Silvercrest ADR 1300 B3 User manual

7
IAN 79821
HANDHELD STEAM CLEANER ADR 1300 B3
HANDHELD STEAM CLEANER
Operating instructions
PЪЧHA ПAPOЧПCTAЧKA
Ръководство за експлоатация
APARAT MANUAL DE
CURĂŢARE CU ABURI
Instrucţiuni de utilizare
ATMOKAΘAPIΣTHΣ XEIPOΣ
Οδηүίες χρήσης
RUČNI ČISTAČ NA PARU
Upute za upotrebu
HANDDAMPFREINIGER
Bedienungsanleitung

GB//IE/CY Operating instructions Page 1
HR Upute za upotrebu Stranica 13
RO Instrucţiuni de utilizare Pagina 25
BG Ръководство за експлоатация Cтраница 37
GR/CY Οδηүίες χρήσης Σελίδα 51
DE/AT/CH Bedienungsanleitung Seite 65
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Prije nego što pročitate tekst, otvorite stranicu sa slikama i upoznajte se na osnovu toga sa svim funkcijama
uređaja.
Înainte de a citi instrucţiunile, priviţi imaginile şi familiarizaţi-vă cu toate funcţiile aparatului.
Преди да прочетете отворете страницата с фигурите и след това се запознайте с всички функции
на уреда.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειωθείτε με όλες τις λειτουργίες
της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.

B
q
A
4
1
2
6
7
5
3
8
9
0

1
ADR 1300 B3
GB
IE
CY
Index
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Copyright. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Items supplied . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Disposal of the packaging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Description of appliance/attachments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Assembling the squeegee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Using the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Filling/refilling with water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Taking the appliance into use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Areas of application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Attaching/detaching accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Child protection system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Scale removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Disposal of the appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Importer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2ADR 1300 B3
GB
IE
CY
Introduction
Congratulations on the purchase of your new appliance.
You have clearly decided in favour of a quality product. These operating instruc-
tions are a part of this product. They contain important information in regard to
safety, use and disposal. Before using the product, familiarise yourself with all of
these operating and safety instructions. Use the product only as described and
only for the specified areas of application. In addition, pass these documents on,
together with the product, to any future owner.
Copyright
This documentation is copyright protected.
Any copying or reproduction of it, including as extracts, as well as the reproduction
of images, also in an altered state, is only permitted with the written authorisation
of the manufacturer.
Intended use
This appliance is intended for the removal of dirt and stains by using steam in
domestic households, for example...
– smooth surfaces: work surfaces, tiles, stove tiles, windows, mirrors
– hard-to-reach areas: corners, joints, louvers, WC, bathroom fittings, etc.
– textiles: curtains, cushions, clothing, car seats.
This appliance is not intended:
– for use outdoors,
– for use with liquids other than water
– for use in commercial or industrial applications.
WARNING
Risks from unintended use!
Risks can be engendered by the appliance if it used for unintended purposes
and/or other types of use.
► Use the appliance exclusively for its intended purposes.
► Observe the procedures described in these operating instructions.

3
ADR 1300 B3
GB
IE
CY
NOTICE
► Risks can be engendered if this appliance is used for purposes not intended
for it and/or for other types of use. Use the appliance exclusively for its
intended purposes. Observe the procedures described in these operating
instructions. Claims of any kind for damage resulting from unintended use,
incompetent repairs, unauthorised modification or the use of unauthorised
spare parts will not be accepted. The operator alone bears liability.
Items supplied
The appliance is delivered with the following components as standard:
▯ Handheld Steam Cleaner
▯ Squeegee
▯ Curved nozzle
▯ Round brush
▯ Operating instructions
1) Remove all parts of the appliance and the operating instructions from the
carton.
2) Remove all packaging material.
NOTICE
► Check the contents to ensure everything is present and for signs of visible
damage.
► If the delivery is not complete, or is damaged due to defective packaging or
through transportation, contact the Service Hotline (see chapter Service).
Disposal of the packaging
The packaging protects the appliance from transport damage. The packaging
materials are selected from the point of view of their environmental friendliness
and disposal technology and are therefore recyclable.
The recirculation of packaging into the material circuit saves on raw material and
reduces the amount of waste generated. Dispose of packaging material that is
no longer needed as per the regionally established regulations.
NOTICE
► If possible preserve the appliance's original packaging during the warranty
period so that in the case of a warranty claim you can package the appli-
ance properly for return.

4ADR 1300 B3
GB
IE
CY
Description of appliance/attachments
Figure A:
1Steam lever
2“Child safety” switch
3Water tank
4“Anti-calc Function” switch
5Water tank fill opening
6Red control lamp
7Green control lamp
8Round brush
9Curved nozzle
0Steam nozzle
Figure B:
qSqueegee
Technical data
Mains voltage 220 - 240 V ~, 50 Hz
Rated power 1300 W
Appliance protection type IPX4
Water tank capacity
300 ml
With a water filling of 300 ml (MAX),
steam can be generated for about
10 minutes.

5
ADR 1300 B3
GB
IE
CY
Safety instructions
RISK OF ELECTRIC SHOCK
► Connect the appliance only to correctly installed mains power sockets
supplying a mains voltage of 220 - 240 V ~/ 50 Hz.
►In the event of operating malfunctions and before cleaning the appliance,
disconnect the plug from the mains power socket.
► To disconnect, always pull the plug itself from the mains power socket, do
not pull on the power cable.
► Do not kink or crimp the power cable and place it in such a way as to
prevent anyone from stepping on or tripping over it.
► To avoid risks, arrange for defective plugs and/or power cables to be
replaced at once by qualified technicians or our Customer Service
Department.
► Ensure that the power cable cannot become wet or damp while the appli-
ance is in operation. Place it such that it cannot be squashed or damaged.
► Should the appliance, the power cable or the plug become damaged, to
avoid personal risks arrange for it/ them to be repaired or replaced by
Customer Services.
► First disconnect the appliance from the mains power socket before filling it
with water, changing accessories or cleaning it.
► Use the appliance only in indoor areas, not outdoors.
► NEVER submerse the appliance in water or other liquids!
► NEVER aim the steam jet directly at electrical appliances or equipment
which contain electrical components, such as the interior of ovens.
► Never leave a heat-generating device unattended! After use or during work
pauses, ALWAYS remove the plug from the mains power socket. The appli-
ance heats up and generates steam pressure continuously when the plug is
connected to a mains power socket!
► Use the appliance only with dry hands and never without shoes (i.e. not
barefoot). This will help reduce the effect of an electric shock in the event of
a malfunction.
► NEVER aim the appliance at moisture-sensitive objects.
► This appliance is not intended for use by individuals (including children)
with restricted physical, physiological or intellectual abilities or deficiences
in experience and/or knowledge unless they are supervised by a person
responsible for their safety or receive from this person instruction in how the
appliance is to be used.

6ADR 1300 B3
GB
IE
CY
WARNING! RISK OF INJURY!
► NEVER remove the water tank if steam is still exiting the steam nozzle!
► Do not operate the appliance with an empty water tank. When the water
reserve is used up, disconnect the power cable to prevent the appliance
from overheating.
► The accessories will get hot during use! There is a risk of being burnt!
► Allow the used accessories to cool down before removing them..
► Use only the original accessory items for this appliance. Other accessories
may not meet the safety requirements.
► This appliance is not intended for use by individuals (including children)
with restricted physical, physiological or intellectual abilities or deficiences
in experience and/or knowledge unless they are supervised by a person
responsible for their safety or receive from this person instruction in how the
appliance is to be used. Children should be supervised to ensure that they
do not play with the appliance.
► Wear gloves, protective glasses and breathing protection equipment when
attempting to remove substances hazardous to health.
► NEVER direct the steam jet toward people or animals. Hot steam under
high pressure can cause serious injuries!
WARNING! RISK OF SCALDING!
This symbol warns you about escaping steam.
Pay heed to the safety instructions!
WARNING - PROPERTY DAMAGE!
► First carry out a test on an unobtrusive area to be certain that the material
is suitable for cleaning with high pressure steam, for instance:
– Painted wood or leather can be bleached by steam.
– Unprotected wood can swell up.
– Protective wax coatings can be dissolved by steam.
– Plastics can become tarnished from the effects of steam.
– Soft plastics can deform when exposed to steam.
– Cold glass or mirror surfaces can crack on encountering hot steam.
► If you wish to clean windows, you must first preheat them, for instance by
applying the steam over large areas from a greater distance, then moving
in progressively closer.
► Acrylics, velvet and silk react sensitively to hot steam, as do plastic fibres.

7
ADR 1300 B3
GB
IE
CY
Assembling the squeegee
1) Open the large screw on the retainer of the squeegee q, such that you can
push in the metal rail with the rubber lip.
2) Thereby ensure that the broad side of the metal rail is at the top.
3) Retighten the large screw.
Using the appliance
WARNING! RISK OF INJURY!
To ensure faultfree operation and a long service life for the
appliance, pay heed to the following instructions:
► First press the steam lever 1when the green control lamp 7glows. If you
press too early it may cause an accumulation of hot water in the appliance,
which will drip or spray from the nozzle. There is a risk of being scalded.
► Before switching the appliance off, always allow all of the steam to drain
out by pressing the steam lever 1until no more steam exits from the nozzle.
Filling/refilling with water
RISK OF ELECTRIC SHOCK
► Always disconnect the plug from the mains power socket before you add
water to the water tank 3!
1) Turn the water tank 3such that the marking on the water tank points to the
open lock on the appliance. The water tank can then be detached from
the appliance.
2) Open the lid of the water tank 3.
WARNING - PROPERTY DAMAGE!
► Do not put any additives or cleaning agents in the water tank 3!
3) Fill the water tank 3with water. Ensure that you never fill the tank with
more water than up to the MAX marking, and never less than up to the
MIN marking.
Should the mains water at your locality be rated as hard, it is recommended that
you mix the mains water with distilled water. Otherwise, the appliance could
calcify prematurely and clog the steam nozzle 0.
