Siemens Simatic S7-1500 CPU 1512C-1 PN User manual

___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
SIMATIC
S7-1500
CPU 1512C-1 PN
(6ES7512-1CK01-0AB0)
Manual
12/2017
A5E40898741
-AA
Preface
Documentation guide
1
Product overview
2
Technology functions
3
Wiring
4
Parameters/address space
5
Interrupts/diagnostics alarms
6
Technical specifications
7
Dimension drawings
A
Parameter data records
B
Analog value processing
C

Siemens AG
Division Digital Factory
Po
stfach 48 48
90026 NÜRNBERG
GERMANY
A5E40898741-AA
Ⓟ
12/2017 Subject to change
Copyright © Siemens AG 2017.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
4Manual, 12/2017, A5E40898741-AA
Preface
Purpose of the documentation
This manual supplements the system manual of the S7-1500 automation system /
ET 200MP distributed I/O system as well as the function manuals. This manual contains a
description of the module-specific information. The system-related functions are described in
the system manual. Cross-system functions are described in the function manuals.
The information provided in this manual and the system manual enables you to commission
the CPU 1512C-1 PN.
Conventions
STEP 7: In this documentation, "STEP 7" is used as a synonym for all versions of the
configuration and programming software "STEP 7 (TIA Portal)".
Please also observe notes marked as follows:
Note
A note contains important information on the product described in the documentation, on the
handling of the product or on the section of the documentation to
which particular attention
should be paid.
Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens’ products and solutions only form one element of such a concept.
Customer is responsible to prevent unauthorized access to its plants, systems, machines
and networks. Systems, machines and components should only be connected to the
enterprise network or the internet if and to the extent necessary and with appropriate security
measures (e.g. use of firewalls and network segmentation) in place.
Additionally, Siemens’ guidance on appropriate security measures should be taken into
account. For more information about industrial security, please visit
(http://www.siemens.com/industrialsecurity).
Siemens’ products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends to apply product updates as soon as available and to
always use the latest product versions. Use of product versions that are no longer supported,
and failure to apply latest updates may increase customer’s exposure to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed under (http://www.siemens.com/industrialsecurity).

Preface
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
Manual, 12/2017, A5E40898741-AA 5
Siemens Industry Online Support
You can find current information on the following topics quickly and easily here:
●
Product support
All the information and extensive know-how on your product, technical specifications,
FAQs, certificates, downloads, and manuals.
●
Application examples
Tools and examples to solve your automation tasks – as well as function blocks,
performance information and videos.
●
Services
Information about Industry Services, Field Services, Technical Support, spare parts and
training offers.
●
Forums
For answers and solutions concerning automation technology.
●
mySupport
Your personal working area in Industry Online Support for messages, support queries,
and configurable documents.
This information is provided by the Siemens Industry Online Support in the Internet
(https://support.industry.siemens.com).
Industry Mall
The Industry Mall is the catalog and order system of Siemens AG for automation and drive
solutions on the basis of Totally Integrated Automation (TIA) and Totally Integrated Power
(TIP).
Catalogs for all the products in automation and drives are available on the Internet
(https://mall.industry.siemens.com).

CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
6Manual, 12/2017, A5E40898741-AA
Table of contents
Preface ................................................................................................................................................... 4
1 Documentation guide .............................................................................................................................. 9
2 Product overview .................................................................................................................................. 13
2.1 Applications of the S7-1500 CPUs......................................................................................... 13
2.2 Hardware properties and firmware functions ......................................................................... 20
2.2.1 Hardware properties of the CPU part .................................................................................... 21
2.2.2 Firmware functions of the CPU part....................................................................................... 23
2.2.3 Hardware properties of the analog on-board I/O module ...................................................... 27
2.2.4 Firmware functions of the analog on-board I/O module......................................................... 30
2.2.5 Hardware properties of the digital on-board I/O module........................................................ 31
2.2.6 Firmware functions of the digital on-board I/O module.......................................................... 34
2.3 Operator controls and display elements ................................................................................ 36
2.3.1 Front view with closed front panel.......................................................................................... 36
2.3.2 Front view of the CPU without front panel and view from below ........................................... 38
2.3.3 Rear view ............................................................................................................................... 40
2.4 Operating mode buttons ........................................................................................................ 41
3 Technology functions ............................................................................................................................ 42
3.1 High-speed counters.............................................................................................................. 42
3.1.1 Functions................................................................................................................................ 43
3.1.1.1 Counting................................................................................................................................. 43
3.1.1.2 Measuring .............................................................................................................................. 44
3.1.1.3 Position detection for motion control...................................................................................... 45
3.1.1.4 Additional functions................................................................................................................ 46
3.1.2 Configuring the high-speed counters..................................................................................... 47
3.1.2.1 General .................................................................................................................................. 47
3.1.2.2 Assignment of the control interface of the high-speed counters............................................ 47
3.1.2.3 Assignment of the feedback interface of the high-speed counters........................................ 50
3.2 Pulse generators.................................................................................................................... 51
3.2.1 Operating modes.................................................................................................................... 51
3.2.1.1 Operating mode: Pulse-width modulation (PWM).................................................................. 51
3.2.1.2 Operating mode: Frequency output ....................................................................................... 58
3.2.1.3 Operating mode: PTO............................................................................................................ 62
3.2.2 Functions................................................................................................................................ 67
3.2.2.1 Function: High-speed output.................................................................................................. 67
3.2.2.2 Function: Direct control of the pulse output (DQA) ................................................................ 68
3.2.3 Configuring the PWM and frequency output modes .............................................................. 69
3.2.3.1 Assignment of the control interface........................................................................................ 69
3.2.3.2 Handling the SLOT parameter (control interface).................................................................. 71
3.2.3.3 Assignment of the feedback interface.................................................................................... 75

Table of contents
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
Manual, 12/2017, A5E40898741-AA 7
4 Wiring ................................................................................................................................................... 77
4.1 Supply voltage ........................................................................................................................77
4.2 PROFINET interfaces .............................................................................................................78
4.3 Terminal and block diagrams..................................................................................................80
4.3.1 Block diagram of the CPU part ...............................................................................................80
4.3.2 Terminal and block diagram of the analog on-board I/O ........................................................81
4.3.3 Terminal and block diagram of the digital on-board I/O..........................................................90
4.3.4 Addresses of the high-speed counters .................................................................................104
4.3.5 Addresses of the pulse generators in the Pulse Width Modulation (PWM) and
Frequency Output modes .....................................................................................................107
4.3.6 Addresses of pulse generators in the PTO mode.................................................................108
4.3.7 Interconnection overview of the inputs .................................................................................109
4.3.8 Interconnection overview of outputs .....................................................................................111
5 Parameters/address space ................................................................................................................. 114
5.1 Address space of the analog on-board I/O...........................................................................114
5.2 Address space of the digital on-board I/O ............................................................................116
5.3 Address space of the pulse generators ................................................................................119
5.4 Measurement types and measuring ranges of the analog on-board I/O ..............................120
5.5 Output type and output ranges of the analog on-board I/O..................................................121
5.6 Parameters of the analog on-board I/O ................................................................................122
5.7 Parameters of the digital on-board I/O..................................................................................125
6 Interrupts/diagnostics alarms............................................................................................................... 127
6.1 Status and error displays ......................................................................................................127
6.1.1 Status and error displays of the CPU part ............................................................................127
6.1.2 Status and error displays of the analog on-board I/O...........................................................130
6.1.3 Status and error displays of the digital on-board I/O ............................................................132
6.2 Interrupts and diagnostics.....................................................................................................134
6.2.1 Interrupts and diagnostics of the CPU part...........................................................................134
6.2.2 Interrupts and diagnostics of the analog on-board I/O .........................................................135
6.2.3 Interrupts and diagnostics of the digital on-board I/O...........................................................138
7 Technical specifications ...................................................................................................................... 141
A Dimension drawings............................................................................................................................ 164

Table of contents
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
8Manual, 12/2017, A5E40898741-AA
B Parameter data records .......................................................................................................................166
B.1 Parameter assignment and structure of the parameter data records of the analog on-
board I/O .............................................................................................................................. 166
B.2 Structure of a data record for input channels of the analog on-board I/O ........................... 166
B.3 Structure of a data record for output channels of the analog on-board I/O ......................... 172
B.4 Parameter assignment and structure of the parameter data records of the digital on-
board I/O .............................................................................................................................. 175
B.5 Structure of a data record for input channels of the digital on-board I/O............................. 176
B.6 Structure of a data record for output channels of the digital on-board I/O........................... 178
B.7 Parameter data records of the high-speed counters ........................................................... 180
B.8 Parameter data records (PWM) ........................................................................................... 187
C Analog value processing ......................................................................................................................189
C.1 Conversion method.............................................................................................................. 189
C.2 Representation of analog values ......................................................................................... 196
C.3 Representation of input ranges............................................................................................ 197
C.3.1 Representation of analog values in voltage measuring ranges........................................... 198
C.3.2 Representation of analog values in current measuring ranges ........................................... 199
C.3.3 Representation of the analog values of resistance-type sensors/resistance-type
thermometers....................................................................................................................... 200
C.3.4 Measured values for wire break diagnostics........................................................................ 202
C.4 Representation of output ranges.......................................................................................... 203
C.4.1 Representation of analog values in the voltage output ranges............................................ 204
C.4.2 Representation of analog values in the current output ranges ............................................ 205

CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
Manual, 12/2017, A5E40898741-AA 9
Documentation guide
1
The documentation for the SIMATIC S7-1500 automation system and the SIMATIC
ET 200MP distributed I/O system is arranged into three areas.
This arrangement enables you to access the specific content you require.
Basic information
The System Manual and Getting Started describe in detail the configuration, installation,
wiring and commissioning of the SIMATIC S7-1500 and ET 200MP systems. The STEP 7
online help supports you in the configuration and programming.
Device information
Product manuals contain a compact description of the module-specific information, such as
properties, wiring diagrams, characteristics and technical specifications.

Documentation guide
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
10 Manual, 12/2017, A5E40898741-AA
General information
The function manuals contain detailed descriptions on general topics regarding the SIMATIC
S7-1500 and ET 200MP systems, e.g. diagnostics, communication, motion control, Web
server, OPC UA.
You can download the documentation free of charge from the Internet
(http://w3.siemens.com/mcms/industrial-automation-systems-simatic/en/manual-
overview/Pages/Default.aspx).
Changes and supplements to the manuals are documented in a Product Information.
You can download the product information free of charge from the Internet
(https://support.industry.siemens.com/cs/us/en/view/68052815).
Manual Collection S7-1500/ET 200MP
The Manual Collection contains the complete documentation on the SIMATIC S7-1500
automation system and the ET 200MP distributed I/O system gathered together in one file.
You can find the Manual Collection on the Internet
(https://support.industry.siemens.com/cs/ww/en/view/86140384).
SIMATIC S7-1500 comparison list for programming languages
The comparison list contains an overview of which instructions and functions you can use for
which controller families.
You can find the comparison list on the Internet
(https://support.industry.siemens.com/cs/ww/en/view/86630375).
"mySupport"
With "mySupport", your personal workspace, you make the best out of your Industry Online
Support.
In "mySupport", you can save filters, favorites and tags, request CAx data and compile your
personal library in the Documentation area. In addition, your data is already filled out in
support requests and you can get an overview of your current requests at any time.
You must register once to use the full functionality of "mySupport".
You can find "mySupport" on the Internet (https://support.industry.siemens.com/My/ww/en).
"mySupport" - Documentation
In the Documentation area in "mySupport" you can combine entire manuals or only parts of
these to your own manual.
You can export the manual as PDF file or in a format that can be edited later.
You can find "mySupport" - Documentation on the Internet
(http://support.industry.siemens.com/My/ww/en/documentation).

Documentation guide
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
Manual, 12/2017, A5E40898741-AA 11
"mySupport" - CAx data
In the CAx data area in "mySupport", you can access the current product data for your CAx
or CAe system.
You configure your own download package with a few clicks.
In doing so you can select:
●Product images, 2D dimension drawings, 3D models, internal circuit diagrams, EPLAN
macro files
●Manuals, characteristics, operating manuals, certificates
●Product master data
You can find "mySupport" - CAx data on the Internet
(http://support.industry.siemens.com/my/ww/en/CAxOnline).
Application examples
The application examples support you with various tools and examples for solving your
automation tasks. Solutions are shown in interplay with multiple components in the system -
separated from the focus on individual products.
You will find the application examples on the Internet
(https://support.industry.siemens.com/sc/ww/en/sc/2054).
TIA Selection Tool
With the TIA Selection Tool, you can select, configure and order devices for Totally
Integrated Automation (TIA).
This tool is the successor of the SIMATIC Selection Tool and combines the known
configurators for automation technology into one tool.
With the TIA Selection Tool, you can generate a complete order list from your product
selection or product configuration.
You can find the TIA Selection Tool on the Internet
(http://w3.siemens.com/mcms/topics/en/simatic/tia-selection-tool).

Documentation guide
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
12 Manual, 12/2017, A5E40898741-AA
SIMATIC Automation Tool
You can use the SIMATIC Automation Tool to perform commissioning and maintenance
activities simultaneously on various SIMATIC S7 stations as a bulk operation independent of
the TIA Portal.
General function overview:
●Network browsing and creation of a table showing the accessible devices in the network.
●Flashing of device LEDs or HMI display to locate a device
●Downloading of addresses (IP, subnet, gateway) to a device
●Downloading the PROFINET name (station name) to a device
●Placing a CPU in RUN or STOP mode
●Setting the time in a CPU to the current time of your PG/PC
●Downloading a new program to a CPU or an HMI device
●Downloading from CPU, downloading to CPU or deleting recipe data from a CPU
●Downloading from CPU or deleting data log data from a CPU
●Backup/restore of data from/to a backup file for CPUs and HMI devices
●Downloading service data from a CPU
●Reading the diagnostics buffer of a CPU
●Performing a CPU memory reset
●Resetting devices to factory settings
●Downloading a firmware update to a device
You can find the SIMATIC Automation Tool on the Internet
(https://support.industry.siemens.com/cs/ww/en/view/98161300).
PRONETA
With SIEMENS PRONETA (PROFINET network analysis), you analyze the PROFINET
network during commissioning. PRONETA features two core functions:
●The topology overview independently scans PROFINET network and all connected
components.
●The IO check is a fast test of the wiring and the module configuration of a system.
You can find SIEMENS PRONETA on the Internet
(https://support.industry.siemens.com/cs/ww/en/view/67460624).

CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
Manual, 12/2017, A5E40898741-AA 13
Product overview
2
2.1
Applications of the S7-1500 CPUs
Application area
The SIMATIC S7-1500 is the modular control system for numerous automation applications
in discrete automation.
The modular and fanless design, the simple implementation of distributed structures and the
user-friendly handling transform the SIMATIC S7-1500 into a cost-effective and convenient
solution for various tasks.
Areas of application of the SIMATIC S7-1500 are, for example:
●Special-purpose machines
●Textile machinery
●Packaging machines
●General mechanical engineering
●Controller engineering
●Machine tool engineering
●Installation engineering
●Electrical industry and crafts
●Automotive
●Water/waste water
●Food & Beverage
Areas of application of the SIMATIC S7-1500T are, for example:
●Packaging machines
●Converting application
●Assembly automation
Several CPUs with various levels of performance and a comprehensive range of modules
with many convenient features are available. Fail-safe CPUs enable use in fail-safe
applications. The modular design allows you to use only the modules that you need for your
application. The controller can be retrofitted with additional modules at any time to expand its
range of tasks.
The high immunity to noise and high resistance to shock and vibration stress make the
SIMATIC S7-1500 suitable for universal use.

Product overview
2.1 Applications of the S7-1500 CPUs
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
14 Manual, 12/2017, A5E40898741-AA
Performance segments of the standard, compact, fail-safe and technology CPUs
The CPUs can be used for smaller and medium-sized applications, as well as for the high-
end range of machine and plant automation.
Table 2- 1 Standard CPUs
CPU
Performance segment
PROFIBUS
interfaces
PROFINET I
O RT/IRT
interface
PROFINET
IO RT inter-
face
PROFINET
basic func-
tionality
Work
memory
Processing
time for bit
operations
CPU 1511-1 PN Standard CPU for small- to
medium-sized applications
-- 1 -- -- 1.15 MB 60 ns
CPU 1513-1 PN Standard CPU for medium-
sized applications
-- 1 -- -- 1.8 MB 40 ns
CPU 1515-2 PN Standard CPU for small- to
medium-sized applications
-- 1 1 -- 3.5 MB 30 ns
CPU 1516-3
PN/DP
Standard CPU for high-end
applications and communi-
cation tasks
1 1 1 -- 6 MB 10 ns
CPU 1517-3
PN/DP
Standard CPU for high-end
applications and communi-
cation tasks
1 1 1 -- 10 MB 2 ns
CPU 1518-4
PN/DP
CPU 1518-4
PN/DP MFP
Standard CPU for high-
performance applications,
demanding communica-
tions tasks and very short
reaction times
1 1 1 1 24 MB 1 ns
Table 2- 2 Compact CPUs
CPU
Performance segment
PROFIBUS
interfaces
PROFINET
IO RT/IRT
interfaces
PROFINET
IO RT
interface
PROFINET
basic func-
tionality
Work memory
Pro-
cessing
time for bit
operations
CPU 1511C-1 PN Compact CPU for small to
medium applications
-- 1 -- -- 1.175 MB 60 ns
CPU 1512C-1 PN Compact CPU for medium
applications
-- 1 -- -- 1.25 MB 48 ns
Table 2- 3 Fail-safe CPUs
CPU
Performance segment
PROFIBUS
interfaces
PROFINET
IO RT/IRT
interfaces
PROFINET
IO RT
interface
PROFINET
basic func-
tionality
Work memory
Pro-
cessing
time for bit
operations
CPU 1511F-1 PN Fail-safe CPU for smaller
to medium-sized applica-
tions
-- 1 -- -- 1.225 MB 60 ns
CPU 1511TF-1 P
N
Fail-safe technology CPU
for small to mid-range
applications
-- 1 -- -- 1.225 MB 60 ns

Product overview
2.1 Applications of the S7-1500 CPUs
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
Manual, 12/2017, A5E40898741-AA 15
CPU
Performance segment
PROFIBUS
interfaces
PROFINET
IO RT/IRT
interfaces
PROFINET
IO RT
interface
PROFINET
basic func-
tionality
Work memory
Pro-
cessing
time for bit
operations
CPU 1513F-1 PN Fail-safe CPU for medium-
sized applications
-- 1 -- -- 1.95 MB 40 ns
CPU 1515F-2 PN Fail-safe CPU for medium-
sized to large applications
-- 1 1 -- 3.75 MB 30 ns
CPU 1515TF-2
PN
Fail-safe technology CPU
for demanding applications
and communication tasks
-- 1 1 -- 3.75 MB 30 ns
CPU 1516F-3
PN/DP
Fail-safe CPU for demand-
ing applications and com-
munications tasks
1 1 1 -- 6.5 MB 10 ns
CPU 1516TF-3
PN/DP
Fail-safe technology CPU
for demanding applications
and communication tasks
1 1 1 -- 6.5 MB 10 ns
CPU 1517F-3
PN/DP
Fail-safe CPU for demand-
ing applications and com-
munications tasks
1 1 1 -- 11 MB 2 ns
CPU 1517TF-3
PN/DP
Fail-safe technology CPU
for demanding applications
and communication tasks
1 1 1 -- 11 MB 2 ns
CPU 1518F-4
PN/DP
CPU 1518F-4
PN/DP MFP
Fail-safe CPU for high-
performance applications,
demanding communica-
tions tasks and very short
reaction times
1 1 1 1 26 MB 1 ns
Table 2- 4 Technology CPUs
CPU
Performance segment
PROFIBUS
interfaces
PROFINET
IO RT/IRT
interfaces
PROFINET
IO RT
interface
PROFINET
basic func-
tionality
Work memory
Pro-
cessing
time for bit
operations
CPU 1511T-1 PN Technology CPU for small-
to medium-sized applica-
tions
-- 1 -- -- 1.225 MB 60 ns
CPU 1515T-2 PN Technology CPU for mid-
range to large applications
-- 1 1 -- 3.75 MB 30 ns
CPU 1516T-3
PN/DP
Technology CPU for high-
end applications and
communication tasks
1 1 1 -- 6.5 MB 10 ns
CPU 1517T-3
PN/DP
Technology CPU for high-
end applications and
communication tasks
1 1 1 -- 11 MB 2 ns
CPU 1511TF-1
PN
CPU 1515TF-2
PN
CPU 1516TF-3
PN/DP
CPU 1517TF-3
PN/DP
These CPUs are described in the fail-safe CPUs

Product overview
2.1 Applications of the S7-1500 CPUs
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
16 Manual, 12/2017, A5E40898741-AA
Performance segments of compact CPUs
The compact CPUs can be used for smaller to medium-sized applications and have an
integrated analog and digital on-board I/O as well as integrated technology functions. The
following table shows the differences in performance between the two compact CPUs.
CPU 1511C-1 PN
CPU 1512C-1 PN
Integrated analog inputs/outputs
5 inputs/2 outputs
5 inputs/2 outputs
Integrated digital inputs/outputs 16 inputs/16 outputs 32 inputs/32 outputs
High-speed counters
6
6
Frequency meter
6 (max. 100 kHz)
6 (max. 100 kHz)
Period duration measurement
6 channels
6 channels
Pulse width modulation (PWM output)
Max. 4 (up to 100 kHz)
Max. 4 (up to 100 kHz)
Pulse Train Output (PTO output)
Max. 4 (up to 100 kHz)
Max. 4 (up to 100 kHz)
Frequency output
Up to 100 kHz
Up to 100 kHz

Product overview
2.1 Applications of the S7-1500 CPUs
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
Manual, 12/2017, A5E40898741-AA 17
Integrated Motion Control technology functions
All CPUs of SIMATIC S7-1500
support Motion Control technology functions. STEP 7 offers
Motion Control instructions standardized according to PLCopen for configuring and
connecting a drive to the CPU.
S7-1500 Motion Control supports the following technology objects:
●Speed-controlled axes
●Positioning axes
●Synchronous axes
●External encoders
●Output cams
●Cam tracks
●Measuring inputs
The technology CPUs of the SIMATIC S7-1500
offer enhanced Motion Control functions:
●Advanced synchronization functions
–Synchronization with specification of the synchronous position
–Actual value coupling
–Shifting of the master value at following axis
–Camming
●Up to 4 encoders or measuring systems as actual position for position control
The technology CPUs of the SIMATIC S7-1500
additionally support the following technology
objects: – Cam – Kinematics
●Cam
●Kinematics
●Controlling of kinematics, such as
–Cartesian portals
–Roller pickers
–Delta pickers
–SCARA
Due to the supported technology functions, the S7-1500T CPUs are suitable for controlling
packaging machines, converting applications, assembly automation, etc.
Additional integrated technology functions
For effective commissioning, diagnostics and fast optimization of drives and controls, the
SIMATIC S7-1500 controller family offers extensive trace functions for all CPU tags.
In addition to drive integration, the SIMATIC S7-1500 has a PID compact closed-loop
controller; easy-to-configure blocks allow automatic optimization of the controller parameters
for optimized control quality.

Product overview
2.1 Applications of the S7-1500 CPUs
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
18 Manual, 12/2017, A5E40898741-AA
Other technology functions
Technology modules also implement functions such as high-speed counting, position
detection, measuring functions and pulse generators (PTO, PWM and frequency output). For
compact CPU 1511C-1 PN and CPU 1512C-1 PN CPUs, these functions are already
integrated and can be implemented without additional technology modules.
SIWAREX is a versatile and flexible weighing module which you can use as a static scale for
operation.
Security Integrated
In conjunction with STEP 7 (TIA Portal), each CPU offers password-based know-how
protection against unauthorized reading out or modification of the program blocks.
The copy protection provides reliable protection against unauthorized reproduction of
program blocks. With copy protection, individual blocks on the SIMATIC memory card are
linked to its serial number so that the block can only be executed if the configured memory
card is inserted in the CPU.
In addition, four different authorization levels in the CPUs can be used to assign different
access rights to various user groups.
Improved manipulation protection allows the CPUs to detect changed or unauthorized
transfers of the engineering data.
The use of an Ethernet CP (CP 1543-1) provides the user with additional access protection
by means of a firewall and/or the option of secured VPN connections.
Safety Integrated
The fail-safe CPUs are intended for users who want to implement demanding standard and
fail-safe applications both centrally and distributed.
These fail-safe CPUs allow the processing of standard and safety programs on a single
CPU. This allows fail-safe data to be evaluated in the standard user program. The integration
also provides the system advantages and the extensive functionality of SIMATIC for fail-safe
applications.
The fail-safe CPUs are certified for use in safety mode up to:
●Safety class (Safety Integrity Level) SIL 3 according to IEC 61508:2010
●Performance Level (PL) e and Category 4 according to ISO 13849-1:2006 or according to
EN ISO 13849-1:2008
Additional password protection for F-configuration and F-program is set up for IT security.

Product overview
2.1 Applications of the S7-1500 CPUs
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
Manual, 12/2017, A5E40898741-AA 19
Design and handling
All CPUs of the SIMATIC S7-1500 product series feature a display with plain text
information. The display provides the user with information on the order numbers, firmware
version, and serial number of all connected modules. In addition, the IP address of the CPU
and other network settings can be adapted locally without a programming device. Error
messages are immediately shown on the display in plain text. In the case of servicing, plant
downtimes are minimized by quick access to diagnostics alarms. Detailed information about
this and a multitude of other display functions is available in the SIMATIC S7-1500 Display
Simulator (http://www.automation.siemens.com/salesmaterial-as/interactive-manuals/getting-
started_simatic-s7-1500/disp_tool/start_en.html).
Uniform front connectors for all modules and integrated potential jumpers for flexible
formation of potential groups simplifies storage. Additional components such as circuit
breakers, relays, etc., can be installed quickly and easily, since a DIN rail is implemented in
the rail of the S7-1500. The CPUs of the SIMATIC S7-1500 product series can be expanded
centrally and modularly with signal modules. Space-saving expansion enables flexible
adaptation to each application.
The system cabling for digital signal modules enables fast and clear connection to sensors
and actuators from the field (fully modular connection consisting of front connector modules,
connection cables and I/O modules), as well as the easy wiring inside the control cabinet
(flexible connection consisting of front connectors with assembled single conductors).
System diagnostics and messages
Integrated system diagnostics is enabled by default for the CPUs. The different types of
diagnostics are configured instead of programmed. System diagnostics information is shown
uniformly and in plain text on the display of the CPU, in STEP 7 (TIA Portal), on the HMI and
on the Web server, even for alarms related to drives. This information is available in RUN
mode, but also in STOP mode of the CPU. The diagnostics information is updated
automatically when you configure new hardware components.
The CPU is available as a central interrupt server in up to three project languages. The HMI
takes over the display in the project languages specified for the CPU. If you require message
texts in additional languages, you can load these via the configured connection to your HMI.
The CPU, STEP 7 and your HMI guarantee data consistency without additional engineering
steps. The maintenance work is easier.

Product overview
2.2 Hardware properties and firmware functions
CPU 1512C-1 PN (6ES7512-1CK01-0AB0)
20 Manual, 12/2017, A5E40898741-AA
2.2
Hardware properties and firmware functions
The CPU 1512C-1 PN consists of a CPU part, an analog on-board I/O module (X10) and a
digital on-board I/O module (X11 and X12). When configured in the TIA Portal, the compact
CPU therefore occupies a single shared slot (slot 1).
The properties and functions of the CPU part and the analog and digital on-board I/O
modules can be found in the subsections below. The
properties
describe the hardware
features of the CPU part and the analog and digital on-board I/O modules. The
functions
describe the functions of the firmware of the CPU part and the analog and digital on-board
I/O modules.
Article number
6ES7512-1CK01-0AB0
Accessories
The following accessories are included in the scope of delivery and can also be ordered
separately as spare parts:
●3 x front connector (push-in terminals) including cable ties
●3 x shield clamp
●3 x shield terminal
●3 x infeed element (push-in terminals)
●3 x labeling strip
●3 x universal front cover
For more information on accessories, refer to the S7-1500, ET 200MP system manual
(http://support.automation.siemens.com/WW/view/en/59191792).
