Simons Voss Technologies SmartCD User manual

SmartCD Programming Device
State of : Dezember 2007

SmartCD Programming Device
2
Content
1.0 Safety notes _________________________________________3
2.0 Introduction _________________________________________3
3.0 Connecting to a PC/laptop _____________________________4
3.1 Charging the batteries ____________________________________ 4
4.0 Configuring the Bluetooth connection____________________5
4.1 First-time installation _____________________________________ 5
4.2 Changing the connection__________________________________ 5
5.0 Configuring the USB connection ________________________5
6.0 Start-up _____________________________________________6
7.0 Programming with the SmartCD . . . ______________________6
7.1 . . . in connection with a PC/laptop __________________________ 6
7.2 . . . in connection with a PDA_______________________________ 6
8.0 Antenna orientation ___________________________________7
9.0 Replacement of the batteries ___________________________8
10.0 Meaning of LED’s _____________________________________9
11.0 Items supplied _______________________________________9
12.0 Specifications_______________________________________10

SmartCD Programming Device
Page 3
3
1.0 Safety notes
•Avoid exposure to direct sunlight.
•Keep unit away from sources of magnetic interference.
•Make sure the unit does not drop onto the floor or receive severe shocks of any
kind.
•If misused, the lithium batteries installed in the programming unit can pose a risk
of fire or burning. Do not open, burn or heat to over 70°C.
•Replace the batteries only with storage batteries approved by SimonsVoss
(currently BMZ Li-Ion manganese type US14500V).
•The integrated batteries must be charged for at least 3 hours before first use.
•Dispose of exhausted or non-functioning batteries without delay in accordance
with applicable regulations far away from children’s reach.
•Faultless programming in conjunction with a Windows Mobile 5.x PDA can only be
guaranteed with units approved by SimonsVoss.
•The manufacturer reserves the right to make technical amendments at any time.
•In cases of dispute, the original German manual shall take precedence.
2.0 Introduction
The SmartCD is a programming unit specially designed to be used with a PC/laptop
or a Windows Mobile 5.x PDA (Personal Digital Assistant). It allows you to program
and retrieve all digital components in the SimonsVoss 3060 system very easily. You
can also compare personal data (such as addresses, calendars, etc.) with the PDA.

SmartCD Programming Device
Page 4
4
3.0 Connecting to a PC/laptop
Using the cable supplied, you can connect the SmartCD directly to a PC or laptop via
a free USB interface.
All digital components in the SimonsVoss 3060 system can be programmed using a
PC/laptop and a SmartCD.
Note: When carrying out programming with a PDA and SmartCD, you must remove
the connecting cable from the SmartCD to the PC/laptop. Bluetooth communication
between the SmartCD and the PC/laptop is not possible.
Please note: Before connecting the SmartCD to the USB port, ensure that the
Bluetooth port is not active. The Bluetooth function will switch off automatically after
approx. 15 minutes. It can also be manually deactivated by pressing the button on the
programming device. Otherwise communication via the USB port will not be possible.
Transponders can only be programmed when the SmartCD is directly connected to a
PC/laptop (by USB cable) and the software program Locking Data Base (LDB) 1.50
or higher or Locking System Management (LSM) 2.2 or higher is installed.
3.1 Charging the batteries
To charge the installed batteries, connect the SmartCD to the PC/laptop using the
USB cable. The batteries in the SmartCD are then charged via the USB interface.
Note: The integrated batteries must be charged for at least 3 hours before first use.
Note: In the case of laptops, the USB interface may be deactivated when the laptop is
switched off.
Tip: If you do not intend to use the SmartCD for a long period, connect the SmartCD
to the USB interface. This will prevent the batteries from running down, and the unit
may be used at any time.
Using several devices via a passive external USB hub (without its own power supply)
can be problematic. This is because the USB interface cannot supply sufficient
power. For this reason, connect the SmartCD directly to a free USB interface on the
PC/laptop for charging or use an active USB hub (with its own power supply).

SmartCD Programming Device
Page 5
5
4.0 Configuring the Bluetooth connection
4.1 First-time installation
When coupling the SmartCD and the PDA, ensure that both units are:
•switched on and can be recognised by Bluetooth.
•placed close to one another.
Please refer to the ‘SmartLSM’ software manual (and the user manual of the PDA
manufacturer as necessary) for more information on coupling the SmartCD and PDA.
Select ‘SV [serial number of your unit]’ as the SimonsVoss unit.
When coupling the PDA and SmartCD for the first time, it is important that the
reception range does not contain several different SmartCDs with activated Bluetooth.
4.2 Changing the connection
It is possible to change the established Bluetooth connection at any time (in order to
perform programming with another SmartCD, for example).
Please refer to the ‘SmartLSM’ software manual for details of the procedure.
5.0 Configuring the USB connection
When you connect the SmartCD to the PC/laptop using a USB cable for the first time,
the Windows operating system will detect new USB hardware. Following the
instructions in the installation menu, install the driver contained on the supplied CD
onto your desktop computer (selecting the directory ‘SmartCD_USB’).
If you are working with LDB 1.40a or earlier (or LSM 2.1 or earlier), please note that
the new hardware will be installed onto one of the COM interfaces 1-4.

SmartCD Programming Device
Page 6
6
6.0 Start-up
The installed batteries are pre-charged. The unit is therefore ready for immediate use.
(Before using the SmartCD for this first time, we recommend charging the unit on a
USB port for around 3-4 hours.) To use the programming unit, please perform the
following steps:
•Connect the SmartCD to the PC/laptop via USB.
•Install the USB driver for the SmartCD onto the PC/laptop (see supplied CD).
To use the SmartCD with a PDA, perform the following steps in addition:
•Install the SmartLSM locking plan software on the PDA via ActiveSync.
•Couple the SmartCD and PDA using Bluetooth (performed through SmartLSM).
•Set the COM port on the PDA for the SmartCD (performed through SmartLSM)
7.0 Programming with the SmartCD . . .
When programming, note that the minimum distance between the SmartCD and the
lock should be 10 cm (30 cm to a Smart Relay and 70 cm to a block lock).
7.1 . . . in connection with a PC/laptop
The latest version of the Locking Data Base (LDB) 1.50a or later, or locking-system-
management (LSM) 2.2 or later) software must be installed on the PC/laptop. A
programming unit must be connected to the PC/laptop for new installations or
software updates.
Note: You will need administrator rights to install the software on Windows
NT/2000/XP.
Always carry out a backup before performing an update.
7.2 . . . in connection with a PDA
The latest version of LDB must be installed on the PC/laptop. The PDA desktop
software must also be set up on the PC/laptop. You must carry out an ActiveSync
when installing on the PDA for the first time.
The latest version of SmartLSM must be installed on the PDA using ActiveSync.
You can now transfer a locking plan compiled on the PC/laptop to the PDA by means
of ActiveSync. For more details, please refer to the PDA user manual.

SmartCD Programming Device
Page 7
7
8.0 Antenna orientation
The antenna orientation for selected components is shown below to guarantee
faultless programming. To ensure the largest possible range when programming, the
antennas of the SmartCD and the lock should be aligned parallel to one another.
To prevent over-modulation, however, the distance between the antennas should
always be at least 10 cm.
All antennas are aligned parallel to one another in this example.
Antenna
SmartCD Cylinder Smart Relay

SmartCD Programming Device
Page 8
8
9.0 Replacement of the batteries
Please proceed as follows when you need to change the batteries:
•Remove the belt clip carefully (if you use a small Phillips screwdriver, you do not
need to remove the belt clip).
•Remove the screw on the back of the unit.
•Detach the bottom half of the housing.
•Take out the old batteries and insert the new batteries with the positive pole
pointing upwards as shown in the diagram. Observe correct polarity and make
sure you are using the correct battery type.
•Replace the bottom half of the housing and fasten the screw finger-tight.
•Attach the belt clip.
Antenna
+ +
- -
Batteries

SmartCD Programming Device
Page 9
9
10.0 Meaning of LED’s
First LED (green) on ÆUnit ready for operation
First LED (green) flashing ÆStandby
Second LED (yellow) on ÆBatteries are charging
Second LED (yellow) off ÆBatteries are charged
Third LED (green) flashing rapidly ÆUnit is communicating
with a SimonsVoss lock
Third LED (green) flashing slowly ÆNo connection to lock
Fourth LED (blue) on ÆBluetooth active
The first LED (green) lights when the unit is connected via
USB to a PC/laptop, or when the SmartCD is switched on
without a USB connection by pressing the button. To save
energy, you can switch off the unit by pressing the button again.
The second LED (yellow) only lights when the SmartCD is connected to the computer
by USB for charging purposes and at least one of the batteries requires charging.
The third LED (green) only lights when radio communication is established between
the SmartCD and a relevant lock (e.g. for programming, retrieval).
The fourth LED (blue) lights when using the Bluetooth interface; it remains lit for the
duration of the programming, retrieval or reset procedure and goes out again
afterwards.
11.0 Items supplied
SmartCD
Two batteries of type US14500V (installed)
Cable for connecting to a USB interface
CD-ROM containing USB drivers
SimonsVoss LDB software (or SmartLSM for mobile on-site programming) is also
needed to use the SmartCD. These are not supplied; they must be purchased
separately.
Before start-up, please read the PDA manufacturer manual.

SmartCD Programming Device
Page 10
10
12.0 Specifications
Housing dimensions H x W x D 112 x 63 x 22 mm
Weight (including batteries) 95 g
Housing material Plastic
Housing colour Grey
Number of LED’s 4
Battery type Li-Ion manganese storage batteries (rechargeable)
Voltage 4.2 V
Manufacturer BMZ
Type US14500V
Number of batteries 2
Protective system IP20
Working temperature range –5°C to +40°C
Storage temperature range –20°C to +60°C
Bluetooth connection Class 2 transmitting power: 2.5 mW
Profiles supported SPP Serial Port Profile, serial data transfer
