Siemens SIMATIC ET 200SP User manual

Manual
Digital input module DI 8xNAMUR (6ES7131-6TF00-0CA0)
ET 200SP
02/2014Edition
Answers for industry.
SIMATIC

DI 8xNAMUR HF digital input module
(6ES7131-6TF00-0CA0)
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
SIMATIC
ET 200SP
DI 8xNAMUR HF
digital input module
(6ES7131-6TF00-0CA0)
Manual
02/2014
A5E03894478
-01
Preface
Guide to documentation
1
Product overview
2
Wiring
3
Parameters/address space
4
Interrupts/diagnostics alarms
5
Technical specifications
6
Parameter data record
A

Siemens AG
Industry Sector
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E03894478-01
Ⓟ
02/2014 Technical data subject to change
Copyright © Siemens AG 2014.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

DI 8xNAMUR HF digital input module (6ES7131-6TF00-0CA0)
Manual, 02/2014, A5E03894478-01 3
Preface
Preface
Purpose of the documentation
This device manual complements the system manual ET 200SP distributed I/O system
(http://support.automation.siemens.com/WW/view/en/58649293). Functions that generally
relate to the system are described in this manual.
The information provided in this manual and in the system/function manuals supports you in
commissioning the system.
Conventions
Please also observe notes marked as follows:
Note
A note contains important information on the product described in the documentation, on the
handling of the product and on the section of the documentation to which particular attention
should
be paid.
Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, solutions, machines, equipment and/or networks. They are
important components in a holistic industrial security concept. With this in mind, Siemens’
products and solutions undergo continuous development. Siemens recommends strongly
that you regularly check for product updates.
For the secure operation of Siemens products and solutions, it is necessary to take suitable
preventive action (e.g. cell protection concept) and integrate each component into a holistic,
state-of-the-art industrial security concept. Third-party products that may be in use should
also be considered. You can find more information about industrial security on the Internet
(http://www.siemens.com/industrialsecurity).
To stay informed about product updates as they occur, sign up for a product-specific
newsletter. You can find more information on the Internet
(http://support.automation.siemens.com).

DI 8xNAMUR HF digital input module (6ES7131-6TF00-0CA0)
4Manual, 02/2014, A5E03894478-01
Table of contents
Preface ................................................................................................................................................... 3
1 Guide to documentation .......................................................................................................................... 5
2 Product overview .................................................................................................................................... 7
2.1 Properties...................................................................................................................................... 7
3 Wiring ..................................................................................................................................................... 9
3.1 Pin assignment.............................................................................................................................. 9
3.2 Block diagram ............................................................................................................................. 10
4 Parameters/address space ................................................................................................................... 11
4.1 Parameters.................................................................................................................................. 11
4.2 Explanation of parameters .......................................................................................................... 13
4.3 Pulse stretching........................................................................................................................... 16
4.4 Address space ............................................................................................................................ 18
5 Interrupts/diagnostics alarms................................................................................................................. 19
5.1 Status and fault displays ............................................................................................................. 19
5.2 Interrupts ..................................................................................................................................... 22
5.3 Diagnostics alarms...................................................................................................................... 24
5.4 Diagnostics for changeover contact sensor type ........................................................................ 25
5.5 Chatter monitoring....................................................................................................................... 26
6 Technical specifications ........................................................................................................................ 29
6.1 Technical specifications .............................................................................................................. 29
A Parameter data record .......................................................................................................................... 32
A.1 Dependencies when configuring with GSD files ......................................................................... 32
A.2 Parameter assignment and structure of parameter data record ................................................. 33

DI 8xNAMUR HF digital input module (6ES7131-6TF00-0CA0)
Manual, 02/2014, A5E03894478-01 5
Guide to documentation
1
Introduction
This modular documentation of the SIMATIC products covers diverse topics concerning your
automation system.
The complete documentation for the ET 200SP distributed I/O system consists of a system
manual, function manuals and product manuals.
The STEP 7 information system (online help) also supports you during the configuration and
programming of your automation system.
Overview of documentation for digital input module DI 8×NAMUR HF
The following table shows additional documentation that you need for using the
DI 8×NAMUR HF digital input module.
Table 1- 1 Documentation for the DI 8×NAMUR HF digital input module
Topic
Documentation
Key contents
System description System manual ET 200SP distributed
I/O system
(http://support.automation.siemens.co
m/WW/view/en/58649293)
•Application planning
•Installation
•Wiring
•Commissioning
Designing interference-
free controllers
Function manual Designing
interference-free controllers
(http://support.automation.siemens.co
m/WW/view/en/59193566)
•Basics
•Electromagnetic compatibility
•Lightning protection
System diagnostics Function manual
Diagnostics
(http://support.automation.siemens.co
m/WW/view/en/59192926)
•Overview
•Diagnostics evaluation of
hardware/software
BaseUnits Manual ET 200SP BaseUnits
(http://support.automation.siemens.co
m/WW/view/en/58532597/133300)
Technical specifications
Amendments and special
features of the
ET 200SP I/O system
ET 200SP Product information
(http://support.automation.siemens.co
m/WW/view/en/73021864)
Current information not yet
documented in the system
manuals, function manuals, or
product manuals.

Guide to documentation
DI 8xNAMUR HF digital input module (6ES7131-6TF00-0CA0)
6Manual, 02/2014, A5E03894478-01
SIMATIC manuals
All current manuals for SIMATIC products are available to download free of charge on the
Internet (http://www.siemens.com/simatic-tech-doku-portal).

DI 8xNAMUR HF digital input module (6ES7131-6TF00-0CA0)
Manual, 02/2014, A5E03894478-01 7
Product overview
2
2.1
Properties
Order number
6ES7131-6TF00-0CA0
View of the module
Figure 2-1 View of the DI 8×NAMUR HF module

Product overview
2.1 Properties
DI 8xNAMUR HF digital input module (6ES7131-6TF00-0CA0)
8Manual, 02/2014, A5E03894478-01
Properties
The module has the following technical properties:
●8 digital inputs each with a value status (quality information)
●8.2 VDC sensor supply for individual connection and disconnection (PROFIenergy)
●Selectable diagnostics (per channel)
●Suitable for connecting NAMUR sensors and connected and unconnected mechanical
contacts
The module supports the following technology functions:
●Pulse stretching
●Chatter monitoring
●Diagnostics for changeover contact sensor type
The module supports the following functions:
●Firmware update
●Identification data I&M0 to I&M3
●Reconfiguration in RUN
You can configure the module with STEP 7 (TIA Portal) and with a GSD file.
Accessories
The following accessories can be ordered separately:
●Labeling strips
●Color identification labels
●Reference identification label
●Shield connection
You can find additional information on the accessories in the ET 200SP distributed
I/O system (http://support.automation.siemens.com/WW/view/en/58649293) system manual.
See also
ET 200SP Product information
(http://support.automation.siemens.com/WW/view/en/73021864)

DI 8xNAMUR HF digital input module (6ES7131-6TF00-0CA0)
Manual, 02/2014, A5E03894478-01 9
Wiring
3
3.1
Pin assignment
General pin assignment
Table 3- 1 Pin assignment for DI 8×NAMUR HF
Pin assignment for DI 8×NAMUR HF (6ES7131-6TF00-0CA0)
Terminal
Assign-
ment
Terminal
Assign-
ment
Description
BaseUnit
1
Color identification label
(terminals 1 to 16)
1
DI
0
2
DI
1
•DIn: Input signal, channel n
•USn: Sensor supply, channel n
A0
CC01
6ES7193-6CP01-2MA0
3
DI2
4
DI3
5
DI
4
6
DI
5
7
DI6
8
DI7
9
U
S0
10
U
S1
11
US2
12
US3
13
U
S4
14
U
S5
15
US6
16
US7
L+
24 VDC
M
M
The figures below show the connections for input signal DI0for all sensor types.
NAMUR sensors / IEC 60947-5-6
sensors
NAMUR changeover contacts /
IEC 60947-5-6 changeover contacts
Single contact connected with 10 kΩ
(mechanical normally open contact)
Changeover contact connected with
10 kΩ(mechanical changeover
contact)
Single contact, unconnected
(mechanical normally open contact with
single contact)
Changeover contact, unconnected
(mechanical changeover contact)
1
BaseUnit types that can be used are identified by the last two digits of the order number. See also "ET 200SP
distributed I/O system" system manual.

Wiring
3.2 Block diagram
DI 8xNAMUR HF digital input module (6ES7131-6TF00-0CA0)
10 Manual, 02/2014, A5E03894478-01
Note
The first BaseUnit of a station must be a light
-colored BaseUnit. Keep this in mind also
during the configuration.
Firmware update
When updating the firmware, the L+ supply voltage must be applied to the module at the
start and during the firmware update.
See also
ET 200SP distributed I/O system
(http://support.automation.siemens.com/WW/view/en/58649293)
3.2
Block diagram
Block diagram
Figure 3-1 Block diagram DI 8×NAMUR HF

DI 8xNAMUR HF digital input module (6ES7131-6TF00-0CA0)
Manual, 02/2014, A5E03894478-01 11
Parameters/address space
4
4.1
Parameters
DI 8xNAMUR HF parameters
The following table lists the configurable parameters. The effective range of the configurable
parameters depends on the type of configuration. The following configurations are possible:
●Distributed operation on PROFINET IO in an ET 200SP system
●Distributed operation with PROFIBUS DP in an ET 200SP system
When assigning parameters in the user program, use the "WRREC" instruction to transfer
the parameters to the module using data records (refer to the section Parameter assignment
and structure of parameter data record (Page 33)).
The following parameter settings are possible:
Table 4- 1 Configurable parameters and their defaults (GSD file)
Parameters
Value range
Default
Changing
parameter
settings in RUN
Effective range with configuration
software, e.g. STEP 7 (TIA-Portal)
GSD file
PROFINET IO
GSD file
PROFIBUS DP
Diagnostics:
Missing supply
voltage L+
•Disable
•Enable
Disable Yes Channel Channel
Diagnostics:
Short-circuit to
ground
•Disable
•Enable
Disable Yes Channel Channel
Diagnostics:
Wire break
•Disable
•Enable
Disable Yes Channel Channel
Diagnostics:
Changeover error
•Disable
•Enable
Disable Yes Channel Channel
Diagnostics:
Chatter error
•Disable
•Enable
Disable Yes Channel -
Chatter monitoring:
Monitoring window
•0.5 s
•1 s to 100 s (can be
set in 1 s-increments)
0.5 s Yes Channel -
Chatter monitoring:
Number of signal
changes
•Deactivated
•2 to 32
Deactivated Yes Channel -

Parameters/address space
4.1 Parameters
DI 8xNAMUR HF digital input module (6ES7131-6TF00-0CA0)
12 Manual, 02/2014, A5E03894478-01
Parameters
Value range
Default
Changing
parameter
settings in RUN
Effective range with configuration
software, e.g. STEP 7 (TIA-Portal)
GSD file
PROFINET IO
GSD file
PROFIBUS DP
Hardware interrupts •Deactivated
•Rising edge
•Falling edge
•Falling and rising
edge
Deactivated Yes Channel -
Sensor type •Channel deactivated
•NAMUR sensor
•Single contact,
unconnected
•Single contact,
connected with 10 kΩ
•NAMUR changeover
contact
•Changeover contact,
unconnected
•Changeover contact,
connected with 10 kΩ
NAMUR
sensor
Yes Channel Channel
Pulse stretching •None
•0.5 s
•1 s
•2 s
None Yes Channel -
Inverted •Disable
•Enable
Disable Yes Channel Channel
Potential group •Use potential group of
the left module
•Enable new potential
group
Use potential
group of the
left module
No Module Module
Changing parameter settings and effects on the technology functions
Reconfiguring a technology function resets its responses. Reconfiguring one technology
function has no effect on other technology functions. Exception: Signal inversion and chatter
monitoring, because an additional edge change is generated when signal inversion is
disabled/enabled.

Parameters/address space
4.2 Explanation of parameters
DI 8xNAMUR HF digital input module (6ES7131-6TF00-0CA0)
Manual, 02/2014, A5E03894478-01 13
Technology functions
All technology functions, such as
●Pulse stretching
●Chatter monitoring
●Changeover errors
●Hardware interrupts
are executed only when there is an error-free signal (QI = 1). In other words, there is no
diagnostics information on the channel (see also section Address space (Page 18)).
4.2
Explanation of parameters
Diagnostics: Missing supply voltage L+
The diagnostics alarm is enabled for missing or insufficient supply voltage L+.
Tip: To avoid a diagnostics overload, you should only enable "Diagnostics: Missing supply
voltage" for an active channel.
Diagnostics: Short-circuit to ground
The diagnostics alarm is enabled if there is a short-circuit of the sensor supply to ground.
"Short-circuit to ground" diagnostics is available with the following sensor setting:
●NAMUR sensor
●NAMUR changeover contact
Diagnostics: Wire break
The diagnostics alarm is enabled if the line to the sensor is interrupted.
"Wire break" diagnostics is available with the following sensor setting:
●NAMUR sensor
●Single contact with 10 kΩ
●NAMUR changeover contact
●Changeover contact with 10 kΩ

Parameters/address space
4.2 Explanation of parameters
DI 8xNAMUR HF digital input module (6ES7131-6TF00-0CA0)
14 Manual, 02/2014, A5E03894478-01
Diagnostics: Changeover error
The diagnostics alarm is enabled when a changeover error occurs.
"Changeover error" diagnostics is available with the following sensor setting:
●NAMUR changeover contact
●Changeover contact, unconnected
●Changeover contact with 10 kΩ
Diagnostics: Chatter error
The diagnostics alarm is enabled when a chatter error occurs.
Chatter monitoring is a process control function for digital input signals. It detects and reports
signal changes that are unexpected in process engineering, for example when an input
signal fluctuates too often between "0" and "1". If signal characteristics like these occur, it is
a sign that the sensors are faulty or that there are instabilities from a process engineering
viewpoint.
Chatter monitoring: Monitoring window
Chatter monitoring: Setting of the monitoring window
Each input channel has a configurable monitoring window. The monitoring window is started
the first time the input signal changes. If the input signal changes within the monitoring
window more often than the configured number of signal changes, this is recognized as a
chatter error. If no chatter error is detected within the monitoring window, the window is
restarted at the next signal change.
Chatter monitoring: Number of signal changes
Chatter monitoring: Setting of the signal change
Settings for the tolerated number of signal changes during chatter monitoring within the
monitoring window.
Number of signal changes = 0 deactivates the chatter monitoring function.
Hardware interrupts
Specifies whether the rising or falling edge or both edges trigger a hardware interrupt.

Parameters/address space
4.2 Explanation of parameters
DI 8xNAMUR HF digital input module (6ES7131-6TF00-0CA0)
Manual, 02/2014, A5E03894478-01 15
Sensor type
Specifies which sensor type is connected (see Table 3-1 Pin assignment for
DI 8×NAMUR HF (Page 9)).
For the following sensor types
●NAMUR changeover contact
●Changeover contact, unconnected
●Changeover contact with 10 kΩ
the following applies: The normally open contact channel must be set according to the
sensor type. The normally closed contact channel must be deactivated.
If "Channel deactivated" is shown, this means that the channel is not activated.
Pulse stretching
Sets whether and for how long pulse stretching is to take place.
Pulse stretching is a function for changing a digital input signal. A pulse at a digital input is
extended to at least the configured length. If the input pulse is already longer than the
configured length, then the pulse will not be changed.
Inverted
Specifies whether or not the input signal is to be inverted.
Inversion is only possible with the following sensor types:
●NAMUR sensor
●Single contact, unconnected
●Single contact with 10 kΩ
Potential group
Specifies that a BaseUnit with an incoming supply voltage is located in this slot (see
ET 200SP distributed I/O system
(http://support.automation.siemens.com/WW/view/en/58649293) system manual).
See also
Pin assignment (Page 9)
Pulse stretching (Page 16)
Diagnostics for changeover contact sensor type (Page 25)

Parameters/address space
4.3 Pulse stretching
DI 8xNAMUR HF digital input module (6ES7131-6TF00-0CA0)
16 Manual, 02/2014, A5E03894478-01
4.3
Pulse stretching
Description
Pulse stretching is a function for changing a digital input signal. A pulse at a digital input is
extended to at least the configured length. If the input pulse is already longer than the
configured length, then the pulse will not be changed.
The pulse-stretched signal is the input signal for the hardware interrupt.
Principle of pulse stretching
The following figure uses examples to show if and how input pulses are changed.
Figure 4-1 Principle of pulse stretching

Parameters/address space
4.3 Pulse stretching
DI 8xNAMUR HF digital input module (6ES7131-6TF00-0CA0)
Manual, 02/2014, A5E03894478-01 17
Note
If you set pulse stretching for an input channel, this will also affect the chatter monitoring that
is enabled for this channel. The "pulse
-stretched" signal is the input signal for the chatter
monitoring. You should therefore match the parameter settings
for pulse stretching and
chatter monitoring to one another. By selecting the appropriate values for the parameters
you can adjust the functions optimally to your process.
Note
Pulse stretching in progress is reset in the event of an error in the value
status (QI = 0, e.g.
wire break).

Parameters/address space
4.4 Address space
DI 8xNAMUR HF digital input module (6ES7131-6TF00-0CA0)
18 Manual, 02/2014, A5E03894478-01
4.4
Address space
Configuration options of the DI 8×NAMUR HF
Configuration with value status:
●DI 8×NAMUR HF QI
Evaluating the value status
As a result of configuration with value status (QI), an additional byte is allocated in the input
address space. Each bit in this byte is assigned to a channel and returns information about
the validity of the digital value.
Deactivated channels or channels that are not operating correctly return a value status
of QI = 0.
With changeover contacts, the value status of a normally closed contact channel is always
QI = 0. The validity of the signal must be checked on the normally open contact channel.
Address space of the digital input module DI 8×NAMUR HF
The following figure shows the assignment of address space for the DI 8×NAMUR HF with
value status (Quality Information (QI)).
Figure 4-2 Address space of the DI 8×NAMUR HF digital input module with value status
Technology functions
All technology functions, such as
●Pulse stretching
●Chatter monitoring
●Changeover error
●Hardware interrupt
require a valid input signal that returns QI = 1 (no diagnostics detected). Otherwise, they will
not run.

DI 8xNAMUR HF digital input module (6ES7131-6TF00-0CA0)
Manual, 02/2014, A5E03894478-01 19
Interrupts/diagnostics alarms
5
5.1
Status and fault displays
LED displays
The figure below shows the LED displays (status and fault displays) of the DI 8×NAMUR HF.
①
DIAG (green/red)
②
Channel status (green)
③
Channel fault (red)
④
PWR (green)
Figure 5-1 LED display
