Simrad IS20 Combi User manual

I
S
2
0
MANUAL
IS20 Graphic
Multifunction instrument
20222576 / A Sw.1.1
English

Copyright
All rights reserved. No part of this document may be
reproduced or otherwise copied without prior written
permission of Navico Holding AS.
© 2007 by Navico Egersund AS
About this manual
This manual is a reference guide for installing and
operating the Simrad IS20 Graphic instrument.
The manual does not include operator or installation
procedures for sensors that can be connected to the
system.
In this manual, names of menu commands, dialog box
text and keys are written in boldface (e.g. Main menu,
Setup command, Left key).
Important text that requires special attention from the
reader is emphasized as follows:
Used to draw the reader’s attention to a comment or
some important information.
Used when it is necessary to warn personnel that a
risk of damage to the equipment or hazard exists if
care is not exercised.
2 | IS20 Graphic instrument

Content
1 Introduction ............................................... 7
1.1 General information..................................7
1.2 Instrument layout ....................................7
1.3 IS20 system examples..............................8
2 Basic operation ......................................... 11
2.1 Turning the IS20 on ............................... 11
2.2 Backlighting .......................................... 12
2.3 Scrolling through data pages ................... 13
2.4 Resetting a data page............................. 14
2.5 Operating the menu system..................... 14
2.6 Disabling/enabling data pages ................. 17
2.7 Locking and unlocking the keys ................ 19
2.8 Power save function ............................... 19
3 Advanced operation .................................. 21
3.1 Customizing the data pages..................... 21
3.2 Remote operation .................................. 23
3.3 SimNet group function ............................ 23
3.4 Demo mode .......................................... 26
4 The log/timer functions............................ 27
4.1 The timer function.................................. 27
4.2 Trip logging........................................... 30
4.3 Speed logging........................................ 30
4.4 Setting the time offset ............................ 31
IS20 Graphic instrument | 3

5 Changing the default settings ................... 33
5.1 General ................................................ 33
5.2 Setting the damping factors..................... 33
5.3 Alarm setup .......................................... 34
5.4 Updating the data sources ....................... 37
5.5 Changing the display settings .................. 39
5.6 Language selection................................. 41
5.7 Changing the units of measure................. 42
6 IS20 Alarm system ................................... 43
6.1 Alarm indication..................................... 43
6.2 Acknowledging an alarm ......................... 44
6.3 Viewing active alarms ............................. 44
6.4 Alarm codes .......................................... 44
7 Installation ............................................... 47
7.1 Location of the unit ................................ 47
7.2 Mechanical installation ............................ 47
7.3 Cable connection.................................... 49
8 Configuration............................................ 57
8.1 First time start-up .................................. 57
8.2 Calibration ............................................ 58
8.3 SimNet groups....................................... 67
9 Maintenance ............................................. 69
9.1 General maintenance.............................. 69
9.2 Service information ................................ 69
9.3 Resetting the instrument system .............. 71
4 | IS20 Graphic instrument

9.4 Displaying instrument information ............ 71
10 Spare parts ............................................. 73
10.1 Spares and auxiliaries ........................... 73
10.2 SimNet cables and accessories ............... 74
11 Specifications ......................................... 75
11.1 Technical specifications ......................... 75
11.2 Dimensional drawing............................. 76
11.3 Menu flow chart ................................... 77
11.4 Data groups and data items ................... 78
IS20 Graphic instrument | 5

Blank page
6 | IS20 Graphic instrument

1Introduction
1.1 General information
The IS20 Graphic is a multifunction instrument that
displays speed, depth, heading, position, wind and
environmental data measured by sensors and other
equipment connected to the system.
Navigational data, engine/battery status and vessel
parameters as e.g. accumulated log and rudder angle
may also be displayed.
The instrument calculates speed trim, wind head/lift, trip
distance and time, average speed, set and drift
parameters. A race timer is also included in the IS20.
1.2 Instrument layout
The IS20 has a 130 * 104 pixels LCD. The display may be
set to red or white illumination color, and the contrast
and light level are adjustable.
The instrument is equipped with 2 SimNet connectors,
and with one NMEA0183 input connector.
Keys
The instrument is operated by 6 keys. These are used to
adjust the light, scroll between data pages, to operate
the menu and to set parameter values.
Introduction | 7

Softkeys
When the basic operation of the
keys is
changed, soft key symbols
will be displayed right above the
keys to indicate the alternate
function.
The softkey symbols are illustrative, and they are
described under the functions as these appear in this
manual. The following general softkey symbols are used:
OK
Cancel
1.3 IS20 system examples
The IS20 may be installed as a stand-alone instrument
system, or as part of an advanced instrument or steering
system on the boat.
The figures below show simplified illustrations for basic
and an expanded IS20 system.
8 | Introduction

IS20 Graphic, Basic system
IS20 Graphic, Basic system with 2 sensors
Introduction | 9

Wind
transducer
T-joiner
Active depth
transducer
Analog
speed/temp
sensor
12V SimNet supply
Red disk
IS20 Expanded system
10 | Introduction

2Basic operation
It is required to read and understand the content in this
chapter. The remaining descriptions and illustrations in
this manual assumes that the user is familiar with how to
operate keys and how to navigate in the menus!
2.1 Turning the IS20 on
IS20 has no power key, and will be running as long as
power is connected.
The IS20 includes a power save function. Refer page 19.
When power is connected, the start up page will show:
−Product name
−Software version
−Release date
After approximately 5 seconds the instrument is
operative.
First time start up
Before the IS20 is ready to operate, it should be
configured as described in Configuration, page 57
onwards.
Restarting the IS20 instrument
When IS20 is re-powered the display will go directly to
the last active page after the start up sequence is
finished.
Basic operation | 11

2.2 Backlighting
The display backlight may be adjusted at any time.
1Press the light key
−The Light level overlay window
will be displayed on top of the
current view
2Press one of the keys as described below to
change the display illumination:
aThe Light key to increase the light level by one
step
bThe Up/Down softkeys to increase/decrease
the light level by one step
/ cThe Day/Night softkey to toggle between day
and night profile
If no adjustment is performed within 3 seconds, the Light
level overlay window will disappear.
For contrast and day/night settings, refer Changing the
display settings, page 39.
12 | Basic operation

2.3 Scrolling through data pages
The IS20 Graphic is pre-configured with 8 instrument
pages, of which 2 are disabled.
The instrument will scroll through the pages by using the
Up and Down keys.
Default page
at first time
turn-on
Note that the pages shown with a are
disabled and will
not be visible when scrolling through the pages!
Basic operation | 13

2.4 Resetting a data page
When a data page is active, the Right key may be used
to reset any calculated data.
The following data types may be reset:
−Head/Lift
−Speed trim
−Trend graph
Pressing the Right key will have no effect if the active
data page not includes any calculated data!
2.5 Operating the menu system
All functions and settings in the
IS20 are available from the menu
system, activated by pressing the
Menu/Enter key.
The main menu items give further
access to sub menus and various
settings.
The set values are usually presented in the window’s
right column, but could also be listed in an overlay
window.
Unit settings presented in the
window’s right column
Language settings
presented in an overlay
window
14 | Basic operation

Use the keys as shown below to navigate in the menu
system:
Key Single press Press and hold
Confirm a selection/parameter
setting
Go to next menu level/
parameter settings
Go to previous menu level/
parameter listing
Return to normal operation
and the last active data
page
Go to previous/next menu item,
increase/decrease parameter
value
When the basic operation of a key
is changed, a soft key symbol will
be displayed right above the key to
indicate the alternate function.
Basic operation | 15

The illustration below shows how to change the display
contrast from 9 to 6.
Press and holding the Left key will always return the
display to normal operation and the last active page!
16 | Basic operation

Menu illustrations
In this manual, the first steps in
a menu operation are illustrated
by overlapping menu windows.
When more detailed illustrations are required to show key
presses and screens, this is shown as below:
2.6 Disabling/enabling data pages
By disabling a data page, the number of pages will be
reduced when scrolling through the data pages.
A disabled page is only visible when using the
Enable/Disable item in the DATA PAGES SETUP
menu, and is then indicated with a crossed rectangle!
Basic operation | 17

Disabling pages
Continue to select pages and repeat the procedure if
more pages are to be disabled.
Enabling a page
Continue to select pages and repeat the procedure if
other pages are to be enabled.
18 | Basic operation

2.7 Locking and unlocking the keys
The IS20 keys may be locked to prevent any unintended
operation.
+The key lock function is enabled by pressing the
Menu/Enter and the Light keys simultaneously.
A locked instrument has a
padlock symbol in the upper left
corner
When the keys are locked, any
key press will activate the
Disable key lock overlay
window. The key lock function is
then disabled by pressing the
Menu/Enter key.
2.8 Power save function
When power save is activated, the
display will be turned off.
Any key press or activated alarm
will disable the power save
function.
Basic operation | 19

Blank page
20 | Basic operation
