Siemens SICHARGE D User manual

OPERATING INSTRUCTIONS
siemens.com/sicharge-d
8EM5907-0AA00-1AA7.06
11/2023
Edition
SICHARGE
SICHARGE D

Introduction 1
Safety instructions 2
Description 3
Transport and storage 4
Installation and mounting 5
Commissioning 6
Operation 7
Error messages and remedy 8
Maintenance and service 9
Decommissioning and
disassembly 10
Recycling and disposal 11
Technical specifications 12
Adhesive surfaces 13
Declaration of Conformity 14
List of abbreviations and
explanation of terms A
Continued on next page
SICHARGE D
Charging station
SICHARGE D
Operating Instructions
11/2023
A5E50556539-AG

Continued
Checklist for commissioning B
Other applicable documents C
Charging station
SICHARGE D
Operating Instructions

Siemens Aktiengesellschaft
Smart Infrastructure
eMobility
Siemenspromenade 10
91058 Erlangen
GERMANY
A5E50556539-AG
Ⓟ 12/2023 Subject to change
Copyright © Siemens 2020 - 2023.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended or
approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of SiemensAktiengesellschaft. The remaining trademarks in
this publication may be trademarks whose use by third parties for their own purposes could violate the rights of
the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

1 Introduction........................................................................................................................................ 9
1.1 About the operating instructions....................................................................................... 9
1.2 Basic information.............................................................................................................. 11
1.3 Open-source software....................................................................................................... 11
1.4 Processing of personal data............................................................................................... 12
2 Safety instructions.............................................................................................................................. 13
2.1 General............................................................................................................................ 13
2.1.1 Requirements................................................................................................................... 13
2.1.2 Intended use, modifications to the device......................................................................... 13
2.1.3 Qualified personnel.......................................................................................................... 15
2.1.4 Protection against unauthorized opening.......................................................................... 15
2.2 Hazards during transport, mounting, operation and maintenance...................................... 16
2.2.1 Personal protective equipment (PPE)................................................................................. 16
2.2.2 Fall arrester...................................................................................................................... 16
2.2.3 Danger to life when standing under raised loads............................................................... 16
2.2.4 Danger to life due to improper transport........................................................................... 16
2.2.5 Work areas........................................................................................................................ 17
2.2.6 Falling parts...................................................................................................................... 17
2.2.7 Risk of crushing or cuts..................................................................................................... 17
2.2.8 Moving parts.................................................................................................................... 18
2.2.9 Fast roll-up....................................................................................................................... 18
2.2.10 Danger of wrapping around body parts............................................................................. 18
2.2.11 Risk of injury due to hot surfaces....................................................................................... 18
2.2.12 Environmental influences................................................................................................. 18
2.3 Hazards in the event of fire, explosions and emergencies.................................................. 18
2.4 Dangers due to electrical current....................................................................................... 19
2.4.1 Protection against ingress of liquid.................................................................................... 19
2.4.2 Damaged parts................................................................................................................. 19
2.4.3 The five safety rules for electrical work.............................................................................. 20
2.4.4 Electric shock due to lack of grounding............................................................................. 20
2.4.5 Danger to life and damage to property due to loose power connections............................ 21
2.4.6 Residual charge in capacitors............................................................................................ 21
2.5 Dangers from electric fields............................................................................................... 21
2.5.1 Pacemakers/implants........................................................................................................ 21
2.5.2 Electromagnetic fields....................................................................................................... 21
2.6 Safety sign........................................................................................................................ 22
2.7 Identification of the device................................................................................................ 23
2.8 Safety loop and emergency stop....................................................................................... 25
5
SICHARGE D
Operating Instructions, 11/2023, A5E50556539-AG 5
Table of contents

2.9 Industrial Security............................................................................................................. 27
3 Description.......................................................................................................................................... 28
3.1 Product overview.............................................................................................................. 28
3.2 Configuration options....................................................................................................... 30
3.3 Scope of supply................................................................................................................ 31
3.4 Scope of delivery of cable management............................................................................ 32
3.5 Display elements and operator controls............................................................................. 33
3.5.1 Overview.......................................................................................................................... 33
3.5.2 Touch screen.................................................................................................................... 34
3.5.3 LED strips.......................................................................................................................... 34
3.5.4 RFID reader....................................................................................................................... 34
3.5.5 Charging plug and charging plug holder............................................................................ 34
3.5.6 AC charging socket........................................................................................................... 35
3.5.7 AC meter (charging outlet)................................................................................................ 35
3.5.8 DC meters......................................................................................................................... 35
3.5.9 Emergency Stop switch..................................................................................................... 36
3.5.10 Locking system & replacing the lock cylinders.................................................................... 37
3.5.11 Black panel....................................................................................................................... 39
3.5.12 Credit card reader............................................................................................................. 39
3.6 Charging points................................................................................................................ 40
3.7 Design of the charging station.......................................................................................... 43
3.8 Dynamic power distribution.............................................................................................. 46
3.9 Electrical protection devices.............................................................................................. 49
3.10 Self-checks & health monitoring........................................................................................ 50
3.11 External Emergency Stop.................................................................................................. 51
3.12 Connection to an external load management system......................................................... 51
3.13 Climate and environmental concept.................................................................................. 52
3.14 Routers............................................................................................................................. 53
3.15 SICHARGE Configuration Backend...................................................................................... 58
3.16 OCPP backend................................................................................................................... 60
3.17 Dispenser......................................................................................................................... 62
4 Transport and storage........................................................................................................................ 63
4.1 General information.......................................................................................................... 63
4.2 Road transport.................................................................................................................. 67
4.3 Sea transport and air transport.......................................................................................... 68
4.4 Storage............................................................................................................................. 70
6
Table of contents
SICHARGE D
Operating Instructions, 11/2023, A5E50556539-AG

5 Installation and mounting.................................................................................................................. 71
5.1 Preparation....................................................................................................................... 71
5.2 Installation location.......................................................................................................... 72
5.3 Base area and foundation................................................................................................. 76
5.4 Goods acceptance............................................................................................................. 81
5.4.1 Checking the delivery for completeness and correctness.................................................... 81
5.4.2 Inspect and remove transport packaging........................................................................... 81
5.4.3 Report missing delivery components or transport damage................................................. 81
5.5 Setting up the charging station......................................................................................... 82
5.5.1 Preparing cables............................................................................................................... 82
5.5.2 Positioning the charging station........................................................................................ 83
5.5.3 Inserting the cables into the cabinet.................................................................................. 85
5.5.4 Securing the charging station............................................................................................ 85
5.5.5 Installing the cable management...................................................................................... 86
5.5.5.1 Installing the mounting plates........................................................................................... 86
5.5.5.2 Installing the cable clamp.................................................................................................. 89
5.5.5.3 Removing the rope stopping mechanism........................................................................... 92
5.5.5.4 Installing the cover........................................................................................................... 93
5.5.6 Mounting the roof and filter cover.................................................................................... 94
5.5.7 Install the cable gland plate............................................................................................... 95
5.5.8 Installing baseboards........................................................................................................ 97
5.6 Connecting the charging station....................................................................................... 97
5.6.1 Safety instructions............................................................................................................ 97
5.6.2 Mains connection............................................................................................................. 98
5.6.3 Dispenser......................................................................................................................... 103
6 Commissioning................................................................................................................................... 106
6.1 Safety precautions before initial commissioning................................................................ 106
6.2 Switch on charging station................................................................................................ 107
6.3 Switching off the charging station..................................................................................... 108
6.4 Restarting the charging station......................................................................................... 108
6.5 Service mode.................................................................................................................... 109
7 Operation............................................................................................................................................ 110
7.1 Safety instructions............................................................................................................ 110
7.2 Starting the charging process............................................................................................ 111
7.3 Monitoring the charging process....................................................................................... 115
7.4 Stopping the charging process.......................................................................................... 116
7.5 Calling the help function................................................................................................... 117
8 Error messages and remedy............................................................................................................... 118
8.1 Error message "Emergency Stop was triggered"................................................................. 119
SICHARGE D
Operating Instructions, 11/2023, A5E50556539-AG 7
Table of contents

8.2 Error message "Charging station out of service"................................................................. 120
8.3 Charging point message "Out of operation"....................................................................... 121
8.4 "Connection failed" message............................................................................................. 122
9 Maintenance and service.................................................................................................................... 123
9.1 Safety instructions............................................................................................................ 123
9.2 Maintenance plan............................................................................................................. 124
9.3 Servicing the charging station........................................................................................... 125
9.3.1 Cleaning the touch screen................................................................................................. 125
9.3.2 Cleaning the cabinet......................................................................................................... 126
9.3.3 Replacing an air filter........................................................................................................ 127
9.3.4 Charging cable gland........................................................................................................ 131
9.3.5 Checking the coolant........................................................................................................ 132
9.3.6 Adding coolant................................................................................................................. 133
9.4 Spare parts....................................................................................................................... 133
10 Decommissioning and disassembly.................................................................................................... 134
11 Recycling and disposal........................................................................................................................ 135
12 Technical specifications...................................................................................................................... 136
13 Adhesive surfaces............................................................................................................................... 140
14 Declaration of Conformity.................................................................................................................. 141
A List of abbreviations and explanation of terms.................................................................................. 142
B Checklist for commissioning............................................................................................................... 143
C Other applicable documents.............................................................................................................. 144
Index................................................................................................................................................... 145
8
Table of contents
SICHARGE D
Operating Instructions, 11/2023, A5E50556539-AG

Introduction 1
1.1 About the operating instructions
These operating instructions contain the information for the safe operation and intended use
of the SICHARGE D charging station. The operating instructions are aimed primarily at
operators. Together with the documentation in the section "AUTOHOTSPOT", they form the
basic documentation of the SICHARGE D.
Safekeeping the operating instructions
The operating instructions are an integral part of the product and an indispensable part of the
product safety concept. The following requirements therefore apply for safekeeping the
operating instructions:
•Keep the operating instructions for the entire service life of the charging station.
•Make the operating instructions easily accessible at all times for all persons involved.
•If you transfer the charging station to third parties, also pass along the operating
instructions.
Topic page SICHARGED technical documentation
The topic page provides you with direct access to the technical documentation of your
SICHARGED. The topic page can be found here on the Internet
(https://www.siemens.com/sicharge-d-manuals).
Using the operating instructions
How to use the operating instructions correctly:
•Make the operating instructions available to all persons involved before and during the
work on the charging station.
•Read the operating instructions carefully before starting work.
•Follow the safety instructions and handling instructions.
•Failure to comply with the information in these operating instructions can result in
personal injury, material damage, dangerous situations and loss of warranty.
Illustrations may deviate
The figures in this manual may have equipment features other than the configuration of your
SICHARGE D.
9
SICHARGE D
Operating Instructions, 11/2023, A5E50556539-AG

Definition
If this document refers to a partly completed machine, then this refers to the rope box of the
cable management system in the non-installed state.
Validity of the documentation
This document is valid as of software version V3.0.0 and hardware version V2.3.
This document applies to devices without measurement in compliance with calibration law.
Use the documents 8EM5907-0AA00-5AA3 and 8EM5907-0AA00-5AA4 for devices with
measurement in compliance with calibration law.
Conventions
Please pay particular attention to notes highlighted as follows:
NOTE
Notes contain important information on the product, handling the product or on part of the
documentation to which you should pay particular attention.
Changes compared to previous versions
Compared to the 11/2022 edition, this manual contains the following changes:
•Addition to the configuration options (section "Configuration options (Page 30)")
–New configurations: CC Terminals Wordline Valina, Payter P66, Castles (NEFTIS); DC
meter MID/LNE
–Invalid configurations: CHAdeMO 200A cable
•Addition to the cable management (section "Installing the cable management (Page 86)")
•Technical specifications updated
•General corrections
Compared to the 01/2022 edition, this manual contains the following changes:
•Conversion of the article number
•Adaptation of the nameplate
•Note on use of the cable bridge for TN-C systems
•List of applicable documents
•List of technical specifications
•Additional maintenance instructions (section "Servicing the charging station (Page 125)")
•General corrections
10 SICHARGE D
Operating Instructions, 11/2023, A5E50556539-AG
Introduction
1.1 About the operating instructions

1.2 Basic information
The charging station complies with all prescribed technical safety standards and thereby
offers the greatest possible product safety. To ensure the safety of all persons, systems and
equipment at all times, adhere to the following basic safety instructions.
Guidelines and regulations
In order to ensure comprehensive safety, adhere to the following guidelines and regulations:
•Guidelines for occupational safety
•Regulations for prevention of accidents
•Trade regulations
•Technical connection conditions of the power supply unit
•Building regulations
•Generally accepted rules of technology
Target group
These operating instructions are intended for the following persons:
•Operators
•Qualified electricians
•Assemblers
•Planners
•Service personnel
•Carriers
1.3 Open-source software
Open-source software is used in the firmware of the product described. The open source
software is provided free of charge. We are liable for the product described, including the
open-source software contained in it, pursuant to the conditions applicable to the product.
Siemens accepts no liability for the use of the open-source software over and above the
intended program sequence, or for any faults caused by modifications to the software.
For legal reasons, we are obliged to publish the original text of the license conditions and
copyright notices. We make the open source software readme available in these ways:
•On the Siemens homepage
(https://support.industry.siemens.com/cs/de/de/view/109796318/en) for download
•On the touch screen of the charging station. To do this, open the front door with the
charging station switched on.
11
Introduction
1.3 Open-source software
SICHARGE D
Operating Instructions, 11/2023, A5E50556539-AG

1.4 Processing of personal data
For operation, the charging station collects, processes and stores the following personal data:
•UID (Unique Identifier) of the RFID card (if RFID authorization method is set)
•EVCC ID (MAC address of the on-board communication controller) (if AUTOCHARGE
authorization method is set)
This data is only available to the manufacturer in pseudonymized form and is processed,
transmitted and stored within the framework of the legal provisions.
12 SICHARGE D
Operating Instructions, 11/2023, A5E50556539-AG
Introduction
1.4 Processing of personal data

Safety instructions 2
The safety instructions section describes the intended use by the target groups and potential
dangers.
2.1 General
2.1.1 Requirements
If you have read and understood the operating instructions and meet the requirements, then
you are allowed to work on the charging station and the partly completed machine.
The minimum age for working on the rope box is 18years.
2.1.2 Intended use, modifications to the device
Intended use
The SICHARGED charging station has up to three ports for charging the batteries of electric
vehicles. For this purpose, the vehicle requires an AC charging socket or a DC charging socket.
DC charging sockets:
•CCS 2
•CHAdeMO
AC charging socket:
•Type 2
NOTICE
Do not use adapters between charging plug and vehicle
You may not use adapters, for example, to extend the charging cables or to charge vehicles
with an unsupported charging standard.
If an adapter was used, then the manufacturer does not assume any responsibility or liability
for any damage caused. Point this out to the users of the charging station, e.g. by means of a
clearly visible sticker.
The charging station can be used indoors and outdoors. For proper use, the permissible
ambient conditions at the location of use must be observed. The SICHARGED charging station
may only be operated in a perfect technical condition.
NOTE
In the device version with EMC emission class A, the charging station is not suitable for use in
residential areas. The charging station could therefore interfere with radio reception in such
areas. If the charging station is installed in residential environments, select the "EMC
emission class B" option.
13
SICHARGE D
Operating Instructions, 11/2023, A5E50556539-AG

NOTE
Charging of buses and trucks
Perform a compatibility test before charging a bus or truck at the charging station. Please
contact your Siemens contact partner in relation to this.
Alterations to the device
The operating instructions describe all permissible alterations to the charging station. Any
other modification that is not part of this or any other official Siemens document is not
permitted. This applies to both electrical modifications (connecting, disconnecting or
swapping connections of electrical devices, etc.) and mechanical modifications (e.g. drill
holes). Unauthorized modifications void the manufacturer's warranty and the approvals of
the device become invalid.
Any person may use the charging station to charge electric vehicles in accordance with the
operating requirements. Only qualified, trained and authorized personnel are allowed to
perform maintenance and repairs. The operator checks the qualification and authorizes the
personnel. The charging station may only be opened by authorized persons (qualified
electricians).
The SICHARGED charging station is intended for charging electric vehicles according to
EN61851‑1/‑23 and must not be used for other vehicles or purposes. Any other use is not as
intended and constitutes misuse of the device.
Set up the charging station according to the specifications in these operating instructions.
Transport, installation, maintenance, cleaning, and normal operation must follow the
instructions or procedures specified in these operating instructions.
WARNING
Danger due to missing or unrecognizable safety signs and warnings
Missing or unrecognizable safety signs or warnings do not indicate that danger is not no
longer present. Undetected dangers can result in accidents with serious physical injury or
death.
• Check the presence of all safety signs and warnings using the operating instructions
• Replace missing safety signs and warnings
• Do not remove safety signs and warnings
• Replace unrecognizable safety signs and warnings
14 SICHARGE D
Operating Instructions, 11/2023, A5E50556539-AG
Safety instructions
2.1 General

2.1.3 Qualified personnel
Qualified personnel
All work on the charging station may only be performed after having received the proper
instructions. Non-electrical work, e.g. transport and assembly, may only be performed by
qualified personnel. Qualified personnel are qualified by training and experience to recognize
risks arising during the respective work and to avoid possible hazards.
Electrical engineering work may only be performed by qualified electricians themselves or
under their direction and supervision.A qualified electrician is someone who is able to assess
the work assigned to them and recognize potential dangers due to their professional training,
knowledge and experience as well as knowledge of the relevant standards.
2.1.4 Protection against unauthorized opening
A lock system protects the charging station from unauthorized opening of the device doors at
the front and back.
•Keep the key for the door locks safe against access by unauthorized persons.
•Only make the key available to authorized personnel for work performed inside the
charging station.
•Do not leave the charging station unattended when the device door is open.
NOTE
The charging station is supplied with replaceable locking cylinders and matching keys. These
standard keys are located on the inside of the front door.
The operator must replace the locking cylinder as protection against unauthorized opening.
The operator must also keep the associated keys safely. The operator must provide service
personnel with access to the charging station for maintenance work.
Use different locking cylinders for each individual charging station. This ensures that each
charging station can only be opened by the matching key.
Replacing the locking cylinders
The charging station is supplied with replaceable locking cylinders (standard half
cylinders(10/30) according to DIN18252) and matching keys. In the section "Locking system
& replacing the lock cylinders (Page 37)", you will find detailed instructions on how to replace
the locking cylinders.
15
Safety instructions
2.1 General
SICHARGE D
Operating Instructions, 11/2023, A5E50556539-AG

2.2 Hazards during transport, mounting, operation and maintenance
2.2.1 Personal protective equipment (PPE)
Personal protective equipment protects you against hazards to your health and safety. Use
your personal protective equipment in accordance with occupational safety guidelines and
accident prevention regulations.
When working use the required personal protective equipment, such as:
•Safety shoes
•Helmet
•Safety vest
•Gloves
•Protective goggles
2.2.2 Fall arrester
When working at heights above 1m, use a fall arrester. Use work platforms or lifting
platforms to provide qualified personnel with a stable surface. Take the necessary precautions
to prevent tools and components from falling.
2.2.3 Danger to life when standing under raised loads
If hoisting gear or load handling equipment fails, a raised load can drop. If you are in the
hazardous area under or next to the raised load at this time, death, serious injury and
material damage may result.
•Always use hoisting gear and load handling equipment properly.
•Do not stay in the hazardous area under or next to raised loads.
2.2.4 Danger to life due to improper transport
If you transport the charging station improperly, the device may tip over. A tipping charging
station can cause death, serious injury and material damage. Observe the following points:
•Only qualified persons may transport the charging station.
•Only use approved means of transport and hoisting gear.
•Pay attention to the center of gravity of the charging station. The center of gravity is
marked on the device and on the packaging.
•Note the weight of the charging station.
•Only transport the charging station in a vertical position.
•The forks of the forklift must protrude at the rear of the transport pallet.
16 SICHARGE D
Operating Instructions, 11/2023, A5E50556539-AG
Safety instructions
2.2 Hazards during transport, mounting, operation and maintenance

2.2.5 Work areas
Danger of tripping or slipping.
Keep work areas clean and tidy to prevent tripping and slipping.
If you allow the rope of the cable management system to protrude too far, there is a risk of
people tripping or falling.
Accident hazards
Avoid accidents and injuries to persons, as well as damage to vehicles and the SICHARGED.
Accident hazards include:
•Inattention
•Danger of tripping or slipping.
•Vandalism
Provide additional protective measures, such as:
•Warning signs
•Safe location of SICHARGED
•Barriers
•Training of drivers and operators
•Sufficient lighting
•Padlocks to protect against restarting
•Suitable weather protection
Safety area for mounting
Create a safety area around the installation area with warning signs and barriers.
2.2.6 Falling parts
When working at an elevated height, watch out for falling parts, cables or plugs.
2.2.7 Risk of crushing or cuts
When mounting, look out for moving parts, sharp-edged parts and protruding cables and
bolts.
The rope box of the cable management system is constantly under spring tension.
The rope box is a partly completed machine. Only use the rope box if it is professionally
installed and covered with the cover.
17
Safety instructions
2.2 Hazards during transport, mounting, operation and maintenance
SICHARGE D
Operating Instructions, 11/2023, A5E50556539-AG

2.2.8 Moving parts
The rope box is a partly completed machine. Therefore, there are possibilities of intervention
in moving mechanical parts. If the rope box is installed according to the instructions, then
contact protection is in place.
Do not reach into the rope box until the assembly is complete. Do not use the rope box until
assembly is complete.
2.2.9 Fast roll-up
If the rope breaks, it is pulled into the rope box by the spring force. Rapid coiling/whipping of
the rope can result in injuries/burns.
During mounting and disassembly, leave the rope clamp and pulley on the rope until the rope
box is fully integrated.
When recycling, only cut the rope directly at the inlet when the roof is installed.
2.2.10 Danger of wrapping around body parts
Do not wrap the rope around body parts. The cable management system retracts the rope
with pretensioned spring force. If the rope is wrapped around body parts it could,
forexample, strangle a person or crush the body part.
2.2.11 Risk of injury due to hot surfaces
When opening the front door or back door, you can come into contact with hot surfaces. This
applies, for example, to the area of the converters or the copper bars. Before starting work,
wait at least 10 minutes after switching off the charging station until all hot surfaces have
cooled down.
2.2.12 Environmental influences
Protect the cable management system and the charging station from water ingress and other
weather conditions.
2.3 Hazards in the event of fire, explosions and emergencies
Fire and explosion protection
Do not store or use flammable liquids that produce flammable vapors, such as gasoline or
ethanol, in the vicinity of the charging station. Electrostatic charges or heat generated during
charging can ignite explosive and flammable liquids.
Fire hazard
In the event of a fire, leave the danger zone. Do not use the charging station in the event of
fire.
18 SICHARGE D
Operating Instructions, 11/2023, A5E50556539-AG
Safety instructions
2.3 Hazards in the event of fire, explosions and emergencies

Insufficient ventilation
Insufficient ventilation clearances result in components overheating and, in the worst case, in
the generation of smoke and fire. A fire can result in severe injuries.
Furthermore, the service life of installed components is reduced significantly by
overtemperatures.
2.4 Dangers due to electrical current
2.4.1 Protection against ingress of liquid
If the doors are locked correctly and the roof is mounted correctly, then the cabinet of the
charging station meets the IP54 degree of protection. The IP54 degree of protection of the
cabinet protects the charging station from ingress of water splashing against it from all
directions. The protection standard prevents ingress of precipitation and any liquid not under
pressure that comes into contact with the cabinet surface.
Also protect the charging station from liquids that exert pressure on the surface of the
cabinet:
•Never use a pressure washer or steam cleaner to clean the charging station
•Set up the charging station at a flood-proof location.
WARNING
Electric shock due to ingress of liquid
Strong jets of water or flooding can cause liquid to enter the charging station. Moisture or
liquid inside the charging station can cause electric shock.
Observe the following points when there is a risk that liquid may have entered the charging
station:
• Take the charging station out of operation by switching it off at the electrical distributor
and the main switch -QA2
• Qualified personnel must dry the charging station and check it for damage.
2.4.2 Damaged parts
Only use undamaged devices or parts
Improper handing can damage devices. Hazardous voltages may be present on the cabinet or
exposed components if devices are damaged. Dangerous voltages can result in severe injuries
or death. Observe the following points:
•Never exceed the limit values of the technical data during transport, storage and
operation.
•Check the charging cables and charging plugs for tempering, damage and foreign bodies
•Never use damaged devices or parts.
19
Safety instructions
2.4 Dangers due to electrical current
SICHARGE D
Operating Instructions, 11/2023, A5E50556539-AG

2.4.3 The five safety rules for electrical work
The European standard EN50110‑1:2023 "Operation of electrical installations" prescribes
safety rules for work on and in electrical installations. To ensure the safety of persons and
property in accordance with the standards, always comply with the following safety rules.
Securing an electrical system before starting work
Before starting work on and in electrical installations, apply the following five safety rules:
1. Disconnect at electric distributor
2. Secure against reconnection at electric distributor
3. Verify there is no voltage on the electrical distribution board and the workstation.
4. Ground and short-circuit at the electric distributor
5. Erect barriers around or cover adjacent live parts
Prepare to switch on again after work is finished
After finishing and checking the work, prepare the restart as follows:
•Inform persons no longer required that the work is completed and no further work is
permitted.
•Withdraw persons who are no longer required.
•Remove all tools, equipment and aids that have been used.
Switch on the electrical system again
After finishing the work, rescind the protective measures and switch the system on again:
1. Remove the short-circuit.
2. Remove the grounding.
3. Remove covers or barriers.
4. Remove the fuse to prevent the system from being switched on again.
5. Reconnect the system to the power supply.
2.4.4 Electric shock due to lack of grounding
If the protective conductor connection is missing or incorrectly connected, high voltages may
be present on exposed parts. Touching the parts can lead to severe injuries or death. To
ground the charging station, connect the protective conductor in conformance with
regulations.
For more information on connection, refer to the section "Connecting the charging station
(Page 97)"
20 SICHARGE D
Operating Instructions, 11/2023, A5E50556539-AG
Safety instructions
2.4 Dangers due to electrical current
