SMA 1C4-313-001-001 Operating and safety instructions

Leistungsmodul-SMC46-60A-70HV-RM-xx-10 | 122440-00.01 | Version 1.0
Spare-part set "Power module" for
SunnyMiniCentral 4600A / 5000A /
6000A / 7000HV
1C4-313-001-001 / 1C4-328-000-001 / 1C3-313-000-001

Leistungsmodul-SMC46-60A-70HV-RM-xx-102
ENGLISH Replacement Manual................................................................3
DEUTSCH Austauschanleitung.................................................................20
ČEŠTINA Návod kvýměně ....................................................................39
ΕΛΛΗΝΙΚΑ Οδηγίες αντικατάστασης........................................................57
ESPAÑOL Instrucciones para la sustitución............................................76
FRANÇAIS Instructions de remplacement................................................94
ITALIANO Istruzioni per la sostituzione ............................................... 112
NEDERLANDS Vervangingshandleiding..................................................... 130
PORTUGUÊS Manual de substituição ....................................................... 149
ROMÂNĂ Instrucțiuni de schimb .......................................................... 167
TÜRKÇE Değiştirme kılavuzu ............................................................. 185
Contact...................................................................................203

Legal Provisions
SMA Solar Technology AG
Replacement Manual Leistungsmodul-SMC46-60A-70HV-RM-xx-10 3
Legal Provisions
The information contained in these documents is the property of SMA Solar Technology AG. No
part of this document may be reproduced, stored in a retrieval system, or transmitted, in any form or
by any means, be it electronic, mechanical, photographic, magnetic or otherwise, without the prior
written permission of SMA Solar Technology AG. Internal reproduction used solely for the purpose
of product evaluation or other proper use is allowed and does not require prior approval.
SMA Solar Technology AG makes no representations or warranties, express or implied, with
respect to this documentation or any of the equipment and/or software it may describe, including
(with no limitation) any implied warranties of utility, merchantability, or fitness for any particular
purpose. All such representations or warranties are expressly disclaimed. Neither SMA Solar
Technology AG nor its distributors or dealers shall be liable for any indirect, incidental, or
consequential damages under any circumstances.
The exclusion of implied warranties may not apply in all cases under some statutes, and thus the
above exclusion may not apply.
Specifications are subject to change without notice. Every attempt has been made to make this
document complete, accurate and up-to-date. Readers are cautioned, however, that product
improvements and field usage experience may cause SMA Solar Technology AG to make changes
to these specifications without advance notice or per contract provisions. SMA Solar Technology
AG shall not be responsible for any damages, including indirect, incidental or consequential
damages, caused by reliance on the material presented, including, but not limited to, omissions,
typographical errors, arithmetical errors or listing errors in the content material.
Trademarks
All trademarks are recognized, even if not explicitly identified as such. Missing designations do not
mean that a product or brand is not a registered trademark.
SMA Solar Technology AG
Sonnenallee 1
34266 Niestetal
Germany
Tel. [phone]
Fax [phone]
www.SMA.de
Email: [email protected]
As of: 8/26/2020
Copyright © 2020 SMA Solar Technology AG. All rights reserved.
ENGLISH

Table of Contents SMA Solar Technology AG
Replacement ManualLeistungsmodul-SMC46-60A-70HV-RM-xx-104
Table of Contents
1 Information on this Document................................................. 5
1.1 Validity........................................................................................................................ 5
1.2 Target Group.............................................................................................................. 5
1.3 Content and Structure of this Document ................................................................... 5
1.4 Levels of Warning Messages.................................................................................... 5
1.5 Symbols in the Document .......................................................................................... 6
1.6 Typographical Elements in the Document ................................................................ 6
1.7 Designations in the Document................................................................................... 6
2 Safety ........................................................................................ 7
2.1 Intended Use .............................................................................................................. 7
2.2 IMPORTANT SAFETY INSTRUCTIONS.................................................................... 7
3 Scope of Delivery..................................................................... 10
4 Overview of the Assemblies ................................................... 11
5 Disconnecting the Inverter from Voltage Sources................. 12
6 Removing Defective Power Module....................................... 13
7 Installing New Power Module................................................ 16
8 Returning and Disposing of the Defective Assembly ............ 19
ENGLISH

1 Information on this Document
SMA Solar Technology AG
Replacement Manual Leistungsmodul-SMC46-60A-70HV-RM-xx-10 5
1 Information on this Document
1.1 Validity
This document is valid for:
• 1C4-313-001-001
• 1C4-328-000-001
• 1C3-313-000-001
1.2 Target Group
The tasks described in this document must only be performed by qualified persons. Qualified
persons must have the following skills:
• Within the SMA factory warranty, participation in an SMA training course is mandatory for
carrying out the activities described in this document. The type of training and the media used
may vary from country to country. The type and method of training can therefore vary from
country to country, but must have been completed before the service is provided.
• Outside the SMA factory warranty, SMA Solar Technology AG recommends participation in
an SMA training course to perform the activities described in this document. This ensures the
quality requirements for proper replacement of assemblies. The type of training and the media
used may vary from country to country.
• Knowledge of how to safely disconnect SMA inverters
• Knowledge of how an inverter works and is operated
• Training in the installation and commissioning of electrical devices and installations
• Knowledge of all applicable laws, standards and directives
• Knowledge of and compliance with this document and all safety information
1.3 Content and Structure of this Document
This document describes how to replace components.
Illustrations in this document are reduced to the essential information and may deviate from the real
product.
1.4 Levels of Warning Messages
The following levels of warning messages may occur when handling the product.
DANGER
Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
WARNING
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
ENGLISH

1 Information on this Document SMA Solar Technology AG
Replacement ManualLeistungsmodul-SMC46-60A-70HV-RM-xx-106
NOTICE
Indicates a situation which, if not avoided, can result in property damage.
1.5 Symbols in the Document
Symbol Explanation
Information that is important for a specific topic or goal, but is not safety-rele-
vant
☐
Indicates a requirement for meeting a specific goal
☑
Desired result
✖
A problem that might occur
Example
Sections describing activities to be performed by qualified persons only
1.6 Typographical Elements in the Document
Typography Use Example
bold • Messages
• Terminals
• Elements on a user interface
• Elements to be selected
• Elements to be entered
• Connect the insulated
conductors to the terminals
X703:1 to X703:6.
• Enter 10 in the field
Minutes.
>• Connects several elements to be
selected
• Select Settings > Date.
[Button]
[Key]
• Button or key to be selected or
pressed
• Select [Enter].
# • Placeholder for variable
components (e.g., parameter
names)
• Parameter WCtlHz.Hz#
1.7 Designations in the Document
Complete designation Designation in this document
Power module Power module, module
Power assembly (AST) AST assembly, AST, assembly
ENGLISH

2 Safety
SMA Solar Technology AG
Replacement Manual Leistungsmodul-SMC46-60A-70HV-RM-xx-10 7
Complete designation Designation in this document
Operation control assembly (BFS) OCS assembly, OCS, assembly
AC/DC terminal assembly CON assembly, CON, assembly
2 Safety
2.1 Intended Use
The product must only be installed in the following SMA inverters:
Spare parts set Inverters
1C3-313-000-001 SMC4600A
SMC4600A-11
SMC5000A
SMC5000A-11
SMC6000A
SMC6000A-11
1C4-313-001-001 SMC 7000HV
1C4-328-000-001 SMC7000HV-11
Use SMA products only in accordance with the information provided in the enclosed
documentation and with the locally applicable laws, regulations, standards and directives. Any
other application may cause personal injury or property damage.
Alterations to the SMA products, e.g., changes or modifications, are only permitted with the express
written permission of SMA Solar Technology AG. Unauthorized alterations will void guarantee and
warranty claims and in most cases terminate the operating license. SMA Solar Technology AG
shall not be held liable for any damage caused by such changes.
Any use of the product other than that described in the Intended Use section does not qualify as the
intended use.
The enclosed documentation is an integral part of this product. Keep the documentation in a
convenient, dry place for future reference and observe all instructions contained therein.
This document does not replace and is not intended to replace any local, state, provincial, federal
or national laws, regulations or codes applicable to the installation, electrical safety and use of the
product. SMA Solar Technology AG assumes no responsibility for the compliance or non-
compliance with such laws or codes in connection with the installation of the product.
If the replacement and all activities stated in this document are carried out by persons who are not
qualified within the meaning of this documentation, this will void the guarantee and warranty claims
and in most cases terminate the operating permit. SMA Solar Technology AG shall not be held
liable for any damage caused directly or indirectly due to such changes by unauthorized persons.
2.2 IMPORTANT SAFETY INSTRUCTIONS
Keep the manual for future reference.
ENGLISH

2 Safety SMA Solar Technology AG
Replacement ManualLeistungsmodul-SMC46-60A-70HV-RM-xx-108
This section contains safety information that must be observed at all times when working.
The product has been designed and tested in accordance with international safety requirements. As
with all electrical or electronical devices, there are residual risks despite careful construction. To
prevent personal injury and property damage and to ensure long-term operation of the product,
read this section carefully and observe all safety information at all times.
DANGER
Danger to life due to electric shock when live components or cables of the
inverter are touched
High voltages are present in the conductive components or cables of the inverter. Touching live
parts and cables of the inverter results in death or lethal injuries due to electric shock.
• Disconnect the inverter from voltage sources and make sure it cannot be reconnected
before working on the device.
• Wear suitable personal protective equipment for all work on the product.
• Do not touch non-insulated parts or cables.
DANGER
Danger to life due to electric shock when live components or DC cables are
touched
When exposed to light, the PV modules generate high DC voltage which is present in the DC
cables. Touching live DC cables results in death or lethal injuries due to electric shock.
• Do not touch non-insulated parts or cables.
• Disconnect the inverter from voltage sources and make sure it cannot be reconnected
before working on the device.
• Do not disconnect the DC connectors under load.
• Wear suitable personal protective equipment for all work on the product.
DANGER
Danger to life due to electric shock when touching live system components in
case of a grounded PV array or an undesired ground fault
If the PV array is grounded or there is an undesired ground fault, parts of the system may still be
live. Touching live parts and cables results in death or lethal injuries due to electric shock.
• Disconnect the inverter from voltage sources and make sure it cannot be reconnected
before working on the device.
• Touch the cables of the PV array on the insulation only.
• Do not connect PV strings with ground faults to the inverter.
• Once disconnected from voltage sources, wait five minutes before touching any parts of the
PV system or the inverter.
ENGLISH

2 Safety
SMA Solar Technology AG
Replacement Manual Leistungsmodul-SMC46-60A-70HV-RM-xx-10 9
WARNING
Danger to life due to fire or explosion
In rare cases, an explosive gas mixture can be generated inside the inverter under fault
conditions. In this state, switching operations can cause a fire inside the inverter or explosion.
Death or lethal injuries due to hot or flying debris can result.
• Ensure that unauthorized persons have no access to the inverter.
• Do not remove the Electronic Solar Switch (ESS) from the inverter.
• Disconnect the PV array from the inverter via an external disconnection device. If there is no
disconnecting device present, wait until no more DC power is applied to the inverter.
• Disconnect the AC circuit breaker, or keep it disconnected in case it has already tripped,
and secure it against reconnection.
• Only perform work on the inverter (e.g., troubleshooting, repair work) when wearing
personal protective equipment for handling of hazardous substances (e.g., safety gloves,
eye and face protection, respiratory protection).
WARNING
Risk of injury due to toxic substances, gases and dusts.
In rare cases, damages to electronic components can result in the formation of toxic substances,
gases or dusts inside the inverter. Touching toxic substances and inhaling toxic gases and dusts
can cause skin irritation, burns or poisoning, trouble breathing and nausea.
• Only perform work on the inverter (e.g., troubleshooting, repair work) when wearing
personal protective equipment for handling of hazardous substances (e.g., safety gloves,
eye and face protection, respiratory protection).
• Ensure that unauthorized persons have no access to the inverter.
WARNING
Danger to life due to electric shock from destruction of the measuring device
due to overvoltage
Overvoltage can damage a measuring device and result in voltage being present in the
enclosure of the measuring device. Touching the live enclosure of the measuring device results in
death or lethal injuries due to electric shock.
• Only use measuring devices with a DC input voltage range of 800V or higher.
CAUTION
Risk of burns due to hot enclosure parts
Some parts of the enclosure can get hot during operation. Touching hot enclosure parts can
result in burn injuries.
• During operation, do not touch any parts other than the enclosure lid of the inverter.
ENGLISH

3 Scope of Delivery SMA Solar Technology AG
Replacement ManualLeistungsmodul-SMC46-60A-70HV-RM-xx-1010
NOTICE
Damage to the enclosure seal in subfreezing conditions
If you open the inverter when temperatures are below freezing, the enclosure seals can be
damaged. This can lead to moisture entering the inverter.
• Only open the inverter if the ambient temperature is not below -5°C.
• If a layer of ice has formed on the enclosure seal when temperatures are below freezing,
remove it prior to opening the inverter (e.g. by melting the ice with warm air).
NOTICE
Damage to the inverter due to sand, dust and moisture
Sand, dust and moisture penetration can damage the inverter, thus impairing its functionality.
• Only open the inverter if the humidity is within the thresholds and the environment is free of
sand and dust.
• Do not open the inverter during a dust storm or precipitation.
• Close the inverter in case of interruption of work or after finishing work.
NOTICE
Damage to the inverter due to electrostatic discharge
Touching electronic components can cause damage to or destroy the inverter through
electrostatic discharge.
• Ground yourself before touching any component.
Grounding conductor test prior to recommissioning
Prior to recommissioning SMA inverters after the installation of SMA components or power
assemblies which cannot be replaced intuitively, ensure that the grounding conductor in the
inverter is correctly connected. The function of the grounding conductor must be ensured and
all locally applicable laws, standards and directives must be observed.
Observe superordinate standards
The repair work on devices and the consideration and application of other standards which
correspond to a superordinate standard is the responsibility of the qualified person performing
the work. Unauthorized alterations will void guarantee and warranty claims and in most cases
terminate the operating license. SMA Solar Technology AG shall not be held liable for any
damage caused by such changes.
3 Scope of Delivery
Check the scope of delivery for completeness and any externally visible damage. Contact the
Service if the delivery is incomplete or damaged.
Quantity Designation
1 Power module
1 Replacement Manual
ENGLISH

4 Overview of the Assemblies
SMA Solar Technology AG
Replacement Manual Leistungsmodul-SMC46-60A-70HV-RM-xx-10 11
4 Overview of the Assemblies
AB
D
E
F
C
Figure 1 : Overview of the assemblies (example: SMC46-6A)
Position Explanation
A Power assembly (AST)
B Cover of the power module with module screw. The power module is located be-
low the power assembly (AST).
C DC link (The DC link is positioned differently depending on the device type)
D Display assembly
E Operation control system assembly (OCS)
F AC/DC terminal assembly
ENGLISH

5 Disconnecting the Inverter from Voltage Sources SMA Solar Technology AG
Replacement ManualLeistungsmodul-SMC46-60A-70HV-RM-xx-1012
5 Disconnecting the Inverter from Voltage Sources
DANGER
Danger to life due to electric shock when live components or DC cables are
touched
When exposed to light, the PV modules generate high DC voltage which is present in the DC
cables. Touching live DC cables results in death or lethal injuries due to electric shock.
• Do not touch non-insulated parts or cables.
• Disconnect the inverter from voltage sources and make sure it cannot be reconnected
before working on the device.
• Do not disconnect the DC connectors under load.
• Wear suitable personal protective equipment for all work on the product.
WARNING
Danger to life due to electric shock from destruction of the measuring device
due to overvoltage
Overvoltage can damage a measuring device and result in voltage being present in the
enclosure of the measuring device. Touching the live enclosure of the measuring device results in
death or lethal injuries due to electric shock.
• Only use measuring devices with a DC input voltage range of 800V or higher.
Prior to performing any work on the inverter, always disconnect it from all voltage sources as
described in this section.
1. Disconnect the circuit breaker and secure it against reconnection.
2. If an ESS is installed, remove the ESS.
3. If no ESS is installed, disconnect the PV array from the inverter via an external DC load-break
switch (e.g. via a PV combiner box including a load-break switch).
4. Use a current clamp to ensure that no current is present in the DC cables.
5. Ensure that the DC connectors are in perfect condition and that none of the DC conductors or
DC plug contacts are exposed.
6. Carefully loosen the DC connectors.
7. Ensure that no voltage is present at the DC inputs of the inverter.
8. Wait ten minutes before opening the enclosure lid.
9. Loosen all screws of the enclosure lid and remove the enclosure lid.
10. Ensure that no voltage is present between L and N at the AC terminal using a suitable
measuring device.
11. Ensure that no voltage is present between L and PE at the AC terminal using a suitable
measuring device.
ENGLISH

6 Removing Defective Power Module
SMA Solar Technology AG
Replacement Manual Leistungsmodul-SMC46-60A-70HV-RM-xx-10 13
12. Actively discharge the DC link. For this purpose use,
for example, a 2-pole voltage detector that does not
have its own voltage source. Using the voltage
detector, conduct a measurement on the connection
screws of the terminal of the DC link connection
cable on the CON assembly until a value of 0V is
displayed.
13. NOTICE
Damage to the inverter due to electrostatic discharge
The internal components of the inverter can be irreparably damaged by electrostatic
discharge.
• Ground yourself before touching any component.
6 Removing Defective Power Module
SMA recommends to replace the power module incl. the AST.
There is a high probability that the AST is damaged or shows signs of damage.
Procedure:
1. Disconnect the inverter from all voltage sources (see Section5, page12).
2. Remove the ribbon cable from the OCS assembly.
3. If present, remove the data cable from the OCS assembly. To do so, note the terminal
assignment, open every screw terminal with a flat-blade screwdriver (blade width: 2 mm) and
remove the conductor from the screw terminal.
4. NOTICE
Damage to the assembly due to mechanical strain
If the assembly is excessively bent, solder contacts, components and conducting paths may
snap.
• Remove the OCS assembly and the display assembly separately. To do this, proceed
as follows.
ENGLISH

6 Removing Defective Power Module SMA Solar Technology AG
Replacement ManualLeistungsmodul-SMC46-60A-70HV-RM-xx-1014
5. Loosen the locking mechanism of the 4 white
spacers in the display assembly, take hold of the
edge of the display assembly and carefully remove
it from the OCS assembly by moving it forward.
6. Using a suitable tool (e.g. socket wrench [AF 4]), loosen the locking mechanism of the 4
spacers in the OCS assembly.
7. Take hold of the edge of the OCS assembly and carefully remove it from the AC power
controller assembly by moving it forward.
8. Reconnect the display assembly to the OCS assembly.
9. Remove the ribbon cable from the CON assembly and the AC power controller assembly.
10. Remove the remaining cables:
C
B
A
• Remove the DC link connection cable (A) from the CON assembly. To do so, loosen the
2 screw terminals with a flat-blade screwdriver (blade width: 5.5 mm) and remove the
conductor from the screw terminals.
• Remove the fan cable (B).
• Remove the cables (C) coming from the transformer.
ENGLISH

6 Removing Defective Power Module
SMA Solar Technology AG
Replacement Manual Leistungsmodul-SMC46-60A-70HV-RM-xx-10 15
11. Loosen and remove the module screw with a Torx
screwdriver (TX20).
12. Remove the cover of the power module and store it safely.
13. NOTICE
The power module may slip while the AC power controller assembly is
being removed.
The power module is located below the AC power controller assembly, and sticks in place
solely by means of the thermal grease on the inverter enclosure. If the AC power controller
assembly is removed without due care, the power module may slip.
• To prevent the power module from slipping, screw the module screw back into the
power module slightly without the cover.
14. Loosen the 6 screws of the AC power controller (AST) assembly with a Torx screwdriver
(TX20) and remove them.
15. Carefully remove the AC power controller (AST) assembly from the inverter enclosure.
16. Note the alignment of the power module positioning
nose so that the new power module can be
positioned identically.
17. Due to the existing thermal grease, the power module can stick to the enclosure. Remove the
screw securing the power module and retain for later use. Detach the old power module from
the enclosure with a rotary motion and remove it.
18. Clean the contact surface of the power module in the enclosure until the old thermal paste is
completely removed.
ENGLISH

7 Installing New Power Module SMA Solar Technology AG
Replacement ManualLeistungsmodul-SMC46-60A-70HV-RM-xx-1016
7 Installing New Power Module
If the pattern of thermal grease on the rear side of the power module shows evidence of damage, it
must be replaced. If small impurities (see image) are present, these can be carefully removed using
a pointed tool.
Procedure:
1. Disconnect the inverter from all voltage sources (see Section5, page12).
2. Align the new power module so that the hole in the power module is above the threaded hole
in the enclosure. The position of the positioning nose must be aligned exactly as with the old
power module.
3. Place the power module into the enclosure without moving it on the enclosure. Tighten the
module screws slightly by hand to prevent the power module from slipping.
4. On the rear side of the new AC power controller
assembly, check whether the contact areas for the
power module are contaminated. If the contact
areas are contaminated, clean them with
isopropanol and an ESD-friendly, lint-free cloth.
ENGLISH

7 Installing New Power Module
SMA Solar Technology AG
Replacement Manual Leistungsmodul-SMC46-60A-70HV-RM-xx-10 17
5. Guide the AC power controller (AST) assembly into
the inverter enclosure using the 4 spacers. Ensure
that the positioning nose is guided through the AST.
6. Ensure that the screw hole for the module screw in
the AC power controller assembly is located directly
above the power module’s screw hole in the inverter
enclosure. Also ensure that there are no cables
below the AC power controller assembly and that
no cables get stuck here.
7. Insert the 6 screws and tighten them with a Torx screwdriver (TX20) (torque: 3Nm).
8. Remove the module screw from the power module.
9. Place the cover of the power module in position,
insert the module screw into the screw hole and
tighten the screw (TX20, torque: 2.4Nm). Ensure
the alignment is correct.
10. Connect the ribbon cable to the CON assembly and the AC power controller assembly.
ENGLISH

7 Installing New Power Module SMA Solar Technology AG
Replacement ManualLeistungsmodul-SMC46-60A-70HV-RM-xx-1018
11. NOTICE
Damage to the assembly due to mechanical strain
If the assembly is excessively bent, solder contacts, components and conducting paths may
snap.
• Place the OCS assembly onto the spacers and carefully press it down in the middle
until the spacers snap into place.
• If present, reconnect the data cables to the OCS assembly in accordance with the
assignment noted during removal. To do so, insert the conductors into the screw
terminals and retighten the screw terminal with a flat-blade screwdriver (blade width: 2
mm).
12. Connect the ribbon cable to the OCS assembly.
13. Connect the remaining cables:
C
B
A
• Connect the DC link connection cable (A) to the CON assembly. To do so, insert the
conductors into the screw terminals and retighten the screw terminals (torque: 1.5 Nm).
Ensure the color assignment is correct (BK = black, RD = red).
• Connect the fan cable (B) to the new AC power controller assembly. Ensure that the
connectors snap into place correctly.
• Connect the cables coming from the transformer (C) (torque for the screw terminals: 1.5
Nm). Ensure the color assignment is correct (GN = green, RD = red).
14. Check the tension of every cable.
ENGLISH

8 Returning and Disposing of the Defective Assembly
SMA Solar Technology AG
Replacement Manual Leistungsmodul-SMC46-60A-70HV-RM-xx-10 19
15. Carry out the necessary tests according to the locally applicable laws, standards and
directives for the correct recommissioning after power assembly replacement. Take the
requirements for component replacements into account (see Section2.2 "IMPORTANT
SAFETY INSTRUCTIONS", page7).
16. Ensure that the grounding conductor in the inverter is correctly connected and functions
properly.
17. After replacing the defective component, ensure operational and system safety in accordance
with the locally applicable electrotechnical rules.
18. Recommission the inverter (see inverter manual).
