Siemens SIMATIC NET SFP Series User manual

SIMATIC NET
Network components
Transceiver SFP/SFP+/SCP/STP
Operating Instructions
10/2019
A5E02630804-13
Introduction 1
Safety notes 2
Description of the device 3
Assembling 4
Uninstalling 5
Connecting up 6
Technical data 7
Dimension drawings 8
Approvals 9

Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will be
used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to property
damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions. Qualified
personnel are those who, based on their training and experience, are capable of identifying risks and avoiding
potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended or
approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software described.
Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the information in this
publication is reviewed regularly and any necessary corrections are included in subsequent editions.
Siemens AG
Digital Industries
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E02630804-13
Ⓟ 11/2019 Subject to change
Copyright © Siemens AG 2011 - 2019.
All rights reserved

Table of contents
1 Introduction...................................................................................................................................................5
2 Safety notes..................................................................................................................................................9
3 Description of the device ............................................................................................................................11
3.1 Product overview....................................................................................................................12
3.2 Components of the product....................................................................................................15
4 Assembling .................................................................................................................................................17
4.1 Safety notices for installation .................................................................................................17
4.2 Notes on installation of SFP / SFP+ transceivers ..................................................................18
4.3 Using a pluggable transceiver (SFP/SFP+) ...........................................................................21
4.4 Notes on installation of SCP / STP transceivers ....................................................................22
4.5 Using a pluggable transceiver (SCP/STP) .............................................................................23
5 Uninstalling .................................................................................................................................................25
5.1 Removing a pluggable transceiver (SFP/SFP+) ....................................................................25
5.2 Removing a pluggable transceiver (SCP/STP) ......................................................................25
6 Connecting up ............................................................................................................................................27
6.1 Safety when connecting up ....................................................................................................27
6.2 Power supply..........................................................................................................................28
7 Technical data ............................................................................................................................................29
7.1 SFP transceiver......................................................................................................................29
7.1.1 SFP991-1/SFP991-1(C).........................................................................................................29
7.1.2 SFP991-1LD/SFP991-1LD(C)................................................................................................30
7.1.3 SFP991-1LH+ ........................................................................................................................30
7.1.4 SFP991-1ELH200 ..................................................................................................................31
7.1.5 SFP992-1 ...............................................................................................................................31
7.1.6 SFP992-1+.............................................................................................................................32
7.1.7 SFP992-1LD/SFP992-1LD(C)................................................................................................32
7.1.8 SFP992-1LD+ ........................................................................................................................33
7.1.9 SFP992-1LH ..........................................................................................................................33
7.1.10 SFP992-1LH+ ........................................................................................................................34
7.1.11 SFP992-1ELH ........................................................................................................................34
7.2 Bidirectional plug-in transceiver SFP .....................................................................................35
7.2.1 SFP992-1BXMT .....................................................................................................................35
7.2.2 SFP992-1BXMR.....................................................................................................................35
7.2.3 SFP992-1BX10T ....................................................................................................................36
7.2.4 SFP992-1BX10R....................................................................................................................36
7.3 SFP+ transceiver....................................................................................................................37
Transceiver SFP/SFP+/SCP/STP
Operating Instructions, 10/2019, A5E02630804-13 3

7.3.1 SFP993-1 ...............................................................................................................................37
7.3.2 SFP993-1LD ..........................................................................................................................38
7.3.3 SFP993-1LH ..........................................................................................................................38
7.4 SCP transceiver .....................................................................................................................39
7.4.1 SCP992-1...............................................................................................................................39
7.4.2 SCP992-1LD ..........................................................................................................................39
7.5 STP transceiver......................................................................................................................40
7.5.1 STP991-1 ...............................................................................................................................40
7.5.2 STP991-1LD ..........................................................................................................................41
7.6 Attenuators.............................................................................................................................41
7.7 Construction ...........................................................................................................................42
7.8 Environmental conditions .......................................................................................................42
7.9 Effective power loss ...............................................................................................................42
7.10 MTBF (Mean Time Between Failure) .....................................................................................43
8 Dimension drawings ...................................................................................................................................45
8.1 SFP dimension drawing .........................................................................................................45
8.2 SFP+ dimension drawing .......................................................................................................46
8.3 SCP dimension drawing.........................................................................................................47
8.4 STP dimension drawing .........................................................................................................48
9 Approvals....................................................................................................................................................49
Index...........................................................................................................................................................57
Table of contents
Transceiver SFP/SFP+/SCP/STP
4Operating Instructions, 10/2019, A5E02630804-13

Introduction 1
Purpose of the compact operating instructions
Based on the compact operating instructions, you will be able to install the SFP, SFP+, SCP
and STP transceivers. The configuration and the integration of the devices in a network are not
described in these instructions.
Validity of these compact operating instructions
These compact operating instructions apply to the SFP, SFP+, SCP and STP product group.
Further documentation
In the system manuals "Industrial Ethernet / PROFINET Industrial Ethernet" and "Industrial
Ethernet / PROFINET passive network components", you will find information on other
SIMATIC NET products that you can operate along with the devices of this product line in an
Industrial Ethernet network.
There, you will find among other things optical performance data of the communications partner
that you require for the installation.
You will find the system manuals here:
● On the data medium that ships with some products:
– Product CD / product DVD
– SIMATIC NET Manual Collection
● On the Internet pages of Siemens Industry Online Support:
– Industrial Ethernet / PROFINET Industrial Ethernet System Manual (https://
support.industry.siemens.com/cs/ww/es/view/27069465)
– Industrial Ethernet / PROFINET Passive Network Components System Manual (https://
support.industry.siemens.com/cs/ww/en/view/84922825)
SIMATIC NET manuals
You will find the SIMATIC NET manuals here:
● On the data medium that ships with some products:
– Product CD / product DVD
– SIMATIC NET Manual Collection
● On the Internet pages of Siemens Industry Online Support (https://
support.industry.siemens.com/cs/ww/en/ps/15247).
Transceiver SFP/SFP+/SCP/STP
Operating Instructions, 10/2019, A5E02630804-13 5

SIMATIC NET glossary
Explanations of many of the specialist terms used in this documentation can be found in the
SIMATIC NET glossary.
You will find the SIMATIC NET glossary here:
● On the data medium that ships with some products:
– Product CD / product DVD
– SIMATIC NET Manual Collection
● On the Internet pages of Siemens Industry Online Support (https://
support.industry.siemens.com/cs/ww/en/view/50305045).
Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens’ products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be connected
to an enterprise network or the internet if and to the extent such a connection is necessary and
only when appropriate security measures (e.g. firewalls and/or network segmentation) are in
place.
For additional information on industrial security measures that may be implemented, please
visit
https://www.siemens.com/industrialsecurity (https://www.siemens.com/industrialsecurity)
Siemens’ products and solutions undergo continuous development to make them more secure.
Siemens strongly recommends that product updates are applied as soon as they are available
and that the latest product versions are used. Use of product versions that are no longer
supported, and failure to apply the latest updates may increase customers’ exposure to cyber
threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed under
https://www.siemens.com/industrialsecurity (https://www.siemens.com/industrialsecurity)
Catalogs
You will find the article numbers for the Siemens products of relevance here in the following
catalogs:
● SIMATIC NET Industrial Communication / Industrial Identification, catalog IK PI
● SIMATIC Products for Totally Integrated Automation and Micro Automation, catalog ST 70
● Industry Mall - catalog and ordering system for automation and drive technology, Online
catalog (https://mall.industry.siemens.com/goos/WelcomePage.aspx?regionUrl=/
de&language=en)
You can request the catalogs and additional information from your Siemens representative.
Introduction
Transceiver SFP/SFP+/SCP/STP
6Operating Instructions, 10/2019, A5E02630804-13

Device defective
If a fault develops, please send the device to your SIEMENS service center for repair. Repairs
on-site are not possible.
Recycling and disposal
The products are low in pollutants, can be recycled and meet the requirements of the WEEE
directive 2012/19/EU for the disposal of electrical and electronic equipment.
Do not dispose of the products at public disposal sites.
For environmentally friendly recycling and the disposal of your old device contact a certified
disposal company for electronic scrap or your Siemens contact (Product return (https://
support.industry.siemens.com/cs/ww/en/view/109479891)).
Note the different national regulations.
Trademarks
The following and possibly other names not identified by the registered trademark sign ® are
registered trademarks of Siemens AG:
SIMATIC NET, SCALANCE, C-PLUG, OLM
Introduction
Transceiver SFP/SFP+/SCP/STP
Operating Instructions, 10/2019, A5E02630804-13 7

Introduction
Transceiver SFP/SFP+/SCP/STP
8Operating Instructions, 10/2019, A5E02630804-13

Safety notes 2
Read the safety notices
Note the following safety notices. These relate to the entire working life of the device.
You should also read the safety notices relating to handling in the individual sections,
particularly in the sections "Installation" and "Connecting up".
CAUTION
To prevent injury, read the manual before use.
Transceiver SFP/SFP+/SCP/STP
Operating Instructions, 10/2019, A5E02630804-13 9

Safety notes
Transceiver SFP/SFP+/SCP/STP
10 Operating Instructions, 10/2019, A5E02630804-13

Description of the device 3
Structure of the type designation
The type designation of an pluggable transceiver is made up of several parts that have the
following meaning:
Interface
Number of ports
-Standard version
(C) Conformal coating
SF Pluggable transceiver with LC connector
SC Pluggable transceiver with SC connector
ST Pluggable transceiver with ST connector
1100 Mbps
21000 Mbps
3 10 Gbps
P99 -
Interface *) Property
[-] 100 Mbps, LC port optical, glass FO cable (multimode), up to max. 3 km
1000 Mbps, LC port optical, glass FO cable (multimode), up to max. 750 m
10 Gbps, LC port optical, glass FO cable (multimode), up to 550 m
+ 1000 Mbps, LC port optical, glass FO cable (multimode), up to max. 2 km
BXMT 1000 Mbps, LC port optical for glass FO cable (multimode), up to max. 500 m, for
transmission over only one fiber
BXMR 1000 Mbps, LC port optical for glass FO cable (multimode), up to max. 500 m, for
transmission over only one fiber
BX10T 1000 Mbps, LC port optical for glass FO cable (single mode), up to max. 10 km, for
transmission over only one fiber
BX10R 1000 Mbps, LC port optical for glass FO cable (single mode), up to max. 10 km, for
transmission over only one fiber
LD 100 Mbps, LC port optical, glass FO cable (single mode), up to max. 26 km
1000 Mbps, LC port optical, glass FO cable (single mode), up to max. 10 km
10 Gbps, LC port optical, glass FO cable (single mode), up to 10 km
LD+ 1000 Mbps LC port optical for glass FO cable (single mode) up to max. 30 km
LH 1000 Mbps, LC port optical, glass FO cable (single mode), up to max. 40 km
10 Gbps, LC port optical, glass FO cable (single mode), up to 40 km
LH+ 100 Mbps, LC port optical, glass FO cable (single mode), up to max. 70 km
1000 Mbps, LC port optical, glass FO cable (single mode), up to max. 70 km
Transceiver SFP/SFP+/SCP/STP
Operating Instructions, 10/2019, A5E02630804-13 11

Interface *) Property
ELH 1000 Mbps, LC port optical, glass FO cable (single mode), up to max. 120 km
ELH200 100 Mbps, LC port optical, glass FO cable (single mode), up to max. 200 km
*) LD (Long Distance), LH (Long Haul), LH+ (Long Haul +), ELH (Extreme Long Haul)
3.1 Product overview
All plug-in transceivers listed below are intended for use in SIMATIC NET devices.
Note
Fiber monitoring
All pluggable transceivers are capable of diagnostics and support fiber monitoring.
Pluggable transceiver SFP (100 Mbps)
Type Property Article number
SFP991-1 1 x 100 Mbps, LC port optical for glass FO cable
(multimode), up to max. 5 km
6GK5 991-1AD00-8AA0
10 packing unit (VPE 10) 6GK5 991-1AD00-8AC0
SFP991-1 (C) 1 x 100 Mbps, SC port optical, for glass FO cable
(multimode), up to max. 5 km, varnished
6GK5 991-1AD00-8FA0
SFP991-1LD 1 x 100 Mbps LC port optical for glass FO cable
(single mode) up to max. 26 km
6GK5 991-1AF00-8AA0
10 packing unit (VPE 10) 6GK5 991-1AF00-8AC0
SFP991-1LD (C) 1 x 100 Mbps LC port optical for glass FO cable
(single mode) up to max. 26 km, varnished
6GK5 991-1AF00-8FA0
SFP991-1LH+ 1 x 100 Mbps LC port optical for glass FO cable
(single mode) up to max. 70 km
6GK5 991-1AE00-8AA0
SFP991-1ELH200 1 x 100 Mbps LC port optical for glass FO cable
(single mode) up to max. 200 km
6GK5 991-1AE30-8AA0
The SFP plug-in transceiver (100 Mbps) cannot be operated in SFP+ slots.
Pluggable transceivers with the supplement (C) in the type name have varnished printed circuit boards
(conformal coating).
Pluggable transceiver SFP (1000 Mbps)
Type Property Article number
SFP992-1 1 x 1000 Mbps, LC port optical for glass FO cable
(multimode), up to max. 750 m
6GK5 992-1AL00-8AA0
10 packing unit (VPE 10) 6GK5 992-1AL00-8AC0
SFP992-1+ 1 x 1000 Mbps, LC port optical for glass FO cable
(multimode), up to max. 2 km
6GK5 992-1AG00-8AA0
Description of the device
3.1 Product overview
Transceiver SFP/SFP+/SCP/STP
12 Operating Instructions, 10/2019, A5E02630804-13

Type Property Article number
SFP992-1LD 1 x 1000 Mbps LC port optical for glass FO cable
(single mode) up to max. 10 km
6GK5 992-1AM00-8AA0
10 packing unit (VPE 10) 6GK5 992-1AM00-8AC0
SFP992-1LD (C) 1 x 1000 Mbps LC port optical for glass FO cable
(single mode) up to max. 10 km, varnished
6GK5 992-1AM00-8FA0
SFP992-1LD+ 1 x 1000 Mbps LC port optical for glass FO cable
(single mode) up to max. 30 km
6GK5 992-1AM30-8AA0
SFP992-1LH 1 x 1000 Mbps LC port optical for glass FO cable
(single mode) up to max. 40 km
6GK5 992-1AN00-8AA0
SFP992-1LH+ 1 x 1000 Mbps LC port optical for glass FO cable
(single mode) up to max. 70 km
6GK5 992-1AP00-8AA0
SFP992-1ELH 1 x 1000 Mbps LC port optical for glass FO cable
(single mode) up to max. 120 km
6GK5 992-1AQ00-8AA0
Pluggable transceivers with the supplement (C) in the type name have varnished printed circuit boards
(conformal coating).
Note
Only the following transceivers are permitted for the SCALANCE W786-2 SFP:
● SFP992-1
● SFP992-1LD
● SFP992-1LH
● SFP992-1LH+
● SFP992-1ELH
Bidirectional plug-in transceiver SFP
Bidirectional plug-in transceivers feature only one fiber connection. They transmit and receive
on two different wavelengths. To establish a connection, you need two matching bidirectional
SFPs. The connected SFPs must respectively transmit on the wavelength at which the
connection partner receives.
Type Properties Article number
SFP992-1BXMT 1 x 1000 Mbps LC port optical for glass FO (mul‐
timode) with max. 500 m, transmits at 1550 nm,
receives at 1310 nm
6GK5 992-1AL00-8TA0
SFP992-1BXMR 1 x 1000 Mbps LC port optical for glass FO (mul‐
timode) with max. 500 m, transmits at 1310 nm,
receives at 1550 nm
6GK5 992-1AL00-8RA0
SFP992-1BX10T 1 x 1000 Mbps LC port optical for glass FO (single
mode) with max. 10 km, transmits at 1550 nm,
receives at 1310 nm
6GK5 992-1AM00-8TA0
SFP992-1BX10R 1 x 1000 Mbps LC port optical for glass FO (single
mode) with max. 10 km, transmits at 1310 nm,
receives at 1550 nm
6GK5 992-1AM00-8RA0
Description of the device
3.1 Product overview
Transceiver SFP/SFP+/SCP/STP
Operating Instructions, 10/2019, A5E02630804-13 13

SFP+ transceiver
Type Properties Article number
SFP993-1 1 x 10 Gbps, LC port optical for glass FO cable
(multimode), up to max. 550 m
6GK5 993-1AT00-8AA0
SFP993-1LD 1 x 10 Gbps, LC port optical for glass FO cable
(single mode), up to max. 10 km
6GK5 993-1AU00-8AA0
SFP993-1LH 1 x 10 Gbps, LC port optical for glass FO cable
(single mode), up to max. 40 km
6GK5 993-1AV00-8AA0
Can only be operated in SFP+ slots.
Note
Restriction with SFP+ pluggable transceivers for SCALANCE XR526-8C
If you use SFP+ transceivers with the SCALANCE XR526-8C, the maximum ambient
temperature is reduced to 50 ℃.
Preassembled IE cable with SFP+ plugs
Component Description Article number
IE Cable SFP+/SFP
+
Preassembled IE cable with two
permanently mounted SFP+
plugs,
electrical, 10 Gbps,
pack of 1
Length 1 m 6GK5 980-3CB00-0AA1
Length 2 m 6GK5 980-3CB00-0AA2
Length 7 m 6GK5 980-3CB00-0AA7
SCP / STP transceiver
Type Properties Article number
SCP992-1 1 x 1000 Mbps SC port optical for glass FO cable
(multimode) up to max. 750 m
6GK5 992-1AJ00-8AA0
SCP992-1LD 1 x 1000 Mbps SC port optical for glass FO cable
(single mode) up to max. 10 km
6GK5 992-1AK00-8AA0
STP991-1 1 x 100 Mbps ST port optical for glass FO cable
(multimode) up to max. 3 km
6GK5 991-1AB00-8AA0
STP991-1LD 1 x 100 Mbps ST port optical for glass FO cable
(single mode) up to max. 26 km
6GK5 991-1AC00-8AA0
Can only be operated in SCP and STP slots.
Description of the device
3.1 Product overview
Transceiver SFP/SFP+/SCP/STP
14 Operating Instructions, 10/2019, A5E02630804-13

Media modules
Note
The SFP media modules MM992-2SFP may only be fitted with approved transceivers. The
media module can be fitted with up to two pluggable transceivers.
The SFP media modules MM992-4SFP may only be fitted with approved transceivers. The
media module can be fitted with up to four pluggable transceivers.
Type Properties Article number Labeling on the
device
MM992-2SFP 2 x 100 / 1000 Mbps, SFP media module 6GK5
992-2AS00-8AA0
9922AS
MM992-2SFP
(C)
2 x 100 / 1000 Mbps, SFP media module,
coated
6GK5
992-2AS00-8FA0
9922AS
MM992-4SFP 4 x 100 / 1000 Mbps, SFP media module 6GK5
992-4AS00-8AA0
9924AS
3.2 Components of the product
The following components are supplied with a transceiver:
● Transceiver
● Information sheet
Unpacking and checking
WARNING
Do not use any parts that show evidence of damage
If you use damaged parts, there is no guarantee that the device will function according to the
specification.
If you use damaged parts, this can lead to the following problems:
● Injury to persons
● Loss of the approvals
● Violation of the EMC regulations
● Damage to the device and other components
Use only undamaged parts.
1. Make sure that the package is complete.
2. Check all the parts for transport damage.
Description of the device
3.2 Components of the product
Transceiver SFP/SFP+/SCP/STP
Operating Instructions, 10/2019, A5E02630804-13 15

Description of the device
3.2 Components of the product
Transceiver SFP/SFP+/SCP/STP
16 Operating Instructions, 10/2019, A5E02630804-13

Assembling 4
4.1 Safety notices for installation
Safety notices
When installing the device, keep to the safety notices listed below.
Safety notices on use in hazardous areas
General safety notices relating to protection against explosion
WARNING
EXPLOSION HAZARD
Replacing components may impair suitability for Class 1, Division 2 or Zone 2.
WARNING
When used in hazardous environments corresponding to Class I, Division 2 or Class I, Zone
2, the device must be installed in a cabinet or a suitable enclosure.
Safety notices for use according to ATEX and IECEx
If you use the device under ATEX or IECEx conditions you must also keep to the following
safety notices in addition to the general safety notices for protection against explosion:
WARNING
Requirements for the cabinet/enclosure
The equipment shall be installed in a suitable enclosure that provides a degree of protection
not less than IP54 in accordance with EN/IEC 60079-15.
WARNING
Suitable cables at high ambient temperatures
If the temperature of the cable or housing socket exceeds 70 °C or the branching point of
conductors exceeds 80 °C, special precautions must be taken.
If the device is operated at ambient temperatures of between 50 °C and 70 °C, only use cables
with a maximum permitted operating temperature of at least 80 °C.
Transceiver SFP/SFP+/SCP/STP
Operating Instructions, 10/2019, A5E02630804-13 17

4.2 Notes on installation of SFP / SFP+ transceivers
General notes on media modules and pluggable transceivers
WARNING
Install and remove media modules only when the power is off
Media modules may only be inserted in or removed from a SCALANCE device when the
power supply to the device has been turned off.
Use only approved media modules
Use only "MM900" media modules in the module slots of SCALANCE devices.
NOTICE
Only use plug-in transceivers in approved SCALANCE devices
Only use the SFP/SFP+ plug-in transceivers in SCALANCE devices that have ATEX/IECEx
approval.
If you use the SFP/SFP+ plug-in transceivers in other devices, Siemens cannot guarantee the
compatibility and risk-free use of these components.
Assembling
4.2 Notes on installation of SFP / SFP+ transceivers
Transceiver SFP/SFP+/SCP/STP
18 Operating Instructions, 10/2019, A5E02630804-13

CAUTION
Remember the orientation of media modules.
On modular devices, there are always two module slots arranged opposite each other.
Remember the correct orientation when installing MM900 media modules.
Example:
● The first MM900 media module is installed in slot 1.
● The second MM900 media module installed in slot 2 must be turned through 180 degrees.
On modular devices for rack mounting, pairs of module slots are located one above the other
in which modules can be inserted in a specific order:
Example of a rack device:
● The first MM900 media module is installed in slot 1.
● The second MM900 media module installed in slot 7 must be turned through 180 degrees.
Other modules are then inserted in slots 2 and 8 or 3 and 9 etc.
The permitted operating temperature is decided by the fully equipped device (switch + media
module + pluggable transceiver).
With modular devices, it is not only the switch that decides the permitted operating
temperature of the overall device but also the temperature ranges of the MM900 media
modules and the SFP transceivers. You will find details in the technical specifications of the
relevant components.
The following aspects can restrict the maximum permitted operating temperature:
● The orientation of the carrier device.
● The use of SFP transceivers.
● The use of transceivers of the types LH, LH+ or ELH.
NOTICE
Use only approved pluggable transceivers
If you use components not approved by Siemens AG, in particular SFP / SFP+ transceivers,
Siemens cannot accept any responsibility for the correct functioning of the "Ethernet switch
system" according to the specification.
If components are used that have not been Siemens approved, Siemens cannot vouch for
their compatibility or for risk-free use of these components.
Note
Use media modules only in an approved modular device
Use an MM900 media module only for a device equipped with suitable slots for such modules.
Example: X308-2M.
The names and labeling of the media modules differ
● Example: The device is called, for example, "MM992-2SFP" [6GK5 992-2AS00-8AA0], the
labeling on the device is "9922AS". You will find detailed information on the labeling of the
media modules in the "MM900 media modules" compact operating instructions.
Assembling
4.2 Notes on installation of SFP / SFP+ transceivers
Transceiver SFP/SFP+/SCP/STP
Operating Instructions, 10/2019, A5E02630804-13 19

Note
Shipbuilding approval
The shipbuilding approval applies to all SFP pluggable transceivers.
Note
Slot number
With modular devices, the MM900 media modules must be given a slot number.
The slot number labels are supplied with the modular devices.
Note
Different colors of the clip
An SFP with multimode has a black clip and an SFP with single mode has a blue clip. To protect
the pins, these are fitted with a dummy plug.
Note
Plugging and pulling during operation
With SCALANCE X, the pluggable transceivers can be plugged and pulled during operation. If
you have questions on the use of SIMATIC NET products, please contact your Siemens sales
partner.
Notes on SCALANCE X-300
Note
Pluggable transceivers with the SCALANCE XR324-4M EEC
In contrast to the information in the product documentation for the SCALANCE MM900,
MM992-2SFP media modules can be operated in the SCALANCE XR324-4M EEC at ambient
temperatures up to a maximum of 70 °C if the following requirements are met:
● MM992-2SFP media modules as of hardware product version 02 are suitable. The
hardware product version can be found on the device. You can also read out this information
with the WBM or the CLI.
● Only the following pluggable transceivers may be used:
– SFP991-1
– SFP991-1LD
– SFP992-1
– SFP992-1LD
Assembling
4.2 Notes on installation of SFP / SFP+ transceivers
Transceiver SFP/SFP+/SCP/STP
20 Operating Instructions, 10/2019, A5E02630804-13
