanualoverrideisactivated)

• Interactivemulti-languagemenus

• CAN-Buscommunicationwiththrustersandaccessories

• Plug&playcables,waterproofandcompactconnectors

• Diagnosticsviapanel

• Built-inaudiblealarm“buzzer”

• Connectorforexternal“buzzer”/loudaudiblealarms

• SupportsSide-Powerretractablethrusterswithor

 withoutSpeedControl

Speedcontroljoystickfor

thruster

Informationdisplay,seefol-

lowingpagesfor

details.

Pressboth“ON”buttons

simultanouslytoactivate

controlpanel.

Presstochange

betweendayand

nightlight

Pressandholdfor3

secondstoaccessmenu

systemandchooseitems

inmenus

Presstode-activate

controlpanelorcancelor

gobackinmenusystem

ormuteinternalalarm

buzzer

DONOTconnectanyothercontrolequipmenttotheS-linkcontrolledproductsexcept

Side-PoweroriginalS-linkproductsorviaaSide-Powersuppliedinterfaceproductmade

forinterfacingwithothercontrols.Anyattempttodirectlycontroloratallconnectinto

theS-linkcontrolsystemwithoutthedesignatedandapprovedinterface,willrenderall

warrantiesandresponsibilitiesforthecompletelineofSide-Powerproductsconnected

voidandnull.IfyouareinterfacingbyagreementwithSleipnerandthroughadesignated

andapprovedinterface,youarestillrequiredtoalsoinstallanoriginalSidepowercontrol

paneltoenableefcienttroubleshootingifnecessary

PJC-211 1.1.1 - 2012

DISPLAY IN NORMAL USE:

Bow thruster information

Remainingrun

timeofthruster

basedonthe

electricmotors

heatatpresent.

Asbarsempties

youhavelessrun

timeleft.

Thrustpower

anddirection

Batterysup-

plyperformance

basedondeliv-

eredvoltageto

thruster.Asthe

batteryempties,

youhaveless

powerandless

runtimeleft

FIRST TIME SETUP

AfterinstallationofaS-linkthrusterssystem,aSCAN SYSTEMproceduretosetupcontrolpanels,thrustersand

additionalequipmentmustbecompletedbeforethesystemcanbeused.

SPECIFICINFORMATIONWHENUSEDINASYSTEM

WITHSR-SERIESRETRACTABLETHRUSTERS

Symbolshownwhenthethrusterdeploys

Symbolshownwhenthethrusterretracts

Indicatingamountofthrustsetbyothercontrolunits

inthesystem,i.eadditonalPJC-212/211panels,8700

Retractpanel,inputvia8730S-linkexternalswitch

interface(remotecontrol,footswitchesetc.)

Iftwoormoreunitsissettorunthethrusterin

oppositedirection,thisinformationwillnotbeshown.

Alarmsareignoredfor3secondsafterturningpanel

ON.

4PJC-211 1.1.1 - 2012

DISPLAY WHEN ALARMS:

Whenthereisaproblemorafault,thepanelwillshowthisalarmsituationbytheLCDdisplayblinkinginred

color.

Thepanelwillalsochangetoshow“AlarmInfo”beneaththe“boat”,indicatingthatbypressingthecorresponding

button(centreON)youwillgetinformationaboutwhattheproblemis(examplebelow).



Iftheproblemisthatthevoltagedeliveredfromthebatteriesaretoolowforthe

thrustertobeallowedtorun,thisisshowndirectlyonthedisplaybythebatterythat

isnotdeliveringbeingreplacedbythealarmsign(seeexample).

Iftheissueissomethingelse,thealarmsignalwillreplacetheremainingruntime

indicatorforthethruster/systemthatiscausingthealarm.



Alarmshownwhenthethrusterisobstructedwhiledeploying.

Theinternalbuzzerwillsound.

Buzzercanbemutedbypressingthe“OFF”button

Alarmshownwhenthethrusterisobstructedwhileretracting.



SPECIFICALARMSWHENUSEDINASYSTEM

WITHSR-SERIESRETRACTABLETHRUSTERS

Voltagebelow9.3V/17.5V(12V/24V system)ortemperatureabove80oC:

singlebeepevery2.4seconds

Voltagebelow8.9V/16.3V(12V/24V system) ortemperatureabove90oC:

twobeepsevery2.4seconds

Voltagebelow8.5V/15V(12V/24V system) ortemperatureabove100oC:

redbacklightindisplayandthreebeepsevery2.4seconds

Thelastwarningsignalwillalsobetriggeredwhenoperatingthethrusterwiththejoysticks,except

withnoexternalbuzzeroutput.

Ifoneorbothofthethrustersentersanalarmstate(Voltagebelow8Volts-forboth12and24Volt

systems-ortemperatureabove110oC):continuousbeeps.Temperaturemustdropbelow100oC

beforethethrustercanbeoperatedagain.

PJC-211 1.1.1 - 2012

MENU SYSTEM:

Access menu system by pressing Menu button (middle ‘ON’ button)

for 3 seconds

Move around in menus by using joysticks

Follow instructions on the screen and press buttons as indicated on

LCD screen

LANGUAGE

SETUP

LANGUAGE

Chooselanguagebymovingbowjoystick:

English,Norwegian,German,French,SpanishandItalian.



SETUP

Usejoysticktochoosefunction

Select:Opensselectedfunction

Cancel:ReturnstoMainMenu

SYSTEMDEVICES

ViewalldevicesconnectedtoS-Linkandmanuallychangesetup

values.

Slidebetweendeviceswiththejoysticktoseedeviceinformationas

location,thrusterdirection,retracttype,rmwareversionandserial

number.

Edit:ChangelocationtoBOW,STERN,BOW-PORTorSTERN-

PORT,thrusterdirectiontoNormalorInvertedorretract

type.ForAutomaticmainswitch18977andinterface8730,

youcanonlychangelocation.Usejoysticktoaltervalues.

Location:

 CanchangeselecteddevicelocationbetweenBOW,STERN,

BOW-PORTorSTERN-PORT.ForPPC800orSR61242only.

(useBOW-PORTonsecondbowthrusterandSTERN-PORT

onsecondsternthruster)

Direction:

 CanchangethrusterdirectiontoNormalorInverted.Change

thisvalueifthethrusterisrunninginthewrongdirection.

ForPPC800orSR61242only.



Retract:

 Setupretracttypes.ForPPC800orSR61242only.

 Normal: standalone,usethisforPPC800withoutany

   retractorSR61242(SR80/100)without

   PPC800orSR150000(SR130/170/210)

   withoutPPC800.

 Type 1: RetractSR61242(SR80/100)withPPC800,

   bothdevicesneedstobesettoType1.

Type 2: RetractSR150000(SR130/170/210)with

   PPC800,bothdevicesneedstobesetto

    Type2 

WHEN INSTALLING A RETRACT THRUSTER WITH

SPEED CONTROL (PPC800), DO NOT TRY TO RUN THE

THRUSTER UNTIL YOU HAVE COMPLETED THE ENTIRE

SETUP PROCEDURE CORRECTLY!



 Thisistopreventdamagetothethrustercausedbyrunning

thethrusterwhiletheretractmechanismisnotfullyopened.

OK: Saveschangesandquitediting.

Select:SwitchbetweenLocation,RetractandRetractsettings.

Cancel:Canceloperationwithoutsavingchanges.

Cancel:Returnsto“SETUP”–menu.

NB! NB!

6PJC-211 1.1.1 - 2012

INFO

Theinfoselectionisaservicescreen.ChoosetheInfoscreenif

youwishtocheckyoursystem.Wheninthisscreenyouwillbe

abletorunthethrustersindividuallywiththejoysticksorsimul-

taneouslywiththe“Hold”function.

Youwillbeabletoseetwoscreensbypressingthe“more”button

1stscreen:Controlpanelinfo:

 -FirmwareandHardwareversion

 -Serialnumber

 -S-linkvoltage

2ndscreen:Bowthrusterinformation

 -Motortemperature

 -Speedcontroller(PPC800)temperature

 -Actualvoltage

 -Thrustpercentageitisrunningat

 -Currentconsumption&wattatpresent.

More: Changestonextinformationpage

Cancel:Returnstomainmenu

SETUP

SCANSYSTEM

Afterselecting“SCANSYSTEM”thedisplayshows“SCANNING

SYSTEMPLEASEWAIT!”forafewsecondswhilethepanelis

scanningtheS-linkbusforattachedequipment.Thisscancan

takeupto15seconds.

Afteracompletedsystemscan,thethrusterwithitsassociated

AMSwillbeshown.Usethejoysticktotogglebetweenbowand

sternthrusterinformation.

Scan: Re-ScantheS-linkbus

Select:Selectthruster.Selectedthrusterwillbehighlightedand

  canberunwiththedesignatedjoysticktoconrmits 

  location

Move: Movestheselectedthrusterassignmentfrombowto 

  stern/sterntobow

OK: SaveschangesandreturnstoSETUP-menu

Anychangesmadewillberelayedtoallotherinstalledpanels



RADIOREMOTESETUP

AdjuststheamountofthrustwhichtheON/OFFremotecontrol

willrunat.Usejoystickstoadjustappliedthrust

OK: Saveschangesandreturnsto“SETUP”-menu

Cancel:Returnsto“SETUP”-menuwithoutsavingchanges

Anychangesmadewillberelayedto8730INTERFACEunitswith

Firmware1.203ornewer

PJC-211 1.1.1 - 2012

DEFAULT

DEFAULT SETTINGS

Resetallsettingstofactorydefault-followinstructionsonscreen

Start: Resetssystemtodefaultfactorysettings

Cancel:Returnstomainmenuwithoutchanges

PANEL

PANEL SETUP

BACKLIGHTLEVEL

 Setlevelofpanelbacklightindaylightmode,1-5

NIGHTLIGHT-COLOR

 Selectcolorofbacklightinnightlightmode:

 GREEN,BLUE,RED,WHITE

NIGHTLIGHT-LEVEL

 Setlevelofpanelbacklightinnightlightmode,1-3

TIMERAUTOOFF

 Setthetimefromlastusetoautopanelshutdown.

 Setfrom5-60minutesin5minutestepsorOFF(panelwill

 notturnoffautomatically)

OK: Saveschangesandreturnstomainmenu

Select: Selectingparameter

Cancel:Returnstomainmenuwithoutsavingchanges

Usejoysticktochangevaluesupordown.

8PJC-211 1.1.1 - 2012

Errors shown

in display

PPC

800

AMS

8977

SR80

SR100

SR130

SR170

SR210

Description Action

Motor

Overcurrent

XMotorcurrentover

1400A

Thrustermustbeservicedbyau-

thorizedpersonel,resetorPPC800

powerOFF/ON

Motor

Overtemp

X X Motortemperature

havebeenover110oC

Motorcooldownbelow100°C

Power

Overtemp

XPPC800temperature

havebeenover80oC

PPC800cooldownbelow45°C

Power

Overtemp

XSR150000temperature

havebeenover80oC

SR150000cooldownbelow45°C

LowPower X X X LowvoltageonMotor Rechargebattery,resetordevice

powerOFF/ON

Termoswitch X X X Motortemperatureover

110oC

Motorcooldownbelow100oC

IPCError X X X Motorrelayfaulty Turnoffthrusterbatterymain

switch.Thrustermustbeserviced

byauthorizedpersonel,poweroff

resetsalarm.

Driverfail XPPC800fail PPC800mustbesendtforservice

Thruster

NoCurrent

XNopowertothruster Checkthrusterconnectionsormo-

tordead!

Thruster

RelayFail

X X Nocurrentonmotor

relaycoil

Checkmotorrelayconnections,

shortcircuitorrelaydead!

SystemError X X X X Fatalerror Systemmustbeservicedby

authorizedpersonnel

Communiction

Fail

X X X X Nocommunicationwith

device

CheckS-linkandpowerconnections

Tempsensor

Fail

XMotortemperaturesen-

sorfail

Checkforanopencirciutonthe

tempsensoronthemotor

PowerFailure XNopower Checkpowerconnections

FuseBlown XFuseblown Replacefuseorcheckifmaincable

frombatteryandmaincableto

thrusterhasbeenswitched

Manual

Override

XMainswitchmanually

overridden

Pullmainswitch

Deploy

obstructed

X X Retractobstructed

whiledeploying

Turnoffallpanels.Goforlower

speed/deeperwaterandretry.

Retract

obstructed

X X Retractobstructed

whileretracting

Turnpanelonandmanuallyover-

ridemainswitch.Removeobstruc-

tionandtryagain.

PowerFail

Actuator

X X Actuatornotgetting

anypower.

Checkactuatorconnectionorpower

toactuator.

Pos.SensorFail XRetractpositionsensor

fail

Checkpositionsensorcablesand

forsensordamage.

NotInRunning

Mode

XRetractnotinrunning

mode

Checkdipswitchsettingonretract

controlbox.

Error message overview

PJC-211 1.1.1 - 2012

+12/24V -

S-link on/off

switch

red

yellow

black

12/24V

Bow thruster

battery

Bow thruster

(SEP model)

black

red

B+

Fixed multicable 5m

+12/24

PPC

Proportional

Power Controller

PJC211

Proportional

Joystick

Controlpanel

Station 2 (optional)

Automatic Main Switch

8977 12 / 8977 24

Manual main switch

w/ANL fuse

S-link control system End terminator

End terminator

Observe PPC battery

terminal polarity !

S-link supply

S-link external

switch interface

(optional)

PJC211

Proportional

Joystick

Controlpanel

Station 1

Visio-Wiring diagram SEP manual_bow 3.pdf 1 22.11.2010 16:50:36

Sample S-link system

10 PJC-211 1.1.1 - 2012

Supply

+12V / 24V DC

(S-link)

External alarm buzzer

12V / 24V DC - max 0,5A

Internal

fuse/relay

External alarm/buzzer connection

Rearside

ofpanel

Connections for optional

external buzzer/audible alarm

PJC-211 1.1.1 - 2012



























 



















Measurements









Argentina

Trimer SA

Buenos Aires

Tel: +54 11 4580 0444

Fax: +54 11 4580 0440

www.trimer.com.ar

trimer@trimer.com.ar

Australia

AMI Sales

Freemantle, WA

Tel: +61 89 331 0000

Fax: +61 89 314 2929

Side-Power S-linkControl Panel PJC211 User manual

Popular Control Panel manuals by other brands
