Siemens SIMATIC IPC477E User manual

SIMATIC
Industrial PC
SIMATIC IPC477E PRO
Operating Instructions
08/2017
A5E39912462
-AA
Preface
1
Overview
2
Safety guidelines
3
Mounting and connecting the
HMI device
4
Commissioning the device
5
Operating the device and
device functions
6
Expanding the device and
assigning the device
parameters
7
Maintaining and repairing the
device
8
Technical specifications
9
Technical support
A
Markings and symbols
B
List of abbreviations
C

Siemens AG
Division Digital Factory
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E39912462-AA
Ⓟ
07/2017 Subject to change
Copyright © Siemens AG 2017.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury
may
result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

SIMATIC IPC477E PRO
Operating Instructions, 08/2017, A5E39912462-AA 3
Table of contents
1 Preface ................................................................................................................................................... 7
2 Overview................................................................................................................................................. 9
2.1 Product description ...................................................................................................................9
2.2 Installation...............................................................................................................................11
2.2.1 Interfaces and operator controls for PRO device ...................................................................13
2.3 Accessory kit...........................................................................................................................14
2.4 Accessories.............................................................................................................................14
2.5 System components ...............................................................................................................15
2.5.1 Base adapter...........................................................................................................................15
2.5.2 Round tube adapter ................................................................................................................16
2.5.3 Adapter set for support arm and stand mounting of PRO device...........................................18
2.5.4 Extension Unit and operator controls......................................................................................19
3 Safety guidelines................................................................................................................................... 21
3.1 General safety instructions .....................................................................................................21
3.2 Notes on usage.......................................................................................................................24
4 Mounting and connecting the HMI device .............................................................................................. 27
4.1 Preparing for mounting ...........................................................................................................27
4.1.1 Checking the delivery package...............................................................................................27
4.1.2 Device identification data........................................................................................................29
4.2 Permitted mounting positions .................................................................................................31
4.3 Mounting the device................................................................................................................33
4.3.1 Notes on mounting..................................................................................................................33
4.3.2 Prepared for support arm or stand without extension elements (flange on top) ....................35
4.3.3 Prepared for support arm and extension elements (flange mount) ........................................38
4.4 Connecting the device ............................................................................................................42
4.4.1 Notes on connecting ...............................................................................................................42
4.4.2 Power supply ..........................................................................................................................44
4.4.2.1 Opening and closing the terminal compartment cover ...........................................................44
4.4.2.2 connecting the PE conductor..................................................................................................47
4.4.2.3 Connecting the 24 VDC power supply....................................................................................48
4.4.3 Connecting peripheral equipment...........................................................................................50
4.4.4 Connecting the device to networks.........................................................................................51
4.4.5 Securing the cables ................................................................................................................52
5 Commissioning the device .................................................................................................................... 53
5.1 Notes on commissioning and operation..................................................................................53
5.2 Initial commissioning...............................................................................................................55
5.3 Windows Action Center...........................................................................................................57

Table of contents
SIMATIC IPC477E PRO
4Operating Instructions, 08/2017, A5E39912462-AA
6 Operating the device and device functions ............................................................................................ 59
6.1 Operator input options ........................................................................................................... 59
6.2 Operating the device.............................................................................................................. 60
6.3 IPC Wizard functions ............................................................................................................. 62
6.4 Extended device functions ..................................................................................................... 63
6.4.1 Monitoring functions............................................................................................................... 63
6.4.1.1 Overview of the monitoring functions..................................................................................... 63
6.4.1.2 Temperature monitoring/display ............................................................................................ 64
6.4.1.3 Watchdog (WD)...................................................................................................................... 64
6.4.1.4 Battery monitoring.................................................................................................................. 65
6.4.1.5 Mass storage monitoring........................................................................................................ 65
6.4.2 Enhanced Write Filter (EWF) ................................................................................................. 66
6.4.3 File Based Write Filter (FBWF).............................................................................................. 69
6.4.4 Buffer memory NVRAM ......................................................................................................... 70
6.4.5 Active Management Technology (AMT) ................................................................................ 71
6.4.6 Trusted Platform Modul (TPM)............................................................................................... 73
7 Expanding the device and assigning the device parameters.................................................................. 75
7.1 Opening and closing the backplane cover............................................................................. 75
7.2 Installing and removing a memory module ............................................................................ 79
7.3 Installing and removing a CFast card .................................................................................... 81
7.4 Assigning CPU power consumption parameters ................................................................... 82
8 Maintaining and repairing the device..................................................................................................... 83
8.1 Maintenance........................................................................................................................... 83
8.2 Repair information.................................................................................................................. 84
8.3 Cleaning the Device Front ..................................................................................................... 87
8.4 Installing and removing hardware .......................................................................................... 88
8.4.1 Replacing the backup battery ................................................................................................ 88
8.4.2 Replace SSD.......................................................................................................................... 89
8.5 Installing the software ............................................................................................................ 91
8.5.1 Reinstalling the operating system.......................................................................................... 91
8.5.1.1 General installation procedure ............................................................................................... 91
8.5.1.2 Restoring the factory state of the software ............................................................................ 92
8.5.1.3 Windows................................................................................................................................. 93
8.5.1.4 Windows Embedded Standard .............................................................................................. 97
8.5.2 Partitioning the data storage medium .................................................................................... 98
8.5.2.1 Partitioning in Windows Embedded Standard 7 .................................................................... 98
8.5.2.2 Partitioning in Windows 7 Ultimate ........................................................................................ 99
8.5.2.3 Changing the partitions under Windows 7 and Windows 10 ................................................. 99
8.5.3 Installing drivers and software ............................................................................................. 100
8.5.4 Update installation ............................................................................................................... 101
8.5.4.1 Updating the operating system ............................................................................................ 101
8.5.4.2 Installing or updating application programs and drivers ...................................................... 101
8.5.5 Backing up data ................................................................................................................... 101
8.6 Recycling and disposal ........................................................................................................ 101

Table of contents
SIMATIC IPC477E PRO
Operating Instructions, 08/2017, A5E39912462-AA 5
9 Technical specifications ...................................................................................................................... 103
9.1 Certificates and approvals ....................................................................................................103
9.2 Directives and declarations...................................................................................................108
9.2.1 Electromagnetic compatibility ...............................................................................................108
9.2.2 ESD guideline .......................................................................................................................108
9.3 Dimension drawings..............................................................................................................111
9.3.1 Dimension drawing of 15" device with capacitive multi-touch screen ..................................111
9.3.2 Dimension drawing of 19" device with capacitive multi-touch screen ..................................114
9.3.3 Dimension drawing of 22" device with capacitive multi-touch screen ..................................117
9.4 Technical specifications ........................................................................................................120
9.4.1 General technical specifications ...........................................................................................120
9.4.2 Environmental conditions......................................................................................................125
9.4.3 Information on insulation tests, protection class and degree of protection...........................126
9.4.4 Rated voltages ......................................................................................................................126
9.4.5 Power requirements of the components ...............................................................................126
9.4.6 Integrated DC power supply .................................................................................................127
9.5 Hardware descriptions ..........................................................................................................128
9.5.1 External interfaces ................................................................................................................128
9.5.1.1 COM1/COM2 ........................................................................................................................128
9.5.1.2 CFast.....................................................................................................................................128
9.5.1.3 DisplayPort............................................................................................................................129
9.5.1.4 Ethernet ................................................................................................................................130
9.5.1.5 USB 3.0 port .........................................................................................................................130
9.5.1.6 USB 2.0.................................................................................................................................131
9.5.2 System resources .................................................................................................................131
9.5.3 Input/output areas .................................................................................................................133
9.5.3.1 Overview of the internal module registers ............................................................................133
9.5.3.2 Watchdog trigger register (read only, address 062h) ...........................................................133
9.5.3.3 Watchdog enable register (read/write address 062h)...........................................................134
9.5.3.4 Battery status register (read only, if the RTC_BAT_SURVEY_EN address is set to "1";
404Dh) ..................................................................................................................................135
9.5.3.5 NVRAM address register ......................................................................................................135
9.6 BIOS description ...................................................................................................................136
9.6.1 Overview ...............................................................................................................................136
9.6.2 Opening the BIOS selection menu .......................................................................................137
9.6.3 Structure of the BIOS Setup menu .......................................................................................139
9.6.4 Exit menu ..............................................................................................................................141
9.6.5 BIOS update .........................................................................................................................142
9.6.6 Alarm, error and system messages ......................................................................................144
9.7 Active Management Technology (AMT) ...............................................................................145
9.7.1 Introduction ...........................................................................................................................145
9.7.2 Overview of AMT ..................................................................................................................146
9.7.3 Enabling Intel® AMT / basic configuration............................................................................146
9.7.4 Resetting the Intel® AMT to the default settings and disabling AMT ...................................148
9.7.5 Determining the network address .........................................................................................148
9.7.6 Forcing user consent ............................................................................................................149
9.8 Functional scope in Windows ...............................................................................................150
9.8.1 Windows Embedded Standard 7 ..........................................................................................150

Table of contents
SIMATIC IPC477E PRO
6Operating Instructions, 08/2017, A5E39912462-AA
A Technical support.................................................................................................................................153
A.1 Service and support ............................................................................................................. 153
A.2 Problem solving.................................................................................................................... 154
A.3 Notes on the use of third-party modules.............................................................................. 155
B Markings and symbols .........................................................................................................................157
B.1 Overview .............................................................................................................................. 157
B.2 Safety ................................................................................................................................... 157
B.3 Operator controls ................................................................................................................. 157
B.4 Certificates, approvals and markings................................................................................... 158
B.5 Interfaces ............................................................................................................................. 159
C List of abbreviations .............................................................................................................................161
Glossary ..............................................................................................................................................167
Index ...................................................................................................................................................175

SIMATIC IPC477E PRO
Operating Instructions, 08/2017, A5E39912462-AA 7
Preface
1
Purpose of the Operating Instructions
These operating instructions contain all the information you need for commissioning and
operating the SIMATIC IPC477E PRO.
It is intended both for programming and testing personnel who commission the device and
connect it with other units (automation systems, programming devices), as well as for service
and maintenance personnel who install add-ons or carry out fault/error analyses.
Basic knowledge required
A solid background in personal computers and Microsoft operating systems is required to
understand this manual. General knowledge in the field automation control engineering is
recommended.
Scope of the operating instructions
These operating instructions apply to "SIMATIC IPC477E PRO" industrial PCs with article
numbers6AV7251-...-... .
Scope of this documentation
The documentation for the IPC includes the following:
●Product information, e.g. "Important notes on your device"
●Quick Install Guide SIMATIC IPC477E PRO
●SIMATIC IPC477E PRO Operating Instructions
The documentation is supplied with the IPC in multiple languages as PDF on the USB stick
supplied in the documentation package.

Preface
SIMATIC IPC477E PRO
8Operating Instructions, 08/2017, A5E39912462-AA
Conventions
In these operating instructions, "device" is used as the standard term for "SIMATIC IPC477E
PRO".
In these operating instructions, the terms "Windows Embedded Standard 7 P" and "Windows
Embedded Standard 7 E" are also abbreviated with the term "Windows Embedded
Standard". "Windows 7" is used as an abbreviation for "Windows 7 Ultimate".
A touch device generally refers to a device with a capacitive multi-touch screen or a resistive
single touch screen. Touch screen is the general term for a resistive single touch screen or a
capacitive multi-touch screen.
Note
A note is important information about the product, handling the product or a reference to
specific sections of the documentation that require special consideration.
History
The following editions of these operating instructions have already been published:
Edition
Comments
08/2017
First edition

SIMATIC IPC477E PRO
Operating Instructions, 08/2017, A5E39912462-AA 9
Overview
2
2.1
Product description
Features
SIMATIC IPC477E PRO provides high-level industrial functionality.
●Compact design
●Maintenance-free operation
●IP65 degree of protection
●Rugged
●Ex approval
●Used for shipping and offshore applications
●Expansion with system components
The range has been expanded by the PRO device with all-round IP65 degree of protection;
the device not only impresses with its ease of servicing, but also with its sophisticated design
and low mounting depth.

Overview
2.1 Product description
SIMATIC IPC477E PRO
10 Operating Instructions, 08/2017, A5E39912462-AA
Device variants
The delivery note contains information on the precise scope of functions and product
package for your device.
The SIMATIC IPC477E PRO is available in the following device variants, which differ in
regard to the display size, operating method and optional expansions:
PRO device with capacitive multi-touch screen
●Display:
–15" display, resolution 1366 × 768 pixels
–19" display, resolution: 1366 x 768 pixels
–22" display, resolution: 1920 x 1080 pixels
●optionally prepared for:
–Support arm without extension components (flange at top)
–Support arm and extension components (round tube)
–Pedestal/extension components (flange at bottom)
●A base adapter and adapter sets that can be ordered separately support mounting
systems from various manufacturers.
–Base adapter for support arm and pedestal included in the product package.
–Cover plate for device version for support arm and extension components included in
the product package.
●Fully dust-proof and splash-proof with IP65 degree of protection and Enclosure Type
4X / 12 (indoor use only)
Operating systems
The following table shows the operating systems that are available:
Operating system
Windows 10 IoT En-
terprise (64-bit)
Windows 7 Ultimate
(32/64-bit)
Windows Embedded
Standard 7 P (32-bit)
Windows Embedded
Standard 7 E (32/64-bit)
x
x
x
x*
* WES7E is also supplied with IPC477E PRO devices. Multitouch is operated in single touch mode with WES7E.

Overview
2.2 Installation
SIMATIC IPC477E PRO
Operating Instructions, 08/2017, A5E39912462-AA 11
2.2
Installation
Front view and side view
①
Display with multi-touch screen
②
Enclosure
③
Backplane cover
④
Terminal compartment cover
Bottom view
①
Mechanical interface for mounting/base adapter

Overview
2.2 Installation
SIMATIC IPC477E PRO
12 Operating Instructions, 08/2017, A5E39912462-AA
Rear view - device version "prepared for pedestal/extension components" and "prepared for support
arm without extension components".
①
Backplane cover
②
Terminal compartment cover
③
Mechanical interface for mounting/base adapter
Rear view - device version "prepared for support arm and extension components"
①
Terminal compartment cover

Overview
2.2 Installation
SIMATIC IPC477E PRO
Operating Instructions, 08/2017, A5E39912462-AA 13
Note
The device version "prepared for support arm and extension components" is intended for
devices with an extension (see
System components (Page 15)).
Bottom - device version "prepared for support arm and extension elements"
①
Cover plate
2.2.1
Interfaces and operator controls for PRO device
The assignment of the interfaces is shown inside the terminal compartment cover.
①
4 x USB port
USB 3.0 high speed/high current
②
Slot for CFast card
Behind the strain relief
③
COM1/2 port (optional)
Serial port, 9-pin D-sub connector
④
Display port
⑤
3 × Ethernet port
RJ45 Ethernet port, 10/100/1000 Mbps
⑥
Connection terminal
24 V DC power supply
Connection terminal inserted in delivered condition
⑦
On/off switch
⑧
Protective conductor connection

Overview
2.3 Accessory kit
SIMATIC IPC477E PRO
14 Operating Instructions, 08/2017, A5E39912462-AA
2.3
Accessory kit
PRO device
●The base adapter including four M4x12 screws is included in the scope of delivery for
devices "prepared for support arm without extension elements (flange on top)" and
devices "prepared for stand/extension elements (flange on bottom)".
●The device version "prepared for support arm and extension components" includes a
cover plate with four M4x12 screws in the product package.
●Additional documents may be supplied with the accessory kit.
2.4
Accessories
Accessories are available for your device. These are not included in the product package.
You can find Information on available accessories on the Internet at:
Industry Mall (https://mall.industry.siemens.com)
Expansion components and accessories (http://www.automation.siemens.com/mcms/pc-
based-automation/en/industrial-pc/expansion_components_accessories)
System components for devices with all-round IP65 protection
(https://mall.industry.siemens.com/mall/de/de/Catalog/Products/10268745?tree=CatalogTree)
SIMATIC IPC CFast cards
●2 GB optional or
●4 GB optional or
●8 GB optional or
●16 GB optional or
●30 GB optional

Overview
2.5 System components
SIMATIC IPC477E PRO
Operating Instructions, 08/2017, A5E39912462-AA 15
2.5
System components
2.5.1
Base adapter
PRO devices of the type "suitable for support arm" or "suitable for stand" can be mounted on
a support arm or stand using the base adapter. Depending on the support arm system used,
an adapter plate may have to be installed in addition (see Accessories (Page 14)).
A base adapter is included with the corresponding PRO devices. The base adapter can also
be ordered separately.
①
Seal
②
Cable channel
③
Mechanical interface to the PRO device
④
Cover
⑤
Mechanical interface to support arm or stand
Article number for the base adapter as accessory: 6AV7674-1KA00-0AA0.
See also
Prepared for support arm or stand without extension elements (flange on top) (Page 35)
Industry Mall (https://mall.industry.siemens.com)
Expansion components and accessories (http://www.automation.siemens.com/mcms/pc-
based-automation/en/industrial-pc/expansion_components_accessories)

Overview
2.5 System components
SIMATIC IPC477E PRO
16 Operating Instructions, 08/2017, A5E39912462-AA
2.5.2
Round tube adapter
Flange mount for device version "prepared for support arm and extension components"
An optional flange mount that is not included in the product package is available for the
device version "prepared for support arm and extension components".
The flange mount converts the flange mount connection into a mechanically compatible
interface to the base adapter. The flange of the flange mount has the same drilling pattern as
the base adapter. This means you can use all couplings of the support arm or pedestal
systems with mechanical interface for the base adapter.
①
Flange mount
②
Ring groove for fastening on PRO device with setscrews
③
Mechanical interface to support arm
Article number of the flange mount: 6AV7674-1KF00-0AA0

Overview
2.5 System components
SIMATIC IPC477E PRO
Operating Instructions, 08/2017, A5E39912462-AA 17
Additional information
You can find information on mounting the PRO device at Prepared for support arm and
extension elements (flange mount) (Page 38).
You can find Information on available accessories on the Internet at:
●Industry Mall (https://mall.industry.siemens.com)
●System components for devices with all-round IP65 protection
(https://mall.industry.siemens.com/mall/de/de/Catalog/Products/10268745?tree=CatalogTree)
See also
Prepared for support arm or stand without extension elements (flange on top) (Page 35)

Overview
2.5 System components
SIMATIC IPC477E PRO
18 Operating Instructions, 08/2017, A5E39912462-AA
2.5.3
Adapter set for support arm and stand mounting of PRO device
The PRO device can be mounted on systems from third-party vendors (see section
"Mounting the device (Page 33)"). For this you will need the Siemens base adapter (see
Base adapter (Page 15)) and a proprietary adapter set.
Siemens also offers its own adapter for VESA-compatible third-party systems:
Adapter set
Suitable for support arm systems
Article number
SIEMENS:
•Adapter set VESA75
•Adapter set VESA100
•VESA75-compatible systems
•VESA100-compatible systems
•6AV7674-0KE00-0AA0
•6AV7674-0KD00-0AA0
RITTAL:
Adapter for
Siemens PRO-Panel
•Intermediate plate
•Screws
•CP40 steel
•CP60/120 for
Support arm connection
120 × 65 mm
•6206.500
ROLEC:
Adapter for
Siemens PRO-Panel
•Intermediate plate
•Screws
•profiPlus-50
•taraPLUS for ∅ 65 mm hole
circle
•142.024.000
BERNSTEIN:
Coupling for Siemens
SIMATIC PRO
•No intermediate plate re-
quired
•Coupling with integrated
adaptation for PRO device
•CS-3000 •1015300187 RAL 9006
white aluminum
•1015300043 RAL 7016
anthracite gray
Information provided without guarantee.

Overview
2.5 System components
SIMATIC IPC477E PRO
Operating Instructions, 08/2017, A5E39912462-AA 19
2.5.4
Extension Unit and operator controls
Extension components - Extension Unit
The Extension Unit is used to install additional operator controls under a SIMATIC PRO
device of the type "Suitable for extension components" with 16:9 display.
The example in the figure below shows the Extension Unit 22" with eight operator controls
including emergency stop button.
The Extension Units have individual configuration possibilities and are supplied without
operator controls. The available slots are suitable for installation of operator controls.
The extension units are available in 4 different sizes:
●12"
●15"
●19"
●22"
For greater flexibility, three different connection options can be selected per size for the PLC
connection of the operator controls:
●Hardwired
●PROFINET
●PROFIsafe
In addition, different operator controls such as emergency stop, selector switch, illuminated
pushbutton, keyswitch, indicator light or RFID reader are available.
Note
Only operator controls with Siemens approval may be installed in the Extension Unit.
You can find information on "System components for PRO device Extension Units" on the
Internet (
https://support.industry.siemens.com/cs/de/de/view/109742323/en).

Overview
2.5 System components
SIMATIC IPC477E PRO
20 Operating Instructions, 08/2017, A5E39912462-AA
Additional information
Information on system components for devices with all-round IP65 protection is available on
the Internet
(https://mall.industry.siemens.com/mall/de/de/Catalog/Products/10268745?tree=CatalogTree).
