Slime 40051 User manual

PART# 40051 | REV041618ART
CARS • LIGHT TRUCKS • SUVS
DIGITAL TIRE INFLATOR
ATTENTION! READ ALL INSTRUCTIONS CAREFULLY
FAILURE TO FOLLOW WARNING INSTRUCTIONS CAN RESULT IN FIRE,
PERSONAL INJURY OR PROPERTY DAMAGE.

LIGHT
• Bright LED
• For night-time
emergencies
LIGHT SWITCH
• Separate switch for
light and inflator
INFLATOR
• Compact design
• Air-cooled motor
EASY READ
DIGITAL
DISPLAY
• Displays PSI
INFLATE
RIGHT™
TECHNOLOGY
• Inflator
automatically
shuts off when
the set pressure
level is achieved
• Guarantees
perfect pressure
with every use
ON/OFF
BUTTON
POWER SOURCE
• Plugs into 12V
power outlet
AIR ADAPTER
STORAGE
• Inflatables adapters
snap-in-place for
easy access
FLOATY BALL
TECH SPECS
IDEAL USES
TIRE INFLATION TIME
CFM
AIR HOSE LENGTH
POWER CORD LENGTH
POWER SOURCE
DIGITAL GAUGE
LIGHT
* (0-35 PSI, Standard Tire: P195/65 R15)
Tires
6 min*
0.75 (21 LPM)
2 ft. (0.6m)
10 ft. (3m)
12 volt accessory power outlet
0 - 99 PSI
LED
AIR HOSE

INFLATE TIRES
1. Screw valve connector onto tire's valve stem.
2. Plug power cord into 12 volt accessory power outlet.
3. Set target pressure value
4. Press on/off switch.
5. The inflator will stop at the pre-set value.
6. Press on/off switch again.
*NOTE: Correct tire pressure can be found in vehicle owner's manual or on driver's side door jamb.
CAUTION: HOT • DO NOT HOLD IN HAND WHILE OPERATING • PLACE INFLATOR ON A
HARD, CLEAN SURFACE.
1. DO NOT run vehicle while inflator is operating. You may need to be in
"accessory" or "on" position. Please make sure emergency brake is set and car is
in park.
2. Always ensure the valve connector is fully seated to depress the core of the valve
stem for proper inflation.
3. DO NOT use inflator continuously for more than 10 minutes. Allow unit to cool
approximately 25 minutes between uses. Do not leave inflator unattended.
4. ALWAYS use a pressure gauge to check tire pressure. DO NOT overinflate.
5. Soft inflatables (i.e. rafts, balls, etc.) may not have recommended pressure
markings. Be careful not to inflate items beyond their capacity.
6. While operating, never block the inflator input or output.
7. Keep inflator out of reach of children.
8. For use with 12 volt DC power outlets rated 15 amps or higher. Do not use with
older 8 amp cigarette lighter receptacles.

TROUBLESHOOTING
Inflator does not turn on:
1. Check the fuse, it may have blown: 12V fuse is
located in the plug adapter. Unscrew the tip,
remove fuse, and inspect. If necessary, replace fuse
with a 15A 250V (5mm×20mm).
2. Check vehicle's power outlet fuse; it should be a minimum of 15 amps.
3. Check receptacle and plug terminals for dirt (particularly tobacco). Use a non-conductive
probe (not fingers or metal) to dislodge and remove debris.
4. Push the power plug firmly into the receptacle and twist it back and forth.
Inflator runs but does not inflate:
1. Be sure the valve connector is tightly screwed onto the valve stem.
2. Check tire for leaks. Check hose for breaks and leaks at fittings.
Inflator runs slowly:
1. The inflator may have overheated from excessive use. Shut it off and allow it to cool for
25 minutes.
2. The voltage may be too low. Check the condition of your vehicle's battery.
NOTE: If tire is totally deflated, it is possible that the tire could separate from the rim
allowing air to leak out when trying to inflate. In the event this occurs, it may be necessary
to jack up the tire prior to inflation.
Warranty: For the period of one year from date of purchase, manufacturer guarantees that this Product will meet the
specifications when used as directed. Manufacturer’s sole liability and Customer’s sole remedy under any warranty
claim is limited to a Manufacturer’s coupon for a replacement product upon return of unit and proof of purchase.
QUESTIONS OR COMMENTS: Call +1-805-489-0490 or visit www.slime.com
ITW Global Tire Repair • 125 Venture Drive, Suite 210, San Luis Obispo, CA 93401 USA
Slime® is a trademark of Illinois Tool Works, Inc., registered in the U.S. and other countries.
DIGITAL GAUGE OPERATING INSTRUCTIONS:
1. Hold the + or – button for approximately 5 seconds until the display flashes. Set the
required pressure using the + or – buttons, then wait 2-3 seconds. The display will show
the pressure value to which the tire will be inflated.
2. Push the ON/OFF button for the inflator to start. When the pressure gauge reaches the
pre-set value, the inflator will automatically switch off.
3. The ON/OFF button can be used to override the present pressure value if required.

¡ATENCIÓN! LEA TODAS LAS INSTRUCCIONES CON ATENCIÓN
SI NO SIGUE LAS INSTRUCCIONES DE ADVERTENCIA, PUEDE CAUSAR
INCENDIO, LESIONES A PERSONAS O DAÑOS MATERIALES.
AUTOS • CAMIONES LIGEROS • SUV
INFLADOR DIGITAL DE NEUMÁTICOS

LUZ
• LED brillante
• Para emergencias
de noche
INFLADOR
• Diseño compacto
• Motor enfriado
por aire
MANGUERA
DE AIRE
BOTÓN DE
ENCENDIDO
FUENTE DE ENERGÍA
• Se conecta en una toma
de corriente de 12 V
COMPARTIMIENTO PARA
EL ADAPTADOR DE AIRE
• Los adaptadores inflables se insertan
en su lugar para fácil acceso
GLOBO ESFERA
ESPECIFICACIONES
USOS IDEALES
TIEMPO DE INFLADO DE LLANTAS
PCM
LONGITUD DE MANGUERA DE AIRE DE ROLLO
LONGITUD DEL CORDÓN DE CORRIENTE
FUENTE DE ENERGÍA
MEDIDOR DIGITAL
LUZ
Llantas
6 min*
0.75 (21 LPM)
2 ft. (0.6 m)
10 ft. (3.0 m)
Toma de corriente para accesorio de 12 voltios
0-99PSI Iluminacíon Posterior
LED
* (0-35 PSI, llanta estándar: P195/65 R15)
INTERRUPTOR
PARA LA LUZ
• Interruptores aparte para
la luz y el compresor
PANTALLA
DIGITAL FÁCIL
DE LEER
• Indica la presión
por pulgada
cuadrada o PSI
TECNOLOGÍA
INFLATE RIGHT™
• El inflador se apaga
automáticamente
cuando se ha
alcanzado el nivel de
presión configurado
• Garantiza una
presión perfecta
con cada uso

INFLE LAS LLANTAS
1. Atornille el conector de la válvula al pivote de la válvula del neumático.
2. Enchufe el cordón eléctrico en la toma de corriente para accesorios de 12 voltios.
3. Configure la presión indicada (consulte: INSTRUCCIONES PARA OPERAR EL INDICADOR
DIGITAL DE PRESIÓN).
4. Oprima el interruptor on/off.
5. El compresor se apaga cuando llega a la presión configurada.
6. Oprima otra vez el interruptor on/off.
*NOTA: La presión de la llanta adecuada se encuentra en el manual del propietario del
vehículo o en el panel de la puerta del lado del conductor.
PRECAUCIÓN: CALIENTE • NO SOSTENGA CON LA MANO AL OPERAR • COLOQUE EL
INFLADOR SOBRE UNA SUPERFICIE FIRME Y LIMPIA.
1. NO PONGA EN MARCHA el vehículo cuando el inflador esté funcionando. Puede
ser necesario tenerlo en la posición de “accesorios” o “encendido.” Asegúrese
de haber puesto el freno de emergencia y de tener la palanca de cambios en la
posición de estacionado “park.”
2. Siempre asegúrese de que el conector de la válvula esté completamente colocado
para presionar el núcleo del pivote de la válvula y tener un inflado adecuado
2. NO USE el inflador continuamente durante más de 10 minutos. Permita que
la unidad se enfríe aproximadamente 25 minutos entre cada uso. No inflador
funcionando solo.
3. SIEMPRE use un manómetro para medir la presión de la llanta. NO INFLE
excesivamente.
4. Los inflables blandos (balsas, pelotas, etc.) pueden no tener marcaciones de presión
recomendada. Tenga cuidado de no inflar los artículos por arriba de su capacidad.
5. Durante la operación, no bloquee la entrada ni la salida del inflador.
6. Mantenga el inflador lejos del alcance de los niños.
7. Para usarse con una alimentación eléctrica de 12 VCD y una corriente nominal de 15
A o mayor. No use con las tomas antiguas para cigarrillos de 8 A.

SOLUCIÓN DE PROBLEMAS
El inflador no enciende:
1. Verifique el fusible, puede haberse fundido: el
fusible de 12 V está ubicado en el adaptador del
enchufe. Desenrosque la punta, retire el fusible e
inspeccione. Si es necesario, reemplace el fusible
con uno de 15A 250V (5mm20mm).
2. Revise el fusible de la toma de corriente del vehículo; debe ser de un mínimo de 15 A.
3. Revise si hay suciedad, especialmente tabaco, en la toma y en las terminales del enchufe.
Use una sonda no conductora, no sus dedos o metales, para aflojar y remover residuos.
4. Empuje con firmeza el enchufe en la toma y gírelo de atrás hacia adelante.
El inflador funciona pero no infla:
1. Asegúrese de que el conector de la válvula esté bien atornillado en el pivote de la
válvula.
2. Verifique que la llanta no tenga fugas. Revise que la manguera no tenga grietas ni fugas
en las conexiones.
El inflador funciona lentamente:
1. El inflador puede estar sobrecalentado debido a uso excesivo. Apáguelo y espere 25
minutos para que se enfríe.
2. El voltaje puede ser demasiado bajo. Revise la condición de la batería de su vehículo.
NOTA: Si la llanta está totalmente desinflada, es posible que esté separada del aro y éste
permite que el aire se escape cuando trata de inflarla. Si ocurre esta situación, puede ser
necesario levantar la llanta con un gato para inflarla.
Garantía: El fabricante garantiza, durante el período de un año desde la fecha de compra, que este producto cumple con las
especificaciones cuando se use según las indicaciones. La única responsabilidad del fabricante y la única solución para el
cliente bajo cualquier reclamación de garantía se limita a un cupón del fabricante para el reemplazo del producto cuando se
haya devuelto el artículo con el comprobante de compra.
PREGUNTAS O COMENTARIOS: Llamar al +1-805-489-0490 o visitar www.slime.com
ITW Global Tire Repair • 125 Venture Drive, Suite 210, San Luis Obispo, CA 93401 USA
Slime® es una marca registrada de Illinois Tool Works, Inc., registrada en Estados Unidos y en otros países.
INSTRUCCIONES PARA OPERAR EL INDICADOR
DIGITAL DE PRESIÓN:
1. Oprima el botón + o - durante unos 5 segundos hasta que parpadee la pantalla.
Configure la presión necesaria con los botones + o -, luego espere unos 2 a 3 segundos.
La pantalla indicará el valor de la presión al cual se inflará el neumático.
2. Pulse el botón ON/OFF para encender el inflador. Cuando el indicador de presión
alcanza la presión configurada, el inflador se apaga automáticamente.
3. Si es necesario, el botón ON/OFF se puede usar para cancelar el valor de presión actual.
