Simons Voss Technologies SmartIntego PadLock AX User manual

SmartIntego
PadLock AX
Manual
24.06.2021

Contents
1 General safety instructions..................................................................................................................... 3
2 Product-specific safety instructions....................................................................................................6
3 Operation...................................................................................................................................................... 7
4 Battery replacement.................................................................................................................................9
5 Signalling .................................................................................................................................................... 14
6 Technical specifications .........................................................................................................................15
6.1 Scale drawings................................................................................................................................................ 16
7 EU/UK Declaration of conformity....................................................................................................... 19
8 Help and other information ................................................................................................................. 20
SmartIntego PadLock AX (Manual) Contents
2 / 21

1 General safety instructions
Signal word (ANSI
Z535.6) Possible immediate effects of non-compliance
DANGER Death or serious injury (likely)
WARNING Death or serious injury (possible, but unlikely)
CAUTION Minor injury
IMPORTANT Property damage or malfunction
NOTE Low or none
WARNING
Blocked access
Access through a door may stay blocked due to incorrectly fitted and/or in-
correctly programmed components. SimonsVoss Technologies GmbH is
not liable for the consequences of blocked access such as access to in-
jured or endangered persons, material damage or other damage!
Blocked access through manipulation of the product
If you change the product on your own, malfunctions can occur and access through a door can
be blocked.
Modify the product only when needed and only in the manner described in the
documentation.
Do not swallow battery. Danger of burns from hazardous substances
This product contains lithium button cell batteries. Swallowing the button cell battery, in can
result in severe internal burns leading to death in as little as two hours.
1. Keep new and used batteries away from children.
2. If the battery compartment does not close securely, cease using the product and keep it
away from children.
3. If you think batteries have been swallowed or are in any part of the body, seek medical
attention immediately.
Risk of explosion due to incorrect battery type
Inserting the wrong type of battery can cause an explosion.
Only use the batteries specified in the technical data.
SmartIntego PadLock AX (Manual) 1. General safety instructions
3 / 21

CAUTION
Fire hazard posed by batteries
The batteries used may pose a fire or burn hazard if handled incorrectly.
1. Do not try to charge, open, heat or burn the batteries.
2. Do not short-circuit the batteries.
IMPORTANT
Damage resulting from electrostatic discharge (ESD)
This product contains electronic components that may be damaged by electrostatic discharges.
1. Use ESD-compliant working materials (e.g. Grounding strap).
2. Ground yourself before carrying out any work that could bring you into contact with the
electronics. For this purpose, touch earthed metallic surfaces (e.g. door frames, water pipes
or heating valves).
Damage resulting from liquids
This product contains electronic components that may be damaged by liquids of any kind.
Keep liquids away from the electronics.
Damage resulting from aggressive cleaning agents
The surface of this product may be damaged as a result of the use of unsuitable cleaning agents.
Only use cleaning agents that are suitable for plastic or metal surfaces.
Damage as a result of mechanical impact
This product contains electronic components that may be damaged by mechanical impacts of
any kind.
1. Avoid touching the electronics.
2. Avoid other mechanical influences on the electronics.
Damage due to polarity reversal
This product contains electronic components that may be damaged by reverse polarity of the
power source.
Do not reverse the polarity of the voltage source (batteries or mains adapters).
Operational malfunction due to radio interference
This product may be affected by electromagnetic or magnetic interference.
Do not mount or place the product directly next to devices that could cause electromagnetic
or magnetic interference (switching power supplies!).
SmartIntego PadLock AX (Manual) 1. General safety instructions
4 / 21

Communication interference due to metallic surfaces
This product communicates wirelessly. Metallic surfaces can greatly reduce the range of the
product.
Do not mount or place the product on or near metallic surfaces.
NOTE
Intended use
SmartIntego-products are designed exclusively for opening and closing
doors and similar objects.
Do not use SmartIntego products for any other purposes.
Malfunctions due to poor contact or different discharge
Contact surfaces that are too small/contaminated or different discharged batteries can lead to
malfunctions.
1. Only use batteries that are approved by SimonsVoss.
2. Do not touch the contacts of the new batteries with your hands.
3. Use clean and grease-free gloves.
4. Always replace all batteries at the same time.
Different times for G2 locks
The internal time unit of the G2 locks has a technical tolerance of up to ± 15 minutes per year.
Qualifications required
The installation and commissioning requires specialized knowledge.
Only trained personnel may install and commission the product.
Incorrect installation
SimonsVoss Technologies GmbH accepts no liability for damage caused to doors or compon-
ents due to incorrect fitting or installation.
Modifications or further technical developments cannot be excluded and may be implemented
without notice.
The German language version is the original instruction manual. Other languages (drafting in the
contract language) are translations of the original instructions.
Read and follow all installation, installation, and commissioning instructions. Pass these instruc-
tions and any maintenance instructions to the user.
SmartIntego PadLock AX (Manual) 1. General safety instructions
5 / 21

2 Product-specific safety instructions
IMPORTANT
Mechanical damage to the knob as a result of obstacles
If the knob can knock against the wall or other objects as a result of the installation situation, it
may become damaged.
In such situations, use a suitable door stop.
Damage caused by moisture in outdoor use
Moisture can damage the electronics.
1. If you want to use the locking cylinder for outdoor applications or in high humidity (bathrooms
or washrooms), use the WP version.
2. Carefully insert the locking cylinder to avoid damaging the O-rings.
Damage to the AX locking cylinder due to unsuitable tools
Special tools are required to open the cover and dismantle the AX locking cylinder. If you use un-
suitable tools, you may damage the AX locking cylinder.
Only use the separately available SimonsVoss special tool (Accessories).
SmartIntego PadLock AX (Manual) 2. Product-specific safety instructions
6 / 21

3 Operation
Open 1. Activate your identification medium on the knob.
2. Turn the knob fully clockwise.
9Shackle unlocked.
3. Open the shackle.
9Padlock open.
Closing 1. Close the shackle.
9SL version: Shackle locks into place automatically.
2. ML version only: Activate your identification medium on the knob.
SmartIntego PadLock AX (Manual) 3. Operation
7 / 21

3. ML version only: Turn the knob fully counter-clockwise.
9Shackle locked.
4. Check for correct closure.
9Padlock locked.
SmartIntego PadLock AX (Manual) 3. Operation
8 / 21

4 Battery replacement
NOTE
Battery contact malfunction due to grease film
When touching batteries, leave a thin film of skin grease on the batteries.
This film deteriorates the contact between the electronics and the batter-
ies.
1. Do not touch the contacts of the new batteries with your hands.
2. Use clean and grease-free gloves.
Maintaining the condition during battery replacement
The Digital Cylinder AX cannot engage or disengage without power supply. Therefore, while the
batteries are removed, the Digital Cylinder AX retains its current locking status and its data status
(programming and stored logs).
üSpecial tool available.
1. Align the thumb-turn horizontally.
2. Attach the special tool.
SmartIntego PadLock AX (Manual) 4. Battery replacement
9 / 21

3. Align the special tool so that the logo is parallel to the recess.
4. Hold the special tool and knob cover firmly at the same time and turn
them together 1-2° clockwise first and then counter-clockwise.
5. Remove the tool and cover.
SmartIntego PadLock AX (Manual) 4. Battery replacement
10 / 21

6. Push the latch inward and open the battery cover.
7. Remove the batteries with the special magnetic tool.
SmartIntego PadLock AX (Manual) 4. Battery replacement
11 / 21

8. Insert the new batteries (positive poles touching in the middle).
9. Close the battery cover.
9Cylinder signals the successful change with triple red flashing and
beeping.
10. Put on the cover.
NOTE
Align the thumb-urn cover and thumb-turn using the triangles as shown in
the graph.
SmartIntego PadLock AX (Manual) 4. Battery replacement
12 / 21

11. Turn the cover clockwise.
9The cover snaps into place with one click.
12. Carry out a function test.
9Batteries are replaced.
SmartIntego PadLock AX (Manual) 4. Battery replacement
13 / 21

5 Signalling
Signalling Meaning
2× shortly before engaging (green) Identification medium assumed,
normal activation
1 x briefly (red) Identification medium not author-
ised
1× briefly, 1× long (green) Flip-flop mode: Engaged
1× long, 1× briefly (green) Flip-flop mode: Disengaged
3× briefly after battery change (red) Successful battery change
8× briefly before engaging (red) Battery Warning Level 1
16× briefly before engaging (red) Battery Warning Level 2
SmartIntego PadLock AX (Manual) 5. Signalling
14 / 21

6 Technical specifications
Dimensions (WxHxD)
Basic body without knob/shackle:
70×51×25 mm (8 mm shackle) or
72.5×60×25 mm (11 mm shackle)
Dimensions knob (Øxlength) Ø 32 mm × 39.5 mm (electronic)
Shackle diameter 8mm / 11mm
Shackle internal heigth For 8mm shackle: 25/60 mm or for
11 mm shackle: 50mm
Material
Body/bracket: Stainless steel, active
knob: Stainless steel ring cap, pass-
ive/hybrid knob: Plastic cap
Colours Stainless steel, brushed
Thumb-turn covers for reader
thumb-turn
Plastic cap (passive/hybrid), metal
ring cap (active), full metal cap
(active)
Certifications Class 3 (8 mm) or Class 4 (11 mm)
according to EN 12320
Weather protection IP67
Temperature range (operation) 25 °C to +65 °C (according to DIN
EN 15684)
Battery type 2x CR2450 3V (lithium)
Approved battery manufacturers Murata, Panasonic, Varta
Battery lifetime Up to 12 years on standby or
100,000 activations
Signalisation Audible signal (buzzer) and/or
visual signal (LED – green/red)
Network capability Yes (integrated LockNode can be
ordered and retrofitted)
Opening modes Pulse flip-flop
Upgradeability Firmware upgradable via BLE
Frequency range; max. transmission
power RFID (~13,56 MHz)
13.560006 MHz - 13.560780 MHz;
1.04 dBµA/m (3 m distance, de-
pending on equipment)
Frequency range; max. transmission
power (~868 MHz)
868.000 MHz - 868.600 MHz; <25
mW ERP (depending on equip-
ment)
SmartIntego PadLock AX (Manual) 6. Technical specifications
15 / 21

Frequency range; max. transmission
power BLE 2402 MHz - 2480 MHz; 2.5 mW
Geographical restrictions within the
EU No
6.1 Scale drawings
8mm shackle, 25mm shackle interior height
SmartIntego PadLock AX (Manual) 6. Technical specifications
16 / 21

8mm shackle, 60mm shackle interior height
SmartIntego PadLock AX (Manual) 6. Technical specifications
17 / 21

8mm shackle, 50mm shackle interior height
SmartIntego PadLock AX (Manual) 6. Technical specifications
18 / 21

7 EU/UK Declaration of conformity
The company SimonsVoss Technologies GmbH hereby declares that
article SV-Z5.PL.*, SI-Z5.PL.*, MK-Z5.PL.* complies with the following
guidelines:
2014/53/EU "Radio equipment"
as well as the corresponding UK statutory 2017 No. 1206 "Radio
equipment"
2014/30/EU "EMC"
as well as the corresponding UK statutory 2016 No. 1091 "EMC"
2012/19/EU "WEEE"
as well as the corresponding UK statutory 2013/3113 "WEEE"
2011/65/EU "RoHS"
as well as the corresponding UK statutory 2012 No. 3032 "RoHS"
and regulation (EG) 1907/2006 "EU REACH"
as well as the corresponding "UK REACH"
The full text of the EU/UK Declaration of conformity is available at the
following internet address:
www.simons-voss.com/en/certificates.html
SmartIntego PadLock AX (Manual) 7. EU/UK Declaration of conformity
19 / 21

8 Help and other information
Information material/documents
You will find detailed information on operation and configuration and other
documents on the website:
www.smartintego.com/int/home/infocenter/documentation
Declarations of conformity
You will find declarations of conformity and other certificates on the
website:
www.simons-voss.com/en/certificates.html
Information on disposal
Do not dispose the device (SV-Z5.PL.*, SI-Z5.PL.*, MK-Z5.PL.*) in the
household waste. Dispose of it at a collection point for electronic waste
as per European Directive 2012/19/EU.
Recycle defective or used batteries in line with European Directive
2006/66/EC.
Observe local regulations on separate disposal of batteries.
Take the packaging to an environmentally responsible recycling point.
Hotline
Our hotline will be happy to help you (landline, costs depend on provider):
+49 (0) 89 / 99 228 333
Email
You may prefer to send us an email.
[email protected]
FAQs
You will find information and help in the FAQ section:
faq.simons-voss.com/otrs/public.pl
Address
SimonsVoss Technologies GmbH
Feringastr. 4
D-85774 Unterfoehring
Germany
SmartIntego PadLock AX (Manual) 8. Help and other information
20 / 21
