Siemens SIRIUS Contactor S2 User manual

SIRIUS
Contactor S2
继电器 S2
3RT5.3
Operating Instructions 使用说明
A5E01135683-02 Last update: 11 November 2010
Order No.: 3ZX1012-0RT53-1AA1
English
DANGER CAUTION
Read and understand these instructions
before installing, operating, or maintaining
the equipment.
Hazardous voltage.
Will cause death or serious injury.
Turn off and lock out all power
supplying this device before working on
this device.
Reliable functioning of the equipment is
only ensured with certified components.
中文
危险 小心
安装、使用和维修本设备前必须先阅
读并理解本说明。
危险电压。
可能导致生命危险或重伤危险。
操作设备时必须确保切断电源。
只有使用经过认证的部件才能保证设
备的正常运转。
!
!
Technical Hotline: Telephone: [phone] (8:30 - 17:15 UTC+8) Fax: ++86-10-6471-9991
E-mail: [e-mail]
Internet: www.4008104288.com.cn or www.ad.siemens.com.cn/service
s
EN Assembly 中文 安装
2
1
1
1
2
RT-00272
RT-00892

2Order No.: 3ZX1012-0RT53-1AA1
EN Accessories 中文 附件
RT-00274
RT-00275
RT-00273
2
1
3RH5921-1....
3RH5921-1..
1
2
1
RT-00276
max. 4 NO / NC
1
2
RT -01088
1
2
RT-00286
1
2
1
RT-00285
2
3RT59.6-1....

Order No.: 3ZX1012-0RT53-1AA1 3
EN Replacement of the contactor coil 中文 更换接触器线圈
9
11
12
10
RT-00278
7
8
3
2
12
4
5
6
RT-00277
11
3RT5034
15 kW
3RT5035
18,5 kW
3RT5036
22 kW
34 35 36
1,2 ... 1,5 Nm
11 ... 13 lb • in
0,7 ... 1 Nm
6 ... 9 lb • in
RT-00279
1
1
2
3
4
RT-00280
RT-00281
6
6
5
0,7 ... 1,2 Nm
6 ... 11 lb • in

Subject to change without prior notice. Store for use at a later date. Order No.: 3ZX1012-0RT53-1AA1
©Siemens AG 2007
EN Connect 中文 连接
A1 / A2; NO / NC L1 L2 L3
T1 T2 T3
3RH5921-1
∅5 ... 6 mm / PZ2
0,8 ... 1,2 Nm
7 to 10.3 lb • in ∅5 ... 6 mm / PZ2
3 ... 4,5 Nm
27 to 40 lb • in
2 x 0,5 ... 1,5 mm²
2 x 0,75 ... 2,5 mm² 2 x 0,75 ... 16 mm²
2 x 0,5 ... 2,5 mm² 2 x 0,75 ... 16 mm²
1 x 0,75 ... 25 mm²
——2 x 0,75 ... 25 mm²
1 x 0,75 ... 35 mm²
AWG 2 x 18 to 14 AWG 2 x 18 to 3
1 x 18 to 2
EN Dimension drawings
(all dimensions in mm)
中文 尺寸图
( 单位：mm)
RT-00284
8
8
7
RT-00282
1
1
2
4
5
RT-00283
3
6
4,5 ... 5,5 Nm
40 ... 48 lb • in
0,7 ... 1,2 Nm
6 ... 11 lb • in
10
13
10
13
13
a = 0 (< 240 V)
a = 3,5 (> 240 V)
a = 17
a
35
55
64
DC: 15 110
5
112
4,8
45
95
22,5° 22,5°
3RT5.3.-.....-1...
3RT5936-1C...
22,5°
22,5°
360°
