Silver Cross Classic Chassis User manual

Classic Chassis
Instructions
IMPORTANT: KEEP FOR FUTURE REFERENCE
Please read these instructions carefully before using your new pram
Keep them in a safe place so that you may use them in the future

CONTENTS
These instructions are important.
Please read carefully and retain for future reference.
Your Classic chassis is a high quality Silver Cross product. It meets current safety
standards and regular light maintenance will ensure long service.
If somebody unfamiliar is using your Classic chassis always ensure that they read
these instructions carefully so that understand how the chassis works best.
Although these instructions clearly outline the correct use of the Classic chassis they
do not relate to the seat unit. To operate the seat unit you must refer to the separate
instructions packed with your chosen seat unit. Remember, the safety of your child is
your responsibility.
The Classic chassis (SX104) is designed and tested to work with the following
Silver Cross seat units
Sleepover (SX301)
Freeway (SX302)
Preparationforuse............................................4
Usingthebrake..............................................7
Heightadjustablehandle .......................................8
Foldingthechassis............................................9
Openingthechassis..........................................11
Using your Classic chassis with the Ventura car seat. . . . . . . . . . . . . . . . . . . .12
Safetynotes................................................13
Description Page No.
CLASSIC CHASSIS - INSTRUCTIONS

4
First check that all your parts have been
supplied. Your complete chassis includes:
A. Chassis C. Wheels x 4
B. Basket x 1
Providing everything is present you are
ready to continue.
1. PREPARATION FOR USE
Gently press down on the handle ensuring
both sides click and lock into place.
Open the chassis by sliding the
folding catches (E) towards you.
This disengages the automatic chassis lock
and allows the handle to rise into the upright
position
2
1
3
E
A B
C

Header
5
1. PREPARATION FOR USE (CONT.)
Your Classic chassis has a multi-position
adjustable handle. Press both adjuster buttons
and rotate the handle to the
mid-position.Release buttons to lock
Now attach your wheels by first removing any
axle packing protection. Present the wheels to
the axle and slide into position. Release the
wheel locking clip (F) by pulling gently and
slide the wheel to the stop position. Release
the clip and check that the wheel has firmly
attached. Repeat on all four wheels.
Carefully position the basket within the
chassis frame with the lower end towards the
brake. Push down on each locking clip to
firmly secure in place.
5
4
6
F

6
1. PREPARATION FOR USE (CONT.)
Your Classic chassis is now ready for use.
We will now proceed to the
features and folding of your Classic chassis
Your Classic chassis is fitted with hard
wearing EVA tyres for convenience and a
puncture free ride.
7
8

Header
7
2. USING THE BRAKE
To engage the brake simply press down on the brake pedal
where ON is marked.
Always check your brake is fully engaged by
gently rocking your chassis.
To disengage the brake simply press on the pedal
in the OFF position.
10
9
11

Header
8
3. HEIGHT ADJUSTABLE HANDLE
Your handle has various different positions
and should always lock firmly into place.
To adjust the handle simply press both the
adjuster buttons and rotate to the desired
height. Release buttons to lock.
The handle is fully adjustable to accommodate
users of varying heights
giving added comfort and allowing for
compact storage
13
12
14

Header
9
4. FOLDING THE CHASSIS
Slide the folding catches (E) towards you until
the locking catches disengage on both sides.
Note: The secondary safety catch will lock at
this stage.
To disengage the secondary safety lock (G),
slightly press down on the handle allowing
the secondary lock (G) to swing freely.
Lift upwards allowing the handle to move
forward, freely.
Rotate the handle until it is parallel to the
wheels and press down on both sides until
you hear a click on both sides.
16
15
17
E
G G
‘click’

10
4. FOLDING THE CHASSIS (CONT.)
The wheels are removable by lifting the
wheel
catch (F - see point 5) towards you and
pulling the wheel away from the axle.
For the most compact fold, adjust the handle
and rotate it towards the floor, then lock.
19
Your Classic chassis has an automatic
locking catch which secures your chassis
for easy transportation and storage
18
20

Header
11
5. OPENING THE CHASSIS
Slide the folding catches (E) towards you to
release the automatic chassis lock
Lift the handle and rotate into the locked
position. Press firmly to ensure both locks
engage
Adjust your handle to the desired height
position.
Your chassis is now ready for use.
22
21
23
E
