Sirona C5+ Turn Quick start guide

`RH=
pÅÜ~äíìåíÉêä~ÖÉå=
táêáåÖ=oÉÑÉêÉåÅÉë=
pÅܨã~ë=ÇÉ=ÅáêÅìáíë=
`çäÉÅÅáμå=ÇÉ=ÉëèìÉã~ë=
kÉì=~ÄW
kÉï=ëáåÅÉW
kçìîÉ~ì=ÇÉéìáëW
kìÉîç=ÇÉëÇÉW
MVKOMMU

59 55 138 D3415
2D3415.050.01.07.09
ACHTUNG
Störung elektromedizinischer Geräte durch Funktelefone:
Zur Gewährleistung der Betriebsbereitschaft elektromedizi-
nischer Geräte ist der Betrieb mobiler Funktelefone im Pra-
xis- oder Klinikbereich untersagt.
ACHTUNG
Wenn Sie das Gerät öffnen:
Bitte beachten Sie die Vorsichtsmaßnahmen
beim Umgang mit Platinen (EGB).
Entladen Sie sich vor Berühren der Bauteile
durch Anfassen eines Erdungspunktes.
ATTENTION
Interference with electromedical devices by radio telepho-
nes:
To guarantee the operational safety of electromedical de-
vices, the operation of mobile radio telephones in the medi-
cal practice or hospital area is prohibited.
ATTENTION
When opening the equipment:
Please observe the safety measures for hand-
ling PC boards. Touch a ground point to remo-
ve any personal electrostatic charge before
touching the components.
kÉì=~ÄW MVKOMMU
C5+ Sirona Dental Systems GmbH
kÉï=ëáåÅÉW MVKOMMU
Inhaltsverzeichnis Blatt List of Contents Sheet
Änderungen gegenüber der letzten Ausgabe:
09.2007
Modification compared with last edition:
09.2007
Kapitel oder Abschnitt, Seite
Blatt..................................................................... 3
Chapter or paragraph, page
Sheet................................................................... 3
Elektrischer Schaltplan:
Patientenstuhl .................................................... 1/1A
Arztelement .............................................................2
Helferinelement, Wassereinheit ...............................3
Videoapplikation Arztelement ..................................4
Videoapplikation Helferinelement....................... 5/5A
Zeichenerklärung ....................................................6
Hydraulisch-pneumatischer Schaltplan:
C5+ mit Desinfektionsanlage....................................7
C5+ ohne Desinfektionsanlage............................. 7A
Zeichenerklärung ....................................................8
CAN BUS, Datenkommunikation .............................9
RS232 Schnittstelle................................................10
Electrical circuit diagram:
Patient's Chair .................................................... 1/1A
Dentist Element ...................................................... 2
Assistant Element, Water Unit................................. 3
Video application Dentist Element .......................... 4
Video application Assistant Element .................5/5A
Legend ................................................................. 6A
Hydraulic-pneumatic diagram:
C5+ with disinfection system ................................... 7
C5+ without disinfection system ........................... 7A
Legend ................................................................. 8A
CAN BUS, data communication .............................. 9
RS232 Interface ..................................................10A

59 55 138 D3415
D3415.050.01.07.09 3
ATTENTION
Perturbation d'appareils électro-médicaux par radiotélé-
phones: Pour garantir la sécurité de fonctionnement d' ap-
pareils électromédicaux, l'utilisation de radiotéléphones
mobiles est interdite dans les hôpitaux et cabinets.
ATTENTION
Ouverture des units:Veuillez respecter les dis-
positions de précaution applicables à la mani-
pulation des cartes. Avant de toucher un com-
posant, éliminez la charge électrostatique de
votre corps en touchant un point de mise à la
terre.
ATTENTION
Interferencia en aparatos electromédicos por radioteléfo-
nos:
Para garantizar la seguridad funcional de aparatos electro-
médicos, se prohibe la utilización de radioteléfonos móviles
en el consultorio o clínica.
ATENCIÓN
Al abrir la unidad
observe las medidas de precaución al mani-
pular con platinas (Componentes sensibles a
descargas electrostáticas).
Antes de tocar los componentes derive su car-
ga eletrostática tocando un punto de puesta a tierra.
kçìîÉ~ì=ÇÉéìáëW MVKOMMU
Sirona Dental Systems GmbH C5+
kìÉîç=ÇÉëÇÉW MVKOMMU
Sommaire Feuille Indice Hoja
Modifications par rapport à la dernière édition:
09.2007
Alteraciones con respecto a la último edición:
09.2007
Chapitre ou passage, page
Feuille ................................................................. 3
Capítulo o párrafo, página
Hoja..................................................................... 3
Schéma électrique:
Fauteuil .............................................................. 1/1A
Elément praticien .....................................................2
Elément assistante, Unité d'eau...............................3
Application vidéo élément praticien .........................4
Application vidéo élément assistante ................ 5/5A
Légende ............................................................... 6B
Schéma hydropneumatique:
C5+avec système de désinfection...........................7
C5+sans système de désinfection....................... 7A
Légende ............................................................... 8B
CAN BUS, echange de données..............................9
Interface RS232 .................................................. 10B
Esquema eléctrico:
Sillón dental........................................................1/1A
Elemento del odontólogo 2
Elemento de la asistente, Unidad de agua ............. 3
Aplicación de vídeo elemento del odontólogo ........ 4
Aplicación de vídeo elemento de la asistente ...5/5A
Leyenda ...............................................................6C
Esquema hidroneumático:
C5+con sistema de desinfección............................ 7
C5+sin sistema de desinfección ......................... 7A
Leyenda ...............................................................8C
CAN BUS, comunicaciones de datos...................... 9
Interfaz RS232 ....................................................10C

Farbcode
Colour-code
Code de couleurs
Código de colores
BK schwarz black noir negro
BN braun brown brun marrón
BU blau blue bleu azul
GN grün green vert verde
GY grau grey gris gris
OG orange orange orange anaranjado
PK rosa pink rose rosado
RD rot red rouge rojo
VT violett lila lilas violeta
WH weiß white blanc blanco
YE gelb yellow jaune amarillo

S5
X2
X1
X1
K1
K2
K3
1
2
3
4
49
47
#
SR
1882567
+24V_X1.1A
K2_X1.2A
K1_X1.3A
K3_X1.4A
NC_X1.5A
NC_X1.1B
GND_X1.2B
X1.3B
DGND_X1.4B
+5V_X1.5B
S2
S6
X1
X9
geaendert
erstellt
Datum Version Name
Blatt
D-Nr:Sachnummer CD:
04.03.04
C5+ Fix Verdrahtung
1.0
Altendorf GEE
Patientenstuhl
1
x
3415
S1
S3
X1
S
T6.3A
F2
X18
M2
X1
X31
FILTER
X2
R1NTC
SS1
X3
X99
X4
S
V5, V7, V8
S5, S7, S8
S2, S3, S4, S6
CFS 5864314
X2.7B-NC
X2.1B_Poti_GND
X2.3B_Poti-Gasp.
X2.2B_Poti_Ref
X2.7A_S5
X2.4B_DGND
X2.5B_F-detect
X2.5A_AGND
X2.3A_S2
X2.1A_S4
X2.2A_S3
X2.8B_NC
X2.8A_NC
X2.6A_S8
X2.6B_S7
X2.4A_S6
123
R8
X70
X6
M3
X90
S1-S8
CK 5864652
S1__lift-up
S2__lift-down
S3__br-inc
S4__br-recl
S6__hr-up
S5__hr-down
S8__hr-inc
S7__hr-rec
GND
R0__HW-DOCE
6
BA
5
1
D
4
E
3
B
D
E
2
C
C
6
5
3
A
2
4
1
