Sierra Wireless AirLink RV50 Series User manual

Cell Specific Supplement
1
Rev 1 866-303-5668 www.AlsoEnergy.com
Sierra Wireless RV50 Install
Scope
Connect the RV50 to power and antennas for RMA upgrade or new field.
SAFETY WARNING
ADHERE TO ALL CAUTIONS AND SAFETY INSTRUCTIONS IN THE SIERRA WIRELESS MANUAL AND THE
ALSOENERGY INSTALLATION MANUAL.
Overview
RV50 runs on 24VDC and uses dual antennas for cell connection. They are typically provided
preconfigured for Verizon 4G service by AlsoEnergy.
Installation Procedure
Power Connection
1. Red and White connect to 24VDC
2. Black connects to negative DC
3. Green is unused

Cell Specific Supplement
2
Rev 1 866-303-5668 www.AlsoEnergy.com
Antenna Connections
Mount the antennas as high as possible and carefully route the cables into the enclosure.
1. Dual antennas use the Cellular and Diversity connectors.
2. Single antenna with three cables, small cable is for GPS connector, other two will be Cellular and
Diversity.

Cell Specific Supplement
3
Rev 1 866-303-5668 www.AlsoEnergy.com
Troubleshooting

Cell Specific Supplement
4
Rev 1 866-303-5668 www.AlsoEnergy.com
More information
More information can be found online in the AirLink RV50 Hardware User Guide.
