Siemens SSB161.05U User manual

Electromotoric actuator
SSB161.05U
For Powermite MZ Series 2-way and 3-way globe valves
●Operating voltage AC/DC 24 V, positioning signal DC 0...10 V
●Self-calibrating to the valve stroke
●Direct mounting with coupling nut, no tools required
●Manually override
●Position and actuator motion indication (LED)
●Positioning force 45 lbf (200 N)
●Parallel operation of multiple actuators possible
A6V12681516_enUS_a Smart Infrastructure
10/12/2022

2
Siemens A6V12681516_enUS_a
Smart Infrastructure 10/12/2022
Use
●For 2-way and 3-way Powermite 599 MZ Series globe valves, 599-01100 - 599-01139
●Typically in chilled ceiling, VAV, unit ventilators, fan coil unit and other terminal unit ap-
plications
●Max.10 units of SSB161.05U can operate in parallel, provided the controller output
suffices.
Technical design When the actuator is driven by DC 0…10 V positioning signal, it produces a stroke, which is
transmitted to the valve stem. This is converted to mechanical stroke which controls the
position of valve stem.
If not specifically stated, the description of operation in this document applies to valve
versions that are fully closed when valve stem is extended / no actuator is mounted.
DC 0...10 V control signal
●The valve opens / closes in proportion to the
control signal at Y.
●At DC 0 V, the actuator stem is retracted, the
normally closed valve is fully closed and the
normally open valve is fully open.
●When no power is supplied, the actuator maintains
its current position.
Y = Control signal Y [V]
H = Percentage of calibrated valve stroke
LED indication
Status LED indication patterns
Variants SSB161.05U
Modulation: Stem retracting Flashing green in sequence: LED1-->LED2-->LED3
(500 ms each)
Modulation: Stem extending Flashing green in sequence: LED3-->LED2-->LED1
(500 ms each)
Stem position At H0 (fully retracted) - H40: Constant green (LED1)
At H40 - H60: Constant green (LED 2)
At H60 - H100 (fully extended): Constant green (LED3)
Calibration Flashing green (LED2): 100 ms on, 100 ms off
Error Constant red (LED2)
Manual operation Flashing green/red alternatively (LED2): Green 500 ms,
red 500 ms

3
Siemens A6V12681516_enUS_a
Smart Infrastructure 10/12/2022
Type summary
Type Stock
number Operating voltage Running speed Running time
5.5 mm Control signal Actuator
characteristic
SSB161.05U S55180-A151 AC/DC 24 V 5 s/mm 27.5 s ± 25 % DC 0...10 V Linear
Accessories
Product Type Stock Number Picture Name Conduit interface
ASY101 S55845-Z277 Conduit cover 3/8 inch flex conduit
Ordering When ordering, specify both type and quantity.
Example:
Type Stock number Designation Quantity
SSB161.05U S55180-A151 Electromotoric actuator 2
Delivery Valves and actuators can be ordered assembled in the factory or ordered separately. For
easier valve assembly, actuators ordered separately have the actuator stem fully retracted.
Equipment combinations
Valves
Combinable valves for SSB161.05U- 2-way Powermite 599 MZ Series
Action Nominal Line Size Flow Rate Connection
Inch mm Cv Kvs FxF FxUM AFxUM
Normally
Closed 0.5 15 0.4 (0.34) 599-01100 599-01101 -
0.5 15 0.63 (0.54) 599-01102 599-01103 -
0.5 15 1.0 (0.85) 599-01104 599-01105 -
0.5 15 1.6 (1.37) 599-01106 599-01107 -
0.5 15 2.5 (2.15) 599-01108 599-01109 -
0.5 15 4(3.44) 599-01110 599-01111 -
0.75 20 6.3 (5.43) 599-01112 599-01113 -
125 10 (8.6) 599-01114 – -
Normally
Open 0.5 15 0.4 (0.34) 599-01115 599-01116 -
0.5 15 0.63 (0.54) 599-01117 599-01118 –
0.5 15 1.0 (0.85) 599-01119 599-01120 –
0.5 15 2.5 (2.15) 599-01123 599-01124 599-01125
0.5 15 4(3.44) 599-01126 599-01127 599-01128

4
Siemens A6V12681516_enUS_a
Smart Infrastructure 10/12/2022
Action Nominal Line Size Flow Rate Connection
Inch mm Cv Kvs FxF FxUM AFxUM
0.75 20 6.3 (5.43) 599-01129 599-01130 –
125 10 (8.6) 599-01131 – –
Combinable valves for SSB161.05U – 3-way Powermite 599 MZ Series
Nominal Line Size Flow Rate Connection
Inch mm Cv Kvs FxF
0.5 15 0.4 (0.34) 599-01132
0.5 15 0.63 (0.54) 599-01133
0.5 15 1.0 (0.85) 599-01134
0.5 15 1.6 (1.37) 599-01135
0.5 15 2.5 (2.15) 599-01136
0.5 15 4(3.44) 599-01137
0.75 20 6.3 (5.43) 599-01138
1.00 25 10 (8.6) 599-01139
Product documentation
Topic Title Document ID
Installation Mounting instruction A6V13122037
Standards and directives CE declarations A5W00254962A
RCM conformity A5W00254983A
Environmental compatibility Environmental declarations A5W00242127A
Related documents such as the environmental declarations, CE declarations, etc., can be
downloaded from the following Internet address:
www.siemens.com/bt/download
Notes
Engineering The actuators must be electrically connected in accordance with local regulations (see
"Connection diagrams”).
CAUTION
National safety regulations
Failure to comply with national safety regulations may result in personal injury and property
damage.
●Observe national provisions and comply with the appropriate safety regulations.

5
Siemens A6V12681516_enUS_a
Smart Infrastructure 10/12/2022
Observe permissible temperatures (see "Technical data [▶9]").
Mounting
WARNING
●Do not use pipe wrenches, pliers or similar tools.
●Avoid lateral pressure or (cable) tension on the mounted actuator!
Valve and actuator are easy to assemble on site before commissioning:
●Remove protective cover from the valve body.
●Position the actuator and tighten the union nut manually.
●See "Mounting instructions" for graphical instructions.
Orientation
Commissioning When commissioning, check both wiring and functioning of the actuator.
●Actuator stem extends Normally open valve closes, normally closed valve opens
●Actuator stem retracts Normally open valve opens, normally closed valve closes
NOTICE
The actuator must be commissioned only with a correctly mounted valve in place!
Self-calibration When operating voltage is applied, the actuator self-calibrates (fully retracted ➙fully
extended ➙setpoint).
Power
On
Calibration
Y
t
Fully retracted
Fullyextended

6
Siemens A6V12681516_enUS_a
Smart Infrastructure 10/12/2022
CAUTION
Never intervene manually during self-calibration.
NOTICE
●Correct calibration is only possible with valve stroke > 0.05 inch (1.2 mm). Valve stroke
< 0.05 inch (1.2 mm) > 1.2 mm. Valve stroke < 1.2 mm results in calibration failure.
●If calibration fails, the actuator performs another calibration automatically after
10 seconds.
●After three failed calibration attempts, the actuator stem remains in the extended
position and the valves are open.
Manual operation A 3-mm hexagonal wrench can be used to move the actuator to any position.
To move the actuator stem manually
1. Open the cover using a proper screwdriver.
2. Press and hold down button (a) illustrated below for at least three seconds.
– The actuator ignores any control signal from the controller.
3. Adjust the position of the actuator stem by rotating hexagonal wrench (b) illustrated
below clockwise or counter-clockwise.
– The actuator stem moves down if you rotate clockwise; it moves up if you rotate
counter-clockwise. The manually set position is retained.
4. To exit manual operation mode, press and hold down button (a) illustrated below again
for at least three seconds.
– The actuator runs a self-calibration automatically. Control signal sent from the
controller takes effect.
5. Close the cover.
NOTICE
If operating voltage is applied to actuator, press button (a) before and after manually
adjusting the position of the actuator stem. If no operating voltage and control signal are
applied, manual operation can be done without pressing button (a).
Cabling operation1. Unscrew cover screw
2. Remove cover
A
6
V
1
1
8
5
8
2
7
8
Z
1
0
3 mm
(b)
(a)
>3s

7
Siemens A6V12681516_enUS_a
Smart Infrastructure 10/12/2022
3. Connect or disconnect wire terminals (terminal block is removable)
4. Install the cover
5. Screw in the cover screw
Maintenance The actuators require no maintenance.
WARNING
Operating voltage must be switched off during any maintenance!
NOTICE
When carrying out service work on the plant, note the following:
●Switch off operating voltage.
●If necessary, disconnect electrical connections from the terminals.
●The actuator must be commissioned only with a correctly mounted valve in place!
Repair
The actuators cannot be repaired; the complete unit must be replaced.
Disposal
The device is considered an electronic
device for disposal and may not be disposed
of as domestic waste.
●Dispose of the device through channels
provided for this purpose.
●Comply with all local and currently
applicable laws and regulations.
Warranty Technical data on specific applications are valid only together with Siemens products listed
under "Equipment combinations". Siemens rejects any and all warranties in the event that
third-party products are used.

8
Siemens A6V12681516_enUS_a
Smart Infrastructure 10/12/2022
Open Source Software (OSS)
Software license overview
These devices use Open Source Software (OSS). All Open Source Software components
used in the product (to include copyrights and licensing agreement) are available at
http://siemens.com/bt/download.
Firmware version OSS document Device
Document ID Title
2.10.0 or above A6V13503690 Readme OSS for Modulating Room Actuator 200N, 300N All

9
Siemens A6V12681516_enUS_a
Smart Infrastructure 10/12/2022
Technical data
Power supply
Operating voltage AC 24 V (± 15 %) or DC 24 V (± 20 %)
Frequency 50/60 Hz
Power consumption 3 VA (AC); 1.2 W (DC)
Primary fuse or breaker rating External, 2 A quick blow
Signal input
Control signal DC 0…10 V
Input impedance 100 kOhm
Parallel operation (number of actuators) Max. 101)
1) Provided that the controller output is sufficient.
Operating data
Position with de-energized contact Y See "Technical design [▶2]"
Running speed (time for 5.5 mm) < 5 s/mm ± 25 % (27.5 s ± 25 %)
Positioning force 45 lbf (200 N)
Stroke 0.05 to 0.25 inch (1.2…6.5 mm)
Permissible temperature of medium in the connected valve 34 to 248°F (1…120℃)
Electrical connection
Permissible length for signal lines 65 ft (20 m)
Wire cross section 18...20 AWG (0.5...0.75 mm²）
Cable diameter <0.2 inch (5 mm)
Mounting
Connection to valve Plastic coupling nut 3/4” inch
Orientation Above horizontal
Standards
EU conformity (CE) A5W00254962A
RCM conformity A5W00254983A
UKCA A5W00257055A
Housing protection degree NEMA 2 / IP20 (EN 60529)
Protection class according to EN 60730 III
Pollution degree 2

10
Siemens A6V12681516_enUS_a
Smart Infrastructure 10/12/2022
Standards
Overvoltage category III
Environmental compatibility The product environmental declaration
(A5W00242127A) contains data on environmentally
compatible product design and assessments (RoHS
compliance, materials composition, packaging,
environmental benefit, disposal).
UL Approval
Federal Communications Commission
UL as per UL60730-1, UL60730-2-14
http://ul.com/database
cUL as per CSA – CAN E60730-1, E730-2-14
FCC CFR 47 Part 15 Class B
ICES003 CAN ICES-3 (B)/NMB-3(B)
FCC regulations
Modification of this device to receive cellular radio telephone service signals is pro-
hibited under FCC rules and federal law.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Housing color
Cover/base 2003, Ti-Gray
Coupling nut RAL 9017
General ambient conditions
Operation Transport Storage
Temperature 34 to 122°F (1…50 ℃)-13 to 158°F (-25…70 ℃) -13 to 158°F (-25…70 ℃)
Humidity 5…95 % r.h.
non condensing <95 % r.h. non condensing 5…95 % r.h. non condensing
Atmospheric
pressure Min. 700 hPa, corresponding to max. 3,000 m above sea level - -

11
Siemens A6V12681516_enUS_a
Smart Infrastructure 10/12/2022
Material
Cover/base PC + ABS
Weight
7.8 ounces (220 g)

12
Siemens A6V12681516_enUS_a
Smart Infrastructure 10/12/2022
Diagrams
Connection terminals
G0 System neutral
Y Control signal DC 0...10 V
G System potential (AC/DC 24 V)
Connection diagrams
N= Controller
Y= Actuator
SP, G = System potential AC 24 V
SN, G0 = System neutral
Y = Control signal
Dimensions mm (inch)
Revision numbers
Type Valid from rev. no.
SSB161.05U ..A
G
Y
G
0
(Y)
SN (-)
AC 24 V (DC 24 V)
2AF
76.7
(3")
27.7
(1.1")
92.6
(3.7)
"
A
6
V
1
2
6
8
1
5
1
1
Z
1
5
49
(1.9")

Issued by
Siemens Switzerland Ltd
Smart Infrastructure
Global Headquarters
Theilerstrasse 1a
CH-6300 Zug
[phone]
www.siemens.com/buildingtechnologies
© Siemens Switzerland Ltd, 2022
Technical specifications and availability subject to change without notice.
Document ID A6V12681516_enUS_a
Edition 10/12/2022
