Smeg CMSC451B User manual
MANUALE D’USO
INSTRUCTIONS
MODE D’EMPLOI
BEDIENUNGSANLEITUNG
GEBRUIKSAANWIJZINGEN
MANUAL DE INSTRUCCIONES
MANUAL DE INSTRUÇÕES
ΟΔΗΓΙΕΣ ΧΡΗΣΗΣ
ИНСТРУКЦИИ ПО ЭКСПЛУАТАЦИИ
UŽIVATELSKÁ PŘÍRUČKA
INSTRUKCJA OBSŁUGI
BRUKSANVISNING
BRUGERVEJLEDNING
MACCHINA PER CAFFÈ E CAPPUCCINO
COFFEE AND CAPPUCCINO MAKER
MACHINE À CAFÉ ET À CAPPUCCINO
KAFFEE-/CAPPUCCINO-VOLLAUTOMAT
KOFFIE- EN CAPPUCCINOAPPARAAT
CAFETERA PARA CAFÉ Y CAPUCHINO
MÁQUINA DE CAFÉ E CAPPUCCINO
ΜΗΧΑΝΗ ΚΑΦΕ ΚΑΙ CAPPUCCINO
КОФЕМАШИНА ДЛЯ ПРИГОТОВЛЕНИЯ КОФЕ И КАПУЧЧИНО
PŘÍSTROJ NA PŘÍPRAVU KÁVY A KAPUČÍNA
EKSPRES DO KAWY I KAWY CAPPUCCINO
KAFFEMASKIN FÖR ESPRESSO OCH CAPPUCCINO
KAFFE- OG CAPPUCCINOMASKINE
AR
6
CONTENTS
INTRODUCTION ........................................................ 7
Symbols used in these instructions ..........................................7
Letters in brackets....................................................................7
Troubleshooting and repairs ....................................................7
SAFETY .................................................................... 7
Fundamental safety warnings .................................................7
Designated use.........................................................................8
Instructions..............................................................................8
DESCRIPTION ........................................................... 8
Description of the appliance ....................................................8
Description of milk container and accessories .........................8
Description of control panel.....................................................8
PRELIMINARY CHECKS .............................................. 8
Controls after transport ...........................................................8
Installing the appliance............................................................8
Connecting the appliance ........................................................9
AUTOMATIC CUP TRAY LIGHT ..................................... 9
BUILTIN INSTALLATION.......................................... 10
USING THE APPLIANCE FOR THE FIRST TIME ............. 12
TURNING ON AND HEATING UP ................................ 12
MAKING COFFEE USING COFFEE BEANS .................... 12
CHANGING THE QUANTITY OF COFFEE IN THE CUP ..... 13
AJUSTING THE COFFEE MILL .................................... 14
MAKING ESPRESSO COFFEE WITH PREGROUND COFFEE
INSTEAD OF BEANS ............................................. 14
DELIVERING HOT WATER ......................................... 14
CHANGING THE QUANTITY OF HOT WATER ................ 14
MAKING CAPUCCINO FROTHED MILK AND COFFEE .. 14
MAKING FROTHED MILK WITHOUT COFFEE............. 15
CHANGING THE QUANTITY OF COFFEE AND MILK FOR
CAPPUCCINO .......................................................... 15
CLEANING AND MAINTENANCE ................................ 16
Cleaning the coee maker......................................................16
Cleaning the coee grounds container...................................16
Cleaning the drip tray.............................................................16
Cleaning the water tank.........................................................16
Cleaning the spouts ...............................................................16
Cleaning the pre-ground coee funnel ..................................16
Cleaning the inside of the coee maker.................................16
Cleaning the infuser...............................................................16
Cleaning the milk container...................................................17
CHANGING AND SETTING MENU PARAMETERS .......... 17
Setting the clock ...................................................................18
Setting auto-start time .........................................................18
Descaling ...............................................................................18
Changing coee temperature ................................................19
Changing the length of time the appliance remains on .........19
Setting water hardness .........................................................19
Resetting default values (reset) .............................................19
Washing procedure ................................................................19
CHANGING THE LANGUAGE...................................... 19
TURNING THE APPLIANCE OFF................................. 19
TECHNICAL SPECIFICATION ..................................... 20
DISPOSING OF THE APPLIANCE ................................ 20
DISPLAYED MESSAGES ............................................ 21
TROUBLESHOOTING................................................ 22
RECIPES ................................................................ 23
6 7
INTRODUCTION
Thank you for choosing the automatic coee and cappuccino
maker.We hope you enjoy using your new appliance.
Take a few minutes to read these instructions.
This will avoid all risks and damage to the machine.
Symbols used in these instructions
Important warnings are identied by these symbols.
These warnings must absolutely be respected.
Failure to observe the instructions could result in electric shock,
serious injury, burns, re or damage to the appliance.
Danger!
Failure to observe the warning could result in possibly life
threatening injury from electric shock.
Important!
Failure to observe the warning could result in injury or damage
to the appliance.
Danger of burns!
Failure to observe the warning could result in scalds or burns.
N.B.:
This symbol identies important advice or information for the
user.
Letters in brackets
The letters in brackets refer to the legend in the Description of
the Appliance on page 3.
Troubleshooting and repairs
In the event of problems, rst try and resolve them following
the information given in the sections “Displayed messages”
and “Troubleshooting”. If this does not resolve the problem or
you require further information, you should consult Customer
Services by calling the number given on the “Customer Service”
sheet.
If your country is not among those listed on the sheet, call the
number given in the guarantee. If repairs are required, contact
Customer Services only. The addresses are given in the guaran-
tee certicate provided with the machine.
SAFETY
Fundamental safety warnings
The appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or instruc-
tion concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that
they do not play with the appliance.
Cleaning and user maintenance shall not be
made by children without supervision.
Never immerse the appliance in water.
This is an household appliance only. It is
not intended to be used in: sta kitchen
areas in shops, oces and other working
environments; farm houses; by clients in
hotels, motels and other residential type
environments; bed and breakfast type envi-
ronments.
If the plug or power cable is damaged, it
must be replaced by customer services only
to avoid all risk.
FOR EUROPEAN MARKETS ONLY:
This appliance can be used by children aged
from 8 years and above if they have been
given supervision or instruction concerning
use of the appliance in a safe way and if they
understand the hazard involved. Cleaning
and user maintenance shall not be made
by children unless they are older than 8 and
supervised. Keep the appliance and its cord
out of the reach of children aged less than
8 years.
Appliances can be used by persons with re-
duced physical, sensory or mental capabili-
8
ties or lack of experience and knowledge if
they have been given supervision or instruc-
tion concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance.
When not in use and before cleaning, always
unplug the appliance.
Surfaces marked with this symbol be-
come hot during use (the symbol is present
in certain models only).
Important! The appliance is designed and produced
for domestic use only.
Danger! This is an electrical appliance and may cause
electric shock.
You should therefore respect the following safety warnings:
enabling the appliance to be unplugged when necessary.
Never pull the power cable as you could damage it.
switch (A19) on the side of the appliance in the 0 position.
Turn it o using the main switch (A19), unplug from the
mains socket and contact Customer Services.
Important! Keep all packaging (plastic bags, polysty-
rene foam) away from children.
Danger of burns! This appliance produces hot water
and steam may form while it is in operation.
Avoid contact with splashes of water or hot steam.
Avoid touching hot surfaces when the appliance is in use.
Important! Do not grasp the coee maker when it
is out of the cabinet. Do not rest recipients containing liquids
or inammable or corrosive materials on top of the appliance.
Place the accessories required to prepare the coee (the meas-
ure for example) in the special holder. Do not rest large objects
which could obstruct movement or unstable objects on the
appliance.
Important! Never make drinks, hot water or steam
when the appliance is extracted. Always make sure the appli-
ance is inactive before extracting it. Failure to observe this pre-
caution could lead to damage to the appliance.
Designated use
This appliance is designed and made to prepare coee and heat
drinks. All other use is considered improper.
This appliance is not suitable for commercial use.
The manufacturer is not liable for damage deriving from im-
proper use of the appliance. This appliance can be installed over
a built-in oven if the latter is tted with a cooling fan at the rear
(maximum oven power: 3 kW).
Instructions
Read these instructions carefully before using the appliance.
persons, they must also be provided with these instruc-
tions.
damage to the appliance.
The manufacturer is not liable for damage deriving from
failure to respect these instructions.
DESCRIPTION
Description of the appliance
(page 3 - A )
A1. Cup tray
A2. Service door
A3. Coee guide
A4. Coee grounds container
A5. Infuser
A6. Lights
A7. Control panel
A8. Hot water and steam nozzle
A9. Water tank
A10. Coee spout (adjustable height)
A11. Drip tray
A12. Bean container lid
A13. Container for coee beans
A14. Grinding adjustment knob
A15. Pre-ground coee funnel door
A16. Compartment for measure
A17. Pre-ground coee funnel
A18. Power cable
A19. Main switch
8 9
A20. Tray
A21. IEC connector
Description of milk container and accessories
(page 3 - B)
B1. Frothed milk regulator
B2. Milk container handle
B3. CLEAN button
B4. Milk intake tube
B5. Frothed milk spout
B6. Milk frother
B7. Hot water spout
B8. Measure
Description of control panel
(page 3 - C)
A number of buttons on the panel have a double function. This is
indicated in brackets in the description.
C1. Display: guides the user in using the appliance.
C2. MENU button to activate or deactivate menu parameter
setting mode
C3. button to select pre-ground coee
(When in the MENU: NEXT button to display the next menu
parameter).
C4. Rinse button to perform a brief rinse to heat the infus-
er.
(When you access the MENU: “CHANGE” button to modify
menu parameters).
C5. button to deliver hot water.
(When you access the MENU: OK button to conrm menu
parameters).
C6. knob to turn the appliance on and o.
C7. button to select the coee taste
C8. button to deliver one or two cups of short coee
C9. button to deliver one or two cups of standard coee
C10. button to deliver one or two cups of long coee
C11. knob to deliver cappuccino or frothed milk
PRELIMINARY CHECKS
Controls after transport
After removing the packaging, make sure the product is com-
plete and undamaged and that all accessories are present.
Do not use the appliance if it is visibly damaged.
Contact Customer Services.
Installing the appliance
Important! When installing the appliance, respect the
following safety warnings:
in compliance with legislation in force in the country of
installation (see section: BUILT-IN INSTALLATION).
etc.) should be kept out of reach of children as they are a
safety hazard.
-
ture may drop to 0°C or lower (the water in the appliance
could freeze and cause damage).
-
sible following the instructions in the “SETTING WATER
HARDNESS”section.
Connecting the appliance
Danger! Check that the mains power supply voltage
corresponds to the value indicated on the appliance rating plate.
Connect the appliance to an eciently earthed and correctly
installed socket with a minimum current rating of 10A only.
If the power socket does not match the plug on the appliance,
have the socket replaced with a suitable type by a qualied pro-
fessional.
To comply with safety directives, an omnipolar switch with a
minimum contact distance of 3 mm must be installed.
Do not use multiple sockets or extensions.
To learn to use the appliance correctly, the rst time you use it
follow the detailed instructions in the following sections.
Important! Safety cutout devices must be included
in the mains power supply in compliance with the installation
regulations in the country concerned.
AUTOMATIC CUP TRAY LIGHT
When the appliance is turned on, the lights (A6) automatically
light up the spout and cup tray.
The lights stay on until the appliance is turned o.
While coee, steam or hot water is being delivered, the cooling
fan comes on.
At the end of the function, the cooling fan remains on to avoid
condensation forming inside the cabinet. After several minutes,
the fan goes o automatically.
N.B.: The appliance also completes this cycle if switched
o by turning the knob (C6) to the right or left.
Important! Do not look at the lights directly or using
an optical instrument.
10
BUILTIN INSTALLATION
Verify the minimum measurements required for correct instal-
lation of the appliance.
The coee maker must be installed in a column and the column
must be rmly xed to the wall with commercially available
brackets.
Important:
be performed with the appliance disconnected from the
mains electricity supply.
be heat resistant (65°C min).
of the cabinet (see measurements in gure).
200 cm2
45 mm
45 mm
45 mm
45 mm
45 mm
45 mm
45 mm
45 mm
450
850 mm
500 mm
550 mm Min
.
560 mm
200 cm
2
455 mm
595 mm
22 mm
361 mm
528 mm
372 mm
30 mm
200 cm2
45 mm
45 mm
45 mm
45 mm
45 mm
45 mm
45 mm
45 mm
450
850 mm
500 mm
550 mm Min.
560 mm
200 cm
2
455 mm
595 mm
22 mm
361 mm
528 mm
372 mm
30 mm
200 cm2
45 mm
45 mm
45 mm
45 mm
45 mm
45 mm
45 mm
45 mm
450
850 mm
500 mm
550 mm Min.
560 mm
200 cm
2
455 mm
595 mm
22 mm
361 mm
528 mm
372 mm
30 mm
10 11
x 4
x 16 x 2
approx. 350mm
x 1
x 4
560 + 1 mm
Position the rails on the sides of the cabinet as shown in the
gure.
Fix with the screws, then extract them completely.
If the coee maker is installed over a warmer drawer (500 W
max.), use the top surface of this as a reference to position the
rails.
In this case, there will be no surface to rest the rails on.
x 4
x 16 x 2
approx. 350mm
x 1
x 4
560 + 1 mm
Fix the power cable with the clip to avoid it tangling when the
appliance is inserted or extracted.
The power cable must be long enough to allow the appliance to
be extracted from the cabinet to ll the coee beans container.
The appliance must be earthed in compliance with legislation.
Electrical connections must be performed by a qualied elec-
trician in compliance with the manufacturer’s instructions and
legislation in force in the country of installation.
The electrical socket must be accessible.
x 4
x 16 x 2
approx. 350mm
x 1
x 4
560 + 1 mm
Position the appliance on the rails, making sure the pins are
correctly inserted in the housings, then x it with the screws
supplied.
x 4
x 16 x 2
approx. 350mm
x 1
x 4
560 + 1 mm
If necessary, correct alignment of the appliance by positioning
the spacers supplied under or at the sides of the support.
12
USING THE APPLIANCE FOR THE FIRST TIME
therefore completely normal for there to be traces of coee
in the mill.
The machine is, however, guaranteed to be new.
following the instructions in the “Setting water hardness”
section.
1. Connect the appliance to the mains electricity supply and
press the main switch (A19).
You must select the required language:
2. To set English, wait for the appliance to display“PRESS OK
TO INSTALL ENGLISH”.While the message is displayed, hold
the OK button (C5) (g. 1) down for at least 3 seconds un-
til “ENGLISH INSTALLED” is displayed. If you set the wrong
language by mistake, follow the instructions in the section
“Changing the language” to choose the right language.
Follow the instructions indicated by the appliance:
3. After 5 seconds, the appliance displays “FILL TANK”. To ll
the water tank, remove (g. 2), rinse and ll with fresh
water without exceeding the MAX line.
Replace the tank and push as far as it will go.
4. Place a cup under the hot water spout (g. 3).
(If the hot water spout is not inserted, the appliance dis-
plays “INSERT WATER SPOUT”. Attach it as shown in gure
4.
The appliance now displays: “HOTWATER PRESS OK”.
Press the OK button (C5) (g. 1) and after a few seconds a
little water comes out of the spout.
(Delivery stops automatically).
5. The machine now displays “TURNING OFF... PLEASE WAIT”
and goes o.
6. Extract the appliance by pulling it out using the handles
(g. 5). Open the lid and ll the container with coee
beans, then close the lid and push the appliance in.
Important! To prevent malfunction, never introduce
pre-ground coee, freeze dried coee, caramelised beans or
anything else which could damage the appliance.
The coee maker is now ready for normal use.
N.B.: When using the appliance for the rst time, you
need to make 4-5 cups of coee and 4-5 cappuccinos before the
appliance starts to give satisfactory results.
N.B.: Each time you turn the coee maker on by the
main switch (A19), it performs a SELF-DIAGNOSIS cycle and
then goes o. To turn it on again, turn the knob (C6) to the
right or left.
TURNING ON AND HEATING UP
Each time the appliance is turned on, it performs an automatic
preheat and rinse cycle which cannot be interrupted.
The appliance is ready for use only after completion of this cycle.
Danger of burns! During rinsing, a little hot water
ows from the coee spouts. Avoid contact with splashes of
water.
To turn the appliance on, turn the knob (C6) to the right or
left (g. 6).“HEATING UP... PLEASE WAIT”is displayed.
After heating, the message “RINSING” is displayed. As well as
heating the boiler, the appliance also heats the internal circuits
by circulating hot water.
The appliance is at temperature when the message “READY
STANDARD TASTE”is displayed.
MAKING COFFEE USING COFFEE BEANS
1. The appliance is preset to make coee with a standard
taste.
You can also choose coee with an extra-mild, mild, strong
or extra-strong taste.
To choose the required taste, press the button (C7)
(g. 7).The required coee taste is displayed.
2. Place 1 cup under the spouts to make 1 coee (g. 8) or 2
cups for 2 coees (g. 9).
Lower the spouts as near as possible to the cup for a cream-
ier coee (g. 10).
3. Press the button (C8) to make a short coee (g. 11),
the button (C9) for a standard coee and the but-
ton (C10) for a long coee. To make 2 coees, press the
button twice (within 2 seconds).
To change the quantity of coee the appliance delivers
automatically into the cup, proceed as described in the
following section.
(The appliance now grinds the beans and starts delivering
the coee into the cup. Once the set amount of coee has
been delivered, the machine stops delivery automatically
and expels the exhausted coee grounds into the grounds
container.
4. After a few seconds, the ready message is displayed again
and you can make another coee.
5. To turn the appliance o, turn the knob (C6) to the
right or left.
(Before going o, the appliance performs an automatic
rinse cycle (a little hot water ows from the spouts and is
collected in the drip tray beneath.
12 13
Take care to avoid scalds).
NOTE 1: If the coee is delivered a drop at a time or not at all,
turn the grinding adjustment knob (g. 12) one click clockwise
(see“Adjusting the coee mill”).
Proceed one click at a time until coee delivery is satisfactory.
NOTE 2: If the coee is delivered too fast and the cream is not
satisfactory, turn the grinding adjustment knob (g. 12) one
click anticlockwise (see“Adjusting the coee mill”).
Avoid turning the grinding adjustment knob excessively other-
wise when you select 2 cups, the coee may be delivered a drop
at a time.
NOTE 3:Tips for a hotter coee:
short coee (less than 60 cc), rinse the cups with hot water
to preheat the cups.
If more than 2/3 minutes have passed since the last coee
was made, before requesting another coee, you must
preheat the infuser by pressing the button (C4) (g.
13).
Deliver the water into the underlying drip tray or alterna-
tively use this water to ll (and then empty) the cup to be
used for the coee, so as to preheat it.
will absorb too much heat.
NOTE 4: While the appliance is making coee, delivery can be
interrupted at any moment by pressing the previously selected
button, (C8), (C9) or (C10).
NOTE 5: As soon as delivery is nished, to increase the quantity
of coee in the cup, just hold down the previously selected cof-
fee button, (C8), (C9) or (C10), until the required
amount is reached (this must be done within 3 seconds after
completion of delivery).
NOTE 6: When the appliance displays “FILL TANK”, ll the tank
with water or the appliance will not deliver coee.
(It is normal for there to be a little water left in the tank when
the message is displayed).
NOTE 7: After about 14 single (or 7 double) coees, the appli-
ance displays “EMPTY GROUNDS CONTAINER”, indicating that
the grounds container is full and must be emptied and cleaned.
Until the grounds container has been cleaned, the appliance
continues to display the message and coee cannot be made.
Even if not full, the empty waste coee container message is
displayed 72 hours after the rst coee has been delivered. For
the 72 hours to be calculated correctly, the machine must never
be turned o with the main switch in the 0 position.
To clean, open the service door on the front of the appliance by
pulling the handle (g. 14), extract the drip tray (g. 15), empty
and clean.
When cleaning, always extract the drip tray completely to
avoid it falling when the grounds container is removed.
Empty the grounds container and clean thoroughly to remove
all residues left on the bottom.
Important! when removing the drip tray, the grounds
container MUST be emptied, even if it is not completely full. If
this is not done, when you make the next coees, the grounds
container may ll up more than expected and clog the machine.
NOTE 8: Never extract the water tank while the machine is de-
livering coee.
If it is removed, it will not be possible to make the coee and
the appliance will display“GROUND TOO FINE ADJUST MILL and
INSERTWATER SPOUT AND PRESS OK”.
To use the appliance again, insert the hot water spout (g. 4) if
not already in position, then press the OK button (C5) and deliv-
er water from the spout for a few seconds.
CHANGING THE QUANTITY OF COFFEE IN THE CUP
The appliance is set by default to automatically make the fol-
lowing types of coee:
button (C8) is pressed;
button (C9) is pressed;
button (C10) is pressed.
To change these quantities, proceed as follows:
want to change, (C8), or (C9) or (C10), for at
least 3 seconds then release until the message“PROGRAM
QUANTITY”is displayed and coee delivery commences;
the same button again to memorise the new amount.
The appliance is now reprogrammed with the new settings and
displays:“READY”.
14
ADJUSTING THE COFFEE MILL
The coee mill is preset in the factory to make coee correctly
and should not require adjusting initially.
However, if after making the rst few coees you nd that de-
livery is either too fast or too slow (a drop at a time), this can be
corrected by adjusting the grinding adjustment knob (g. 12).
Turn one click clockwise (one number) for more rapid coee
delivery (not a drop at a time).
Turn one click anticlockwise for slower coee delivery and a
creamier coee. These adjustments will only be evident after at
least 2 cups of coee have been delivered.
The grinding adjustment knob must only be turned when the
coee mill is in operation.
For slower delivery and creamier coee, turn one click anticlock-
wise (ner pre-ground coee).
For faster delivery (not a drop at a time), turn one click clockwise
(coarser pre-ground coee).
(Coee has been used to factory test the appliance and it is
therefore completely normal for there to be traces of coee in
the mill. It is, however, guaranteed to be new.)
MAKING ESPRESSO COFFEE WITH PREGROUND
COFFEE INSTEAD OF BEANS
button (C3) (g. 16) to select the pre-
ground coee function. This disables the coee mill func-
tion.
The appliance now displays the message: “READY PRE-
GROUND”.
-
dles.
in the funnel (g. 17), push the appliance in then proceed
as described in the section “Making coee using coee
beans”.
N.B.:You can make just one coee at a time by pressing the
(C8), (C9) or (C10) button once only.
to making coee using beans, deactivate the pre-ground
coee function by pressing the button (C7) again to
enable the coee mill.
NOTE 1: Never introduce pre-ground coee when the machine is
o or it could spread through the inside of the appliance.
NOTE 2: Never add more than 1 level measure, otherwise either
the appliance will not make the coee and the pre-ground
coee will be dispersed inside the appliance, dirtying it, or the
coee will be delivered a drop at a time.
NOTE 3: Use the measure provided to add the right amount of
coee.
NOTE 4: Introduce only pre-ground coee for espresso coee
machines into the funnel. Never ll with coee beans, freeze
dried coee or other substance that could damage the appli-
ance.
NOTE 5: If more than one measure of pre-ground coee is used
and the funnel clogs, push the coee down with a knife (g. 18)
then remove and clean the infuser and machine as described in
the“Cleaning the infuser”section.
DELIVERING HOT WATER
button (C5) (g. 1).
The message“HOTWATER”is displayed and hot water ows
out of the hot water spout into the container.
(You should not deliver hot water for more than 2 minutes
at a time).
To interrupt the ow, press the button (C5).
Once the set quantity of hot water has been reached, deliv-
ery stops automatically.
CHANGING THE QUANTITY OF HOT WATER
The appliance is set by default to automatically deliver about
200 ml of hot water.
To change these quantities, proceed as follows:
button (C5) down for at least 2 seconds then
release it.The message“HOT WATER PROGRAM QUANTITY”
is displayed and hot water ows out of the hot water spout.
press the button (C5) to memorise the new amount.
(You should not deliver hot water for more than 2 minutes
at a time).
MAKING CAPPUCCINO FROTHED MILK AND COF
FEE
cappuccino by pressing the button (C7).
14 15
cappuccino to be prepared (g. 19). Never exceed the MAX
level (corresponding to about 750 ml) marked on the jug.
You should ideally use skimmed or semi-skimmed milk at
refrigerator temperature (about 5°C).
-
ber washer (g. 20) then replace the milk container lid.
words CAPPUCCINO and CAFFELATTE printed on the milk
container lid.
The quality of froth can be adjusted by moving the frothed
milk regulator towards the word CAFFELATTE for a denser
froth.
Moving it towards the word CAPPUCCINO obtains a less
dense froth.
container to the nozzle (g. 22).
suciently large cup under the coee and milk spouts.
knob (C11) to the right.
“CAPPUCCINO...” is displayed and after a few seconds,
frothed milk ows out of the milk spout into the cup below.
(Delivery stops automatically).
and displays the“ready”message again.
-
sired, sprinkle the froth with a little cocoa powder.
NOTE 1: While making cappuccino, the ow of frothed milk or
coee can be interrupted by turning the knob (C11) to the
right.
NOTE 2: If the milk in the container nishes while delivering
frothed milk, remove the container and add milk.
Then re-attach it and turn the knob (C11) to the right to
request cappuccino again.
NOTE 3: To ensure the complete cleanliness and hygiene of the
milk frother, always clean the circuits in the milk container lid
after making cappuccino
least 3 seconds (g. 25). The appliance displays “CLEAN-
ING”.
After cleaning, remove the milk container and place in the
refrigerator.
The milk should not be left out of the refrigerator for more
than 15 minutes.
NOTE 4: To change the quantity of coee or frothed milk the
appliance delivers automatically into the cup, proceed as de-
scribed in the section“Changing the quantity of coee and milk
for cappuccino”.
MAKING FROTHED MILK WITHOUT COFFEE
prepare (g. 19).
knob (C11) to the left.
“FROTHED MILK” is displayed and after a few seconds,
frothed milk ows out of the milk spout into the cup below.
by pressing the CLEAN button as described in the previous
section (note 3).
CHANGING THE QUANTITY OF COFFEE AND MILK
FOR CAPPUCCINO
The appliance is set by default to automatically deliver a stand-
ard cappuccino.
To change these quantities, proceed as follows:
-
cated on the container.
knob (C11) to the right and keep it turned for
at least 3 seconds until“MILK FOR CAPPUCCINO PROGRAM
QUANTITY”is displayed. Release the knob.
The appliance starts delivering milk.
the knob (C11) to the right again. Milk delivery stops.
(You should not deliver frothed milk for more than 3 min-
utes at a time.)
cup and displays“COFFEE FOR CAPPUCC. PROGRAM QUAN-
TITY”.
turn the knob (C11) to the right again. Coee delivery
stops.
The appliance is now re-programmed with the new settings and
displays: READY.
NO schiuma
Schiuma
“più compatta”
Cursore
Schiuma“meno densa”
16
CLEANING AND MAINTENANCE
Before performing any cleaning operations, leave the machine
to cool down completely and unplug from the mains power
supply.
Never immerse the coee maker in water. It is an electrical ap-
pliance.
Do not use solvents or abrasive detergents to clean the coee
maker. A soft damp cloth will suce. Never wash any of the
components of the coee maker in the dishwasher.
Cleaning the coee maker
The following parts of the machine must be cleaned regularly:
door (A2).
Cleaning the coee grounds container
When “EMPTY GROUNDS CONTAINER” is displayed, the grounds
container must be emptied and cleaned.
Until the grounds container has been cleaned, the appliance
continues to display the message and coee cannot be made.
To clean:
(g. 14), extract the drip tray (A11) (g. 15), empty and
clean.
-
move all residues left on the bottom.
Important! When removing the drip tray, the grounds
container must be emptied, even if it is not completely full. If
this is not done, when you make the next coees, the grounds
container may ll up more than expected and clog the machine.
Cleaning the drip tray
Important! If the drip tray is not emptied regular-
ly, the water could overow from the edge and seep inside or
around the coee maker. This could damage the appliance and
cabinet.
The drip tray is tted with a level indicator (red) showing the
level of water it contains (g. 31).
Before the indicator protrudes from the cup tray, the drip tray
must be emptied and cleaned.
To remove the tray:
1. Open the service door (A2) (g. 14).
2. Remove the drip tray (A11) and the grounds container (A4)
(g. 15).
3. Empty the drip tray and grounds container and wash them.
4. Replace the drip tray complete with grounds container.
5. Close the service door.
Cleaning the water tank
1. Clean the water tank (A9) regularly (about once a month)
with a damp cloth and a little mild washing up liquid.
2. Clean to remove all washing up liquid residues, then rinse
the water tank thoroughly.
Cleaning the spouts
1. Clean the coee spout nozzles (A10) periodically using a
sponge or cloth (g. 27).
2. Check regularly that the holes in the coee spout are not
blocked.
If necessary, remove coee deposits with a toothpick (g.
26).
Cleaning the pre-ground coee funnel
coee funnel (A17) is not blocked.
If necessary, remove coee deposits with a knife (g. 18).
Danger! Before performing any cleaning operations,
the machine must be turned o by pressing the main switch
(A19) and unplugged from the mains power supply. Never im-
merse the coee maker in water.
Cleaning the inside of the coee maker
1. Check regularly (about once a week) that the inside of the
appliance is not dirty.
If necessary, remove coee deposits with a knife and a
sponge.
2. Remove the residues with a vacuum cleaner (g. 30).
Cleaning the infuser
The infuser (A5) must be cleaned at least once a month.
Important! The infuser (A5) must not be removed
when the appliance is on.
Do not attempt to use force to remove the infuser as this could
damage the coee maker.
1. Make sure the machine is correctly turned o (see“Turning
the appliance o”).
16 17
2. Open the service door (A2) (g. 14).
3. Remove the drip tray (A11) and grounds container (g. 15).
4. Press the two red release buttons inwards and at the same
time pull the infuser outwards (g. 28).
Important! Do not use washing up liquid to clean the
infuser.
It would remove the lubricant applied to the inside of the piston,
causing the infuser to seize up and become unusable.
5. Soak the infuser in water for about 5 minutes, then rinse
under the tap.
6. After cleaning, replace the infuser (A5) by sliding it onto
the internal support and pin at the bottom;
then push the PUSH symbol fully in until it clicks into place.
N.B.: If the infuser is dicult to insert, you must rst
adapt it to the right dimensions by pressing it forcefully from the
bottom and top as shown in the gure.
7. Once inserted, make sure the two red buttons have
snapped out.
8. Replace the drip tray (A11) and grounds container.
9. Close the service door (A2).
Cleaning the milk container
Important! Always clean the tubes inside the milk
container (B) when you prepare milk. If there is still milk in the
container, do not leave it out of the refrigerator for longer than
strictly necessary. Clean the container each time you prepare
milk as described in Note 3 in the section“Making cappuccino”.
1. Turn the milk container lid clockwise then remove it.
2. Remove the milk spout and intake tube.
Groove
Frothed milk regulator
3. Remove the frothed milk regulator by pulling it outwards.
4. Wash all the components thoroughly with hot water and
mild washing-up liquid.
Make sure there are no milk residues left inside the holes
and the groove on the ne end of the frothed milk regula-
tor.
5. Check that the intake tube and spout are not clogged with
milk residues.
6. Replace the frothed milk regulator, milk spout and intake
tube.
7. Replace the milk container lid.
CHANGING AND SETTING MENU PARAMETERS
After turning the knob (C6) to the right or left and waiting
for the appliance to be ready, you can use the internal menu to
modify the following parameters and functions:
Support
Pin
Spout
Milk intake tube
Hole
Hole
18
Setting the clock
To set the clock, proceed as follows:
comes on) then press the NEXT button (C3) repeatedly until
the appliance displays:“CLOCK… 00:00”.
(If you hold the CHANGE button (C4) down, the time is
changed rapidly).
NEXT (C3) to change other parameters.
Setting auto-start time
This function programmes the time the machine will come on
automatically to be ready for use.
the previous section.
comes on) then press the NEXT button (C3) repeatedly until
the appliance displays:“START TIME… 00:00”.
(If you hold the CHANGE button (C4) down, the time is
changed rapidly).
the message:“AUTO-START NO”.
Press the CHANGE button (C4) to modify the function (the
machine displays “AUTO-START YES”).
NOTE: when the machine is o and an auto-start time has been
set, the symbol appears alongside the time on the unlit
display.
NEXT (C3) to change other parameters.
Descaling
Important! Before descaling, make sure the water
softener lter has been removed.
Important! Descaler contains acids which may irri-
tate the skin and eyes. It is vital to respect the manufacturer’s
safety warnings given on the descaler pack and the warnings
relating to the procedure to follow in the event of contact with
the skin and eyes.
N:B:: Use the descaler recommended by the manufac-
turer only. Use of other descalers invalidates the guarantee.
Failure to descale the appliance as described also invalidates the
guarantee.
Over time, constant heating up of the water used to make the
coee leads to limescale building up in the inner circuits of the
appliance.
When“DESCALE”is displayed, the machine requires descaling.
Proceed as follows:
comes on) then press the NEXT (C3) button repeatedly until
the appliance displays“DESCALE NO”;
“DESCALE YES”
bottle into the tank respecting the instructions given on
the descaler pack, then add water.
When descaling subsequently, use descaler of the same
type and brand as supplied (available from the manufac-
turer’s authorised Customer Services) or a descaler recom-
mended by Customer Services. Always follow the instruc-
tions on the pack.
-
der the hot water spout (g. 3);
-
ter spout into the container below.
“APPLIANCE IN DESCALE”is displayed;
deliveries and pauses to remove limescale deposits from
inside the machine.
FILL TANK”.
The appliance must now be rinsed through to eliminate residues
of descaling solution from inside the appliance. Proceed as fol-
lows:
spout;
into the container below and the appliance displays“RINS-
ING”;
message“RINSING COMPLETE... PRESS OK”;
18 19
clean water.
-
ance is ready to make coee again.
NOTE: If descaling is interrupted before completion, the ma-
chine still displays the descaling message and the process must
be begun again from the beginning.
Empty the water tank, rinse with clean water and deliver a cup
of hot water.
Important! FAILURETO DESCALETHE APPLIANCE REG-
ULARLY INVALIDATES THE GUARANTEE.
Changing coee temperature
To change coee temperature, proceed as follows:
comes on) then press the NEXT button (C3) repeatedly until
the appliance displays“TEMPERATURE HIGH...”;
the required coee temperature;
-
lected;
NEXT (C3) to change other parameters.
Changing the length of time the appliance re-
mains on
The appliance is set by default to go o automatically 30 min-
utes after the last coee has been made.
To change this interval (max. 120 min), proceed as follows:
comes on) then press the NEXT button (C3) repeatedly until
the appliance displays“OFF AFTER...”
hours the appliance remains on.
NEXT (C3) to change other parameters.
Setting water hardness
The descale message is displayed after the appliance has been
operated for a factory set period of time calculated on the basis
of the maximum quantity of limescale which may be contained
in the water used.
The operating period can be extended if required, making des-
caling less frequent by programming the machine on the basis
of the real lime content in the water used.
Proceed as follows:
from its packaging then dip it fully in the water for a few
seconds,
Then remove and wait about 30 seconds (until it changes
colour and forms red squares).
knob (C6) to the
right or left (g. 6);
(C3) repeatedly until the appliance displays“WATER HARD-
NESS 4”;
coincides with the number of red squares on the test strip
(for example, if there are 3 red squares on the test strip,
press the button until“WATER HARDNESS 3”is displayed).
The coee maker is now programmed to provide the des-
cale warning when necessary based on the actual hardness
of the water.
Resetting default values (reset)
If you change the original values, the default values can be reset
as follows:
(C3) repeatedly until the appliance displays “RESET TO DE-
FAULT NO”;
“RESET TO DEFAULT YES”;
“READY”message is displayed.
Washing procedure
This function is available to customer services personnel only.
CHANGING THE LANGUAGE
To change the language, press the CHANGE button (C4) for at
least 5 seconds until the appliance displays the installation mes-
sage in various languages.
Select the required language as described in the section “Using
the appliance for the rst time”.
TURNING THE APPLIANCE OFF
Each time the appliance is turned o, it performs an automatic
rinse cycle which cannot be interrupted.
Danger of burns! During rinsing, a little hot water
ows from the coee spouts. Avoid contact with splashes of
water.
To turn the appliance o, turn the knob (C6).
The appliance performs the rinse cycle then goes o.
20
N.B.: If the appliance is not used for an extended period,
place the main switch (A19) on the back of the appliance in the
0 position.
TECHNICAL SPECIFICATION
Voltage: 220-240 V~ 50/60 Hz max. 10A
Absorbed power: 1350W
Pressure: 15 bars
Water tank capacity: 1.7 litres
Size LxHxD: 595 x 455 x 412 mm
Weight: 26 kg
The appliance complies with the following EC direc-
tives:
-
ments;
Materials and accessories coming into contact with food con-
form to European regulation (EC) no. 1935/2004.
DISPOSING OF THE APPLIANCE
In compliance with European directive 2002/96/EC, the appli-
ance must not be disposed of with household waste, but taken
to an authorised waste separation and recycling centre.
ELECTRICAL CONNECTION UK ONLY
A) If your appliance comes tted with a plug, it will incorpo-
rate a 13 Amp fuse. If it does not t your socket, the plug
should be cut o from the mains lead, and an appropriate
plug tted, as below.
WARNING: Very carefully dispose of the cut o plug after
removing the fuse: do not insert in a 13 Amp socket else-
where in the house as this could cause a shock hazard.
With alternative plugs not incorporating a fuse, the circuit
must be protected by a 15 Amp fuse. If the plug is a mould-
ed-on type, the fuse cover must be re-tted when chang-
ing the fuse using a 13 Amp Asta approved fuse to BS 1362.
In the event of losing the fuse cover, the plug must NOT be
used until a replacement fuse cover can be obtained from
your nearest electrical dealer. The colour of the correct re-
placement fuse cover is that as marked on the base of the
plug.
B) If your appliance is not tted with a plug, please follow the
instructins provided below:
WARNING - THIS APPLIANCE MUST BE EARTHED
IMPORTANT
The wires in the mains lead are coloured in accordance with the
following code:
Green and yellow: Earth
Blue: Neutral
Brown: Live
As the colours of the wires in the mains lead may not corre-
spond with the coloured markings identifying the terminals in
your plug, proceed as follows:
The green and yellow wire must be connected to the terminal
in the plug marked with the letter E or the earth symbol or
coloured green or green and yellow.
The blue wire must be connected to the terminal marked with
the letter N or coloured black.
The brown wire must be co
20 21
DISPLAYED MESSAGES
DISPLAYED MESSAGE POSSIBLE CAUSE REMEDY
FILL TANK The water tank is empty or positioned
incorrectly.
Fill the tank with water and/or insert it
correctly, pushing it as far as it will go.
GROUND TOO FINE ADJUST MILL
Insert water spout and press OK (C5)
The grinding is too ne and the coee is
delivered too slowly.
The machine cannot make coee as there
is air in the hydraulic circuit.
Turn the grinding adjustment knob one
click clockwise towards “7”.
Insert the hot water spout, press the OK
button (C5) and deliver water from the
spout for a few seconds.
INSERT WATER SPOUT The hot water spout is not inserted or is
inserted incorrectly.
Insert the hot water spout as far as it will
go.
INSERT GROUNDS CONTAINER The grounds container (A4) is too full or
more than 3 days have passed since you
last made coee (this guarantees correct
hygiene of the machine).
Empty the grounds container and clean,
then replace.
Important: when removing the drip tray,
the grounds container MUST be emptied,
even if it is not completely full.
If this is not done, when you make the
next coees, the grounds container may
ll up more than expected and clog the
machine.
INSERT GROUNDS CONTAINER After cleaning, the grounds container has
not been replaced.
Open the service door and insert the
grounds container.
INSERT MILK CONTAINER The milk container is not inserted. Insert the milk container as far as it will
go.
ADD PRE-GROUND COFFEE With the pre-ground function selected,
pre-ground coee has not been poured
into the funnel.
The funnel (A17) is blocked.
Extract the appliance and place pre-
ground coee in the funnel.
Empty the funnel with the help of a knife,
as described in the section “Cleaning the
pre-ground coee funnel”.
DESCALE! The machine must be descaled. The descaling procedure described in
the “Descaling” section needs to be per-
formed as soon as possible.
LESS COFFEE Too much coee has been used Select a milder taste or reduce the quan-
tity of pre-ground coee, then make the
coee again
FILL BEANS CONTAINER The coee beans have run out. Fill beans container
INSERT INFUSER ASSEMBLY The infuser has not been replaced after
cleaning.
Insert the infuser as described in the sec-
tion“Cleaning the infuser”.
CLOSE DOOR The service door is open Close the service door.
GENERAL ALARM! The inside of the appliance is very dirty. Clean the inside of the appliance thor-
oughly, as described in the section
“Cleaning and maintenance”.
If the message is still displayed after
cleaning, contact a customer services.
22
TROUBLESHOOTING
Below is a list of some of the possible malfunctions.
If the problem cannot be resolved as described, contact Custom-
er Services.
PROBLEM POSSIBLE CAUSE REMEDY
The coee is not hot. The cups were not preheated.
The infuser has cooled down because 2/3
minutes have elapsed since the last cof-
fee was made.
Heat the cups by rinsing them in hot wa-
ter or leaving them to rest for at least 20
minutes on the cup warmer tray.
Before making coee, heat the infuser by
pressing the button (C4).
The coee is not creamy enough . The coee is ground too coarsely.
Wrong type of coee
Turn the grinding adjustment knob one
click anticlockwise towards “1” while the
coee mill is in operation.
Use a type of coee for espresso coee
makers.
The coee is delivered too slowly or a
drop at a time.
The coee is ground too nely. Turn the grinding adjustment knob one
click clockwise towards the 7 while the
coee mill is in operation.
Continue one click at a time until coee
delivery is satisfactory.
The eect is only visible after delivering
two coees.
The coee is delivered too quickly. The coee is ground too coarsely. Turn the grinding adjustment knob one
click anticlockwise towards “1” while the
coee mill is in operation.
Avoid turning the grinding adjustment
knob excessively otherwise when you
select 2 cups, the coee may be delivered
a drop at a time.
The eect is only visible after delivering
two coees.
Coee does not come out of one of the
spouts.
The spouts are blocked. Clean the spouts with a toothpick (g.
26).
The coee does not come out of the
spouts, but from around the service door
(A2).
The holes in the spouts are clogged with
dry coee dust.
The coee guide (A3) inside the service
door is blocked and cannot swing.
If necessary, remove coee deposits with
a toothpick, sponge or sti bristled kitch-
en brush.
Thoroughly clean the coee guide (A3),
particularly near the hinges.
Water comes out of the spouts instead of
coee.
The pre-ground coee may be blocked in
the funnel (A17).
Clean the funnel (A17) with a wooden
or plastic fork, clean the inside of the
appliance.
The milk does not come out of the milk
spout (B5).
The intake tube is not inserted or is in-
serted incorrectly.
Insert the intake tube (B4) in the rubber
washer in the milk container lid (g. 20).
The milk is not well frothed. The milk container lid is dirty.
The frothed milk regulator is not posi-
tioned correctly.
Clean the milk container lid as described
in the section“Cleaning the milk contain-
e r ”.
Adjust following the instructions in the
section“Making cappuccino”.
22 23
PROBLEM POSSIBLE CAUSE REMEDY
The milk contains bubbles or squirts out
of the milk spout.
The milk is not cold enough or is not
semi-skimmed.
The frothed milk regulator is incorrectly
adjusted.
The milk container lid is dirty.
You should ideally use skimmed or
semi-skimmed milk at refrigerator tem-
perature (about 5°C). If the result is still
disappointing, try another brand of milk.
Move the frothed milk regulator slightly
towards the word“CAFFELATTE”(see sec-
tion“Making cappuccino”).
Clean the milk container lid as described
in the section“Cleaning the milk contain-
e r ”.
RECIPES
Coee punch
Ingredients (serves 6):
1/2 l of hot coee
1/2 l of white Port
1/2 l of rum
100 g of candied brown sugar
Method: Pour the coee into a pot, add the rum and the Port
and heat until it reaches boiling point. Gradually add the can-
died sugar, tasting now and then until suciently sweet. When
the sugar has dissolved serve in traditional, short stemmed
glasses.
Emperor’s coee
Ingredients (serves 3):
3 espresso coees
3 egg yolks
3 teaspoons of sugar
3 dl of milk
2 small glasses of brandy
Method: Beat the egg yolks with the sugar and the brandy.
Add hot milk and hot coee.
RECIPE TIP: lightly whip the milk and add slowly at the very last
ingredient. Best served accompanied by a chocolate cake.
Danish coee
Ingredients:
6 eggs
grated rind of one lemon
100 g of sugar
3/4 l strong, cold coee
1 large glass of brandy
Method: Beat the eggs and the lemon rind, and then add the
sugar a little at a time until the eggs become light and airy.
Slowly add the coee and the brandy, stirring constantly. Serve
in chilled teacups or“Ballon”glasses.
Irish cofee
Ingredients (serves 3):
2 spoons of sugar
1 spoon of water
9 teaspoons of whipping cream
6 spoon of Irish Whisky
4 cups of hot coee
Method: Boil the water and the sugar for approximately one
minute then add to the Whiskey and the hot coee. Mix and
pour into stem glasses. Carefully pour the cream onto the coee
(3 teaspoons per glass).
RECIPE TIP: lightly whip the cream so that it stays on top of the
coee. Grand Marnier or Calvados can also be added.
Coee sorbet
Ingredients (serves 4):
200 g of granulated sugar
2 dl of espresso coee
Method: Combine ½ l of water and the sugar to make a syrup
and simmer for a few minutes; allow it to cool then mix in the
coee. Filter as soon as a smooth mixture is obtained then place
in the freezer to set, mixing often until of a grainy consistency.
Iced coee
Ingredients:
4 espresso coees
4 teaspoons of sugar
12 ice cubes
Method: Crush the ice and add to the pre-sugared coee.
Shake in a shaker until a frothy, creamy mixture
is obtained.
RECIPE TIPS: blend on a low blender setting and
serve in a ute or glass tumbler.
2 3
B7 B8
B4
B6
B5
B1
B2
B3
A
C
A1A2
A3 A4 A5
A7 A9
A10
A15
A16
A11
A14
A13
A12
A8A6
A17
A18
A21
A19
A20
B
C1
C6 C2 C3 C4 C5 C7 C8 C9 C10 C11
This manual suits for next models
2
Table of contents
Other Smeg Coffee Maker manuals
