Flowrite 599 Series
Technical Instructions
Document No. 155-184P25
VF 599-3
May 2, 2016
Two-Way Valves, 1/2 to 2-
inch Bronze Body, ANSI 250
Siemens Industry, Inc.
Description
The Flowrite 599 Series two-way valves are designed to work with either a
pneumatic or electronic actuator with a 3/4-inch (20 mm) stroke. They are available
in ANSI Class 250 for normally open or normally closed action.
Features
ANSI Leakage Class IV (0.01% of Cv)
Cartridge type packing
Choice of brass or stainless steel trim
Direct-coupled universal bonnet
Choice to two flow characteristics
Application
Flowrite valves are generally recommended for water, steam, and 50% water-glycol
solutions.
Product Numbers
See Table 1 and Table 2.
Ordering a Valve
Plus Actuator
Assembly
To order a complete valve plus actuator assembly from the factory, combine the
actuator prefix code with the suffix of the valve assembly product number. See
Flowrite Technical Bulletins (155-772 and 155-776) for complete selection
procedure and ordering codes.
Valve assemblies can be ordered using the valve part numbers in Table 1 and
Table 2 and the actuator prefix codes in Table 10.

Technical Instructions Flowrite 599 Series Two-Way Valves, 1/2 to 2-Inch, Bronze Body, ANSI 250
Document Number 155-184P25
May 2, 2016
Page 2 Siemens Industry, Inc.
Specifications
Material
Line size 1/2 to 2-inches (15 to 50 mm)
Capacity See Table 3 through Table 6 and
Figure 3
Body style F × F Globe style
Seat style Single seat, metal-to-metal
Action Normally Open (NO)
Normally Closed (NC)
Stem travel (stroke) 3/4-inch (20 mm)
Valve body rating ANSI Class 250; see Table 7
Body UNS CA 844 bronze
Body trim See Table 1 and Table 2.
Stem Stainless steel ASTM A582
Type 303
Packing
Normal duty packing EPDM O-rings
Steam packing Teflon®V-ring/EPDM O-ring
Operating
Controlled medium Saturated steam, water,
50% water-glycol solutions
Medium temperature range
Normal duty packing 20°F to 250°F (–7°C to 120°C)
Steam packing 337°F (170°C) maximum
Maximum inlet pressure
Water See Table 7.
Steam 100 psig (690 kPa)
Maximum recommended differential pressure for modulating service
Brass trim
Stainless steel trim
Liquid
25 psi (173 kPa)
50 psi (345 kPa)
Steam
15 psi (103 kPa)
50 psi (345 kPa)
Rangeability >100:1
Close-off pressures See Table 8, Table 9, and Figure 4.
Close-off ratings According to ANSI/FCI 70-2
Leakage rate Class IV (0.01% of Cv)
Flow characteristics See Table 1 and Table 2.
Mounting location NEMA 1 (interior only)
Miscellaneous
Canadian Registration Numbers 0H7645.5ADD2
0C0838.9
Dimensions See
Table 10, Table 11, and Figure 6.
Valve Weight See Table 13.

Flowrite 599 Series Two-Way Valves, 1/2 to 2-Inch, Bronze Body, ANSI 250 Technical Instructions
Document Number 155-184P25
May 2, 2016
Siemens Industry, Inc. Page 3
Accessories
Figure 1. Packing Heating Element
For Use with SKD Actuators.
599-00417 Packing heating element.
The heater allows the stem to move freely
in valves that control fluids at temperatures
below 32°F (0°C). It reduces ice crystal
formation on the stem, which can damage
the packing.
Operating Voltage 24 Vac
Heating Output 20W
Figure 2. Packing Heating Element
For Use with SKB/C and 8-inch
Actuators.
599-00418: Packing heating element.
The element allows the stem to move
freely in valves that control fluids at
temperatures below 32°F (0°C). It prevents
ice crystal formation on the stem, which
can damage the packing.
Operating Voltage 24 Vac
Heating Output 20W
Service Kits
Valve packing kit
Normal duty packing 599-03390
Steam packing 599-03391
Rebuild/repack kits See Table 14 and Table 15.

Technical Instructions Flowrite 599 Series Two-Way Valves, 1/2 to 2-Inch, Bronze Body, ANSI 250
Document Number 155-184P25
May 2, 2016
Page 4 Siemens Industry, Inc.
Product Numbers
Table 1. Female NPT x Female NPT (FxF) Normally Open Valves.
Flow Rate
Nominal
Line Size
Equal Percentage
Linear
Stainless
Steel Trim
Brass Trim
Stainless Steel Trim
Cv
(Kvs)
inch
(mm)
Normal Duty Packing
Normal Duty
Packing
Steam
Packing
1
(0.85)
1/2
(15)
599-03108
599-03162
599-03000
599-03054
1.6
(1.37)
1/2
(15)
599-03109
599-03163
599-03001
599-03055
2.5
(2.15)
1/2
(15)
599-03110
599-03164
599-03002
599-03056
4
(3.44)
1/2
(15)
599-03111
599-03165
599-03003
599-03057
6.3
(5.43)
3/4
(20)
599-03112
599-03166
599-03004
599-03058
10
(8.6)
1
(25)
599-03113
599-03167
599-03005
599-03059
16
(13.8)
1-1/4
(32)
599-03114
599-03168
599-03006
599-03060
25
(21.5)
1-1/2
(40)
599-03115
599-03169
599-03007
599-03061
40
(34.4)
2
(50)
599-03116
599-03170
599-03008
599-03062

Flowrite 599 Series Two-Way Valves, 1/2 to 2-Inch, Bronze Body, ANSI 250 Technical Instructions
Document Number 155-184P25
May 2, 2016
Siemens Industry, Inc. Page 5
Table 2. Female NPT x Female NPT (FxF) Normally Closed Valves.
Flow Rate
Nominal
Line Size
Equal Percentage
Linear
Stl. Steel Trim
Brass Trim
Stainless Steel Trim
Cv
(Kvs)
Inch
(mm)
Normal Duty Packing
Normal Duty
Packing
Steam Packing
1
(0.85)
1/2
(15)
599-03126
599-03180
599-03018
599-03072
1.6
(1.37)
1/2
(15)
599-03127
599-03181
599-03019
599-03073
2.5
(2.15)
1/2
(15)
599-03128
599-03182
599-03020
599-03074
4
(3.44)
1/2
(15)
599-03129
599-03183
599-03021
599-03075
6.3
(5.43)
3/4
(20)
599-03130
599-03184
599-03022
599-03076
10
(8.6)
1
(25)
599-03131
599-03185
599-03023
599-03077
16
(13.8)
1-1/4
(32)
599-03132
599-03186
599-03024
599-03078
25
(21.5)
1-1/2
(40)
599-03133
599-03187
599-03025
599-03079
40
(34.4)
2
(50)
599-03134
599-03188
599-03026
599-03080

Technical Instructions Flowrite 599 Series Two-Way Valves, 1/2 to 2-Inch, Bronze Body, ANSI 250
Document Number 155-184P25
May 2, 2016
Page 6 Siemens Industry, Inc.
Table 3. Maximum Water Capacity - U.S. Gallons per Minute.
Valve
Size
in
inches
Pressure Differential - psi
Cv\1
2
3
4
5
6
8
10
15
20
25
30
40
50
60
75
1/2
1.0
1.4
1.7
2.0
2.2
2.5
2.8
3.2
3.9
4.5
5.0
5.5
6.3
7.1
7.8
8.7
1.6
2.3
2.8
3.2
3.6
3.9
4.5
5.1
6.2
7.2
8.0
8.8
10.1
11.3
12.4
13.9
2.5
3.5
4.3
5.0
5.6
6.1
7.1
7.9
97
11.2
12.5
13.7
15.8
17.7
19.4
22
4
5.7
7
8.0
8.9
10
11.3
12.6
15.5
17.9
20.0
21.9
25
28
31
35
3/4
6
8.9
10.9
12.6
14.1
15.4
17.8
20
24
28
32
35
40
45
49
55
1
10
14.1
17.3
20
22
24
28
32
39
45
50
55
63
71
77
87
1-1/4
16
23
28
32
36
39
45
51
62
72
80
88
101
113
124
139
1-1/2
25
35
43
50
56
61
71
79
97
112
125
137
158
177
194
217
2
40
57
69
80
89
98
113
126
155
179
200
219
253
283
310
346
Table 4. Maximum Water Capacity - Cubic Meters per Hour (m3/hr).
Valve Size
mm
Pressure Differential - kPa
1
10
20
30
40
50
60
80
Kvs/
100
150
200
300
400
500
15
0.09
0.3
0.4
0.5
0.5
0.6
0.7
0.8
0.9
1.0
1.2
1.5
1.7
1.9
0.14
0.4
0.6
0.8
0.9
1.0
1.1
1.2
1.4
1.7
1.9
2.4
2.7
3.1
0.2
0.7
1.0
1.2
1.4
1.5
1.7
1.9
2.2
2.6
3.0
3.7
4.3
4.8
0.3
1.1
1.5
1.9
2.2
2.4
2.7
3.1
3.4
4.2
4.9
6.0
6.9
7.7
20
0.5
1.7
2.4
3.0
3.4
3.8
4.2
4.9
5.4
6.7
7.7
9.4
10.9
12.1
25
0.9
2.7
3.8
4.7
5.4
6.1
6.7
7.7
8.6
10.5
12.2
14.9
17.2
19.2
32
1.4
4.4
6.2
7.6
8.7
9.8
10.7
12.3
13.8
16.9
19.5
23.9
27.6
30.9
40
2.2
6.8
9.6
11.8
13.6
15.2
16.7
19.2
22
26
30
37
43
48
50
3.4
10.9
15.4
18.8
22
24
27
31
34
42
49
60
69
77

Flowrite 599 Series Two-Way Valves, 1/2 to 2-Inch, Bronze Body, ANSI 250 Technical Instructions
Document Number 155-184P25
May 2, 2016
Siemens Industry, Inc. Page 7
Table 5. Steam Capacity - Pounds per Hour.
Line
Size
inches
Cv
Inlet Pressure - psig
2
5
10
15
25
50
75
100
Pressure Differential - psi
1
2
3
4
5
6
8
10
9
12
15
5
15
20
15
30
32.5
20
30
40
45
30
40
50
57.5
1/2
1
12.0
16.6
22
25
28
34
38
42
45
50
54
41
65
72
87
115
118
119
141
157
163
162
183
199
209
1.6
19.1
27
35
40
44
54
61
67
72
80
86
65
104
116
139
183
188
109
225
251
261
260
292
318
334
2.5
30
42
55
62
69
85
96
104
112
125
135
101
163
181
217
287
294
296
351
392
408
406
457
497
522
4
48
67
88
100
110
136
153
167
179
200
216
162
261
289
348
459
471
474
562
627
653
650
731
796
835
3/4
6.3
75
105
138
157
174
213
241
263
282
316
341
255
411
455
548
722
742
747
886
988
1029
1023
1152
1253
1315
1
10
120
166
219
250
275
339
382
417
447
501
541
405
653
723
870
1147
1178
1186
1406
1568
1633
1624
1828
1989
2088
1-1/4
16
191
266
351
400
441
542
611
667
716
801
865
648
1044
1156
1392
1835
1884
1897
2249
2509
2612
2599
2925
3182
3340
1-1/2
25
299
416
549
625
689
847
955
1042
1118
1252
1351
1013
1632
1806
2175
2867
2944
2964
3515
3920
4081
4061
4570
4972
5219
2
40
478
666
878
1000
1102
1356
1529
1667
1789
2003
2162
1620
2611
2890
3480
4587
4710
4743
5624
6272
6530
6497
7311
7956
8350
Table 6. Steam Capacity - Kilograms per Hour.
Line
Size
mm
Cv
Inlet Pressure - kPa
100
150
200
500
Pressure Differential - kPa
10
20
50
15
30
75
20
40
100
50
100
250
15
1
6.04
8.54
13.50
9.07
12.8
3
20.2
9
12.11
17.13
27.08
30.3
42.9
67.8
1.6
9.66
13.6
7
21.61
14.5
2
20.5
3
32.4
7
19.37
27.40
43.32
48.51
68.60
108.47
2.5
15
21
34
23
32
51
30
43
68
76
107
169
4
24
34
54
36
51
81
48
69
108
121
172
271
20
6.3
38
54
85
57
81
128
76
108
171
191
270
427
25
10
60
85
135
91
128
203
121
171
271
303
429
678
32
16
97
137
216
145
205
325
194
274
433
485
686
1085
40
25
151
214
338
227
321
507
303
428
677
758
1072
1695
50
40
242
342
540
363
513
812
484
685
1083
1213
1715
2712

Technical Instructions Flowrite 599 Series Two-Way Valves, 1/2 to 2-Inch, Bronze Body, ANSI 250
Document Number 155-184P25
May 2, 2016
Page 8 Siemens Industry, Inc.
Table 7. Body Temperature-Pressure Rating.
Valve
Body
Temperature
°F °C
Pressure
psig (kPa)
ANSI Class 250
Bronze
–20 to +150 (–30 to 66)
+200 (93)
+250 (121)
+300 (149)
+350 (177)
400 (2758)
385 (2655)
365 (2586)
335 (2300)
300 (2068)
Figure 3. Water Capacity Graph.
Selection Example
Select a valve given:
1. Required flow = 20 gpm.
2. Desired pressure drop = 5 psi.
3. Select a 1-inch (25 mm) valve, Cv 10.

Flowrite 599 Series Two-Way Valves, 1/2 to 2-Inch, Bronze Body, ANSI 250 Technical Instructions
Document Number 155-184P25
May 2, 2016
Siemens Industry, Inc. Page 9
Table 8. Maximum Available Close-off Pressures for Pneumatic Actuators, with Normally Open Valves.
Action
Valve
Size
Inch
(mm)
Spring Range
3 to 8 psi ( 21 to 55 kPa)
10 to 15 psi (69 to 103 kPa)
4-Inch
Actuator
8-Inch Actuator
12-Inch Actuator
4-Inch
Actuator
8-Inch
Actuator
12-Inch
Actuator
15 psi
(103 kPa)
15 psi
(103 kPa)
30 psi
(207 kPa)
15 psi
(103 kPa)
30 psi
(207 kPa)
0 psi
(0 kPa)
0 psi
(0 kPa)
0 psi
(0 kPa)
Normally Open
1/2 (15)
142 (979)
250 (1724)
250 (1724)
—
—
—
—
—
3/4 (20)
80 (552)
231 (1593)
250 (1724)
—
—
—
—
—
1 (25)
52 (359
150 (1034)
250 (1724)
250 (1724)
250 (1724)
—
—
—
1-1/4 (32)
32 (221)
93 (641)
250 (1724)
250 (1724)
250 (1724)
—
—
—
1-1/2 (40 )
20 (138)
60 (414)
198 (1365)
205(1413)
250 (1724)
—
—
—
2 (50)
12 (83)
37 (255)
123 (848)
130 (896)
250 (1724)
—
—
—
Normally Closed
1/2 (15)
—
—
—
—
—
236 (1627)
250 (1724)
—
3/4 (20)
—
—
—
—
—
155 (1069)
250 (1724)
—
1 (25)
—
—
—
—
—
91 (627)
250 (1724)
250 (1724)
1-1/4 (32)
—
—
—
—
—
52 (359)
148 (1020)
250 (1724)
1-1/2 (40 )
—
—
—
—
—
32 (331)
92 (634)
250 (1724)
2 (50)
—
—
—
—
—
20 (138)
55 (379)
185 (1776)
Table 9. Close-off Pressures for Electronic Actuators.
Action
Valve
Size
Inches
(mm)
SAX
psi (kPa)
Rack &
Pinion
psi (kPa)
(GMA)
Rack &
Pinion
psi (kPa)
(GCA)
SKD
psi (kPa)
SKB
psi (kPa)
Normally Open
1/2 (15)
250 (1724)
250 (1724)
250 (1724)
250 (1724)
250 (1724)
3/4 (20)
211 (1456)
174 (1200)
231 (1593)
250 (1724)
250 (1724)
1 (25)
137 (945)
136 (938)
149 (1028)
201 (1386)
250 (1724)
1-1/4 (32)
85 (586)
84 (580)
92 (634)
124 (855)
250 (1724)
1-1/2(40)
55 (379)
55 (380)
59 (407)
80 (552)
250 (1724)
2 (50)
34 (235)
30 (207)
36 (248)
49 (338)
201 (1386)
Normally Closed
1/2 (15)
250 (1724)
250 (1724)
250 (1724)
250 (1724)
250 (1724)
3/4 (20)
250 (1724)
174 (1200)
250 (1724)
250 (1724)
250 (1724)
1 (25)
159 (1097)
136 (938)
173 (1193)
203 (1400)
250 (1724)
1-1/4 (32)
92 (634)
84 (580)
100 (690)
117 (807)
250 (1724)
1-1/2(40)
57 (393)
55 (380)
61 (421)
73 (503)
208 (1334)
2 (50)
35 (241)
30 (207)
37 (255)
44 (303)
126 (869)

Technical Instructions Flowrite 599 Series Two-Way Valves, 1/2 to 2-Inch, Bronze Body, ANSI 250
Document Number 155-184P25
May 2, 2016
Page 10 Siemens Industry, Inc.
ELECTRONIC PNEUMATIC
Figure 4. Close-off Pressures.
Operation
Figure 5 shows the normally open valve in
the open position and the normally closed
valve in the closed or zero flow position.
In the event of power failure, a spring
return actuator returns the valve to its
normal position. Non-spring return
actuators will hold the last commanded
position. See the Technical Instructions of
the various actuators for additional
information.
Figure 5.

Flowrite 599 Series Two-Way Valves, 1/2 to 2-Inch, Bronze Body, ANSI 250 Technical Instructions
Document Number 155-184P25
May 2, 2016
Siemens Industry, Inc. Page 11
Sizing
The sizing of a valve is important for correct system operation. An undersized valve will
not have sufficient capacity at maximum load. An oversized valve can initiate cycling
and the seat and throttling plug can be damaged because of the restricted opening.
Correct sizing of the control valve for actual expected conditions is considered essential
for good control.
The following variables must be determined:
The medium to be controlled, such as steam, water, and so on.
The maximum inlet temperature and pressure of the medium at the valve.
The pressure differential that will exist across the valve under maximum load
demand.
The maximum capacity the valve must deliver.
The maximum line pressure differential the valve actuator must close against.
See the Control Valve Selection and Sizing (AB-1) section of HVAC
Systems/Controls Reference Data (125-1853) for further recommendations.
See Table 3 through Table 6 for valve capacities.
Mounting and
Installation
Install the valve so that the flow follows the direction of the arrow indicated on the
valve body.
For best performance, install the valve assembly with the actuator above the valve
body. The valve and actuator can be installed in any position between vertical and
horizontal. Siemens Industry, Inc. does not recommend installing the valve
assembly so that the actuator is below horizontal or upside down.
Allow sufficient space for servicing the valve and actuator. See Table 11 for valve
body dimensions. See Figure 6 and
Table 10 for dimensions of the service envelope recommended around the actuator.
NOTE: Instructions for field mounting an actuator, wiring diagrams, and start-up are
covered in the Technical Instructions and Installation Instructions for each
actuator.

Technical Instructions Flowrite 599 Series Two-Way Valves, 1/2 to 2-Inch, Bronze Body, ANSI 250
Document Number 155-184P25
May 2, 2016
Page 12 Siemens Industry, Inc.
Dimensions
Figure 6.
The letters in Figure 6 refer to actuator and service envelope dimensions in
Table 10.
See Table 11 for valve body dimensions.
Table 10. Dimensions of the Actuator and Recommended Service Envelope.
Dimensions in Inches (Millimeters).
Actuator
Actuator
Prefix
Code
Actual
Height of
Actuator
H1
Service
Height
H
Actual Width or
Diameter of Actuator
W1
Service
Width
W
4-inch
Pneumatic
268, 269
270
5-3/4
(146)
14
(350)
5-1/2 (137)
diameter
18
(450)
8-inch
Pneumatic
277, 278
283, 284
14-1/8
(359)
26
(660)
8-3/4 (222)
diameter
21
(533)
12-inch
Pneumatic
279, 285
17-7/8
(454)
30
(762)
15-1/8 (384)
diameter
27
(686)
SAX
371, 373
9-9/16
(242)
17-1/4
(442)
4-7/8 (124) Width
5-7/8 (150) Depth
17-3/4
(450)
Rack and Pinion
298, 299
14-1/2
(368)
24-1/2
(622)
5 (127) Width*
5-1/8 (131) Depth
13
(331)
SKD
267, 274
275, 276
11-13/16
(300)
19-3/4
(500)
5 (127) Width
6-5/8 (169) Depth
14-1/2
(360)
SKB
289, 291,
290
14-3/4
(375)
22-3/4
(578)
7 (178) Width × 8-15/16
(226) Depth
25
(635)

Flowrite 599 Series Two-Way Valves, 1/2 to 2-Inch, Bronze Body, ANSI 250 Technical Instructions
Document Number 155-184P25
May 2, 2016
Siemens Industry, Inc. Page 13
Dimensions,
Continued
Table 11. 2-Way Female NPT x Female NPT (FxF Valve Dimensions in Inches (Millimeters).
Valve
Action
Valve
Size
A
B
C
Normally
Open
1/2
(15)
1-7/16
(36)
2-15/16
(74)
1-1/4
(31)
3/4
(20)
1-11/16
(43)
3-15/16
(99)
1-7/16
(36)
1
(25)
2
(50)
3-3/4
(96)
1-1/4
(32)
1-1/4
(32)
2-1/2
(62)
4-1/4
(108)
2
(51)
1-1/2
(40)
2-9/16
(65)
4-1/4
(108)
2
(51)
2
(50)
3-1/8
(79)
4-9/16
(116)
2-1/4
(57)
Normally
Closed
1/2
(15)
1-7/16
(36)
3-13/16
(97)
2-3/16
(55)
3/4
(20)
1-11/16
(43)
3-13/16
(97)
2-3/16
(55)
1
(25)
2
(50)
3-13/16
(97)
2-3/16
(55)
1-1/4
(32)
2-1/2
(62)
3-13/16
(97)
2-3/16
(55)
1-1/2
(40)
2-9/16
(65)
3-7/8
(99)
2-1/4
(58)
2
(50)
3-1/8
(79)
4-1/2
(114)
2-9/16
(65)

Technical Instructions Flowrite 599 Series Two-Way Valves, 1/2 to 2-Inch, Bronze Body, ANSI 250
Document Number 155-184P25
May 2, 2016
Page 14 Siemens Industry, Inc.
1/2-inch (15 mm) Valve Size.
3/4-inch to 2-inch (20 to 50 mm) Valve Size
Figure 7. Normally Open Valves.
Figure 8. Normally Closed Valves
1/2-inch to 2-inch (15 to 50 mm) Valve Size.

Flowrite 599 Series Two-Way Valves, 1/2 to 2-Inch, Bronze Body, ANSI 250 Technical Instructions
Document Number 155-184P25
May 2, 2016
Siemens Industry, Inc. Page 15
Parts List
Table 12. Parts List for 2-Way Bronze Valves.
See Figure 8 and Figure 8.
Item
Part Name
Part Number
Quantity
Material
1
Packing Cartridge
Assembly
—
1
—
2
Gasket
—
1
Copper
3
Normally Open
3/4-inch to 2-inch Bonnet
—
1
Brass
4
Stem and Plug Assembly
—
1
Bronze or
Stainless
Steel
5
Valve Body
—
1
Bronze
6
O-ring
1
EPDM
7
Normally closed Cap
—
1
Brass
—
Packing Kit
Normal Duty Service
Steam Service
599-03390
599-03391
—
Items 1 and 2
—
Rebuild/Repack Kit
Normally Closed
See Table 14
and Table 15
—
Items 1, 2, 4,
and 6
—
Rebuild/Repack Kit
Normally Open
See Table 14
and Table 15
—
Items 1, 2, 4,
and 6
Valve Assembly
Weight
Table 13. Weight in Pounds (Kilograms).
Valve Size
Normally Closed
Normally Open
.50 (15)
3 (1.4)
3 (1.4)
.75 (20)
4 (1.8)
4 (1.8)
1.0 (25)
5 (2.3)
5 (2.3)
1.25 (32)
7 (3.2)
7 (3.2)
1.50 (40)
8 (3.6)
9 (4.1)
2.0 (50
16 (7.3)
13 (5.9)

Technical Instructions Flowrite 599 Series Two-Way Valves, 1/2 to 2-Inch, Bronze Body, ANSI 250
Document Number 155-184P25
May 2, 2016
Page 16 Siemens Industry, Inc.
Service Kit
NOTE: To select the service kit, know your valve body part number and model number. Read
down the Part Number column until you find the valve body part number and then read to
the far right to identify the correct kit. The valve body part number and model number are
stamped on the metal tag on the valve body.
Table 14. Rebuild/Repack Service Kits Part Numbers.
See Table 12 for Items in Kit.
Flow
Action
Valve
Size
Part
Number
Valve Description
Model 1
Kit No.
Model 2
Kit No.
Linear
Normally Open
1/2-Inch
599-03000
Stainless steel 1.0 Cv O-ring
599-03300
—
599-03001
Stainless steel 1.6 Cv O-ring
599-03301
—
599-03002
Stainless steel 2.5 Cv O-ring
599-03302
—
599-03003
Stainless steel 4.0 Cv O-ring
599-03303
—
3/4-Inch
599-03004
Stainless steel O-ring
599-03304
—
1-Inch
599-03005
Stainless steel O-ring
599-03305
—
1-1/4 Inch
599-03006
Stainless steel O-ring
599-03306
599-09201
1-1/2-Inch
599-03007
Stainless steel O-ring
599-03307
599-09202
2-Inch
599-03008
Stainless steel O-ring
599-03308
599-09203
Normally Closed
1/2-Inch
599-03018
Stainless steel 1.0 Cv O-ring
599-03309
—
599-03019
Stainless steel 1.6 Cv O-ring
599-03310
—
599-03020
Stainless steel 2.5 Cv O-ring
599-03311
—
599-03021
Stainless steel 4.0 Cv O-ring
599-03312
—
3/4-Inch
599-03022
Stainless steel O-ring
599-03313
—
1-Inch
599-03023
Stainless steel O-ring
599-03314
—
1-1/4 Inch
599-03024
Stainless steel O-ring
599-03315
599-09213
1-1/2-Inch
599-03025
Stainless steel O-ring
599-03316
599-09214
2-Inch
599-03026
Stainless steel O-ring
599-03317
599-09215
Normally Open
1/2-Inch
599-03054
Stainless steel 1.0 Cv Steam
599-03318
—
599-03055
Stainless steel 1.6 Cv Steam
599-03319
—
599-03056
Stainless steel 2.5 Cv Steam
599-03320
—
599-03057
Stainless steel 4.0 Cv Steam
599-03321
—
3/4-Inch
599-03058
Stainless steel Steam
599-03322
—
1-Inch
599-03059
Stainless steel Steam
599-03323
—
1-1/4 Inch
599-03060
Stainless steel Steam
599-03324
599-09204
1-1/2-Inch
599-03061
Stainless steel Steam
599-03325
599-09205
2-Inch
599-03062
Stainless steel Steam
599-03326
599-09206
Normally Closed
1/2-Inch
599-03072
Stainless steel 1.0 Cv Steam
599-03327
—
599-03073
Stainless steel 1.6 Cv Steam
599-03328
—
599-03074
Stainless steel 2.5 Cv Steam
599-03329
—
599-03075
Stainless steel 4.0 Cv Steam
599-03330
—
3/4-Inch
599-03076
Stainless steel Steam
599-03331
—
1-Inch
599-03077
Stainless steel Steam
599-03332
—
1-1/4 Inch
599-03078
Stainless steel Steam
599-03333
599-09216
1-1/2-Inch
599-03079
Stainless steel Steam
599-03334
599-09217
2-Inch
599-03080
Stainless steel Steam
599-03335
599-09218

Flowrite 599 Series Two-Way Valves, 1/2 to 2-Inch, Bronze Body, ANSI 250 Technical Instructions
Document Number 155-184P25
May 2, 2016
Information in this publication is based on current specifications. The company reserves the right to make changes in specifications and models as
design improvements are introduced. Product or company names mentioned herein may be the trademarks of their respective owners.
© 2016 Siemens Industry, Inc.
Siemens Industry, Inc.
Building Technologies Division
1000 Deerfield Parkway
Buffalo Grove, IL 60089-4513
USA
[phone]
Your feedback is important to us. If you have
comments about this document, please send them
to [e-mail]
Document No. 155-184P25
Printed in the USA
Page 17
Service Kits, Continued
Table 15. Rebuild/Repack Service Kits Part Numbers Continued. See Table 12 for Items in Kit.
Flow
Action
Size
Part Number
Description
Model 1
Kit No.
Model 2
Kit No.
Equal Percentage
Normally Open
1/2 Inch
599-03108
Stainless steel 1.0 Cv O-ring
599-03336
—
599-03109
Stainless steel 1.6 Cv O-ring
599-03337
—
599-03110
Stainless steel 2.5 Cv O-ring
599-03338
—
599-03111
Stainless steel 4.0 Cv O-ring
599-03339
—
3/4-Inch
599-03112
Stainless steel O-ring
599-03340
—
1-Inch
599-03113
Stainless steel O-ring
599-03341
—
1-1/4-Inch
599-03114
Stainless steel O-ring
599-03342
599-09207
1-1/2-Inch
599-03115
Stainless steel O-ring
599-03343
599-09208
2-Inch
599-03116
Stainless steel O-ring
599-03344
599-09209
Normally Closed
1/2-Inch
599-03126
Stainless steel 1.0 Cv O-ring
599-03345
—
599-03127
Stainless steel 1.6 Cv O-ring
599-03346
—
599-03128
Stainless steel 2.5 Cv O-ring
599-03347
—
599-03129
Stainless steel 4.0 Cv O-ring
599-03348
—
3/4-Inch
599-03130
Stainless steel O-ring
599-03349
—
1-inch
599-03131
Stainless steel O-ring
599-03350
—
1-1/4 Inch
599-03132
Stainless steel O-ring
599-03351
599-09219
1-1/2-Inch
599-03133
Stainless steel O-ring
599-03352
599-09220
2-Inch
599-03134
Stainless steel O-ring
599-03353
599-09221
Normally Open
1/2-Inch
599-03162
Bronze 1.0 Cv O-ring
599-03354
—
599-03163
Bronze 1.6 Cv O-ring
599-03355
—
599-03164
Bronze 2.5 Cv O-ring
599-03356
—
599-03165
Bronze 4.0 Cv O-ring
599-03357
—
3/4-Inch
599-03166
Bronze O-ring
599-03358
—
1-Inch
599-03167
Bronze O-ring
599-03359
—
1-1/4-Inch
599-03168
Bronze O-ring
599-03360
599-09210
1-1/2-Inch
599-03169
Bronze O-ring
599-03361
599-09211
2-Inch
599-03170
Bronze O-ring
599-03362
599-09212
Normally Closed
1/2-Inch
599-03180
Bronze 1.0 Cv O-ring
599-03363
—
599-03181
Bronze 1.6 Cv O-ring
599-03364
—
599-03182
Bronze 2.5 Cv O-ring
599-03365
—
599-03183
Bronze 4.0 Cv O-ring
599-03366
—
3/4-Inch
599-03184
Bronze O-ring
599-03367
—
1-Inch
599-03185
Bronze O-ring
599-03368
—
1-1/4-Inch
599-03186
Bronze O-ring
599-03369
599-09222
1-1/2-Inch
599-03187
Bronze O-ring
599-03370
599-09223
2-Inch
599-03188
Bronze O-ring
599-03371
599-09224
