Siemens SIMATIC S7 User manual

SIMATIC Automation Tool V2.1 user
guide
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
SIMATIC
S7
SIMATIC Automation Tool V2.1
user guide
Manual
V2.1.1 07/2016
A5E33042676
-AC
Preface
SIMATIC Automation Tool
overview
1
Prerequisites and
communication setup
2
Tool operations
3
Saving your device table
information
4
Menu, toolbar, and shortcut
key reference
5
SIMATIC Automation Tool
API for .NET framework
6
SIMATIC Automation Tool
device support
7
Network example and API
interfaces
A

Siemens AG
Division Digital Factory
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E33042676-AC
Ⓟ
07/2016 Subject to change
Copyright © Siemens AG 2016.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

SIMATIC Automation Tool V2.1 user guide
Manual, V2.1.1 07/2016, A5E33042676-AC 3
Preface
Service and support
In addition to our documentation, Siemens offers technical expertise on the Internet and on
the customer support web site (https://www.siemens.com/automation/).
Contact your Siemens distributor or sales office for assistance in answering any technical
questions, for training, or for ordering S7 products. Because your sales representatives are
technically trained and have the most specific knowledge about your operations, process
and industry, as well as about the individual Siemens products that you are using, they can
provide the fastest and most efficient answers to any problems you might encounter.
Document source language
The English version of the SIMATIC Automation Tool user guide is the authoritative (original)
language for SIMATIC Automation Tool information. All translated manuals refer back to the
English manual as the authoritative and/or original source. Siemens identifies the English
manual as the authoritative and/or original source in the case of discrepancies between the
translated manuals.
Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens’ products and solutions only form one element of such a concept.
Customer is responsible to prevent unauthorized access to its plants, systems, machines
and networks. Systems, machines and components should only be connected to the
enterprise network or the internet if and to the extent necessary and with appropriate security
measures (e.g. use of firewalls and network segmentation) in place.
Additionally, Siemens’ guidance on appropriate security measures should be taken into
account. For more information about industrial security, please visit
(http://www.industry.siemens.com/topics/global/en/industrial-security/Pages/default.aspx).
Siemens’ products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends to apply product updates as soon as available and to
always use the latest product versions. Use of product versions that are no longer supported,
and failure to apply latest updates may increase customer’s exposure to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed under (https://support.industry.siemens.com/cs/us/en/).

Preface
SIMATIC Automation Tool V2.1 user guide
4Manual, V2.1.1 07/2016, A5E33042676-AC

SIMATIC Automation Tool V2.1 user guide
Manual, V2.1.1 07/2016, A5E33042676-AC 5
Table of contents
Preface ................................................................................................................................................... 3
1 SIMATIC Automation Tool overview ........................................................................................................ 9
1.1 Managing networks...................................................................................................................9
1.2 Network access.......................................................................................................................13
1.3 Network options ......................................................................................................................14
1.4 .NET API (application interface) .dll file ..................................................................................16
2 Prerequisites and communication setup ................................................................................................ 17
2.1 PG/PC Operating system requirement ...................................................................................17
2.2 Installing the SIMATIC Automation Tool.................................................................................17
2.3 Starting the SIMATIC Automation Tool...................................................................................18
2.4 CPU configuration requirements.............................................................................................18
2.5 Communication setup .............................................................................................................21
3 Tool operations ..................................................................................................................................... 25
3.1 CPU passwords ......................................................................................................................25
3.2 Scan a network and use the device table...............................................................................26
3.3 Download new IP, subnet, and gateway addresses...............................................................32
3.4 Download new PROFINET device names..............................................................................33
3.5 Set CPUs to RUN or STOP mode ..........................................................................................34
3.6 Flash the LEDs on devices .....................................................................................................36
3.7 Download new programs to CPUs..........................................................................................37
3.8 Install new firmware in CPUs and modules ............................................................................40
3.9 Backup and Restore CPU data...............................................................................................45
3.10 Reset CPUs and modules to factory default values ...............................................................47
3.11 Reset CPU memory ................................................................................................................48
3.12 Upload service data from CPUs .............................................................................................49
3.13 Set time in CPUs.....................................................................................................................51
3.14 Read diagnostic buffer in a CPU ............................................................................................52
3.15 Execution order of operations.................................................................................................53
4 Saving your device table information ..................................................................................................... 55
4.1 Save/Save as - Device table stored in encrypted .sat format.................................................55
4.2 Import/Export - Device table loaded from/stored in open .csv format ....................................56

Table of contents
SIMATIC Automation Tool V2.1 user guide
6Manual, V2.1.1 07/2016, A5E33042676-AC
5 Menu, toolbar, and shortcut key reference............................................................................................. 59
5.1 Main menu ............................................................................................................................. 59
5.1.1 File menu ............................................................................................................................... 59
5.1.2 Edit menu ............................................................................................................................... 60
5.1.3 Network menu........................................................................................................................ 61
5.1.4 Tools menu ............................................................................................................................ 62
5.1.5 Help menu.............................................................................................................................. 64
5.2 Toolbar icons.......................................................................................................................... 65
5.3 Shortcut keys ......................................................................................................................... 66
6 SIMATIC Automation Tool API for .NET framework ............................................................................... 67
6.1 API Introduction...................................................................................................................... 67
6.2 Architectural overview............................................................................................................ 68
6.3 Referencing the API in a customer application...................................................................... 70
6.4 Common support classes ...................................................................................................... 71
6.4.1 The EncryptedString class ..................................................................................................... 71
6.4.2 The Fail-Safe password ......................................................................................................... 72
6.4.3 The Result class..................................................................................................................... 72
6.5 The Network class.................................................................................................................. 73
6.5.1 Network constructor ............................................................................................................... 73
6.5.2 QueryNetworkInterfaceCards method ................................................................................... 74
6.5.3 SetCurrentNetworkInterface method ..................................................................................... 75
6.5.4 CurrentNetworkInterface property.......................................................................................... 75
6.5.5 ScanNetworkDevices method................................................................................................ 76
6.6 The IProfinetDeviceCollection class ...................................................................................... 77
6.6.1 Iterating items in the collection............................................................................................... 77
6.6.2 Filtering items in the collection............................................................................................... 78
6.6.2.1 Collection items...................................................................................................................... 78
6.6.2.2 FilterByDeviceFamily method ................................................................................................ 78
6.6.2.3 FilterOnlyCPUs method ......................................................................................................... 79
6.6.3 Finding a specific device in the collection.............................................................................. 80
6.6.3.1 FindDeviceByIP method ........................................................................................................ 80
6.6.3.2 FindDeviceByMAC method.................................................................................................... 81
6.6.4 Serialization............................................................................................................................ 82
6.6.4.1 Transferring a collection to/from an external data file............................................................ 82
6.6.4.2 WriteToStream method.......................................................................................................... 82
6.6.4.3 ReadFromStream method ..................................................................................................... 83
6.7 The IProfinetDevice interface................................................................................................. 84
6.7.1 IProfinetDevice properties...................................................................................................... 84
6.7.2 IProfinetDevice methods........................................................................................................ 87
6.7.2.1 RefreshStatus method ........................................................................................................... 87
6.7.2.2 FirmwareUpdate method ....................................................................................................... 88
6.7.2.3 FlashLED method .................................................................................................................. 90
6.7.2.4 Reset method......................................................................................................................... 91
6.7.2.5 SetIP method ......................................................................................................................... 92
6.7.2.6 SetProfinetName method....................................................................................................... 93
6.7.3 IProfinetDevice events ........................................................................................................... 94
6.7.3.1 DataChanged event ............................................................................................................... 94

Table of contents
SIMATIC Automation Tool V2.1 user guide
Manual, V2.1.1 07/2016, A5E33042676-AC 7
6.7.3.2 ProgressChanged event .........................................................................................................95
6.8 IModuleCollection class and module properties .....................................................................97
6.8.1 The IModuleCollection class...................................................................................................97
6.8.2 The IModule interface .............................................................................................................98
6.9 The ICPU interface .................................................................................................................99
6.9.1 Identifying CPU devices in an IProfinetDeviceCollection .......................................................99
6.9.2 ICPU properties ....................................................................................................................100
6.9.3 ICPU methods.......................................................................................................................100
6.9.3.1 Protected CPUs and passwords...........................................................................................100
6.9.3.2 Backup method .....................................................................................................................101
6.9.3.3 GetCurrentDateTime method ...............................................................................................102
6.9.3.4 GetDiagnosticsBuffer method...............................................................................................103
6.9.3.5 GetOperatingState method...................................................................................................104
6.9.3.6 MemoryReset method...........................................................................................................105
6.9.3.7 ProgramUpdate method........................................................................................................106
6.9.3.8 ResetToFactory method .......................................................................................................107
6.9.3.9 Restore method ....................................................................................................................108
6.9.3.10 SetOperatingState method ...................................................................................................109
6.9.3.11 SetCurrentDateTime method................................................................................................110
6.9.3.12 UploadServiceData method..................................................................................................111
6.9.4 RemoteInterfaces properties ................................................................................................112
6.9.4.1 Decentralized I/O modules ...................................................................................................112
6.9.4.2 IRemoteInterface properties .................................................................................................113
6.10 Enumerations........................................................................................................................116
6.10.1 DataChangedType................................................................................................................116
6.10.2 DeviceFamily ........................................................................................................................116
6.10.3 ErrorCode .............................................................................................................................117
6.10.4 OperatingState......................................................................................................................118
6.10.5 OperatingStateREQ ..............................................................................................................118
6.10.6 ProgressAction......................................................................................................................119
6.10.7 RemoteInterfaceType ...........................................................................................................119
6.10.8 FeatureSupport .....................................................................................................................120
7 SIMATIC Automation Tool device support ........................................................................................... 121
7.1 Unrecognized firmware versions and devices ......................................................................121
7.2 S7-1200 CPU support...........................................................................................................121
7.3 S7-1500 CPU support...........................................................................................................122
7.4 ET 200SP CPU support (Distributed I/O controller based on ET 200SP and S7-1500) ......123
7.5 ET 200SP support (PROFINET I/O) .....................................................................................124
7.6 ET 200MP support (PROFINET I/O) ....................................................................................124
7.7 ET 200AL support (PROFINET I/O) .....................................................................................125
7.8 ET 200S support (PROFINET I/O) .......................................................................................126
7.9 ET 200M support (PROFINET I/O).......................................................................................127
7.10 ET 200eco support (PROFINET I/O) ....................................................................................127
7.11 ET 200pro support (PROFINET I/O).....................................................................................128

Table of contents
SIMATIC Automation Tool V2.1 user guide
8Manual, V2.1.1 07/2016, A5E33042676-AC
A Network example and API interfaces....................................................................................................129
A.1 Network example ................................................................................................................. 129
Index ...................................................................................................................................................133

SIMATIC Automation Tool V2.1 user guide
Manual, V2.1.1 07/2016, A5E33042676-AC 9
SIMATIC Automation Tool overview
1
1.1
Managing networks
Managing networks of SIMATIC devices
After a control program is created and verified with the Siemens TIA Portal software, the
SIMATIC Automation Tool can be used in the field for configuring, operating, maintaining,
and documenting automation networks.
If you are managing a network with many devices, the SIMATIC Automation Tool can
simplify operations and save time by automatically processing a group of devices with
multiple processing threads. While a PG/PC communication processing thread is waiting for
a SIMATIC device's task complete message, other threads can use this time to communicate
with other devices in the group.
Automation Tool operations
●Scan the network and create a table that maps the accessible devices on the network.
Unconfigured and configured CPUs and modules are included in the table that is stored
in a secure *.sat project file.
●Flash LEDs on a device to help physically locate the device
●Download addresses (IP, subnet, gateway) to a device
●Download PROFINET name (station name) to a device
●Set the time in a CPU to the current time in your PG/PC (Programmer/Personal
Computer)
●Download a new program to a CPU
●Download a firmware update to a CPU or module
●Put a CPU in RUN or STOP mode
●Perform a CPU Memory reset
●Read the diagnostic buffer of a CPU
●Upload service data from a CPU
●Backup/Restore CPU data to/from a backup file
●Reset devices to factory default values

SIMATIC Automation Tool overview
1.1 Managing networks
SIMATIC Automation Tool V2.1 user guide
10 Manual, V2.1.1 07/2016, A5E33042676-AC
SIMATIC device support
The SIMATIC Automation Tool supports standard and fail-safe CPUs and I/O modules.
The safety relevant operations Reset to factory defaults, Restore from backup file, and
Program update are not allowed on fail-safe CPUs.
For some devices, some of the SIMATIC Automation Tool operations are not supported.
Click on a device for support details.
S7-1200 CPU (Page 121)
S7-1500 CPU (Page 122)
ET 200SP CPU (Distributed controller based on ET 200SP and S7-1500) (Page 123)
ET 200SP (PROFINET I/O) (Page 124)
ET 200MP (PROFINET I/O) (Page 124)
ET 200AL (PROFINET I/O) (Page 125)
ET 200S (PROFINET I/O) (Page 126)
ET 200M PROFINET I/O) (Page 127)
ET 200eco (PROFINET I/O) (Page 127)
ET 200pro (PROFINET I/O) (Page 128)

SIMATIC Automation Tool overview
1.1 Managing networks
SIMATIC Automation Tool V2.1 user guide
Manual, V2.1.1 07/2016, A5E33042676-AC 11
Example S7-1200 network installation
Panel shop fabrication and initial program load
●Each CPU uses the same hardware configuration and control program
●The CPU PROFINET configuration uses "Set IP Address on the device" and "Set
PROFINET device name on the device" options
●Each Panel is identical
●The panel shop uses an SD Card or the TIA Portal to load the CPU program.

SIMATIC Automation Tool overview
1.1 Managing networks
SIMATIC Automation Tool V2.1 user guide
12 Manual, V2.1.1 07/2016, A5E33042676-AC
Field installation and operations
●Scan a network to find CPUs and modules
●Flash LEDs to identify a device
●Assign IP addresses and PROFINET names for each device, when you set up your
network
●Set the time in CPUs to the current time in your PG/PC
●Update a CPU program/firmware and module firmware
●Put CPUs in RUN or STOP mode
●Read a CPU diagnostic buffer and upload service data
●Reset a CPU memory
●Perform CPU data backup and restore operations
●Document and save your network information in a standard text .csv file or an encrypted
and password protected .sat file.
●Save time working with devices as a group and using parallel processing threads

SIMATIC Automation Tool overview
1.2 Network access
SIMATIC Automation Tool V2.1 user guide
Manual, V2.1.1 07/2016, A5E33042676-AC 13
1.2
Network access
Communicating with Siemens devices
PROFINET devices connected directly to a network are discovered by using the MAC
(Media Access Control) address. A MAC address is unique to each device, cannot be
changed, and is printed on the device. Connected PROFINET devices are discovered
whether they are configured with an IP, subnet, and gateway address, or not configured
(addresses are 0.0.0.0).
However, a directly connected CPU must have a valid IP address, before communication
modules, signal modules, and decentralized I/O that are located behind the CPU become
visible in the SIMATIC Automation Tool device table.
For example, an S7-1500 CPU has a PROFINET network connection to the SIMATIC
Automation Tool and uses a local CP card to connect with another PROFINET network
where decentralized I/O are connected. You must assign a valid IP address to the S7-1500
CPU before the decentralized I/O network is visible in the SIMATIC Automation Tool device
table.
The type of network access you have depends on the command that you execute, as shown
in the following table.
SIMATIC Automation Tool
command
Device
address
used
Must provide CPU
password for a pro-
tected CPU
PG/PC and device connectivity
Scan (discover CPUs and I/O de-
vices)
MAC No •
Local network
: You can access devices
through Ethernet switches, but cannot access
devices on another network through an IP ad-
dress router.
•
VPN
(Virtual Private Network) connection to a
local network
Flash LEDs on devices
MAC
No
Set IP address, subnet mask, and
gateway address on devices
MAC No
Set PROFINET name on devices
MAC
No
Reset devices to factory default
values
(for PROFINET I/O devices only)
MAC -
Set CPU time to PG/PC time
IP
Yes
•
Local network
: You can access devices
through Ethernet switches.
•
Remote network
: You can access devices on
another network through an IP address router.
•
VPN
connection to local network
Download program to CPUs
IP
Yes
Download new firmware to CPUs
and I/O devices
IP Yes
Put CPUs in RUN or STOP
IP
Yes
Set CPU time to PG/PC time
IP
Yes
Reset CPU memory
IP
Yes
Read CPU Diagnostic buffer
IP
Yes
Upload service data from CPUs
IP
Yes
Backup/restore CPU data
IP
Yes
Reset devices to factory default
values
(for CPU devices only)
IP Yes

SIMATIC Automation Tool overview
1.3 Network options
SIMATIC Automation Tool V2.1 user guide
14 Manual, V2.1.1 07/2016, A5E33042676-AC
Note
IP subnet mask assignment on a local network
The PG/PC running the SIMATIC Automation Tool and devices connected to the local
network must use the same subnet mask assignment.
1.3
Network options
Local and remote networks
The following examples show local and remote networks that the SIMATIC Automation Tool
can use. The diagrams are simplified to show basic connectivity and do not show the local
I/O, CPs, and distributed I/O devices (PROFINET and PROFIBUS) that are also accessible.
Different network topologies are also possible.
IP addressing and therefore valid network IP addresses are necessary to get access behind
Ethernet IP routers. You can fill the SIMATIC Automation Tool device table by automatically
scanning a network (Page 26) or by importing a list (Page 56)that identifies stations behind
a router.
Example 1: S7-1200 local network

SIMATIC Automation Tool overview
1.3 Network options
SIMATIC Automation Tool V2.1 user guide
Manual, V2.1.1 07/2016, A5E33042676-AC 15
Example 2: S7-1200 remote network
Example 3: S7-1200 combined local and remote networks

SIMATIC Automation Tool overview
1.4 .NET API (application interface) .dll file
SIMATIC Automation Tool V2.1 user guide
16 Manual, V2.1.1 07/2016, A5E33042676-AC
1.4
.NET API (application interface) .dll file
The Microsoft .NET API used by the SIMATIC Automation Tool is documented in this user
guide. You can create your own application software that uses the API to perform the same
device operations as the SIMATIC Automation Tool.
The SIMATIC Automation Tool must be installed on any PG/PC that uses this API. The
SIMATIC Automation Tool and your application software use the API .dll file and additional
S7 communication files. The SIMATIC Automation Tool installation provides all the files that
you need.
API .dll file
The AutomationToolAPI.dll file is located in the folder where the SIMATIC Automation Tool is
installed.
Compatibility with previous versions
The SIMATIC Automation Tool API has been redesigned for V2.1. Any programs previously
written against this API must be refactored. For details of the V2.1 API, refer to the SIMATIC
Automation Tool API for .NET framework (Page 67) chapter.

SIMATIC Automation Tool V2.1 user guide
Manual, V2.1.1 07/2016, A5E33042676-AC 17
Prerequisites and communication setup
2
2.1
PG/PC Operating system requirement
PG/PC operating systems
The SIMATIC Automation Tool V2.1 supports the following operating systems.
●Windows 7 Home Premium SP1 (32 and 64 bit)
●Windows 7 Professional SP1 (32 and 64 bit)
●Windows 7 Enterprise SP1 (32 and 64 bit)
●Windows 7 Ultimate SP1 (32 and 64 bit)
●Windows 8.1 (64 bit only)
●Windows 8.1 Professional (64 bit only)
●Windows 8.1 Enterprise (64 bit only)
2.2
Installing the SIMATIC Automation Tool
Tool installation
1. On your PG/PC, save all your work in progress and close all applications, before installing
the SIMATIC Automation Tool.
2. Execute the SIMATICAutomationToolSetup.exe file to begin the installation.
Installation Restrictions
Only one version of the SIMATIC Automation Tool can be installed on a PG/PC. If you have
a previously installed version (V1.0 or V2.0) this version must be uninstalled before installing
V2.1.
The setup program for SIMATIC Automation Tool V2.1 checks for a previous installation.
This check results in one of the following behaviors:
●If no version of SIMATIC Automation Tool is found, the setup proceeds normally.
●If a V2.1 installation is found, the setup presents the options to "Repair" or "Uninstall" the
previous installation. This is standard behavior for setup applications.
●If a previous version of the application (V1.0 or V2.0) is found, you are informed that the
previous version will be automatically uninstalled to proceed. You may either cancel the
setup, or proceed.
●If a newer version of the application (> V2.1) is found, you are informed of this fact and
the setup does not proceed.

Prerequisites and communication setup
2.3 Starting the SIMATIC Automation Tool
SIMATIC Automation Tool V2.1 user guide
18 Manual, V2.1.1 07/2016, A5E33042676-AC
2.3
Starting the SIMATIC Automation Tool
Options for starting the SIMATIC Automation Tool:
●Double-click the SIMATIC Automation Tool shortcut icon on your desktop.
●Use the Windows Start button.
–Click the Windows start button and "All Programs".
–Click the "Siemens Automation" folder, then the "SIMATIC Automation Tool" folder,
and finally "Automation Tool".
●Start the Windows command prompt (cmd.exe) and enter the executable file name and
optional project parameter.
AutomationTool.exe [projectname.sat].
2.4
CPU configuration requirements
Ethernet address configuration
If you want the SIMATIC Automation Tool to set the IP address or PROFINET name of a
CPU, then your TIA portal project must enable these actions in the CPU device
configuration. Use the TIA portal to view and modify a program's IP protocol setting, as
shown in the following S7-1200 example.
IP address and PROFINET name change
●It Is
possible
for CPUs directly connected to the network that is connected to the
SIMATIC Automation Tool (including connection through an Ethernet switch).
●It is
not possible
for CPU's with an indirect connection through a CP module, or a CPU's
secondary Ethernet port when the direct connection is to the primary Ethernet port.
●It is
not possible
for CPU's on another network with a connection to the SIMATIC
Automation Tool that passes through an IP address router.

Prerequisites and communication setup
2.4 CPU configuration requirements
SIMATIC Automation Tool V2.1 user guide
Manual, V2.1.1 07/2016, A5E33042676-AC 19
S7-1200 example configuration
1. Click the PROFINET port on the device configuration CPU image, to view the port
parameters.
2. On the
Properties
tab, click the
General
tab to view the
Ethernet addresses
options. Click
the
SET IP address on the device
option. This option may be called
Set IP address using
a different method
, depending on the TIA portal version that you have. For multi-port
devices like the S7-1500 CPU, you can similarly configure all ports to enable IP address
changes (when connected to the SIMATIC Automation Tool) or you can configure only
the port you want to change.
3. Also on the
Ethernet addresses
options, click the
Set PROFINET device name on the
device
option. This selection allows the SIMATIC Automation Tool to assign names. For
multi-port devices like the S7-1500 CPU, you can similarly configure all ports to enable
PROFINET name changes (when connected to the SIMATIC Automation Tool) or you
can configure only the port you want to change.
4. Save your project and download the new configuration changes to the CPU.

Prerequisites and communication setup
2.4 CPU configuration requirements
SIMATIC Automation Tool V2.1 user guide
20 Manual, V2.1.1 07/2016, A5E33042676-AC
Note
Default settings of PROFINET IP parameters
When you create a new TIA portal project, the default PROFINET parameter options are set
to "Set IP address in the project"
and
"Generate PROFINET device name automatically"
.
With the default options, you cannot set IP addresses
or PROFINET device names with the
SIMATIC Automation Tool. However, you can use other CPU operations like RUN/STOP
control, program/firmware updates, time setting, and service data/diagnostic analysis.
Note
Setting IP addresses for S7-1200 CPUs with V1 firmware
S7
-1200 V1 CPUs do not support the "Set IP address on the device" option. If the IP
addresses were previously set by a TIA portal program, then you must perform a factory
reset operation to delete the old IP addresses before the SIMATIC Automati
on Tool can
assign new IP addresses.
