Preface
Purpose of the manual
This document contains reference information for engineering and operation of the
Advanced Process Functions (APF) together withSIMATIC BATCH.
You can find additional information on APF in the following manuals:
● Advanced Process Functions (APF) Function Manual
● Advanced Process Functions Installation and Configuration
● Advanced Process Functions Engineering Manual
● Advanced Process Functions Operating Manual
Also refer to the SIMATIC BATCHmanuals.
Core content
The Advanced Process Functions (APF) provide functions for material master data
management. Integration with SIMATIC BATCH allows the automatic synchronization
and shared use of materials in APF and SIMATIC BATCH.
The APFs provide a dialogs that allows easy recording of data for orders and batches. Data
are transferred to SIMATIC BATCH and the batches are created there. All other steps are
carried out in the SIMATIC BATCH.
APF provides a freely programmable interface in the form of WinCC global scripts which can
be used for automatic creation, releasing and starting of batches in SIMATIC BATCH . All
relevant batch header data (basic recipe or formula, order or batch name, batch size, start
mode and start time, unit assignment) as well as the batch parameters (process parameters,
input material and output material) are transferred in the process.
The following core issues are covered in this document:
● Amendment to the Installation / Configuration Manual:
– Installation of the APF for shared operation with SIMATIC BATCH
● Amendment to the Engineering Manual:
– Activation of the APF integration with SIMATIC BATCH
– Configuration of the "Order Creation" dialog
– Runtime-Interface and WinCC Script for automatically creating, releasing and starting
of batches in SIMATIC BATCH
Advanced Process Functions SIMATIC BATCH Integration
Function Manual, 07/2016, A5E38719543-AA 3

● Amendment to the Operating Manual:
– Synchronization of the material master data between APF and SIMATIC BATCH
– "Order Creation" dialog
● Amendment to the Function Manual:
– "Order Creation" interface
Validity
This documentation is valid for V2.1 of the APF software package.
Preface
Advanced Process Functions SIMATIC BATCH Integration
4Function Manual, 07/2016, A5E38719543-AA

Table of contents
Preface.........................................................................................................................................................3
1Security information......................................................................................................................................7
2Amendment to the Installation and Configuration Manual............................................................................9
3Amendment on Engineering Manual..........................................................................................................11
3.1 Integration..............................................................................................................................12
3.2 Configuration of the "Order Creation" dialog..........................................................................13
3.3 Runtime interface to SIMATIC BATCH..................................................................................19
4 Amendment to the Operating Manual.........................................................................................................25
4.1 Material management ...........................................................................................................26
4.2 "Order Creation" dialog..........................................................................................................29
5 Amendment to the Function Manual...........................................................................................................33
5.1 "Order Creation" interface......................................................................................................33
5.2 Formula Split Mode................................................................................................................38
Advanced Process Functions SIMATIC BATCH Integration
Function Manual, 07/2016, A5E38719543-AA 5

Table of contents
Advanced Process Functions SIMATIC BATCH Integration
6Function Manual, 07/2016, A5E38719543-AA

Security information 1
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens’ products and solutions only form one element of such a concept.
Customer is responsible to prevent unauthorized access to its plants, systems, machines and
networks. Systems, machines and components should only be connected to the enterprise
network or the internet if and to the extent necessary and with appropriate security measures
(e.g. use of firewalls and network segmentation) in place.
Additionally, Siemens’ guidance on appropriate security measures should be taken into
account. For more information about industrial security, please visit:
http://www.siemens.com/industrialsecurity
Siemens’ products and solutions undergo continuous development to make them more secure.
Siemens strongly recommends to apply product updates as soon as available and to always
use the latest product versions. Use of product versions that are no longer supported, and
failure to apply latest updates may increase customer’s exposure to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed under:
http://www.siemens.com/industrialsecurity
Advanced Process Functions SIMATIC BATCH Integration
Function Manual, 07/2016, A5E38719543-AA 7

Security information
Advanced Process Functions SIMATIC BATCH Integration
8Function Manual, 07/2016, A5E38719543-AA

Amendment to the Installation and Configuration
Manual 2
Please read the "Advanced Process Functions Installation and Configuration" manual before
you read this section. The following only describes relevant changes that result when you use
APF together with SIMATIC BATCH.
Server
The BATCH server must be installed on the APF OS server.
OS setup on all clients
When you use SIMATIC BATCH integration, the APF OS setup must be installed on all APF
clients. (It is the same setup as for the OS servers. No additional APF licenses are required
for the APF clients.)
For installation and license terms of SIMATIC BATCH refer to the corresponding SIMATIC
BATCH manuals.
Note
Ensure that the APF OS setup is performed on the client when you operate APF with BATCH.
Otherwise, for example, the APF Material Editor may be affected due to lack of communication
partners.
User rights
Please assign at least the "Process controlling" rights for the "Order Creation" dialog.
Advanced Process Functions SIMATIC BATCH Integration
Function Manual, 07/2016, A5E38719543-AA 9

Amendment to the Installation and Configuration Manual
Advanced Process Functions SIMATIC BATCH Integration
10 Function Manual, 07/2016, A5E38719543-AA

Amendment on Engineering Manual 3
Please read the "Advanced Process Functions Engineering Manual" before you read this
section. The following only describes the relevant changes that result when you use APF
together with SIMATIC BATCH .
Advanced Process Functions SIMATIC BATCH Integration
Function Manual, 07/2016, A5E38719543-AA 11

3.1 Integration
The integration of APF with SIMATIC BATCH is configured using the "Einstellungen –
Allgemein" / "Settings - General" dialog of the APF engineering tool:
The release of APF integration using SIMATIC BATCH occurs through the option box "Use
SIMATIC BATCH" / "SIMATIC BATCH will be used".
This option box can only be activated if a SIMATIC BATCHprocess cell (installation) is
configured in a PCS 7 project.
The name of the process cell (plant) in the Plant Hierarchy (PH) is specified with the PCS 7
project configuration where it is automatically determined. If you change the name of the
process cell in the PCS 7 project, you must update the APF Engineering settings in the
"Settings - General" dialog.
Run the APF Integrator once you have applied the settings.
Note
Ensure that the BATCH server is started when you operate APF with BATCH. Otherwise, for
example, the APF Material Editor may be affected due to lack of communication partners.
Amendment on Engineering Manual
3.1 Integration
Advanced Process Functions SIMATIC BATCH Integration
12 Function Manual, 07/2016, A5E38719543-AA

3.2 Configuration of the "Order Creation" dialog
The "Order Creation" dialog offers numerous possible settings to tailor the dialog to customer-
specific requirements. These settings are specified during the engineering phase directly at
the dialog control @FB_OrderCreation.pdl using WinCC Graphics Designer or through a user-
specific script.
Note
If configuration changes are required, it is recommended to make a copy of
@FB_OrderCreation.pdl.
Possible settings are described below:
Control Settings (object properties)
Name Description
FormulaCategoryMode Options:
● enabled:
The operator must select a formula category before he/she can select the
relevant formula.
● disabled (default):
The operator can select the recipe or formula without previously selecting a
formula category.
FormulaCategoryOperation Options:
● enabled (default):
The operator can select a formula category.
● disabled:
The operator is not authorized to select a formula category.
FormulaCategoryFilter ● Filter for selectable formula category names. Formula categories are
displayed when their name starts with FormulaCategoryFilter.
● No default
● Can be set in Graphics Designer or in script.
● If only one formula category matches the filter, this will be selected
automatically.
RecipeOperation Options:
● enabled (default):
The operator can select a formula / recipe.
● disabled:
The operator is not authorized to select a formula / recipe.
Amendment on Engineering Manual
3.2 Configuration of the "Order Creation" dialog
Advanced Process Functions SIMATIC BATCH Integration
Function Manual, 07/2016, A5E38719543-AA 13

Name Description
RecipeFilter (In/Out) ● Filter for selectable formula or recipe names Formulas or recipes are displayed
when their name starts with RecipeFilter.
● No default
● Can be set in Graphics Designer or in script.
● If only one formula or recipe matches the filter, this will be selected
automatically.
OrderCategoryMode Options:
● SelectExisting (select existing)
● UserInput (manual input)
● FormulaCategoryName (formula category name)
● FormulaOrRecipeName (formula / recipe name) (default)
● ProductCode (product code)
OrderCategoryOperation Valid when OrderCatMode = SelectExisting or manual input
Options:
● enabled (default):
The operator can select/edit the order category.
● disabled:
The operator is not authorized to select/edit the order category.
OrderCategoryFilter ● Valid when OrderCatMode = SelectExisting
● Filter for selectable order category names. Order categories are displayed
when their name starts with OrderCategoryFilter.
● No default
● Can be set in Graphics Designer or in script.
● If only one order category matches the filter, this will be selected automatically.
OrderCategoryPreselection ● Valid when OrderCatMode = manual input
● Start value of OrderCategory input field
● No default
● Can be set in Graphics Designer or in script.
OrderNameCalculationMode Options:
● UserInput (manual input)
● DateTimeAndUserInput (date + time + manual input)
● ProductCodeAndUserInput (product code + manual input)
● ProductCodeAndDateTime (product code + date + time)
OrderNameOperation Options:
● enabled (default):
The operator can enter or overwrite order names.
● disabled:
The operator is not authorized to enter or overwrite order names.
OrderNamePreselection ● Valid when OrderNameMode includes manual input
● Start value of the manual input part
● No default
● Can be set in Graphics Designer or in script.
Amendment on Engineering Manual
3.2 Configuration of the "Order Creation" dialog
Advanced Process Functions SIMATIC BATCH Integration
14 Function Manual, 07/2016, A5E38719543-AA

Name Description
OrderSizePreselection ● Start value of OrderSize field
● Default is 0
● Can be set in Graphics Designer or in script.
OrderSizeOperation Options:
● enabled (default):
The operator can select the order size.
● disabled:
The operator is not authorized to select the order size. The order size is
calculated using the batch sizes.
OrderSplitModePreselection Start value of selection of order split mode.
Options:
● Evenly (default)
● MaxSizeWithRemain (maximum size + remainder) (default)
● MaxSizeWithOverProd (maximum size rounded up)
● MaxSizeWithUnderProd (maximum size rounded down)
More information on the calculation principles for this mode can be found in
Amendment to Function Manual under Formula Split Mode.
Can be set in Graphics Designer or in script.
OrderSplitModeOperation Options:
● enabled (default):
The operator can select the order split mode.
● disabled:
The operator is not authorized to select the order split mode.
BatchLimitsOperation Options:
● enabled:
The operator can overwrite the minimum and maximum batch size.
● disabled:
The operator is not authorized to overwrite minimum and maximum batch
sizes.
MinBatchSizePreselection ● Start value of the Minimum Batch Size field
● Default is 0
● Can be set in Graphics Designer or in script.
MaxBatchSizePreselection ● Start value of the Maximum Batch Size field
● Default is 0
● Can be set in Graphics Designer or in script.
Amendment on Engineering Manual
3.2 Configuration of the "Order Creation" dialog
Advanced Process Functions SIMATIC BATCH Integration
Function Manual, 07/2016, A5E38719543-AA 15

Name Description
BatchesSizeOperation Options:
● enabled:
The operator can change the batch, including the remainder batch size.
● disabled:
The operator is not authorized to change the batch, including the remainder
batch size. These are then calculated automatically.
Note:
● If BatchLimitsOperation is enabled, the recipe limits are checked against the
Min and MaxSizePreselection setting of the Order Creation dialog when a
recipe is selected for the first time. When a new recipe is selected, the recipe
limits are checked against the entries in the Order Creation dialog.
● If BatchLimitsOperation is disabled, the recipe limits are checked against the
Min and MaxSizePreselection setting of the Order Creation dialog each time
a recipe is selected.
NumberBatchesOperation Options:
● enabled:
The operator can change the number of batches
● disabled (default):The operator is not authorized to change the number of
batches. These are then calculated automatically.
OrderCreationModeOperation Options:
● enabled (default):
The operator can select the order creation mode.
● disabled:
The operator is not authorized to select the order creation mode.
OrderCreationModePreselection Options:
● Created (all batches are created)
● Released (all batches are created and released)
● FirstStarted (all batches are created, released and the first batch started)
● AllStarted (all batches are created, released and started) (default)
● FirstStartedAtTime (all batches are created, released and the first batch
started in a time-controlled manner)
● AllStartedAtTime (all batches are created, released and started in a time-
controlled manner)
● StartedChained (all batches are created, released and started in a chain)
Can be set in Graphics Designer or in script.
OrderStartTimeOperation Options:
● enabled (default):
The operator can select the start time of the order.
● disabled:
The operator is not authorized to select the start time of the order.
OrderStartTimePreselection Start time of the order (the first batch of the order)
Can be set using script.
Amendment on Engineering Manual
3.2 Configuration of the "Order Creation" dialog
Advanced Process Functions SIMATIC BATCH Integration
16 Function Manual, 07/2016, A5E38719543-AA

Name Description
BatchesWaitingTimeOperation Options:
● enabled (default):
The operator can select the waiting time of the batch.
● disabled:
The operator is not authorized to select the waiting time of the batch.
BatchesWaitingTimePreselection Waiting time after which the next batch is started.
Can be set in Graphics Designer or in script.
BatchListNameOperation Options:
● enabled (default):
The operator can overwrite the individual batch names.
● disabled:
The operator is not authorized to overwrite the individual batch names.
BatchListSizeOperation Options:
● enabled (default):
The operator can overwrite the individual batch sizes.
● disabled:
The operator is not authorized to overwrite the individual batch sizes.
BatchListCreationModeOperation Options:
● enabled (default):
The operator can overwrite the individual creation modes.
● disabled:
The operator is not authorized to overwrite the individual batch creation modes.
BatchListStartTimeOperation Options:
● enabled (default):
The operator can overwrite the individual batch start times.
● disabled:
The operator is not authorized to overwrite the individual batch start times.
BatchListCustomColumn1Type Type of the first user-defined column in the batch list
Options:
● none (default ): No user-defined column is displayed.
● Integer: One column with numerical content is displayed.
● Real: One column with floating-point content is displayed.
● String: One column with text content is displayed.
● Enumeration: One column with a combined box as content is displayed.
→ Not supported at present
BatchListCustomColumn1Caption Valid when BatchListCustomColumn1Type is not "none"
Heading of column, if visible (default: Custom1)
BatchListCustomColumn1Operation Options:
● enabled (default):
The operator can change the values in the use-defined column.
● disabled:
The operator is not authorized to change the values in the user-defined column.
BatchListCustomColumn1Min Valid when BatchListCustomColumn1Type = Integer or Real
Minimum input value for the user-defined column (default: 0)
Amendment on Engineering Manual
3.2 Configuration of the "Order Creation" dialog
Advanced Process Functions SIMATIC BATCH Integration
Function Manual, 07/2016, A5E38719543-AA 17

Name Description
BatchListCustomColumn1Max Valid when BatchListCustomColumn1Type = Integer or Real
Maximum input value for the user-defined column (default: 0)
BatchListCustomColumn1MaxChar Valid when BatchListCustomColumn1Type = String
Maximum number of characters for entry in the user-defined column (default: 0)
BatchListCustomColumn1Enumeration
→ Not supported at present
Valid when BatchListCustomColumn1Type = Enumeration
List of alternatives separated by | which are to be shown in the combined box of
the user-defined column.
The default for new batches can be overwritten via SelectedBatchCustomCol‐
umn1Enumeration.
BatchListCustomColumn2Type Type of the second user-defined column in the batch list
Options:
● none (default ): No user-defined column is displayed.
● Integer: One column with numerical content is displayed.
● Real: One column with floating-point content is displayed.
● String: One column with text content is displayed.
● Enumeration: One column with a combined box as content is displayed.
→ Not supported at present
BatchListCustomColumn2Caption Valid when BatchListCustomColumn2Type is not "none"
Heading of column, if visible (default: Custom2)
BatchListCustomColumn2Operation Options:
● enabled (default):
The operator can change the values in the use-defined column.
● disabled:
The operator is not authorized to change the values in the user-defined column.
BatchListCustomColumn2Min Valid when BatchListCustomColumn2Type = Integer or Real
Minimum input value for the user-defined column (default: 0)
BatchListCustomColumn2Max Valid when BatchListCustomColumn2Type = Integer or Real
Maximum input value for the user-defined column (default: 0)
BatchListCustomColumn2MaxChar Valid when BatchListCustomColumn2Type = String
Maximum number of characters for entry in the user-defined column (default: 0)
BatchListCustomColumn2Enumeration
→ Not supported at present
Valid when BatchListCustomColumn2Type = Enumeration
List of alternatives separated by | which are to be shown in the combined box of
the user-defined column.
The default for new batches can be overwritten via SelectedBatchCustomCol‐
umn2Enumeration.
Amendment on Engineering Manual
3.2 Configuration of the "Order Creation" dialog
Advanced Process Functions SIMATIC BATCH Integration
18 Function Manual, 07/2016, A5E38719543-AA

3.3 Runtime interface to SIMATIC BATCH
With the Runtime interface to SIMATIC BATCH you can do the following in APF:
● Create orders and batches
● Release and start batches
● Set batch header parameters: order and batch names, recipes or formula for the batch,
batch size, batch start mode and start time
● Allocate units
● Set batch parameters: process values, input and output materials
Note
A Batch ID cannot be transferred.
Opening the Runtime interface to SIMATIC BATCH
You can open the Runtime interface to SIMATIC BATCH with the Global Script Template
FB_BMBatchCreation.tpl under <…SIEMENS\WINCC\bin\Engineeringtool\Konfig\PAS>. You
need to copy the template to the <OSProject>\<SERVERNAME>\PAS directory to use this
functionality in the PCS 7 OS project. Then change the extension from .tpl to .pas. To use the
script in a specific project, you need to adapt it in the Global Script editor. The script includes
sections with the comment "//TODO" for this purpose.
To activate the script, you need to add a cyclic trigger (for example, 10 or 20 seconds cycle
time). We recommend you also add all employed tags as tag triggers.
The Global Script consists of two sections. In the first section, an action is prepared and
triggered in SIMATIC BATCH. Because these actions are mostly asynchronous, the return
values must be determined and checked in a later call of the Global Script; this is the job of
the second part of the script.
Note
Use the SIMATIC BATCH OS Controls
The main applications for this Global Script are automatic background actions without user
interaction, for example, based on trigger events from the production process. We recommend
you use of SIMATIC BATCH OS Controls for user operations of SIMATIC BATCH in the context
of PCS 7 OS.
NOTICE
This script cannot run without adaptation.
The project engineer / customer has to make these adaptations. This script cannot be used
without adaptations.
Amendment on Engineering Manual
3.3 Runtime interface to SIMATIC BATCH
Advanced Process Functions SIMATIC BATCH Integration
Function Manual, 07/2016, A5E38719543-AA 19

Global Script flow diagram
Amendment on Engineering Manual
3.3 Runtime interface to SIMATIC BATCH
Advanced Process Functions SIMATIC BATCH Integration
20 Function Manual, 07/2016, A5E38719543-AA
