SKYDANCE S1-T User manual

Output current Max 1.2A
Input voltage AC100-240V
Output voltage AC100-240V
Operation temperature
Case temperature (Max.)
Environment
IP20
IP rating
Dimming data
Dimming range
Touch key + RF 2.4GHz
30m
256 levels
0 -100%
Technical Parameters
Input and Output
Safety and EMC
EMC standard (EMC)
EN 55015:2013
EN 61547:2009
EN 61000-3-2:2014
EN 61000-3-3:2013
Certification CE,EMC,LVD
EN 61347-2-11:2002
EN 61347-1:2015
EN 62493:2015
Safety standard(LVD)
Warranty
5 years
Warranty
Input signal
RF Control distance
Dimming level
Ta: -30
O
C ~ +55
O
C
T c: +85
O
C
Model No.: S1-T
Touch glass panel/Brightness slide/Leading edge or trailing edge/Wireless remote control
Features
AC Triac Touch Glass Panel Dimmer
LVD
● Touch glass panel AC phase-cut dimmer, 1 channel output.
● To dim and switch single color dimmable LED lamps, traditional incandescent and halogen lights.
● Ultra sensitive high strength glass touch panel with touch slide in the middle and backlighting.
● Leading edge dimming or trailing edge dimming set by dip switch.
Skydance’s 2.4G dimming remote control● Compatibility with .
Output power 120-288W
User Manual Ver 1.0.2 www.iskydance.com Page 1

Mechanical Structures and Installations
DIP switch for Leading edge
or trailing edge phase-cut select
Caution: Please carefully ensure all wire connections and polarities are correct and secure before applying power,
otherwise this controller will be damaged.
● Connect with dimmable LED light
Wiring diagram
AC100-240V
Input
AC100-240V
Output
Dimmable LED light
AC N output
AC L output AC L input
AC N input
11.5mm
86mm
86mm
59mm
62mm
35mm
45.5mm
Typical base as below:
European style 86 size
Baseplate Base
Uninstall
Installation diagram:
Touch panel
N1
L1
OUTP UT
AC10 0- 24 0V
N L
INPU T
AC100-240V
N1
L1
OUTPUT
AC100-24 0V
N L
INPUT
AC100-24 0V
S1-T AC Triac Touch Glass Panel Dimmer
User Manual Ver 1.0.2 www.iskydance.com Page 2

● Connect with Triac dimmable LED driver
Note: When calculating the maximum number of load lamps or drivers, the input power or input
current parameters of a single lamp or driver must be used, the output power parameters can
not be used, otherwise, the product will be overloaded and damaged.
AC100-240V
Output
LED light
Triac Dimmable
LED Driver
AC100-240V
Input
N1
L1
OUTPUT
AC100-24 0V
N L
INPUT
AC100-24 0V
Turn on/off light.
Play dynamic mode,6 level speed.
Brightness,10 levels.
Turn off light after 20s.
Brightness slide
Power
20S
Delay Off
ModeBright
Key function
User Manual Ver 1.0.2 www.iskydance.com Page 3

Leading edge or trailing edge dimming setting
Reverse-phase
Forward-phase
Select leading edge(forward-phase) dimmer or trailing edge(reverse-phase) dimmer
according to dimmable LED light or driver.
Caution: before power on, you must confirm the selection of dip switch.
ON
Match Remote Control (two match ways)
Use On/Off key
Match:
Turn on light, turn off, immediately press the On/Off
key of the panel for 5s, then press on/off key
(single zone remote) or zone key (multiple zone remote)
of the RF remote within 5s.
Use Power Restart
Match:
Switch off the power, then switch on power again,
immediately short press on/off key (single zone remote)
or zone key (multiple zone remote) 3 times on the remote.
The light blinks 3 times means match is successful.
.
Delete:
Switch off the power, then switch on power again,
immediately short press on/off key (single zone remote)
or zone key (multiple zone remote) 5 times on the remote.
The light blinks 5 times means all matched remotes were
deleted.
Delete:
Turn on light, turn off, immediately press the On/Off
key of the panel for 10s, delete all matched RF remote.
End user can choose the suitable match/delete ways. Two options are offered for selection:
The AC Triac touch panel dimmer can also match with the RF dimming remote (optional).
S1-T AC Triac Touch Glass Panel Dimmer
User Manual Ver 1.0.2 www.iskydance.com Page 4
