Siemens SIMATIC NET SFP User manual

SIMATIC NET
Network components
Transceiver SFP/SFP+/SCP/STP
Operating Instructions
10/2023
A5E02630804-18
Introduction 1
Safety notes 2
Description of the device 3
Assembling 4
Uninstalling 5
Connecting up 6
Maintenance and cleaning 7
Technical data 8
Dimension drawings 9
Approvals 10

Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Quali󹪝ed Personnel
The product/system described in this documentation may be operated only by personnel quali󹪝ed for the speci󹪝c
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Quali󹪝ed personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended or
approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance
are required to ensure that the products operate safely and without any problems. The permissible ambient
conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identi󹪝ed by ® are registered trademarks of SiemensAG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens AG
Digital Industries
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E02630804-18
Ⓟ 10/2023 Subject to change
Copyright © SiemensAG 2011 - 2023.
All rights reserved

Table of contents
1 Introduction ........................................................................................................................................... 5
2 Safety notes ........................................................................................................................................... 9
3 Description of the device..................................................................................................................... 11
3.1 Product overview............................................................................................................... 12
3.2 Components of the product ............................................................................................... 15
4 Assembling .......................................................................................................................................... 17
4.1 Safety notices for installation ............................................................................................. 17
4.2 Notes on installation of SFP / SFP+ transceivers................................................................... 18
4.3 Using a pluggable transceiver (SFP/SFP+)............................................................................ 19
4.4 Notes on installation of SCP / STP transceivers .................................................................... 20
4.5 Using a pluggable transceiver (SCP/STP) ............................................................................. 21
5 Uninstalling ......................................................................................................................................... 25
5.1 Removing a pluggable transceiver (SFP/SFP+) ..................................................................... 25
5.2 Removing a pluggable transceiver (SCP/STP)....................................................................... 26
6 Connecting up ..................................................................................................................................... 29
6.1 Safety when connecting up................................................................................................ 29
6.2 Power supply ..................................................................................................................... 31
7 Maintenance and cleaning .................................................................................................................. 33
8 Technical data...................................................................................................................................... 35
8.1 SFP transceiver .................................................................................................................. 35
8.1.1 SFP991-1/SFP991-1(C) ....................................................................................................... 36
8.1.2 SFP991-1A......................................................................................................................... 36
8.1.3 SFP991-1LD/SFP991-1LD(C) ............................................................................................... 37
8.1.4 SFP991-1LD A.................................................................................................................... 37
8.1.5 SFP991-1LH+..................................................................................................................... 38
8.1.6 SFP991-1ELH200 ............................................................................................................... 38
8.1.7 SFP992-1/SFP992-1(C) ....................................................................................................... 38
8.1.8 SFP992-1+......................................................................................................................... 39
8.1.9 SFP992-1LD/SFP992-1LD(C) ............................................................................................... 39
8.1.10 SFP992-1LD+ ..................................................................................................................... 40
8.1.11 SFP992-1LH....................................................................................................................... 40
8.1.12 SFP992-1LH+..................................................................................................................... 41
8.1.13 SFP992-1ELH ..................................................................................................................... 41
8.2 Bidirectional plug-in transceiver SFP ................................................................................... 42
8.2.1 SFP992-1BXMT .................................................................................................................. 42
8.2.2 SFP992-1BXMR .................................................................................................................. 42
Transceiver SFP/SFP+/SCP/STP
Operating Instructions, 10/2023, A5E02630804-18 3

8.2.3 SFP992-1BX10T ................................................................................................................. 43
8.2.4 SFP992-1BX10R ................................................................................................................. 43
8.3 SFP+ transceiver ................................................................................................................ 44
8.3.1 SFP993-1........................................................................................................................... 44
8.3.2 SFP993-1LD ....................................................................................................................... 45
8.3.3 SFP993-1LH....................................................................................................................... 45
8.4 SCP transceiver .................................................................................................................. 46
8.4.1 SCP992-1........................................................................................................................... 46
8.4.2 SCP992-1LD....................................................................................................................... 46
8.5 STP transceiver .................................................................................................................. 47
8.5.1 STP991-1........................................................................................................................... 47
8.5.2 STP991-1LD....................................................................................................................... 48
8.6 Attenuators ....................................................................................................................... 48
8.7 Construction...................................................................................................................... 49
8.8 Environmental conditions .................................................................................................. 49
8.9 E󹪜ective power loss ........................................................................................................... 50
8.10 MTBF (Mean Time Between Failure) ................................................................................... 51
9 Dimension drawings............................................................................................................................ 53
9.1 SFP dimension drawing...................................................................................................... 53
9.2 SFP+ dimension drawing.................................................................................................... 54
9.3 SCP dimension drawing...................................................................................................... 55
9.4 STP dimension drawing...................................................................................................... 56
10 Approvals............................................................................................................................................. 57
Index .................................................................................................................................................... 63
Table of contents
Transceiver SFP/SFP+/SCP/STP
4Operating Instructions, 10/2023, A5E02630804-18

Introduction 1
Purpose of the compact operating instructions
Based on the compact operating instructions, you will be able to install the SFP, SFP+, SCP and
STP transceivers. The con󹪝guration and the integration of the devices in a network are not
described in these instructions.
Validity of these compact operating instructions
These compact operating instructions apply to the SFP, SFP+, SCP and STP product group.
Further documentation
In the system manuals "Industrial Ethernet / PROFINET Industrial Ethernet" and "Industrial
Ethernet / PROFINET passive network components", you will 󹪝nd information on other SIMATIC
NET products that you can operate along with the devices of this product line in an Industrial
Ethernet network.
There, you will 󹪝nd among other things optical performance data of the communications
partner that you require for the installation.
You will 󹪝nd the system manuals here:
• On the data medium that ships with some products:
– Product CD / product DVD
– SIMATIC NET Manual Collection
• On the Internet pages of Siemens Industry Online Support:
– Industrial Ethernet / PROFINET Industrial Ethernet System Manual (https://
support.industry.siemens.com/cs/ww/es/view/27069465)
– Industrial Ethernet / PROFINET Passive Network Components System Manual (https://
support.industry.siemens.com/cs/ww/en/view/84922825)
SIMATIC NET manuals
You will 󹪝nd the SIMATIC NET manuals here:
• On the Internet pages of Siemens Industry Online Support (https://
support.industry.siemens.com/cs/ww/en/ps/15247).
SIMATIC NET glossary
Explanations of many of the specialist terms used in this documentation can be found in the
SIMATIC NET glossary.
Transceiver SFP/SFP+/SCP/STP
Operating Instructions, 10/2023, A5E02630804-18 5

You will 󹪝nd the SIMATIC NET glossary here:
• On the data medium that ships with some products:
– Product CD / product DVD
– SIMATIC NET Manual Collection
• On the Internet pages of Siemens Industry Online Support (https://
support.industry.siemens.com/cs/ww/en/view/50305045).
Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens’ products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be connected
to an enterprise network or the internet if and to the extent such a connection is necessary
and only when appropriate security measures (e.g. 󹪝rewalls and/or network segmentation)
are in place.
For additional information on industrial security measures that may be implemented, please
visit
https://www.siemens.com/industrialsecurity (https://www.siemens.com/industrialsecurity)
Siemens’ products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends that product updates are applied as soon as they are
available and that the latest product versions are used. Use of product versions that are no
longer supported, and failure to apply the latest updates may increase customers’ exposure
to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed under
https://www.siemens.com/industrialsecurity (https://www.siemens.com/industrialsecurity)
Catalogs
You will 󹪝nd the article numbers for the Siemens products of relevance here in the following
catalogs:
• SIMATIC NET Industrial Communication / Industrial Identi󹪝cation, catalog IKPI
• SIMATIC Products for Totally Integrated Automation and Micro Automation, catalog ST70
• Industry Mall - catalog and ordering system for automation and drive technology, Online
catalog (https://mall.industry.siemens.com/goos/WelcomePage.aspx?regionUrl=/
de&language=en)
You can request the catalogs and additional information from your Siemens representative.
Introduction
Transceiver SFP/SFP+/SCP/STP
6Operating Instructions, 10/2023, A5E02630804-18

Device defective
If a fault develops, send the device to your SIEMENS representative for repair. Repairs on-site are
not possible.
Recycling and disposal
The products are low in pollutants, can be recycled and meet the requirements of the WEEE
directive 2012/19/EU for the disposal of electrical and electronic equipment.
Do not dispose of the products at public disposal sites.
For environmentally friendly recycling and the disposal of your old device contact a certi󹪝ed
disposal company for electronic scrap or your Siemens contact (Product return (https://
support.industry.siemens.com/cs/ww/en/view/109479891)).
Note the di󹪜erent national regulations.
Trademarks
The following and possibly other names not identi󹪝ed by the registered trademark sign ® are
registered trademarks of Siemens AG:
SCALANCE, C-PLUG, OLM
Electrostatic discharge
NOTICE
Electrostatic sensitive devices (ESD)
Electronic modules contain electrostatic sensitive components
These components can easily be destroyed if handled incorrectly.
Note the following instructions to avoid damage.
• Touch electronic modules only when you absolutely need to work on them.
• If electronic modules need to be touched, the body of the person involved must 󹪝rst be
electrostatically discharged and grounded.
• Do not bring electronic modules in contact with electrically isolating materials such as
plastic 󹪝lm, isolating table top pads or clothing made of synthetic 󹪝bers.
• Place the modules only on conductive surfaces.
• Pack, store and transport electronic modules and components only in their product
packaging or in a conductive packaging such as metalized plastic or metal containers,
conductive foam or household aluminum foil.
Introduction
Transceiver SFP/SFP+/SCP/STP
Operating Instructions, 10/2023, A5E02630804-18 7

Introduction
Transceiver SFP/SFP+/SCP/STP
8Operating Instructions, 10/2023, A5E02630804-18

Safety notes 2
Read the safety notices
Note the following safety notices. These relate to the entire working life of the device.
You should also read the safety notices relating to handling in the individual sections,
particularly in the sections "Installation" and "Connecting up".
CAUTION
To prevent injury and damage, read the manual before using the device.
Transceiver SFP/SFP+/SCP/STP
Operating Instructions, 10/2023, A5E02630804-18 9

Safety notes
Transceiver SFP/SFP+/SCP/STP
10 Operating Instructions, 10/2023, A5E02630804-18

Description of the device 3
Structure of the type designation
The type designation of an pluggable transceiver is made up of several parts that have the
following meaning:
Interface
Number of ports
-Standard version
(C) Conformal coating
SF Pluggable transceiver with LC connector
SC Pluggable transceiver with SC connector
ST Pluggable transceiver with ST connector
1100 Mbps
21000 Mbps
3 10 Gbps
P99 -
Interface *) Property
[-] 100 Mbps, LC port optical, glass FO cable (multimode), up to max. 3 km
1000 Mbps, LC port optical, glass FO cable (multimode), up to max. 750 m
10 Gbps, LC port optical, glass FO cable (multimode), up to 550 m
+ 1000 Mbps, LC port optical, glass FO cable (multimode), up to max. 2 km
A 100 Mbps, LC port optical, glass FO cable (multimode), up to max. 3 km to use Gigabit
slots as Fast Ethernet interfaces
BXMT 1000 Mbps, LC port optical for glass FO cable (multimode), up to max. 500 m, for
transmission over only one 󹪝ber
BXMR 1000 Mbps, LC port optical for glass FO cable (multimode), up to max. 500 m, for
transmission over only one 󹪝ber
BX10T 1000 Mbps, LC port optical for glass FO cable (single mode), up to max. 10 km, for
transmission over only one 󹪝ber
BX10R 1000 Mbps, LC port optical for glass FO cable (single mode), up to max. 10 km, for
transmission over only one 󹪝ber
LD 100 Mbps, LC port optical, glass FO cable (single mode), up to max. 26 km
1000 Mbps, LC port optical, glass FO cable (single mode), up to max. 10 km
10 Gbps, LC port optical, glass FO cable (single mode), up to 10 km
LD A 100 Mbps, LC port optical, glass FO cable (single-mode), up to max. 26 km to use
Gigabit slots as Fast Ethernet interfaces
LD+ 1000 Mbps LC port optical for glass FO cable (single mode) up to max. 30km
Transceiver SFP/SFP+/SCP/STP
Operating Instructions, 10/2023, A5E02630804-18 11

Interface *) Property
LH 1000 Mbps, LC port optical, glass FO cable (single mode), up to max. 40 km
10 Gbps, LC port optical, glass FO cable (single mode), up to 40 km
LH+ 100 Mbps, LC port optical, glass FO cable (single mode), up to max. 70 km
1000 Mbps, LC port optical, glass FO cable (single mode), up to max. 70 km
ELH 1000 Mbps, LC port optical, glass FO cable (single mode), up to max. 120 km
ELH200 100 Mbps, LC port optical, glass FO cable (single mode), up to max. 200 km
*) LD (Long Distance), LH (Long Haul), LH+ (Long Haul+), ELH (Extreme Long Haul)
3.1 Product overview
All plug-in transceivers listed below are intended for use in SIMATIC NET devices.
Note
Fiber monitoring
All pluggable transceivers are capable of diagnostics and support 󹪝ber monitoring.
Pluggable transceiver SFP (100 Mbps)
Type Property Article number
SFP991-1 1 x 100 Mbps, LC port optical for glass FO cable
(multimode), up to max. 5 km
6GK5 991-1AD00-8AA0
10 packing unit (VPE 10) 6GK5 991-1AD00-8AC0
SFP991-1 (C) 1 x 100 Mbps, SC port optical, for glass FO cable
(multimode), up to max. 5 km, varnished
6GK5 991-1AD00-8FA0
SFP991-1LD 1 x 100 Mbps LC port optical for glass FO cable (sin‐
gle mode) up to max. 26 km
6GK5 991-1AF00-8AA0
10 packing unit (VPE 10) 6GK5 991-1AF00-8AC0
SFP991-1LD (C) 1 x 100 Mbps LC port optical for glass FO cable (sin‐
gle mode) up to max. 26 km, varnished
6GK5 991-1AF00-8FA0
SFP991-1LH+ 1 x 100 Mbps LC port optical for glass FO cable (sin‐
gle mode) up to max. 70 km
6GK5 991-1AE00-8AA0
SFP991-1ELH200 1 x 100 Mbps LC port optical for glass FO cable (sin‐
gle mode) up to max. 200 km
6GK5 991-1AE30-8AA0
The SFP plug-in transceiver (100 Mbps) cannot be operated in SFP+ slots.
Pluggable transceivers with the supplement (C) in the type name have varnished printed circuit boards
(conformal coating).
Description of the device
3.1Product overview
Transceiver SFP/SFP+/SCP/STP
12 Operating Instructions, 10/2023, A5E02630804-18

Active plug-in transceiver SFP (100 Mbps)
With active plug-in transceivers, Gigabit slots can be used as Fast Ethernet interfaces.
Type Property Article number
SFP991-1A 1 x 100 Mbps, LC port optical for glass FO cable
(multimode), up to max. 5km
6GK5 991-1AD00-8GA0
SFP991-1LD A 1 x 100 Mbps LC port optical for glass FO cable (sin‐
gle mode) up to max. 26km
6GK5 991-1AF00-8GA0
Pluggable transceiver SFP (1000 Mbps)
Type Property Article number
SFP992-1 1 x 1000 Mbps, LC port optical for glass FO cable
(multimode), up to max. 750 m
6GK5 992-1AL00-8AA0
10 packing unit (VPE 10) 6GK5 992-1AL00-8AC0
SFP992-1 (C) 1 x 1000 Mbps, LC port optical, for glass FO cable
(multimode), up to max. 750 m, varnished
6GK5 992-1AL00-8FA0
SFP992-1+ 1 x 1000 Mbps, LC port optical for glass FO cable
(multimode), up to max. 2 km
6GK5 992-1AG00-8AA0
SFP992-1LD 1 x 1000 Mbps LC port optical for glass FO cable
(single mode) up to max. 10 km
6GK5 992-1AM00-8AA0
10 packing unit (VPE 10) 6GK5 992-1AM00-8AC0
SFP992-1LD (C) 1 x 1000 Mbps LC port optical for glass FO cable
(single mode) up to max. 10 km, varnished
6GK5 992-1AM00-8FA0
SFP992-1LD+ 1 x 1000 Mbps LC port optical for glass FO cable
(single mode) up to max. 30km
6GK5 992-1AM30-8AA0
SFP992-1LH 1 x 1000 Mbps LC port optical for glass FO cable
(single mode) up to max. 40 km
6GK5 992-1AN00-8AA0
SFP992-1LH+ 1 x 1000 Mbps LC port optical for glass FO cable
(single mode) up to max. 70 km
6GK5 992-1AP00-8AA0
SFP992-1ELH 1 x 1000 Mbps LC port optical for glass FO cable
(single mode) up to max. 120 km
6GK5 992-1AQ00-8AA0
Pluggable transceivers with the supplement (C) in the type name have varnished printed circuit boards
(conformal coating).
Note
Only the following transceivers are permitted for the SCALANCE W786-2 SFP:
• SFP992-1
• SFP992-1LD
• SFP992-1LH
• SFP992-1LH+
• SFP992-1ELH
Description of the device
3.1Product overview
Transceiver SFP/SFP+/SCP/STP
Operating Instructions, 10/2023, A5E02630804-18 13

Bidirectional plug-in transceiver SFP
Bidirectional plug-in transceivers feature only one 󹪝ber connection. They transmit and receive
on two di󹪜erent wavelengths. To establish a connection, you need two matching bidirectional
SFPs. The connected SFPs must respectively transmit on the wavelength at which the
connection partner receives.
Type Properties Article number
SFP992-1BXMT 1 x 1000 Mbps LC port optical for glass FO (multi‐
mode) with max. 500 m, transmits at 1550 nm,
receives at 1310 nm
6GK5 992-1AL00-8TA0
SFP992-1BXMR 1 x 1000 Mbps LC port optical for glass FO (multi‐
mode) with max. 500 m, transmits at 1310 nm,
receives at 1550 nm
6GK5 992-1AL00-8RA0
SFP992-1BX10T 1 x 1000 Mbps LC port optical for glass FO (single
mode) with max. 10km, transmits at 1550 nm,
receives at 1310 nm
6GK5 992-1AM00-8TA0
SFP992-1BX10R 1 x 1000 Mbps LC port optical for glass FO (single
mode) with max. 10km, transmits at 1310 nm,
receives at 1550 nm
6GK5 992-1AM00-8RA0
SFP+ transceiver
Type Properties Article number
SFP993-1 1 x 10 Gbps, LC port optical for glass FO cable
(multimode), up to max. 550 m
6GK5 993-1AT00-8AA0
SFP993-1LD 1 x 10 Gbps, LC port optical for glass FO cable
(single mode), up to max. 10 km
6GK5 993-1AU00-8AA0
SFP993-1LH 1 x 10 Gbps, LC port optical for glass FO cable
(single mode), up to max. 40 km
6GK5 993-1AV00-8AA0
Can only be operated in SFP+ slots.
Note
Restriction with SFP+ pluggable transceivers for SCALANCE XR526-8C
If you use SFP+ transceivers with the SCALANCE XR526-8C, the maximum ambient temperature
is reduced to 50℃.
Preassembled IE cable with SFP+ plugs
Component Description Article number
IE Cable SFP+/SFP+ Preassembled IE cable with two
permanently mounted SFP+
plugs,
electrical, 10 Gbps,
pack of 1
Length 1 m 6GK5 980-3CB00-0AA1
Length 2 m 6GK5 980-3CB00-0AA2
Length 7 m 6GK5 980-3CB00-0AA7
Description of the device
3.1Product overview
Transceiver SFP/SFP+/SCP/STP
14 Operating Instructions, 10/2023, A5E02630804-18

SCP / STP transceiver
Type Properties Article number
SCP992-1 1 x 1000 Mbps SC port optical for glass FO cable
(multimode) up to max. 750 m
6GK5 992-1AJ00-8AA0
SCP992-1LD 1 x 1000 Mbps SC port optical for glass FO cable
(single mode) up to max. 10 km
6GK5 992-1AK00-8AA0
STP991-1 1 x 100 Mbps ST port optical for glass FO cable (mul‐
timode) up to max. 3km
6GK5 991-1AB00-8AA0
STP991-1LD 1 x 100 Mbps ST port optical for glass FO cable (sin‐
gle mode) up to max. 26 km
6GK5 991-1AC00-8AA0
Can only be operated in SCP and STP slots.
Media modules
Note
The SFP media modules MM992-2SFP may only be 󹪝tted with approved transceivers. The media
module can be 󹪝tted with up to two pluggable transceivers.
The SFP media modules MM992-4SFP may only be 󹪝tted with approved transceivers. The media
module can be 󹪝tted with up to four pluggable transceivers.
Type Properties Article number Labeling on
the device
MM992-2SFP 2 x 100 / 1000 Mbps, SFP media module 6GK5
992-2AS00-8AA0
9922AS
MM992-2SFP
(C)
2 x 100 / 1000 Mbps, SFP media module,
coated
6GK5 992-2AS00-8FA0 9922AS
MM992-4SFP 4 x 100 / 1000 Mbps, SFP media module 6GK5
992-4AS00-8AA0
9924AS
3.2 Components of the product
The following components are supplied with a transceiver:
• Plug-in transceivers with sealing plug
• Information sheet
Description of the device
3.2Components of the product
Transceiver SFP/SFP+/SCP/STP
Operating Instructions, 10/2023, A5E02630804-18 15

Description of the device
3.2Components of the product
Transceiver SFP/SFP+/SCP/STP
16 Operating Instructions, 10/2023, A5E02630804-18

Assembling 4
4.1 Safety notices for installation
Safety notices
When installing the device, keep to the safety notices listed below.
NOTICE
Improper mounting
Improper mounting may damage the device or impair its operation.
• Before mounting the device, always ensure that there is no visible damage to the device.
Note
The plug-in transceivers are only developed for a limited number of plug-in cycles.
• Pull and plug the plug-in transceiver only as often as required.
Safety notices on use in hazardous areas
General safety notices relating to protection against explosion
WARNING
EXPLOSION HAZARD
Replacing components may impair suitability for Class 1, Division 2 or Zone 2.
WARNING
When used in hazardous environments corresponding to Class I, Division 2 or Class I, Zone 2,
the device must be installed in a cabinet or a suitable enclosure.
Notes for use in hazardous locations according to ATEX, IECEx, UKEX and CCC Ex
If you use the device under ATEX, IECEx, UKEX or CCC Ex conditions you must also keep to
the following safety instructions in addition to the general safety instructions for protection
against explosion:
Transceiver SFP/SFP+/SCP/STP
Operating Instructions, 10/2023, A5E02630804-18 17

WARNING
Requirements for the cabinet/enclosure
The equipment shall be installed in a suitable enclosure that provides a degree of protection not
less than IP54 in accordance with EN/IEC 60079-15.
WARNING
Suitable cables at high ambient temperatures
If the temperature of the cable or housing socket exceeds 70 °C or the branching point of
conductors exceeds 80 °C, special precautions must be taken.
If the device is operated at ambient temperatures of between 50 °C and 70 °C, only use cables
with a maximum permitted operating temperature of at least 80 °C.
4.2 Notes on installation of SFP / SFP+ transceivers
General notes on media modules and pluggable transceivers
NOTICE
Use only approved pluggable transceivers
If you use components not approved by Siemens AG, in particular SFP / SFP+ transceivers,
Siemens cannot accept any responsibility for the correct functioning of the "Ethernet switch
system" according to the speci󹪝cation.
If components are used that have not been Siemens approved, Siemens cannot vouch for their
compatibility or for risk-free use of these components.
Note
Di󹪜erent colors of the clip
An SFP with multimode has a black clip and an SFP with single mode has a blue clip. To protect
the pins, these are 󹪝tted with a dummy plug.
Note
Plugging and pulling during operation
With SCALANCE X, the pluggable transceivers can be plugged and pulled during operation. If
you have questions on the use of SIMATIC NET products, please contact your Siemens sales
partner.
Assembling
4.2Notes on installation of SFP / SFP+ transceivers
Transceiver SFP/SFP+/SCP/STP
18 Operating Instructions, 10/2023, A5E02630804-18

Notes on SCALANCE W:
Note
With a SCALANCE W786-2, do not plug or pull an SFP transceiver during operation!
If you have questions on the use of SIMATIC NET products, please contact your Siemens sales
partner.
4.3 Using a pluggable transceiver (SFP/SFP+)
NOTICE
Electrostatic sensitive devices (ESD)
Plug-in transceiver are delivered in a carton. The cartons protect the plug-in transceiver against
direct contact and thus against ESD damages.
• Only unpack the plug-in transceiver in an ESD-protected mounting and installation area.
• Make sure that the corresponding safety measures are met if you use the plug-in transceiver:
– They are permanently grounded via an ESD wristband.
– You wear ESD shoes or ESD shoe grounding protection strip in connection with an ESD
base.
• Before touching an ESD, discharge your own body. To this purpose, touch a conductive,
grounded object immediately beforehand, e.g. a bare metal control cabinet part.
• Do not touch the electrical contacts of the PCB.
• Only always touch the plug-in transceiver at the metal enclosure.
Figure4-1 Plugging in a transceiver
Assembling
4.3Using a pluggable transceiver (SFP/SFP+)
Transceiver SFP/SFP+/SCP/STP
Operating Instructions, 10/2023, A5E02630804-18 19

Follow the steps below to insert a pluggable transceiver:
1. Make sure that the package is complete (Page15).
2. Check all the parts for transport damage.
WARNING
Do not use any parts that show evidence of damage
If you use damaged parts, there is no guarantee that the device will function according to
the speci󹪝cations.
If you use damaged parts, this can lead to the following problems:
• Injury to persons
• Loss of approvals
• Violation of the EMC regulations
• Damage to the device and other components
Use only undamaged parts.
3. Remove the plug-in transceiver from its packaging.
4. Make sure that the bracket at the plug-in transceiver is closed.
5. Insert the pluggable transceiver in the pluggable transceiver slot until you hear it engage, see
󹪝gure.
The pluggable transceiver is then 󹪝rmly secured.
6. Remove the sealing plug of the plug-in transceiver.
7. Insert the connecting cable into the pluggable transceiver until you hear it engage.
The connecting cable is then 󹪝rmly secured.
4.4 Notes on installation of SCP / STP transceivers
General notes on pluggable transceivers
NOTICE
Use only approved pluggable transceivers
If you use components not approved by Siemens AG, in particular SCP / STP transceivers,
Siemens cannot accept any responsibility for the correct functioning of the "Ethernet switch
system" according to the speci󹪝cation.
If components are used that have not been Siemens approved, Siemens cannot vouch for their
compatibility or for risk-free use of these components.
Assembling
4.4Notes on installation of SCP / STP transceivers
Transceiver SFP/SFP+/SCP/STP
20 Operating Instructions, 10/2023, A5E02630804-18
