CP 5622
Operating Instructions, 05/2021, C79000-G8976-C279-04 3
Preface
What the consignment contains
The following components are supplied with the CP 5622:
•CP 5622 communications processor
Please check that the consignment you have received is complete. If it is not complete, please
contact your supplier or your local Siemens office.
Validity of this documentation
These operating instructions are valid for the following product:
•CP 5622
Article number: 6GK1 562-2AA00
Content of this documentation
These operating instructions contain information about the installation and configuration of
the CP 5622 communications processor.
Updated operating instructions on the Internet
You will find the current version of these operating instructions on the Product Support pages
under the following entry ID:
58826340 (https://support.industry.siemens.com/cs/ww/en/view/58826340)

Preface
CP 5622
4Operating Instructions, 05/2021, C79000-G8976-C279-04
Further documentation
The documents listed below contain more detailed information on commissioning and using
the communications processor. You will find this documentation on the Product Support
pages on the Internet under the following entry link:
Support (https://support.industry.siemens.com/cs/ww/en/ps)
Enter the entry ID shown below of the relevant manual as the search item.
•Configuration manual Commissioning PC Stations
This provides you with detailed information on commissioning and configuring SIMATIC
NET PC communications modules.
Entry ID:
109488960 (https://support.industry.siemens.com/cs/ww/en/view/109488960)
•System manual SIMATIC NET Industrial Communication with PG/PC
–Volume 1– Basics
Entry ID:
77376110 (https://support.industry.siemens.com/cs/ww/en/view/77376110)
–Volume 2– Interfaces
Entry ID:
77378184 (https://support.industry.siemens.com/cs/ww/en/view/77378184)
The system manuals introduce the topic of industrial communication and explain the
communications protocols used. There is also a description of the OPC interface as user
programming interface.
•Installation manual "SIMATIC NET PC Software"
This document contains detailed information on installing the "SIMATIC NET
PC Software".
Entry ID:
77377602 (https://support.industry.siemens.com/cs/ww/en/view/77377602)
•System manual PROFIBUS Network Manual
In this document you will find detailed information about setting up a PROFIBUS network.
Entry ID:
35222591 (https://support.industry.siemens.com/cs/ww/en/view/35222591)
SIMATIC NET documentation
You will find the entire SIMATIC NET documentation on the pages of Product Support:
15247 (https://support.industry.siemens.com/cs/ww/en/ps/15247)
Go to the required product group and make the following settings:
→Entry list →Entry type "Manuals / Operating Instructions"

Preface
CP 5622
Operating Instructions, 05/2021, C79000-G8976-C279-04 5
Trademarks
The following and possibly other names not identified by the registered trademark sign ® are
registered trademarks of Siemens AG:
SIMATIC NET, HARDNET, SOFTNET, CP 1612, CP 1613, CP 5612, CP 5613, CP 5614, CP 5622
Industry Online Support
In addition to the product documentation, you are supported by the comprehensive online
information platform of Siemens Industry Online Support at the following Internet address:
Link: (https://support.industry.siemens.com/cs/de/en/)
Apart from news, there you will also find:
•Project information: Manuals, FAQs, downloads, application examples etc.
•Contacts, Technical Forum
•The option submitting a support query:
Link: (https://support.industry.siemens.com/My/ww/en/requests)
•Our service offer:
Right across our products and systems, we provide numerous services that support you in
every phase of the life of your machine or system - from planning and implementation to
commissioning, through to maintenance and modernization.
You will find contact data on the Internet at the following address:
Link: (https://www.automation.siemens.com/aspa_app/?ci=yes&lang=en)
SITRAIN - Training for Industry
The training offer includes more than 300 courses on basic topics, extended knowledge and
special knowledge as well as advanced training for individual sectors - available at more than
130 locations. Courses can also be organized individually and held locally at your location.
You will find detailed information on the training curriculum and how to contact our
customer consultants at the following Internet address:
Link: (https://sitrain.automation.siemens.com/DE/sitrain/default.aspx?AppLang=en)
Industrial Networks Education
Training and certification for Industrial Networks
In our Industrial Networks Education courses you’ll learn to design and implement wired and
wireless data networks and connect them to a corporate network. You will also receive
instruction on how to secure, diagnose and optimize communication networks. Certification
can also be offered to supplement almost all training courses.
Link: (https://www.siemens.com/industrial-networks-education)

Preface
CP 5622
6Operating Instructions, 05/2021, C79000-G8976-C279-04
Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines, and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens’ products and solutions form one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. These systems, machines and components should only be
connected to the enterprise network or the Internet if and only to the extent necessary and
with appropriate security measures (firewalls and/or network segmentation) in place.
You can find more information on protective measures in the area of industrial security by
visiting: (https://www.siemens.com/industrialsecurity).
Siemens’ products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends performing product updates as soon as they are
available and using only the latest product versions. Use of product versions that are no
longer supported, and failure to apply latest updates may increase customer’s exposure to
cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed under (https://www.siemens.com/industrialsecurity).
SIMATIC NET glossary
Explanations of many of the specialist terms used in this documentation can be found in the
SIMATIC NET glossary.
You will find the SIMATIC NET glossary on the Internet at the following address:
50305045 (http://support.automation.siemens.com/WW/view/en/50305045)
Recycling and disposal
The products are low in harmful substances, can be recycled and meet the requirements of
the Directive 2012/19/EU for disposal of waste electrical and electronic equipment (WEEE).
Do not dispose of the products at public disposal sites.
For environmentally compliant recycling and disposal of your electronic waste, please contact
a company certified for the disposal of electronic waste or your Siemens representative.
Note the different national regulations.

CP 5622
Operating Instructions, 05/2021, C79000-G8976-C279-04 7
Table of contents
Preface ................................................................................................................................................... 3
1 Description of the device....................................................................................................................... 9
1.1 Product characteristics ......................................................................................................... 9
1.2 PROFIBUS interface ............................................................................................................ 11
1.3 Meaning of the LED display................................................................................................ 12
2 Software installation ........................................................................................................................... 13
2.1 Installing the "SIMATIC NET PC Software"............................................................................ 13
2.2 Uninstalling the "SIMATIC NET PC Software" ....................................................................... 14
3 Hardware installation .......................................................................................................................... 15
3.1 Safety notices .................................................................................................................... 15
3.2 Installing hardware............................................................................................................ 16
3.3 Hardware compatibility...................................................................................................... 17
4 Configuration....................................................................................................................................... 19
5 Technical data...................................................................................................................................... 21
A Approvals............................................................................................................................................. 23

Table of contents
CP 5622
8Operating Instructions, 05/2021, C79000-G8976-C279-04

CP 5622
Operating Instructions, 05/2021, C79000-G8976-C279-04 9
Description of the device
1
1.1 Product characteristics
Properties
The CP 5622 is a communications processor for connecting PCs (personal computers) or PGs
(programming devices) to PROFIBUS and MPI networks. The essential properties are as
follows:
•Transmission speeds up to 12 Mbps.
•Floating RS-485 connector.
•Linking of up to 32 devices (PC, PG, SIMATIC S7 or ET 200) to form a network segment.
–By linking several segments with repeaters, up to 64 nodes can be connected.
•The additional interface signals for a direct link to a PLC (Programmable Logic Controller)
are supported up to 187.5 Kbps.
•Installation in PGs and PCs with a PCI Express slot. The following is supported:
–PCI Express x1
–Can also be operated in x4, x8 and x16 slots
–Plug and play

Description of the device
1.1 Product characteristics
CP 5622
10 Operating Instructions, 05/2021, C79000-G8976-C279-04
Appearance
The following graphic shows the CP 5622 communications processor:
1
LEDs
2
PROFIBUS interface PB1 (master or slave)
