Siemens FC2005 User manual

A6V10333722_m_en_--
2021-12-28
Smart Infrastructure
Fire Alarm Control Panel
Model FC2005
Installation, Operation and Maintenance Manual
firealarmresources.com

i
TABLE OF CONTENTS
INTRODUCTION ........................................................................................................................................................1
CONTROL PANEL LIMITATIONS ........................................................................................................................1
PREFACE ..............................................................................................................................................................3
FCC Part 68 WArning ...........................................................................................................................................3
INDUSTRY CANADA STATEMENT .....................................................................................................................4
SERVICE REQUIREMENTS .................................................................................................................................4
DESCRIPTIONS.........................................................................................................................................................5
FC2005 SYSTEM DESCRIPTION .........................................................................................................................5
Power Supply ......................................................................................................................................................6
Signaling Line Circuit (SLC) ................................................................................................................................6
Notification Appliance Circuits.............................................................................................................................6
Serial Interface Circuit (UFP) ..............................................................................................................................6
Status Relays ......................................................................................................................................................6
Programming Port ...............................................................................................................................................6
DACT...................................................................................................................................................................6
Programmable Key..............................................................................................................................................6
OPTIONAL MODULES..........................................................................................................................................6
City Tie Module (FCI2020-U1) ............................................................................................................................6
Battery Sets.........................................................................................................................................................7
Remote Printer Module (FCA2018-U1)...............................................................................................................7
AUXILIARY MODULES .........................................................................................................................................7
Serial LCD Annunciators .....................................................................................................................................7
FT Series LED Driver/Annunciators ....................................................................................................................7
Battery Housing (FH2072-UA) ............................................................................................................................8
Universal Enclosure for Annunciators (FTH2073-UA) ........................................................................................8
SLC ADDRESSABLE DEVICES...........................................................................................................................9
Smoke Detector...................................................................................................................................................9
Heat Detectors.....................................................................................................................................................9
Addressable Modules (Monitor and Control).......................................................................................................9
Manual Stations...................................................................................................................................................9
Sounder Base......................................................................................................................................................9
Programming SLC Devices .............................................................................................................................. 10
PAD-5 ............................................................................................................................................................... 10
EVENT HISTORY ............................................................................................................................................... 11
GENERAL DESIGN FEATURES ....................................................................................................................... 12
Environmental................................................................................................................................................... 12
Power Limiting.................................................................................................................................................. 12
Ground Fault Detection .................................................................................................................................... 12
NAC Operation ................................................................................................................................................. 12
Security Features ............................................................................................................................................. 12
REGULATORY STANDARDS ........................................................................................................................... 13
Underwriters Laboratories ................................................................................................................................ 13
Underwriters Laboratories of Canada .............................................................................................................. 13
Federal Communications Commission ............................................................................................................ 13
GENERAL SPECIFICATIONS ........................................................................................................................... 14
Environmental................................................................................................................................................... 14
Primary Power Supply (FP2011-U1)................................................................................................................ 14
Secondary Power Supply ................................................................................................................................. 14
Auxiliary Power Outputs ................................................................................................................................... 14
Status Relays ................................................................................................................................................... 15
Notification Appliance Circuits.......................................................................................................................... 15
Serial Interface Circuit (UFP) ........................................................................................................................... 15
SLC Addressable Device Circuits .................................................................................................................... 15
firealarmresources.com

ii
City Tie Circuits ................................................................................................................................................ 16
DACT Circuits................................................................................................................................................... 17
CONTROL PANEL OPERATION ........................................................................................................................... 18
OPERATION INSTRUCTIONS ........................................................................................................................... 18
Standby Condition ............................................................................................................................................ 18
Alarm Conditions .............................................................................................................................................. 18
Trouble Conditions ........................................................................................................................................... 19
Supervisory Conditions .................................................................................................................................... 19
ADDITIONAL OPERATING PROCEDURES ..................................................................................................... 21
Lamp Test......................................................................................................................................................... 21
History .............................................................................................................................................................. 21
FC2005 OPERATING INSTRUCTIONS ............................................................................................................. 22
Alarm Operation ............................................................................................................................................... 22
Authorized Personnel Only............................................................................................................................... 22
Trouble Operation ............................................................................................................................................ 22
Event Scrolling.................................................................................................................................................. 22
Fuse Replacement and Battery Maintenance .................................................................................................. 22
FSD901 OPERATING INSTRUCTIONS............................................................................................................. 23
Alarm Operation ............................................................................................................................................... 23
Authorized Personnel Only............................................................................................................................... 23
Trouble Operation ............................................................................................................................................ 23
Event Scrolling.................................................................................................................................................. 23
Normal Standby Condition ............................................................................................................................... 23
CONTROL PANEL INSTALLATION ...................................................................................................................... 24
PARTS SUPPLIED –FC2005 ............................................................................................................................ 24
1. FC2005 Enclosure Package......................................................................................................................... 24
2. FC2005 Main Board Package ...................................................................................................................... 24
3. FC2005 Configuration Kit Package .............................................................................................................. 25
4. FC2005 product documentation ................................................................................................................... 25
CONTROL PANEL LOCATION ......................................................................................................................... 26
INSTALLATION .................................................................................................................................................. 26
Enclosure Mounting.......................................................................................................................................... 26
Remove Knock-Outs ........................................................................................................................................ 29
Power Supply FP2011-U1 Mounting................................................................................................................ 30
Ground Wire Installation................................................................................................................................... 31
Battery Installation............................................................................................................................................ 32
Optional City Tie Mounting ............................................................................................................................... 33
Main Board Assembly Installation .................................................................................................................... 34
Earth Cable Installation .................................................................................................................................... 34
SYSTEM WIRING.................................................................................................................................................... 35
AC Connection ................................................................................................................................................. 35
Battery Connection........................................................................................................................................... 35
WIRING ............................................................................................................................................................... 35
Control Panel Wiring Overview ........................................................................................................................ 36
Wiring Entering Enclosure................................................................................................................................ 36
Install Wiring ..................................................................................................................................................... 36
Wiring Separation............................................................................................................................................. 37
Internal Structure.............................................................................................................................................. 37
Power Supply and Battery Wiring..................................................................................................................... 38
Status Relays ................................................................................................................................................... 39
Auxiliary Power Outputs Wiring........................................................................................................................ 39
NAC Wiring....................................................................................................................................................... 41
Serial Interface Circuit (UFP) ........................................................................................................................... 42
Serial Remote Device Wiring Overview ........................................................................................................... 44
SLC Addressable Device Circuit ...................................................................................................................... 45
SLC Addressable Device Wiring Diagrams...................................................................................................... 46
Optional City Tie/Leased Line .......................................................................................................................... 49
firealarmresources.com

iii
DACT Wiring..................................................................................................................................................... 49
PROGRAMMING THE CONTROL PANEL ............................................................................................................ 50
KEYPAD PROGRAMMING ................................................................................................................................ 50
PC PROGRAMMING .......................................................................................................................................... 50
PROGRAMMING SECURITY ............................................................................................................................. 50
MAINTENANCE ...................................................................................................................................................... 51
GENERAL ........................................................................................................................................................... 51
QUICK TEST....................................................................................................................................................... 52
APPENDIX-A: REFERENCE DATA ....................................................................................................................... 54
WIRE SELECTION GUIDES .............................................................................................................................. 54
Resistance of Solid Copper Wire ..................................................................................................................... 54
Addressable Device Circuit Wire Selection Guide ........................................................................................... 54
BATTERY SIZE CALCULATIONS..................................................................................................................... 55
System Current Draw Break down ................................................................................................................... 55
SLC Current Draw Break down ........................................................................................................................ 56
Battery Size ...................................................................................................................................................... 57
APPENDIX-B: COMPATIBLE DEVICES................................................................................................................ 58
DEVICES FOR ADDRESSABLE DEVICE CIRCUITS..................................................................................... 58
UFP devices ..................................................................................................................................................... 61
APPENDIX-C: TROUBLESHOOTING.................................................................................................................... 62
A. General ........................................................................................................................................................ 62
B. System Events ............................................................................................................................................. 63
APPENDIX-D: ALARM VERIFICATION................................................................................................................. 64
APPENDIX-E: APPLICATION SPECIFIC DETECTION ........................................................................................ 66
APPENDIX-F: TESTING/MAINTENANCE ............................................................................................................. 67
APPENDIX-G: LCD, CONTROLS AND INDICATORS .......................................................................................... 68
Panel in US....................................................................................................................................................... 68
Panel in Canada............................................................................................................................................... 68
Communication Port Connector ....................................................................................................................... 69
LEDS, Buzzer and Dedicated Push Buttons .................................................................................................... 69
LCD Display...................................................................................................................................................... 72
APPENDIX-H: OUTPUT FEATURES ..................................................................................................................... 74
Output Activation- and Deactivation- Delays.................................................................................................... 74
APPENDIX-I: PAS / PRE-SIGNAL ......................................................................................................................... 75
PAS .................................................................................................................................................................. 75
Pre-Signal......................................................................................................................................................... 76
APPENDIX-J: DACT INFORMATION OVERVIEW ................................................................................................... 77
DACT Compatible Alarm Communicators ...................................................................................................... 82
Wiring Diagram for DSC’s TL300CF and LE4010CF Connection, Including Trouble Reporting Route ... 83
LE4010-CF Configuration................................................................................................................................. 84
TL300-CF Configuration................................................................................................................................... 85
LE4010-CF & TL300-CF Power Supply Wiring Configuration ......................................................................... 86
APPENDIX-K: DRIFT COMPENSATION ............................................................................................................... 87
APPENDIX-L: RELEASING OPERATION ............................................................................................................. 88
APPENDIX-M: GLOSSARY.................................................................................................................................... 91
APPENDIX-N: PAD-4 WIRING INSTRUCTION ..................................................................................................... 94
firealarmresources.com

firealarmresources.com

1
INTRODUCTION
CONTROL PANEL LIMITATIONS
This control panel may not show an alarm condition without compatible initiating devices
(smoke detectors, etc.) and notification devices (horn, strobes, etc.) connected to it. Electrical
ratings of the initiation and notification appliances must be compatible with the electrical ratings
of the control panel and must be properly interconnected. The wiring used for interconnection
must be large enough to carry the total current for all appliances without excessive voltage
drop.
The control panel must be connected to a dedicated primary electrical source that has a high
degree of reliability and adequate capacity for this control panel. The only means of
disconnecting this power source shall be available only to authorized personnel and clearly
marked "Fire Alarm Circuit Control".
The control panel must also have connected to it a battery set (24V) that has enough capacity
to properly operate the system for the following conditions:
•24 hours standby and 5 minutes fire alarm in US
•24 hours standby and 4 minutes CO alarm and 12 hours extended CO alarm (at up to
60 s intervals) in US
•24 hours standby and 30 minutes alarm in Canada
These batteries do lose capacity with age. Batteries must be replaced when they fail to provide
the control panel with the required standby and alarm power or after 4 years, whichever
happens first. These batteries must be checked for performance at least two (2) times a year
or more often if local requirements dictate.
Even though this control panel was made to last for the expected life of the fire alarm system,
any part could fail at any time. Therefore, a regular test program should be followed and
documented to make sure that each part of the system is tested as in Chapter 7 of NFPA 72 or
more often if dictated by local code requirements. Malfunctioning units must be replaced or
repaired immediately by factory authorized service personnel.
Note:
•This control panel is designed to show an alarm condition when the initiating devices
connected to it detect specific conditions. These conditions may or may not represent a life-
threatening condition. Also, evacuation of a building or area unnecessarily may subject
individuals to an unnecessary hazard. Therefore, it is most important that the building owner,
manager, or representative promulgate, distribute, and/or post instructions describing steps
to be taken when the fire alarm control panel signals an alarm condition. These instructions
should be developed in cooperation and conformance with representatives of the local
authority having jurisdiction.
As a precautionary measure, it is strongly suggested that one of these steps should be to
notify the local fire department of an abnormal condition even where the DACT option (or
similar device) is included in the system.
firealarmresources.com

2
NOTICE TO USERS, INSTALLERS, AUTHORITIES HAVING JURISDICTION, AND OTHER INVOLVED PARTIES
This product incorporates field-programmable software. In order for the product to comply with the requirements in the
Standard for Control Units and Accessories for Fire Alarm Systems, UL 864, certain programming features or options must be
limited to specific values or not used at all as indicated below.
Program Feature or Option
Possible Settings
Settings Permitted in UL 864
Supervision/Trouble Resound
Not enabled
0-30 hours
Yes
1-24 hours
DACT Phone Line Settings
Disable 1 phone line connection
Enable both phone line connections
Manual Release delay
10-60 seconds
10-30 seconds
DACT supervision time
1 hour, 6 hours and 24 hours
6 hours or less
NOTICE TO USERS, INSTALLERS, AUTHORITIES HAVING JURISDICTION, AND OTHER INVOLVED PARTIES
This product incorporates field-programmable software. In order for the product to comply with the requirements in
CAN/ULCS527, Standard for Control Units for Fire Alarm Systems, certain programming features or options must be limited to
specific values or not used at all as indicated below.
Program Feature or Option
Possible Settings
Settings Permitted in CAN/
ULC-S527
Supervision/Trouble Resound
Not enabled
0-30 hours
Yes
1-24 hours
DACT Phone Line Settings
Disable 1 phone line connection
Enable both phone line connections
Manual Release delay
10-60 seconds
10-30 seconds
Panel Buzzer On
Check/Uncheck (default)
Uncheck
firealarmresources.com

3
PREFACE
Along with the use of this instruction manual, the appropriate following standards and the
manufacturer's instructions for initiating and notification devices should be used to install and
maintain a functioning fire alarm signaling system.
National Electrical Code, NFPA 70;
National Fire Alarm Code, NFPA 72;
Clean Agent Fire Extinguishing Systems, NFPA 2001.
For other standards that may apply contact the authority having jurisdiction.
For NFPA publications, contact:
National Fire Protection Association
Batterymarch Park
Quincy, Massachusetts 02269
FCC PART 68 WARNING
1. This equipment complies with Part 68 of the FCC rules and the requirements adopted by
the ACTA. On bottom of this equipment is a label that contains, among other information, a
product identifier of [US: 02XAL00BFCM901]. If requested, this number must be provided
to the telephone company.
2. If this equipment FC2005 causes harm to the telephone network, the telephone company
will notify you in advance that temporary discontinuance of service may be required. But if
advance notice isn’t practical, the telephone company will notify the customer as soon as
possible. Also, you will be advised of your right to file a complaint with the FCC if you
believe it is necessary.
3. The telephone company may make changes in this facilities, equipment, operations or
procedures that could affect the operation of the equipment. If this happens the telephone
company will provide advance notice in order for you to make necessary modification to
maintain uninterrupted service.
4. If you experience trouble with this equipment, you disconnect it from the network until the
problem has been corrected or until you are sure that the equipment is not malfunctioning.
5. Please follow instructions for repairing if any (e.g. battery replacement section); otherwise
do not alternate or repair any parts of device except specified.
6. Connection to party line service is subject to state tariffs. Contact the state public utility
commission public service commission or corporation commission for information.
7. If the telephone company requests information on what equipment is connected to their
lines, inform them of:
a) The telephone number that this unit is connected to,
b) The ringer equivalence number [0.0B]
c) The USOC jack required [RJ11C], and
firealarmresources.com

4
d) The FCC Registration Number [US:02XAL00BFCM901]
Items (b) and (d) are indicated on the label. The ringer equivalence number (REN) is used
to determine how many devices can be connected to your telephone line. In most areas,
the sum of the RENs of all devices on any one line should not exceed five (5.0). If too
many devices are attached, they may not ring properly.
INDUSTRY CANADA STATEMENT
Industry Canada Equipment Standard for Digital Equipment (ICES) –Canada
CAN ICES-3 (A) / NMB-3 (A)
Industry Canada (IC CS) –Canada
NOTICE: This product meets the applicable Industry Canada terminal technical
specifications. This is confirmed by the registration number. The abbreviation, IC,
before the registration number signifies that registration was performed based on a
Declaration of Conformity indicating that Industry Canada technical specifications
were met. It does not guarantee the equipment will operate to the user’s satisfaction.
AVIS: Ce produit est conforme aux spécifications techniques terminales applicables
d’Industrie Canada. Cette conformitéest confirmée par le numéro d’enregistrement.
Le sigle IC, placédevant le numéro d’enregistrement, signifie que l’enregistrement
s’est effectuéconformément àune déclaration de conformitéet indique quelles
spécifications techniques d’Industrie Canada ont étérespectées. Il ne garantit pas
que le matériel fonctionnera àla satisfaction de l’utilisateur.
NOTICE: The Ringer Equivalence Number (REN) for this terminal equipment is
0.1. The REN assigned to each terminal equipment provides an indication of the
maximum number of terminals allowed to be connected to a telephone interface.
The termination on an interface may consist of any combination of devices subject
only to the requirement that the sum of the Ringer Equivalence Numbers of all the
devices does not exceed five.
AVIS: L’indice d’équivalence de la sonnerie (IES) du présent matériel est de 0.1.
L’IES assignéàchaque dispositif terminal indique le nombre maximal de terminaux
qui peuvent être reliés àune interface téléphonique. La terminaison d’une interface
peut consister en une combinaison quelconque de dispositifs, àla seule condition
que la somme d’indices d’équivalence de la sonnerie de tous les dispositifs
n’excède pas 5.
SERVICE REQUIREMENTS
In the event of equipment malfunction, all repairs should be performed by our Company or an
authorized agent. It is the responsibility of users requiring service to report the need for service
to our Company or to one of our authorized agents. Service can be facilitated through our
office at:
SIEMENS INDUSTRY, INC. –SMART INFRASTRUCTURE DIVISION –FIRE SAFETY
8 FERNWOOD RD., FLORHAM PARK, NJ 07932
[phone]
firealarmresources.com

5
DESCRIPTIONS
FC2005 SYSTEM DESCRIPTION
The FC2005 is a compact but powerful standalone fire alarm control panel. It features
advanced addressable fire detection, keypad and offline programming, notification circuits, a
160 by 64 dots LCD display and event history retention capability. Its typical configuration
includes a power supply, a signaling addressable device circuit, two notification appliance
circuits (NAC), Digital Alarm Communication Transmitter (DACT), four system status relays
and a USB programming port.
All the components of the FC2005 control panel are mounted in an 18.1" x 16.5" enclosure.
The FC2005 has only one electronic main board which integrates most functional parts
together (the CPU board is mounted to main board before delivery), including DACT, System
Display, signaling line circuit, NAC, serial interface circuits, system status relays, programming
port and battery charging circuit. The main board is mounted on the supporting frame, and it
provides the connections for external field wiring. An optional city tie module can be mounted
on the backside of the main board. The power supply is located under the main board and
supporting frame.
The FC2005 supports English, French and Spanish operation menu for user selection. When
the tool language changes from English to French or Spanish, it is recommended, but not
necessary, to create a new French or Spanish configuration and upload it to the panel.
The FC2005 features one LCD screen which is used to indicate the specific indications for
system events while LEDs indicate general panel status.
FC2005 supports surface mounting and semi-flush mounting. Semi-flush mounting kits are
available for the enclosure.
System status information is provided by a 160 by 64 dots (7 by 26 characters), backlit LCD
and by discrete LED indicators for major control panel functions.
The LCD is used to display event data, including alarms and troubles conditions, zone or
device custom identification of messages, and a log of the system event history. A back light is
included in the display to assure visibility in low light. To conserve power, the back light is only
activated during a reported event or on operation of a display control button.
Individual LEDs on the panel are provided to indicate:
in US: ALARM, Power, Silenced, Trouble, Supervisory, Ground Fault and Audibles On;
in Canada: ALARM, Power On, Signal Silence, Trouble, Supervisory, Ground Fault and Alarm
Signal.
Direct push-button controls are provided for:
in US: Reset, Acknowledge/Buzzer Silence, Silence/Unsilence, Programmable, MENU, OK, C
(cancel) and a four-way button for menu navigation;
in Canada: Reset, Acknowledge/Buzzer Silence, Signal Silence/Unsilence, Alarm Signal
Activation, MENU, OK, C (cancel) and a four-way button for menu navigation.
firealarmresources.com

6
Power Supply
A 26 V (nominal) power supply provides all operating power to the control panel for both
standby and alarm conditions. Batteries no smaller than 12 AH and no greater than 19 AH for
US, and no smaller than 12 AH for Canada must be used to meet code requirements. Sealed
lead-acid batteries within this range have sufficient charging capability to provide 24 hours of
normal standby operation plus 5 minutes of alarm operation for US installations and 30
minutes of alarm operation for Canadian installations. The battery will be automatically
disconnected at low battery voltage to prevent deep discharge and battery damage.
Signaling Line Circuit (SLC)
The FC2005 fire alarm control panel provides a signaling line circuit with the capacity of 50
addressable devices.
Notification Appliance Circuits
The FC2005 control panel has two independent notification appliance circuit (NACs). It can be
configured as two Class B NACs or one Class A NAC. Each circuit can be selected to give
continuous output or one of five sounding patterns. There is also a system coder capable of
zone operation. All of the NACs are power limited and support synchronization of listed
devices using the Siemens sync protocol.
Serial Interface Circuit (UFP)
The FC2005 control panel has a Serial Interface Circuit that can connect up to 8 devices, e.g.:
remote LCD annunciators, LED driver/tabular annunciator or remote printer module.
Status Relays
Four relays with dry contacts are provided. Three relays are dedicated to alarm, supervisory,
and trouble conditions on the panel. The remaining relay is programmable. The relay contacts
are Form C and are rated for 2 A @ 30 VDC resistive.
Programming Port
A USB standard type B plug is provided for temporary connection to a computer for panel
programming and firmware download when using the FXS901-U2 System Configuration Tool.
DACT
The Digital Alarm Communication Transmitter (DACT) is integrated on the FC2005 main board
and it will send control panel status information to a central or remote receiving station through
the Public Switched Telephone Network (PSTN).
Programmable Key
Press the programmable key to execute the user defined and configured functions. Supported
functions are: DACT bypass, Addressable device bypass, NAC bypass, Fire drill, Manual
evacuation, Co test and Lamp test.
OPTIONAL MODULES
City Tie Module (FCI2020-U1)
The city tie module provides local energy and polarity reversal connections. The polarity
reversal connections provide a trouble circuit and an alarm circuit with optional trouble output.
The city tie board mounts onto the main board.
firealarmresources.com

7
Battery Sets
The FC2005 control panel can only use rechargeable sealed lead-acid batteries for back-up
power. The battery charging capacity is 12 Ah for Canada and 12 - 18 Ah for US.
Remote Printer Module (FCA2018-U1)
The Model FCA2018-U1 is a Universal Fire Protocol module that interfaces to a parallel
printer. It must be located where there is access to the fire system’s serial interface circuit
network. Up to 2 FCA2018-U1 may be addressed by the communication circuit.
The Model FCA2018-U1 is required whenever a logging printer is needed. It translates the
serial interface circuit messages into a standard printer interface. When the PAL-1 is used with
the RPM (FCA2018-U1), the RPM supervises the printer for on/off line, power on, paper out,
paper jam, and wiring fault conditions, as required by Underwriters Laboratories for NFPA 72
proprietary systems.
Note: For printer connection, wiring between the RPM and printer must be in conduit
within 6 feet and in the same room as the panel.
AUXILIARY MODULES
Serial LCD Annunciators
The FSD901 Serial LCD Annunciator consists of a backlit 160 by 64 dot (7 by 26 characters)
LCD display, acknowledge, silence, unsilence, and reset buttons, a four-way button for event
navigation, seven system status LED indicators and a security key switch. To prevent
unauthorized system operation, the control buttons are only enabled when the key switch is
activated. The display and controls of the FSD901 are the same as those on the front of the
control panel. The backlight activates only upon active button press or when events are
present in the system to conserve power.
FT Series LED Driver/Annunciators
The FT Series LED driver/annunciator includes five options:
•FT2007-U1
•FT2008-U1 and FT2008-R1
•FT2009-U1 and FT2009-R1
•FT2018-U1 and FT2018-R1
•FT2019-U1 and FT2019-R1
The FT2007-U1 is a LED driver for use in graphic annunciators.
firealarmresources.com

8
The information of the rest annunciators is displayed in the below table:
Product
Zones
System status LEDs
Buttons
FT2008-U1/R1
16
7
Audibles On/Silenced
Acknowledge
Signal Reset
Lamp Test
FT2009-U1/R1
32
7
Audibles On/Silenced
Acknowledge
Signal Reset
Lamp Test
FT2018-U1/R1
16
6
N/A
FT2019-U1/R1
32
6
N/A
Up to 8 annunciators may be addressed by the communication circuit. Each annunciator
requires connection to the Serial Interface circuit on the mainboard.
For installation in Canada, the FT2018-U1/R1 or FT2019-U1/R1, only one can be and
must be installed adjacent to the panel and interconnection must be in metallic conduit.
For installation in Canada, a separate ULC listed power supply (PAD-4 or PAD-5) must
be installed adjacent to the FC2005 or FC901 panel to power the FT2018-U1/R1 or
FT2019-U1/R1 annunciator. See Appendix N for PAD-4 Wiring Instruction.
When configuring the FT2018-U1/R1 or FT2019-U1/R1 for Canadian applications, it must
be programmed as a local device so that lamp test can be initiated from panel.
When annunciator FT2018-U1/R1 or FT2019-U1/R1 is connected to a Canadian panel,
the buzzer on the panel must be disabled (panel buzzer ON must be unchecked)
Battery Housing (FH2072-UA)
FH2072-UA is used to install batteries separately. Supported batteries are: 12 Ah for Canada
and 12 - 18 Ah for US.
Universal Enclosure for Annunciators (FTH2073-UA)
FTH2073-UA is used to install annunciators.
Supported annunciators are: FSD901, FT2008, FT2009, FT2018 and FT2019.
firealarmresources.com

9
SLC ADDRESSABLE DEVICES
Smoke Detector
The control panel processor sends the sensitivity settings to the detectors and polls the
detectors for their status. The detector determines normal, trouble and alarm conditions and
communicates the conditions to the control panel.
Variable Thresholds - The detectors can be set to operate in various pre-programmed profiles,
depending on the environment where the detectors are used.
Operator Alerts - The control panel can indicate a trouble event automatically on the
occurrence of a number of conditions of the detector. The supported conditions include:
◼Channel Active
◼Un-configured Device
◼Device Type Mismatch
◼Device Communication Trouble
◼Address Invalid
◼Address Unspecified
◼Multiple Device Response
◼Parameter Error
◼Device Type Unknown
◼Fatal Fault
◼General Trouble
◼Dirty
◼Replace
Heat Detectors
Addressable heat sensing detectors may be intermixed on the circuit for locations where heat
sensing may be the most effective detection method. The heat detectors may be programmed
for rate of rise operation or fixed temperature.
Addressable Modules (Monitor and Control)
In addition to detectors, the circuit can communicate with addressable monitor and control
modules. Monitor modules allow remote contact closure initiating devices to generate event
conditions on the system. Control modules provide the system remote relay outputs or
notification appliance circuits
Manual Stations
Addressable manual stations may be intermixed on the circuit with proper response
programmed into the control panel.
Sounder Base
The ABHW-4B and ABHW-4S are the intelligent supervised audible based which provides 6
selectable tone patterns, 2 volume levels and 2 different power types for alarm.
The 6 tone patterns supported by the ABHW-4B and ABHW-4S are: Steady, Temporal 3,
Temporal 4, Temporal 4 low power, March time 120 and Canadian March time 30.
When the audible base ABHW-4B and ABHW-4S is used with Global ASA/FD182UL detectors,
it can be programmed to 2 output channels, and up to 6 tone patterns can be selected using
firealarmresources.com

10
the system configuration tool. When users need to disable the audible base, they will need to
select the “disable audible base” option.
When the audible base ABHW-4B and ABHW-4S is used with H series detectors, it can be
programmed to 1 output channel, and only 2 tone patterns (steady, temporal 3) can be
selected using the system configuration tool. When users need to disable the audible base,
they will need to select the “disable outputs” option.
When users need to disable the ABHW-4B and ABHW-4S audible bases connected to
the entire loop consisting of H series and Global ASA/FD182 detectors, they will need to
select both the “disable outputs” and “disable audible base” options.
There are two methods for powering the audible base during alarm. They are “Loop powered”
and “External powered” which can be configured using the system configuration tool. The
ABHW-4B can be powered by loop power and external power, the ABHW-4S can only be
powered by external power.
For additional information please refer to installation manual of ABHW-4B (A6V10405587) and
ABHW-4S (A6V10405588).
When using external power source, the power supply unit must be UL Listed for fire use
only, Power Limited and rated 19-28 VDC.
Audible signals are synchronized on zone basis.
Use sounder base in addition to panel NAC or PAD5 NAC when multiple alarm tones are
needed in one zone.
Programming SLC Devices
SLC devices can be assigned their electronic address and be tested by using the DPU Device
Programmer/ Loop Tester.
PAD-5
The Model PAD-5 Main board is an intelligent notification and auxiliary power expander that
provides up to 9 A @ 24 VDC (with FP2012-U1) or 6 A @ 24 VDC (with FP2011-U1).
The purpose of the PAD-5 main board is to provide remote power for notification devices, and
accessory modules, such as door holders.
A maximum of 7 PAD-5s, including expander board, can be connected to FC2005 at the same
time.
Up to 8 Class B, or 4 Class A NACs are supported by one PAD-5 device.
Optional modules
CDC for conventional detection circuit
CLSA for NAC circuits and releasing capability.
If there is a short on the activated PAD-5 releasing circuit, after the short is removed,
users need to restart the control panel to reactivate the releasing circuit. If the PAD-5
releasing circuit is not activated when the short happens, then there's no need to restart
the control panel to reactivate the releasing circuit.
firealarmresources.com

11
EVENT HISTORY
The control panel includes a non-volatile memory recording 1000 system events. Identified
alarm, trouble, supervisory, status and other significant events will be recorded along with the
date and time of occurrence. The history event log can be viewed at the main system display
by operating menu controls from the panel. The history event log can also be transferred from
the panel to a computer using the FXS901-U2 system configuration tool.
Events recorded in the history are:
◼Alarm, trouble, supervisory and status conditions
◼Signal silence/un-silence (Manual)
◼System reset
◼User level login/logout
◼Start and stop of quick test
◼Expiration of quick test Timer
◼Trouble/supervisory reminder
◼Acknowledgment
◼Trouble/supervisory restored to normal
firealarmresources.com

12
GENERAL DESIGN FEATURES
Environmental
The FC2005 panels and subassemblies are suitable for use in a dry, indoor or protected
location.
Power Limiting
The AC power connection, battery wiring and four system status relays are not power limited.
All other circuits leaving the control panel meet the requirements for power limited circuits
when installed in accordance with the National Electrical Code and local requirements.
Ground Fault Detection
The control panel provides system ground fault detection. Main board ground fault event is
annunciated as a trouble condition on the system. In addition, the addressable circuit and
serial interface circuit have their own ground detection circuitry and indicator.
System- NAC (+) Ground Fault Threshold <20 kΩ
System- NAC (-) Ground Fault Threshold <20 kΩ
System- Auxiliary Power (+) Ground Fault Threshold <5 kΩ
System- Auxiliary Power (-) Ground Fault Threshold <5 kΩ
System- City Tie (+) Ground Fault Threshold <5 kΩ
System- City Tie (-) Ground Fault Threshold <5 kΩ
SLC grounding detection threshold
SLC (+) –Ground <5 kΩ
SLC (-) –Ground <5 kΩ
NAC Operation
The notification appliance circuits are controlled by the system microprocessor in accordance
with the site-specific system configuration.
The notification appliance circuits can operate audible and visual notification appliances. Each
NAC can provide any of five software-generated codes or continuous operation to audible
notification appliances. Also, each NAC supports synchronization of visual notification
appliances.
Silence Inhibit - The control panel may be programmed to inhibit silence for up to four minutes
from the first alarm.
All of the NACs are power limited.
If PAD-5 is added to the system, the panel NAC and PAD-5 NAC will be
synchronized when the panel NAC is set as source and PAD-5 NAC is set as
follower.
Security Features
Multi-level password protection of programming functions prevents unauthorized configuration
changes.
firealarmresources.com

13
Device type supervision: If the device type identifier reported by an addressable detector or
module does not agree with the configuration, the system reports a trouble condition.
Device address supervision: The system checks that all configured devices on the addressable
device circuit respond to an address poll. The system reports a trouble condition if the
following conditions are detected:
◼Configured device is missing.
◼Unconfigured device is installed.
◼Two devices are programmed with the same address.
◼Signaling line circuit experiences a wire-to-wire short.
◼Signaling line circuit experiences an earth ground condition.
REGULATORY STANDARDS
The FC2005 control panel meets the requirements of industry and government regulatory
agencies as noted.
Underwriters Laboratories
The FC2005 control panel is listed under UL 864 (Tenth Edition) and to be installed in
Accordance with the applicable National Fire Protection Association Installation Standard for
NFPA 72 and NFPA 2001.
Underwriters Laboratories of Canada
The FC2005 control panel is listed under ULC-S527-11 (Third Edition) Amendment 1, and to
be installed in accordance with CSA C22.1-06, Canadian Electrical Code, CAN/ULC-S524,
Installation of Fire Alarm Systems, CAN/ULC-S536, Inspection and Testing of Fire Alarm
Systems.
Federal Communications Commission
The DACT meets the Class A requirements of the Code of Federal Regulations (CFR 47), Part
15 for electromagnetic field emissions. The DACT also meets the requirements of the Code of
Federal Regulations (CFR 47), Part 68, for connection of equipment to the public switched
telephone network.
firealarmresources.com

14
GENERAL SPECIFICATIONS
Operating specifications for the FC2005 are as follows:
Environmental
Operating temperature - 32 –120 F (0 –49 C)
Relative humidity - Up to 93% @ 90 F (32 C)
To be installed in an indoor dry protected environment only
Primary Power Supply (FP2011-U1)
Input: 120 VAC, 60 Hz or 240 VAC, 50 Hz
@ 2.0 A max.
Supervised
Output: 26 VDC @ 6.5 A max.
Max current: 6.5 A (2 hours max.)
Filtered and Regulated
Secondary Power Supply
24 V lead-acid battery set
Max. charged voltage: 27.8 VDC
Automatic low battery disconnect voltage: 19.20.1 VDC
Max. charge current: 0.45 A
Battery capacity:12 Ah (for US and Canada) internally to 18 Ah (for US only) with separate
enclosure FH2072-UA
Supervised
Auxiliary Power Outputs
Non-resettable power output
Power limited
Current: 0.75 A
Voltage: 19 to 28 VDC
Ripple: 0.1 VAC
Special Application
Resettable power output
Power limited
Current: 0.75 A
Voltage: 19 to 28 VDC
Ripple: 0.1 VAC
Special Application
firealarmresources.com

15
Status Relays
Non-power limited
One programmable relay
Three non-programmable relays: Trouble, Supervisory, Alarm
Contact rating: 2 A, 30 VDC maximum
Form C contact
Notification Appliance Circuits
Power limited
Supervised
Current Draw
Maximum Line Resistance
2.5 A
3.2 Ω
2.0 A
4.0 Ω
1.5 A
5.3 Ω
1.0 A
8.0 Ω
0.5 A
16.0 Ω
Alarm voltage: 16 to 32 VDC
Maximum ripple: 0.1 VAC
Used for special application only
Two Class B or one Class A
Total Max. Current: 2.5 A
Serial Interface Circuit (UFP)
Power limited
Supervised
Maximum wire loop resistance: 50 Ω total
Physical layer: RS485
SLC Addressable Device Circuits
Max. 32 VDC
Power limited
Supervised
Max. current: 0.07 A (RMS)
Maximum wire loop resistance: 50 Ω
Two Class B (DCLB) or one Class A (DCLA) circuit or one Class X (DCLC) circuit
firealarmresources.com
