Siemens SICHARGE D User manual

Preventive Maintenance Checklist for SICHARGE D and Dispenser
Preventive Maintenance Checklist
for SICHARGE D and Dispenser
Product Information
07/2023
A5E52386197
-AB
Introduction
1
Preparation
2
Preventive Maintenance
Checklist for SICHARGE D
3
Preventive Maintenance
Checklist for Dispenser
4

Siemens AG
Smart Infrastructure
eMobility
Siemenspromenade 10
91058 Erlangen
GERMANY
A5E52386197-AB
Ⓟ
07/2023 Subject to change
Copyright © Siemens AG 2022 - 2023.
All
rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

Preventive Maintenance Checklist for SICHARGE D and Dispenser
Product Information, 07/2023, A5E52386197-AB 3
Table of contents
1 Introduction ........................................................................................................................................... 4
2 Preparation ............................................................................................................................................ 5
3 Preventive Maintenance Checklist for SICHARGE D .............................................................................. 7
4 Preventive Maintenance Checklist for Dispenser................................................................................ 10

Preventive Maintenance Checklist for SICHARGE D and Dispenser
4Product Information, 07/2023, A5E52386197-AB
Introduction
1
The condition of the system and any defects found must be documented with suitable
photos.
If an inspection point is marked "FAIL (F)", a more detailed description of the defect must be
given at the end of the checklist.
Criteria that cannot be checked, e.g. because they are not present, are to be marked with
"N/A".
The list must be filled in completely.
Defects that have been directly eliminated are to be entered in the defect list and marked as
completed.
Note
After commissioning, carry out the checks at the following intervals:
•
6 months after commissioning
•
12 months after commissioning
After the first year, carry o
ut the tests every 12 months. Perform the checks at shorter
intervals if necessitated by the ambient conditions of the SICHARGE D charging station (e.g.
high dust exposure).

Preventive Maintenance Checklist for SICHARGE D and Dispenser
Product Information, 07/2023, A5E52386197-AB 5
Preparation
2
Before going to the job site, make sure to bring the following items to ensure a correct
maintenance in the most efficient time possible.
•Keys to unlock the device.
•Check the FW version and LOGO! version.
–Ask for the customer's agreement to update in case new software is available.
–Prepare a USB stick and microSD card for these updates.
•Check and use latest version of the Preventive Maintenance Checklist
(https://support.industry.siemens.com/cs/de/en/view/109814289)
•Check for available and latest versions of the Q-Feedbacks (https://siemens.com/sicharge-
d-manuals) and if they are applicable. Make sure you are logged in and the Intranet view
is enabled.
•Check if additional spare parts for maintenance are required.
•Check for current error flag events and events that have occurred in the recent days. Be
prepared to resolve them on the same trip to the site.
Note
Estimated time
Keep in mind that the estimated time to complete all maintenance steps is approximately 2.5
hours for the SICHARGE D and 1.5 hours for the Dispenser.
List of Tools
•Allen set - 4 to 19 mm
•Cleaning wipes
•Cutter
•Digital multi-meter up to 1 000 V
•Insulation tester
•Earth Resistance Meter
•Hand pump for liquid-cooled cable coolant
•Insulated screwdriver set
•Ladder
•Lubricant
•Torque wrench - 3 to 150 Nm
•Torx set - TX 8 to 30
•Vacuum cleaner

Preparation
Preventive Maintenance Checklist for SICHARGE D and Dispenser
6Product Information, 07/2023, A5E52386197-AB
Required material for standard maintenance per SICHARGE D
Part Number
Functional Description
Quantity
8EM5905-0AA00-0AA3
Filter Mat G4 380x480x20mm Bottom Side
2
8EM5905-0AA00-0AA4
Filter Mat G4 380x550x20mm Bottom Rear
1
8EM5905-0AA00-0AA5
Filter Mat G4 220x520x20mm Top Side
2
8EM5905-0AA00-0AA6
Filter Mat G4 200x640x20mm Top Rear
1
8EM5905-0AA00-0AA8
Filter Mat G4 130x170x20mm Automation
1
8EM5905-0AA00-0AA2 (Optional)
Cooling Liquid Glysofor N 52%
1
Required material for standard maintenance per Dispenser
Part Number
Functional Description
Quantity
8EM5901-2AA00-2AA8
Filter Mat G4 220x215x20mm Dispenser Bottom
2
8EM5901-2AA00-3AA0
Filter Mat G4 430x100x20mm Dispenser Top
1
Recommended additional components
Note
Quantities vary depending on the configuration.
Part Number
Functional Description
Qty. SICHARGE D
Qty. Dispenser
8EM5905-0AA00-2AA5
Mating Face Repair Kit Phoenix CCS 250/400 A
1 or 2
2
8EM5905-0AA00-2AA6
Mating Face Repair Kit Phoenix CCS 500 A
none or 1
-
8EM5902-1AA00-2AA4
Charging Plug Retainer CCS
1 or 2
2
8EM5902-1AA00-2AA5
Charging Plug Retainer CHAdeMO
none or 1
-

Preventive Maintenance Checklist for SICHARGE D and Dispenser
Product Information, 07/2023, A5E52386197-AB 7
Preventive Maintenance Checklist for SICHARGE D
3
Control (at least annually)
Customer:
Date:
Serial number:
Date of manufacture:
Location:
Name:
Signature:
No.
Checklist item
P
F
N/A
1
Visual Inspection Outside
Check the exterior of the cabinet for visible damage, stickers or graffiti.
Check the control panel (HMI) for visible damage.
Check the charging cables and plugs for moisture, dust, corrosion, demolition or wear.
Check cable management system (CMS), rope and cable clamp for moisture, dust, corrosion, dem-
olition or wear.
Check positioning of the charging cables in the CMS.
Check ease of movement of the CMS on both sides.
Check retraction of the CMS.
Check the AC charging socket for damage.
Check the position of the charging plug in the plug holder.
Check for material deposits, such as snow or accumulations of dirt, and remove if necessary.
Check the display windows of meters.
Check the housing LEDs.
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
2
Emergency Stop
Check the emergency stop button (NOT during charging process).
Check whether an error message appears on the HMI and LED turn red after pressing the button.
Observe if the charger returns to the default state after releasing the emergency stop button (LED
white, then green).
☐
☐
☐
☐
☐
☐
☐
☐
☐
3
Open Door, Shutdown and Power-Free State
Open the door and check if any error message appears on the HMI and the LEDs are red.
Check that the RCD trips by pushing the test button (RCD for AC charging needs the door contact
switch to be closed to be energized and being able to trip).
Press "Shutdown" on the HMI and wait for the charging station to shut down. Turn off -QA2.
Establish the power-free state.
Check the fans for any damages.
Check the ventilation openings.
Clean the grilles of fans and air intakes.
Check all the filter mats and replace if dirty.
Check the internal fans and clean them if necessary.
Check the insulation of the fan cables for visible damage.
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐

Preventive Maintenance Checklist for SICHARGE D
Preventive Maintenance Checklist for SICHARGE D and Dispenser
8Product Information, 07/2023, A5E52386197-AB
No.
Checklist item
P
F
N/A
4
Doors
Check the function of the cabinet door (lubricate the hinges if necessary).
Check the door locks and hinges for ease of movement.
Check if the earthing straps are damaged, complete and/or tightened on both doors.
☐
☐
☐
☐
☐
☐
☐
☐
☐
5
AC Charging Socket
Check for smooth running of the AC locking motor (red lever) (-XD102).
Check the actuator of the AC socket.
☐
☐
☐
☐
☐
☐
6
Visual Inspection Inside
Inspect the inside charger ceiling, doors, grating, and cable bushings.
Check the heating system.
Make a visual inspection for any damages to all components.
Check whether the cylinder fuses of the SPDs at the dispenser outlets are still intact.
Check the safety signs. (Front side: plastic cover MCCB, surge protection, Back side: chimney).
Are country-specific additional signs available?
Is system documentation (circuit diagrams, product documentation, OEM documentation) avai-
lable?
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
7
AC Mains and Dispenser Bus Bar Connection
Check the tightening torques (40 Nm) or mark on the nut of the L1, L2, L3, N connections.
Check the tightening torque (40 Nm) or mark on the nut of the PE ground connections.
Check the tightening torques (40 Nm) or mark on the nut of the Dispenser DC+ and DC- connec-
tions.
☐
☐
☐
☐
☐
☐
☐
☐
☐
8
Cooling Unit
Check the fill level of the coolant.
Check for any leaks in the coolant circuit.
Check the tubes and connectors of the cooling unit.
Add coolant, if the fill level is too low.
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
9
Clean Interior
Clean the interior if necessary
☐
☐
☐
10 Electrical Safety Measurements
Perform and document the electrical safety measurements of electrical protective devices and
earth resistance according to the local regulations and standards.
☐☐☐
11 Power-On, Update and Close Door
Turn on -QA2 and supply power to the charging station.
Wait until the charging station is ready (LEDs green).
Install FW updates if available and the customer has agreed in written form.
Install LOGO! updates if available and the customer has agreed in written form. For this purpose, a
micro-SD card is needed.
Close and lock the door.
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐

Preventive Maintenance Checklist for SICHARGE D
Preventive Maintenance Checklist for SICHARGE D and Dispenser
Product Information, 07/2023, A5E52386197-AB 9
Comments and findings:
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Name
Function
Signature
Responsible person
(optional) Customer
Please take into consideration that the document is only valid after signatures of technician or if included in the final
document delivered to the customer.

Preventive Maintenance Checklist for SICHARGE D and Dispenser
10 Product Information, 07/2023, A5E52386197-AB
Preventive Maintenance Checklist for Dispenser
4
Control (at least annually)
Customer:
Date:
Serial number:
Date of manufacture:
Location:
Name:
Signature:
No.
Checklist item
P
F
N/A
1
Visual Inspection Outside
Check the exterior of the cabinet for visible damage, stickers or graffiti.
Check the charging cables and plugs for moisture, dust, corrosion, demolition or wear.
Check cable management system (CMS), rope and cable clamp for moisture, dust, corrosion, dem-
olition or wear.
Check positioning of the charging cables in the CMS.
Check ease of movement of the CMS on both sides.
Check retraction of the CMS.
Check the position of the charging plug in the plug holder.
Check for material deposits, such as snow or accumulations of dirt, and remove if necessary.
Check the display windows of meters.
Check the housing LEDs.
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
2 Emergency Stop
Check if the LEDs turn red after pressing the emergency stop button on the SICHARGE D.
Observe if the Dispenser returns to the default state after releasing the emergency stop button
(first white LED, then green LED).
☐
☐
☐
☐
☐
☐
3
Open Door, Shutdown and Power-Free State
Open the door and check if any error message appears on the HMI of the SICHARGE D and the
LEDs are red.
Check that the RCD trips by pushing the test button.
Press "Shutdown" on the HMI of SICHARGE D and wait for the shutdown. Turn off -QA2.
Establish the power-free state.
Check the fans for any damages.
Check the ventilation openings.
Clean the grilles of fans and air intakes.
Check all the filter mats and replace if dirty.
Check the internal fans and clean them if necessary.
Check the insulation of the fan cables for visible damage.
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
4
Door
Check the function of the cabinet door (lubricate the hinges if necessary).
Check the door locks and hinges for ease of movement.
Check if the earthing straps are damaged, complete and/or tightened on both doors.
☐
☐
☐
☐
☐
☐
☐
☐
☐

Preventive Maintenance Checklist for Dispenser
Preventive Maintenance Checklist for SICHARGE D and Dispenser
Product Information, 07/2023, A5E52386197-AB 11
No.
Checklist item
P
F
N/A
5
Visual Inspection Inside
Inspect the inside charger ceiling, doors, grating, and cable bushings.
Check the heating system.
Make a visual inspection for any damages to all components.
Check the safety signs.
Are country-specific additional signs available?
Is system documentation (circuit diagrams, product documentation, OEM documentation) avai-
lable?
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
☐
6
Dispenser Bus Bar Connection
Check the tightening torque (40 Nm) or mark on the nut of the PE ground connections.
Check the tightening torques (40 Nm) or mark on the nut of the Dispenser DC+ and DC- connec-
tions.
☐
☐
☐
☐
☐
☐
7
Clean Interior
Clean the interior if necessary.
☐
☐
☐
8
Electrical Safety Measurements
Perform and document the electrical safety measurements of electrical protective devices and
earth resistance according to the local regulations and standards.
☐☐☐
9
Power-On, Update and Close Door
Close and lock the door.
Turn on -QA2 in the SICHARGE D and power on the system.
Wait until the charging station is ready (LEDs green).
☐
☐
☐
☐
☐
☐
☐
☐
☐
Comments and findings:
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Name
Function
Signature
Responsible person
(optional) Customer
Please take into consideration that the document is only valid after signatures of technician or if included in the final
document delivered to the customer.
