This quick reference guide contains the most important operating
sequences for the IP telephone HiNet LP5100. You will find more
detailed informations in the "Operation and Administration Manual".
Symbols
Repeat dialing
Symbol Meaning
or page forward or backward in the menu
call the indicated menu, confirm a value or
execute a function
Gcancel the action
increase the value depending on the current
operating mode
reduce the value depending on the current
operating mode
Press the key
Repeat dialing
1)72261494? > The number dialed last is
displayed
Move to the required call
number
Repeat dialing
4)08972226944? > Confirm the number
displayed
08972226944_
Dial? Start the dialing process
Back to Menu

4
Call a number from the Missed Calls list
Switching to handsfree mode at incoming call
Calls
Missed calls (1 new)? >1 new call has been
entered in the list
Press the key
1) 12*72226944
Dial? >1st entry is displayed
1) 12*72226944
Next entry/Previous entry
>Choose "Next entry"
or
"Previous entry"
2) 3*089722556442
Dial? > Choose "Dial"
2) 3*089722556442
Dial? > Confirm the number to be
called
089722556442_
Dial? Start the dialing process
722617384
Pickup call? >Incomingcallisdisplayed,
handset is replaced
Press the key
722617384
Consultation? >The connection is dis-
played and you can talk in
handsfree mode with the
person calling

5
Switching to handsfree mode during a call
Setting loudspeaker volumes in idle mode
0611226184
Consultation? >You are talking to some-
body with handset lifted
off
Keep the key "Loud-
speaker" pressed and
replace the handset
0611226184
Consultation? >The loudspeaker and the
microphone in the base
unit are switched on
Service:
2=Configuration? >
Go to "Audio Settings"
Service:
5=Audio Settings? > Call "Audio Settings"

Go to
"Loudspeakervolume",to
"Ringer volume" or to
"Handset volume"
Audio Settings:
01=Loudspeaker volume?
5
>Confirm your choice
(volume is at 5)
Loudspeaker volume :
 5 >Increase to required
volume or
reduce and
Loudspeaker volume :
 3 >confirm the setting
Audio Settings:
01=Loudspeaker volume?
3
>The new setting is
displayed

6
Setting loudspeaker volumes during a call
You can vary the volume of the base unit loudspeaker, or of the
handset loudspeaker by means of the keysandduring a
telephone call. Then press the key to save the setting. Other-
wise the setting will only apply to the current call.
Deflect an incoming call to another number
Transfer conversation
0711456378
Pickup call? >Incoming call is displayed
Choose "Deflect call"
0711456378
Deflect call? >Confirm your choice
0711456378 ?
08972261485_ to: The number of the last
deflected call is displayed
0711456378 ?
08972261458_ to: If necessary, correct the
destination number and
confirm
72261496
Consultation? >You are talking to some-
body
Choose "Transfer"
452_
Please dial #? >Enter the number of the
subscriber to whom the
call is meant to be
transferred
4523589_
Please dial? >Confirm the dialing
process
Consultation:
Transfer? 4523589 >As soon as the subscriber
is displayed, confirm one
more time
The call has been trans-
ferred
18:10
Please replace receiver
20.06.98
>Replace the handset

7
Picking up a call waiting
Deflecting a call waiting
0711456378
Consultation? >Call signal for "Call
waiting" rings
and
0611226184
Pickup call? >the number of the addi-
tional caller waiting is
displayed
Confirm the query
Consultation:0611226184
Disconnect and return? >You will talk to the
additional caller waiting
Consultation:0611226184
Disconnect and return? >Confirm the message to
interrupt the connection
with the additional caller
and return to the first
connection held
0711456378
Consultation? >The call signal for "Call
waiting" rings
and
0611226184
Pickup call? >the number of the addi-
tional caller waiting is
displayed
Choose "Deflect call"

0611226184
Deflect call? >Confirm your choice
0611226184 ?
08972261485 to: The number of the last
deflected call is displayed
0611226184 ?
08972261485_ to: If necessary, correct the
destination number and
confirm
0711456378
Consultation?
>The active connection is
displayed

8
Take a consultation from another user and return
When you have finished the consultation, you can cut off the user
who has just been active and switch the conversation back to the
user "held" in the waiting position:
456378
Consultation? >Display of the active (1st)
connection
Confirm the display
_
Please dial # >Enter the number of the
second party to be called
0611226184
Please dial? >Start dialing process
0611226184
Disconnect and return? >The connection is set up
and displayed
Your first partner is held in
a waiting position
Consultation: 0611226184
Disconnect and return? >
The 2nd connection exists
Consultation: 0611226184
Disconnect and return? >
The 2nd connection exists
Choose
"Disconnect and return"
0611226184
Disconnect and return? >Confirm the display
The2ndConnection is cut
off
456378
Consultation? >
The 1st connection still
exists

9
Assign number to a function key (Selected Dialing)
Programming the function keys
18:10
Page forward with
20.06.98
>Display of the Basic
menu
Press the desired
function key
Program destination? IP? > Choose input mode
"IP" or "#" and
confirm
08972226994
Program destination? >Enter the call number
to be stored and
confirm
Press the function key
18:10
Page forward with
20.06.98
>Display of the Basic
menu
18:10
Page forward with
20.06.98
>Display of the Basic menu
Go to "Service"
18:10
Service?
20.06.98
>Call the "Service" menu
Go to "Function keys"
Service:
4=Function keys? >Call the "Function keys"
menu and
Press the function key to
be programmed
Function keys:
XX=YYYYYYY? > Choose the required
function (see table below)
A signal will sound to
confirm

10
Table function keys
Selection Function
00=End Return to the preceding menu
01=Clear definition Clear key assignment
02=Selected dialing Assign call number to the function key
03=Abbrev. dialing Assign call number to a digit
04=Repeat dialing Repeat dialing from the list of the last
20 numbers of outgoing calls
05=Missed calls Choiceof acall numberfrom the list of
the last 20 numbers of incoming calls
06=Forwarding Forward an incoming call
07=Loudspeaker Switch on and off the loudspeaker in
the base unit
08=Mute Switch off the microphone
09=Ringer off Switch off an incoming call signal
10=Alternate Alternate between two parties
11=Transfer Transfer an incoming call
12=Deflect Deflect an incoming call
13=Service Menu Call Service menu
14=Room echoing Set room character to echoing
15=Room muffled Set room character to muffled
16=Shift key Switch over to the second level of
function keys
17=Notebook Call Notebook function
18=Status Check current status
