Skil 1415 User manual

2
AGF
EDC
B
H
2
11415
125 W
0,5 kg
15000-35000
MAX
2,4 mm MAX
3,2 mm
3
4
EDC
B
5
B
CC
D
(3,2mm) (2,4mm)
6

3
A
7
G
8
3,2
mm
3,2
mm
3,2
mm
3,2
mm
3,2
mm
3,2
mm
3,2
mm
3,2
mm
2,4
mm
2,4
mm
9

4
0
2
3
4
!
K
J
@

5
DC
3,2 mm
E
#
D
L
CE
$

6
^
P
N
M
M
Q
MAX 6 cm
%
&

High-speed rotation tool 1415
INTRODUCTION
●This tool is intended for high-precision grinding, sanding,
cutting, engraving, polishing and drilling in different
materials
●SKIL does not supply spare accessories for this tool, but
recommends to buy Ø 2,4 mm/Ø 3,2 mm DREMEL
accessories
●Read and save this instruction manual 3
TECHNICAL SPECIFICATIONS 1
SAFETY
GENERAL SAFETY INSTRUCTIONS
WARNING! Read all instructions. Failure to follow all
instructions listed below may result in electric shock, fire
and/or serious injury. The term "power tool" in all of the
warnings listed below refers to your mains operated
(corded) power tool.
1) WORK AREA
a) Keep work area clean and well lit. Cluttered and dark
areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose
control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk
of electric shock.
b) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personal injury.
b) Use safety equipment. Always wear eye protection.
Safety equipment such as dust mask, non-skid safety
shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
c) Avoid accidental starting. Ensure the switch is in the
off position before plugging in. Carrying power tools
with your finger on the switch or plugging in power tools
that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal
injury.
e) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of these devices
can reduce dust related hazards.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct power
tool for your application. The correct power tool will do
the job better and safer at the rate for which it was
designed.
b) Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source before
making any adjustments, changing accessories, or
storing power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool
or these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tools
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
GB
7

g) Use the power tool, accessories and tool bits etc., in
accordance with these instructions and in the
manner intended for the particular type of power
tool, taking into account the working conditions and
the work to be performed. Use of the power tool for
operations different from those intended could result in a
hazardous situation.
5) SERVICE
a) Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is
maintained.
SAFETY INSTRUCTIONS FOR HIGH-SPEED ROTATION
TOOLS
GENERAL
●This tool should not be used by people under the age of
16 years
●Only use this tool for applications without the use of
water
●Always disconnect plug from power source before
making any adjustment or changing any accessory
ACCESSORIES
●SKIL can assure flawless functioning of the tool only
when original accessories are used
●Use only accessories recommended by SKIL
●For mounting/using non-SKIL accessories observe the
instructions of the manufacturer concerned
●Use only accessories with an allowable speed matching
at least the highest no-load speed of the tool
●Do not use damaged, deformed or vibrating accessories
●Handle and store grinding/cutting discs carefully to avoid
chipping and cracking
●Protect accessories from impact, shock and grease
●Never use grinding discs over 32 mm (1 1/4") Ø
●Never use drill bits over 3.2 mm (1/8") Ø
●Never use a cutting disc for side grinding
●Never use reducors or adaptors to fit large-hole grinding/
cutting discs
BEFORE USE
●Always check that the supply voltage is the same as the
voltage indicated on the nameplate of the tool (tools with
a rating of 230V or 240V can also be connected to a
220V supply)
●Do not work with materials containing asbestos
●Clamp the workpiece in case it does not remain
stationary from its own weight
●Use completely unrolled and safe extension cords with a
capacity of 16 Amps (UK 13 Amps)
●Wear protective glasses 4and gloves, hearing
protection 4, a dust mask, and sturdy shoes; when
necessary, also wear an apron
●Wear a dust protection mask when working with
materials which produce dust that is detrimental to
health; inform yourself beforehand about the materials to
be worked on
●Ensure that the collet size corresponds with the shaft
size of the accessory
●Be sure tool is switched off when plugging in
DURING USE
●Always keep the cord away from moving parts of the
tool; direct the cord to the rear, away from the tool
●Never use tool when cord is damaged; have it replaced
by a qualified person
●Never use spindle lock while tool is running (damage
due to improper handling will be excluded from the
guarantee)
●Keep hands away from rotating accessories
●When grinding metal, sparks are generated; keep other
persons and combustible material from work area
●Keep ventilation slots H 2uncovered
●In case of electrical or mechanical malfunction,
immediately switch off the tool and disconnect the plug
AFTER USE
●The accessory continues to rotate for a short time after
the tool has been switched off
●Before you put down the tool, switch off the motor and
ensure that all moving parts have come to a complete
standstill
●After switching off the tool, never stop the rotation of the
accessory by a force applied against it
●Store tool in locations where temperature will not exceed
50°C
WHEN CONNECTING NEW 3-PIN PLUG (U.K. ONLY):
●Do not connect the blue (= neutral) or brown (= live) wire
in the cord of this tool to the earth terminal of the plug
●If for any reason the old plug is cut off the cord of this
tool, it must be disposed of safely and not left
unattended
TOOL ELEMENTS 2
AOn/off switch
BSpindle-lock button
CCollet
DCollet nut
EWrench
FSupport grip
GSpeed selection wheel
HVentilation slots
USE
●Changing accessories 5
! switch off the tool and disconnect the plug
! ensure that collet size corresponds with shaft size
of accessory
- push spindle-lock button B and hold it while you turn
collet nut D by hand until the spindle lock prevents
further rotation and loosen collet nut D with wrench E
- insert an accessory in collet C as far as possible to
minimize run-out and unbalance
- push spindle-lock button B and hold it while you
tighten collet nut D with wrench E
! avoid excessive tightening of collet nut D
! never tighten collet nut, if there is no accessory in
collet; collet may be damaged
●Changing collets 6
! switch off the tool and disconnect the plug
- push spindle-lock button B and hold it while you
remove collet nut D
8

- remove collet C
- insert new collet
! never tighten collet nut, if there is no accessory in
collet; collet may be damaged
●Before using the tool
- ensure that accessory is correctly mounted and firmly
tightened
- check if accessory runs freely by turning it by hand
- test-run tool for at least 30 seconds at highest no-load
speed in a safe position
- stop immediately in case of considerable vibration or
other defects and check tool to determine the cause
●On/off switch 7
- switch on/off the tool by pushing knob A in "I"/"O"
position
! before the accessory reaches the workpiece, the
tool should run at full speed
! before switching off the tool, you should lift it
from the workpiece
●Speed control 8
For optimal results on different materials
- select speed with wheel G (also while tool is running)
- use table 9as reference for determining the right
speed
- before starting a job, find the optimal speed by testing
out on spare material
! after longer periods of working at low speed, allow
the tool to cool down by running it for
approximately 3 minutes at high speed with no load
●Holding and guiding the tool 0
- pencil grip for precision work (engraving)
- one-hand grip for less precise work (grinding)
- support grip for additional control/comfort
- do not apply too much pressure on the tool; let the
speed do the work for you
●Support grip !
- can be adjusted as illustrated
- can be mounted in 4 different positions
- switch on/off spotlight J by turning knob K counter-
clockwise/clockwise @(spotlight not standard
included)
●Flexible shaft (not standard included) #
- mount flexible shaft as illustrated
- use flexible shaft for hard-to-reach places
Changing accessories when using flexible shaft $
- pull sleeve L down (= lock spindle) and hold it while
you turn collet nut D by hand until the spindle lock
prevents further rotation and loosen collet nut D with
wrench E
- insert an accessory in collet C
- pull sleeve L down (= lock spindle) and hold it while
you tighten collet nut D with wrench E
●Mounting stand (not standard included) %
- mount stand on a workbench or table-top with a
maximum thickness of 60 mm
- adjust height of stand by turning tubes M counter-
clockwise, pulling them to desired height, and turning
them clockwise
- adjust height of suspension bracket N by loosening
knob P, adjusting suspension bracket to desired
height, and tightening knob P
- attach tool to suspension bracket with hook Q
●Assembly of specific accessories ^
GUARANTEE / ENVIRONMENT
●Always keep tool and cord clean (especially ventilation
slots H 2)
! disconnect the plug before cleaning
●This SKIL product is guaranteed in accordance with
statutory/country-specific regulations; damage due to
normal wear and tear, overload or improper handling
will be excluded from the guarantee (spotlight J @is
also excluded from the guarantee)
●In case of a complaint, send the tool undismantled
together with proof of purchase to your dealer or the
nearest SKIL service station (addresses as well as the
service diagram of the tool are listed on
www.skileurope.com)
●Do not dispose of electric tools, accessories and
packaging together with household waste material
(only for EU countries)
- in observance of European Directive 2002/96/EC on
waste of electric and electronic equipment and its
implementation in accordance with national law,
electric tools that have reached the end of their life
must be collected separately and returned to an
environmentally compatible recycling facility
- symbol &will remind you of this when the need for
disposing occurs
Outil rotatif à grande vitesse 1415
INTRODUCTION
●Cet outil est conçu pour le meulage, ponçage,
tronçonnage, gravure, polissage et perçage de haute
précision des différents matériaux
●SKIL ne fournit pas d'accessoires de rechange pour cet
outil, mais recommande l'achat d'accessoires Ø 2,4 mm/
Ø 3,2 mm DREMEL
●Lisez et conservez ce manuel d'instructions 3
SPECIFICATIONS TECHNIQUES 1
SECURITE
INSTRUCTIONS GENERALES DE SECURITE
ATTENTION! Lisez toutes les instructions. Le non-
respect des instructions indiquées ci-après peut entraîner
un choc électrique, un incendie et/ou de graves blessures
sur les personnes. La notion d’«outil électroportatif»
mentionnée par la suite se rapporte à des outils électriques
raccordés au secteur (avec câble de raccordement).
1) PLACE DE TRAVAIL
a) Maintenez l’endroit de travail propre et bien éclairé.
Un lieu de travail en désordre ou mal éclairé augmente
le risque d’accidents.
F
9

94
CE DECLARATION OF CONFORMITY We declare under our sole responsibility that this product is in conformity with the following
standards or standardized documents: EN 60 745, EN 55 014, in accordance with the provisions of the directives 73/23/EC,
89/336/EC, 98/37/EC, 2002/96/EC.
NOISE/VIBRATION Measured in accordance with EN 60 745 the sound pressure level of this tool is 72 dB(A) and the sound power
level 83 dB(A) (standard deviation: 3 dB), and the vibration < 2.5 m/s2(hand-arm method).
CE DÉCLARATION DE CONFORMITÉ Nous déclarons sous notre propre responsabilité que ce produit est en conformité avec les
normes ou documents normalisés suivants: EN 60 745, EN 55 014, conforme aux réglementations 73/23/EC, 89/336/EC, 98/37/EC,
2002/96/EC. BRUIT/VIBRATION Mesuré selon EN 60 745 le niveau de la pression sonore de cet outil est 72 dB(A) et le niveau de la
puissance sonore 83 dB(A) (déviation standard: 3 dB), et la vibration < 2,5 m/s2(méthode main-bras).
CE KONFORMITÄTSERKLÄRUNG Wir erklären in alleiniger Verantwortung, daß dieses Produkt mit den folgenden Normen oder
normativen Dokumenten übereinstimmt: EN 60 745, EN 55 014, gemäß den Bestimmungen der Richtlinien 73/23/EG, 89/336/EG,
98/37/EG, 2002/96/EG.
GERÄUSCH/VIBRATION Gemessen gemäß EN 60 745 beträgt der Schalldruckpegel dieses Gerätes 72 dB(A) und der
Schalleistungspegel 83 dB(A) (Standard- abweichung: 3 dB), und die Vibration < 2,5 m/s2(Hand-Arm Methode).
CE CONFORMITEITSVERKLARING Wij verklaren, dat dit product voldoet aan de volgende normen of normatieve documenten:
EN 60 745, EN 55 014, overeenkomstig de bepalingen van de richtlijnen 73/23/EG, 89/336/EG, 98/37/EG, 2002/96/EG.
GELUID/VIBRATIE Gemeten volgens EN 60 745 bedraagt het geluidsdrukniveau van deze machine 72 dB(A) en het
geluidsvermogen-niveau 83 dB(A) (standaard deviatie: 3 dB), en de vibratie < 2,5 m/s2(hand-arm methode).
CE KONFORMITETSFÖRKLARING Vi intygar och ansvarar för, att denna produkt överensstämmer med följande norm och
dokument: EN 60 745, EN 55 014, enl. bestämmelser och riktlinjema 73/23/EWG, 89/336/EG, 98/37/EG, 2002/96/EG.
LJUD/VIBRATION Ljudtrycksnivån som uppmätts enligt EN 60 745 är på denna maskin 72 dB(A) och ljudeffektnivån 83 dB(A)
(standard deviation: 3 dB), och vibration < 2,5 m/s2(hand-arm metod).
CE KONFORMITETSERKLÆRING Vi erklærer under almindeligt ansvar, at dette produkt er i overensstemmelse med følgende
normer eller normative dokumenter: EN 60 745, EN 55 014, i henhold til bestemmelserne i direktiverne 73/23/EF, 89/336/EF,
98/37/EF, 2002/96/EF. STØJ/VIBRATION Måles efter EN 60 745 er lydtrykniveau af dette værktøj 72 dB(A) og lydeffektniveau
83 dB(A) (standard deviation: 3 dB), og vibrationsniveauet < 2,5 m/s2(hånd-arm metoden).
CE SAMSVARSERKLÆRING Vi erklærer at det er under vårt ansvar at dette produkt er i samsvar med følgende standarder eller
standard- dokumenter: EN 60 745, EN 55 014, i samsvar med reguleringer 73/23/EF, 89/336/EF, 98/37/EF, 2002/96/EF.
STØY/VIBRASJON Målt ifølge EN 60 745 er lydtrykknivået av dette verktøyet 72 dB(A) og lydstyrkenivået 83 dB(A) (standard
deviasjon: 3 dB), og vibrasjonsnivået < 2,5 m/s2(hånd-arm metode).
CE TODISTUS STANDARDINMUKAISUUDESTA Todistamme täten ja vastaamme yksin siitä, että tämä tuote en allalueteltujen
standardien ja standardoimisasiakirjojen vaatimusten mukainen EN 60 745, EN 55 014, seuraavien sääntöjen mukaisesti 73/23/ETY,
89/336/ETY, 98/37/ETY, 2002/96/ETY. MELU/TÄRINÄ Mitattuna EN 60 745 mukaan työkalun melutaso on 72 dB(A) ja yleensä
työkalun äänen voimakkuus on 83 dB(A) (keskihajonta: 3 dB), ja tärinän voimakkuus < 2,5 m/s2(käsi-käsivarsi metodi).
CE DECLARACION DE CONFORMIDAD Declaramos bajo nuestra sola responsabilidad que este producto está en conformidad
con las normas o documentos normalizados siguientes: EN 60 745, EN 55 014, de acuerdo con las regulaciones 73/23/CE,
89/336/CE, 98/37/CE, 2002/96/CE.
RUIDOS/VIBRACIONES Medido según EN 60 745 el nivel de la presión acústica de esta herramienta se eleva a 72 dB(A) y el nivel
de la potencia acústica 83 dB(A) (desviación estándar: 3 dB), y la vibración a < 2,5 m/s2(método brazo-mano).
CE DECLARAÇÃO DE CONFIRMIDADE Declaramos sob nossa exclusiva responsabilidade que este producto cumpre as
seguintes normas ou documentos normativos: EN 60 745, EN 55 014, conforme as disposições das directivas 73/23/CE, 89/336/CE,
98/37/CE, 2002/96/CE. RUÍDO/VIBRAÇÕES Medido segundo EN 60 745 o nível de pressão acústica desta ferramenta é 72 dB(A) e
o nível de potência acústica 83 dB(A) (espaço de erro: 3 dB), e a vibração < 2,5 m/s2(método braço-mão).
GB
F
D
NL
S
DK
N
FIN
E
P
05 SKIL Europe B.V. A. v.d. Kloot
CE DICHIARAZIONE DI CONFORMITÀ Dichiaramo, assumendo la piena responsabilità di tale dichiarazione, che il prodotto è
conforme alle seguenti normative e ai relativi documenti: EN 60 745, EN 55 014 in base alle prescrizioni delle direttive CE 73/23,
CE 89/336, CE 98/37, CE 2002/96.
RUMOROSITÀ/VIBRAZIONE Misurato in conformità al EN 60 745 il livello di pressione acustica di questo utensile è 72 dB(A) ed il
livello di potenza acustica 83 dB(A) (deviazione standard: 3 dB), e la vibrazione < 2,5 m/s2(metodo mano-braccio).
I
CE MINÖSÉGI TANUSITVANY Teljes felelösségünk tudatában kijelentjük, hogy jelen termék a következö szabványoknak vagy
kötelezö hatósági elöírásoknak megfelel: EN 60 745, EN 55 014, a 73/23/EK, 89/336/EK, 98/37/EK, 2002/96/EK elöírásoknak
megfelelöen. ZAJ/REZGÉS Az EN 60 745 alapján végzett mérések szerint ezen készülék hangnyomás szintje 72 dB(A) a
hangteljesítmény szintje 83 dB(A) (normál eltérés: 3 dB), a kézre ható rezgésszám < 2,5 m/s2.
H
CE STRVZUJÍCÍ PROHLÅ◊ENÍ Potvrzujeme na odpovπdnost, Ωe tento v¥robek odpovídå nåsledujícím normåm nebo normativním
podkladüm: EN 60 745, EN 55 014, podle ustanovení smπrnic 73/23/EG, 89/336/EG, 98/37/EG, 2002/96/EG.
HLUÇNOSTI/VIBRACÍ Mπ®eno podle EN 60 745 çiní tlak hlukové vlny tohoto p®ístroje 72 dB(A) a dávka hluçnosti 83 dB(A)
(standardní odchylka: 3 dB), a vibrací < 2,5 m/s2(metoda ruka-paΩe).
CZ
CE STANDARDIZASYON BEYANI Ye¤ane sorumlu olarak, bu ürünün afla¤ıdaki standartlara veya standart belgelerine uygun
oldu¤unu beyan ederiz: EN 60 745, EN 55 014, yönetmeli¤i hükümleri uyarınca 73/23/EC, 89/336/EC, 98/37/EC, 2002/96/EC.
GÜRÜLTÜ/T‹TREfiIM Ölçülen EN 60 745 göre ses basıncı bu makinanın seviyesi 72 dB(A) ve çal›flma s›ras›ndaki gürültü
83 dB(A) (standart sapma: 3 dB), ve titreflim < 2,5 m/s2(el-kol metodu).
TR

95
05 SKIL Europe B.V. A. v.d. Kloot
ЗАЯВЛЕНИЕ О СООТВЕТСТВИИ Мы с полной ответственностыо заявляем, что это изделие соответствует следующим
стандартам или стандартизованным документам: EN 60 745, EN 55 014, в соответсувии с инструкциями 73/23/EC,
89/336/EC, 98/37/EC, 2002/96/EC. ШУМНОСТИ/ВИБРАЦИИ При измерении в соответствии co стандартoм EN 60 745 уровень
звукового давления для этого инструмента составляет 72 дБ (A) и уровeнь звуковой мощности - 83 дБ (A) (стандартное
отклонение: 3 dB), и вибрации - < 2,5 м/с2(по методу для рук).
RU
CE ВІДПОВІДНІСТЬ Ми заявляємо, що відповідність даного продукту наступним стандартам і регулюючим документам
повністю нашою відповідальністю: EN 60 745, EN 55 014, відповідно до положень директив 73/23/ЄС, 89/336/ЄС, 98/37/ЄС,
2002/96/ЄС. ШУМ/ВІБРАЦІЯ Зміряний відповідно до EN 60 745 рівень тиску звуку даного інструменту 72 дБ(А) i потужність
звуку 83 дБ(А) (стандартне відхилення: 3 дБ), i вібрація < 2,5 м/с2(ручна методика).
UA
CE ∆ΗΛΩΣΗ ΣYMBATOTΗΤΑΣ ∆ηλούµε υπευθύνως τι το προϊν αυτ είναι κατασκευασµένο σύµφωνα µε τους εξής
κανονισµούς ή κατασκευαστικές συστάσεις: EN 60 745, EN 55 014, κατά τις διατάξεις των κανονισµών της Κοινής Αγοράς
73/23/EK, 89/336/EK, 98/37/EK, 2002/96/EK. ΘΟΡYΒΟ/ΚΡΑ∆ΑΣΜΟYΣ Μετρηµένη σύµφωνα µε EN 60 745 η στάθµη
ακουστικής πίεσης αυτού του εργαλείου ανέρχεται σε 72 dB(A) και η στάθµη ηχητικής ισχύoς σε 83 dB(A) (κοινή απκλιση:
3 dB), και ο κραδασµς σε < 2,5 m/s2(µεθοδος χειρς/βραχίονα).
GR
DECLARAØIE DE CONFORMITATE CE Declaråm pe proprie råspundere cå acest product este conform cu urmåtoarele standarde
sau documente standardizate: EN 60 745, EN 55 014, în conformitate cu regulile 73/23/EC, 89/336/EC, 98/37/EC, 2002/96/EC.
ZGOMOT/VIBRAØII Måsurat în conformitate cu EN 60 745 nivelul de presiune a sunetului generat de acest instrument este de
72 dB(A) iar nivelul de putere a sunetului 83 dB(A) (abaterea standard: 3 dB), iar nivelul vibraøiilor < 2,5 m/s2(metoda mînå - braø).
RO
CE ДЕKЛАPAЦИЯ ЗA CБOTВETCTBИE Декларираме на изцяло наша отговорност, че това изделие е съобразено със
следните стандарти или стандартизирани документи: EN 60 745, EN 55 014, в съответствие с нормативната уредба на
73/23/EG, 89/336/EG, 98/37/EG, 2002/96/EG.
ШУМ/ВИБPAЦИИ Измерено в съответствие с EN 60 745 нивото на звуково налягане на този инструмент е 72 dB(A) а
нивото на звукова мощност е 83 dB(A) (стандартно отклонение: 3 dB), а вибрациите са < 2,5 m/s2(метод ръка-рамо).
BG
CE IZJAVA O USKLA ĐENOSTI Izjavljujemo uz punu odgovornost da je ovaj proizvod usklađen sa slijedeçim normama i
normativnim dokumentima: EN 60 745, EN 55 014, prema odredbama smjernica 73/23/EG, 89/336/EG, 98/37/EG, 2002/96/EG.
BUCI/VIBRACIJAMA Mjereno prema EN 60 745, prag zvuãnog tlaka ovog elektriãnog alata iznosi 72 dB(A) a jakost zvuka 83 dB(A)
(standardna devijacija: 3 dB), a vibracija < 2,5 m/s2(postupkom na ‰aci-ruci).
HR
CE IZJAVA O USKLA ĐENOSTI Pod punom odgovorno‰çu izjavljujemo da je ovaj proizvod usklađen sa sledeçim standardima ili
standardizovanim dokumentima: EN 60 745, EN 55 014, u skladu sa odredbama smernica 73/23/EG, 89/336/EG, 98/37/EG,
2002/96/EG. BUKA/VIBRACIJE Mereno u skladu sa EN 60 745, nivo pritiska zvuka ovog alata iznosi 72 dB(A), a jaãina zvuka
83 dB(A) (normalno odstupanje: 3 dB), a vibracija < 2,5 m/s2(mereno metodom na ‰aci-ruci).
SCG
IZJAVA O USTREZNOSTI CE Odgovorno izjavljamo, da je ta izdelek v skladu z naslednjimi standardi ali standardnimi dokumenti:
EN 60 745, EN 55 014, v skladu s predpisi navodil 73/23/EG, 89/336/EG, 98/37/EG, 2002/96/EG.
HRUP/VIBRACIJA Izmerjeno v skladu s predpisom EN 60 745 je raven zvoãnega pritiska za to orodje 72 dB(A) in jakosti zvoka
83 dB(A) (standarden odmik: 3 dB), in vibracija < 2,5 m/s2 (metoda ‘dlan-roka’).
SLO
CE VASTAVUSDEKLARATSIOON Kinnitame ainuvastutajana, et see toode vastab järgmistele standarditele või
normdokumentidele: EN 60 745, EN 55 014 vastavalt direktiivide 73/23/EÜ, 89/336/EÜ, 98/37/EÜ, 2002/96/EÜ nõuetele.
MÜRA/VIBRATSIOON Vastavalt kooskõlas normiga EN 60 745 läbi viidud mõõtmistele on antud seadme helirõhk 72 dB(A) ja
helitugevus 83 dB(A) (standardkõrvalekalle: 3 dB), ja vibratsioon < 2,5 m/s2(käe-randme-meetod).
EST
CE DEKLARÅCIJA PAR ATBILST±BU STANDARTIEM Mïs ar pilnu atbild¥bu pazi¿ojam, ka ‰is izstrÇdÇjums atbilst standartiem vai
standartizÇcijas dokumentiem EN 60 745, EN 55 014 un ir saska¿Ç ar direkt¥vÇm 73/23/EG, 89/336/EG, 98/37/EG, 2002/96/EG.
TROKSNIS/VIBRÅCIJA Saska¿Ç ar standartu EN 60 745 noteiktais instrumenta rad¥tÇ trok‰¿a ska¿as spiediena l¥menis ir
72 dB(A) un ska¿as jaudas l¥menis ir 83 dB (A) (pie tipiskÇs izkliedes: 3 dB), un vibrÇcijas intensitÇte ir < 2,5 m/s2
(strÇdÇjot rokas reÏ¥mÇ).
LV
CE KOKYBñS ATITIKTIES DEKLARACIJA Mes atsakingai parei‰kiame, kad ‰is gaminys atitinka tokius standartus ir normatyvinius
dokumentus: EN 60 745, EN 55 014 pagal EEB reglament˜ 73/23/EG, 89/336/EG, 98/37/EG, 2002/96/EG nuostatas.
TRIUK·MINGUMAS/VIBRACIJA ·io prietaiso triuk‰mingumas buvo i‰matuotas pagal EN 60 745 reikalavimus keliamo triuk‰mo
garso slògio lygis siekia 72 dB(A) ir akustinio galingumo lygis 83 dB(A) (standartinis nuokrypis: 3 dB), ir vibracijos pagreitis rankos
pla‰takos srityje tipiniu atveju yra maÏesnis, kaip < 2,5 m/s2.
LT
CE ДЕKЛАPAЦИЯ ЗA CБOTВETCTBИE Декларираме на изцяло наша отговорност, че това изделие е съобразено със
следните стандарти или стандартизирани документи: EN 60 745, EN 55 014, в съответствие с нормативната уредба на
73/23/EG, 89/336/EG, 98/37/EG, 2002/96/EG.
ШУМ/ВИБPAЦИИ Измерено в съответствие с EN 60 745 нивото на звуково налягане на този инструмент е 72 dB(A) а
нивото на звукова мощност е 83 dB(A) (стандартно отклонение: 3 dB), а вибрациите са < 2,5 m/s2(метод ръка-рамо).
SK
OÂWIADCZENIE ZGODNOÂCI CE Niniejszym oÊwiadczamy ponoszàc osobistà odpowiedzialnoÊç, ˝e produkt wykonany jest zgodnie
z nast´pujàcymi normami i dokumentami normalizujàcymi: EN 60 745, EN 55 014, z godnie z wytycznymi 73/23/WE, 89/336/WE,
98/37/WE, 2002/96/WE. HA¸ASU/WIBRACJE Pomiarów dokonano zgodnie z normà EN 60 745 ciÊnienie akustyczne narz´dzia
wynosi 72 dB(A) zaÊ poziom mocy akustycznej 83 dB(A) (poziom odchylenie: 3 dB), zaÊ wibracje < 2,5 m/s2(metoda d∏oƒ-r´ka).
PL
