Smithco 300G255 Quick start guide

Spray Star 3180
Model 30-000-C
SN: 300G255
September 2016
Product Support: Hwy SS & Poplar Ave; Cameron WI 54822
1-800-891-9435 [e-mail]
Parts & Service

Introduction Service Diagrams Parts Accessories Reference
CONTENTS
Introduction............................................1-3
Introduction........................................................................ 1
General Safe Practices...................................................... 2
Specications ................................................................... 3
Optional Spray Equipment................................................. 3
Service..................................................4-11
Maintenance...................................................................4-6
Wheel Creep...................................................................... 6
Adjustments....................................................................... 7
Service Chart..................................................................8-9
Storage....................................................................... 10-11
Diagrams ............................................12-15
Wiring Diagram...........................................................12-13
Hydraulic Diagram......................................................14-15
Parts....................................................16-53
Body & Frame ............................................................16-17
Nose Cone .................................................................18-21
Linkage.......................................................................22-23
Front Axle .................................................................24-25
Oil Tank and Fuel Tank ...............................................26-27
Seat Panel..................................................................28-29
Engine and Pumps .....................................................30-33
Cooler and Exhaust....................................................34-35
Rear Wheel Drive .......................................................36-37
Spray Tank..................................................................38-39
Turbo Quad Agitator .................................................. 40-41
15-301 Orbitor ...........................................................42-43
16-998 Hypro®Pump ...................................................... 44
76-197 Eaton Gear Pump................................................ 45
30-102 Hydrostatic Pump...........................................46-49
30-101 Eaton Motor....................................................50-51
30-099 Auburn Power Wheel®...................................52-53
Accessories .....................................54-110
Plumbing 3182 System (Raven 440) ...........................54-55
Plumbing 3184 System (Raven 203) ............................ 56-57
Plumbing 3185/3186 (Envizio Pro II/SharpShooter) ........58-59
Plumbing 3187/3188 (Raven 440/SharpShooter) ............ 60-63
Controls 3182 System (Raven 440) ............................. 64-65
Controls 3184 System (Raven 203)..............................66-67
Controls 3185/3186 (Envizio Pro II/SharpShooter) .......... 68-69
Controls 3187/3188 (Raven 440/SharpShooter).............70-71
16-524 Motorized Control Valve .................................... 72
15-737 Strainer................................................................ 72
15-743 Manifold Ball vlave .........................................74-75
17-580 20’ Heavy Duty Boom.....................................76-79
17-580 Plumbing ............................................................. 80
17-585 Plumbing ............................................................. 81
17-585 18’ Heavy Duty Boom.....................................82-85
Triple Nozzle Assembly ................................................... 86
Star Command Capstan Nozzles .................................... 87
30-010 Electric Hose Reel .........................................88-90
30-009 Hose Reel ........................................................... 91
Hose Reel Installation.................................................92-93
Hose Reel Adjustments ................................................... 92
30-004 Foam Marker Installation..............................94-100
15-511 Foam Nozzle Sub Assembly ............................. 102
14-515 Water Meter Kit (Gallons).................................. 103
15-618 Water Meter Kit (Liters) ..................................... 103
30-006 Fresh Water Tank ......................................104-105
30-007 Chemical Cleanload System ......................106-107
15-620 Chemical Cleanload®Eductor ....................108-109
15-835 Tank Rinsing System........................................ 110
Reference ....................................... 111-112
Decal List........................................................................111
Quick Reference Replacement Parts ............................ 112
Warranty ..............................................................................

1
Introduction
INTRODUCTION
Thank you for purchasing a Smithco product.
Read this manual and all other manuals pertaining to the Spray Star 3180 carefully as they contain safety, op-
erating, assembly and maintenance instructions. Failure to do so could result in personal injury or equipment
damage.
Keep manuals in a safe place after operator and maintenance personnel have read them. Right and left sides
are from the operator’s seat, facing forward.
All Smithco machines have a Serial Number and Model Number. Both numbers are needed when ordering
parts. Refer to engine manual for placement of engine serial number.
For product and accessory information, help nding a dealer, or to register your procuct please contact us at
www.Smithco.com.
Information needed when ordering replacement parts:
1. Model Number of machine
2. Serial Number of machine
3. Name and Part Number of part
4. Quantity of parts
For easy access record your Serial and Model numbers here.
 
WARNING:
Engine exhaust and some of its constituents are
known to the State of California to cause cancer,
birth defects, and other reproductive harm.
For more information visit
www.P65Warning.ca.gov

2
Introduction
SAFE PRACTICES
1. It is your responsibility to read this manual and all publications associated with this machine.
2. Never allow anyone to operate or service the machine or its optional equipment without proper training
and instructions. Never allow minors to operate any equipment.
3. Learn the proper use of the machine, the location and purpose of all the controls and gauges before
you operate the equipment. Working with unfamiliar equipment can lead to accidents.
4. Wear all the necessary protective clothing and personal safety devises to protect your head, eyes, ears,
hands and feet. Operate the machine only in daylight or in good articial light.
5. Inspect the area where the equipment will be used. Pick up all debris you can nd before operating.
Beware of overhead obstructions and underground obstacles. Stay alert for hidden hazards.
6. Never operate equipment that is not in perfect working order or without decals, guards, shields, or other
protective devices in place.
7. Never disconnect or bypass any switch.
8. Carbon monoxide in the exhaust fumes can be fatal when inhaled, never operate a machine without
proper ventilation.
9. Fuel is highly ammable, handle with care.
10. Keep engine clean. Allow the engine to cool before storing and always remove the ignition key.
11. Disengage all drives and set park brake before starting the engine.
12. Never use your hands to search for oil leaks. Hydraulic uid under pressure can penetrate the skin and
cause serious injury.
13. This machine demands your attention. To prevent loss of control or tipping of the vehicle:
A. Use extra caution in backing up the vehicle. Ensure area is clear.
B. Do not stop or start suddenly on any slope.
C. Reduce speed on slopes and in sharp turns. Use caution when changing directions on slopes.
D. Stay alert for holes in the terrain and other hidden hazards.
14. Before leaving operator’s position:
A. Disengage all drives.
B. Set park brake.
C. Shut engine o󰀨 and remove the ignition key.
D. If engine has to run to perform any maintenance keep hands, feet, clothing and all other parts of
body away from moving parts.
15. Keep hands, feet and clothing away from moving parts. Wait for all movement to stop before you clean,
adjust or service the machine.
16. Keep the area of operation clear of all bystanders.
17. Stop engine before making repairs/adjustments or checking/adding oil to the crankcase.
18. Use parts and materials supplied by Smithco only. Do not modify any function or part.
19. Use caution when booms are down as they extend out beyond the center line of the machine.
20. The tank is a conned space, take precaution.
These machines are intended for professional maintenance on golf courses, sports turf, and any other
area maintained turf and related trails, paths and lots. No guaranty as to the suitability for any task is
expressed or implied.

3
Introduction
SPECIFICATIONS SPRAY STAR 3180
WEIGHTS AND DIMENSIONS
Length 128" (325 cm)
Width 72" (183 cm)
Height w/ ROPS 84" (213 cm)
Height w/ Booms Folded 136" (345 cm)
Wheel Base 68" (173 cm)
Weight Empty 2340 lbs (1061 kg)
Weight Full 4950 lbs (2245 kg)
SOUND LEVEL (DBA)
At ear level 88.4 dBA
At 30 ft. (9.14 m) 77 dBA
ENGINE
Make Kubota
Model# V1505
Code / Spec# 1G994-0000
Horsepower 35.5 hp (26.6 kW)
Fuel (EMISSIONS) No.1-D or No. 2-D, S500: Low Sulfur Diesel (LSD) less than 500 ppm or 0.05 wt.%
No1-D or No.2-D, S15: Ultra Low Sulfur Diesel (ULSD) less than 15 ppm or 0.0015 wt.%
Cooling System Liquid Cooled
Lubrication System Full Pressure
Alternator 40 Amp
WHEELS & TIRE Front: Two 20 x 11.00 x 10 Turf; 20 psi (1.4 bar)
Rear: Two 29 x 14.00 x 15 Multi-Trac; 30 psi (2.0 bar)
SPEED
Innitely Variable 0-10 m.p.h. (0-18 kph)
BATTERY Automotive type 24F - 12 volt
BCI Group Size 24
Cold Cranking Amps 900 minimum
Ground Terminal Polarity Negative (-)
Maximum Length 10.25" (26 cm)
Maximum Width 6.88" (17 cm)
Maximum Height 10" (25 cm)
FLUID CAPACITY
Crankcase Oil See Engine Manual
Fuel 7 gallon (26.5 liters)
Hydraulic Fluid 10 gallon (37.8 liters)
Radiator 1.06 gallons ( 4 liters)
Grade of Hydraulic Fluid SAE 10W-40 API Service SJ or higher Motor Oil
OPTIONAL EQUIPMENT
15-618 Water Meter Kit 30-009 Manual Hose Reel
17-585 18' HD Super Boom 30-010 Electric Hose Reel
17-580 20' HD Super Boom 30-004 Foam Marker
30-006 Fresh Water Tank 15-835 Tank Rinse System
30-007 Chemical Cleanload Safe Fill 15-850 Sunshade Canopy
31-004 All Weather Top 14-515 Water Meter Kit (Gal)
17-590 Lazer-Beam Auto Boom for HD Booms 30-140 Electric Wash Tank

4
Service
MAINTENANCE
Before servicing or making adjustments to machine, stop engine and remove key from igni-
tion.
Use all procedures and parts prescribed by the manufacturer's. Read the engine manual
before operation.
LUBRICATION
Use No. 2 General purpose lithium base grease and lubricate every 100 hours. The Spray Star 3180 has 7
grease ttings.
A. One on the rod end of hydraulic cylinder.
B. One on each the right and left spindles.
C. One on the center front pivot.
D. One on the idler arm.
E. One on each of the pedal relays.
ELECTRICAL CONNECTIONS
Use dielectric grease on all electrical connections.
AIR CLEANER ON ENGINE
Since the air cleaner on this engine is a dry type, never apply oil to it.
1. Open evacuator valve (see engine manual) once a week to remove large particles of dust and dirt.
2. Wipe the inside of the air cleaner with a cloth if it gets wet or dirty.
3. Avoid touching the element except when cleaning.
4. When dust adheres to the element, gently tap element on at surface.
5. When carbon or oil adheres to the element clean according to engine manual.
6. Replace the element every year or every 6 months.
7. IMPORTANT - Make sure wing bolt for the element is tight enough. If it is loose, dust and dirt may be
sucked in, wearing down the cylinder liner and piston ring, resulting in poor power output.
Do not use petroleum solvents, e.g.., kerosene, which will cause cartridge to deteriorate. Do
not use pressurized air to clean cartridge. Pressurized air can damage cartridge.
FUEL
CHECK EMISSION REGULATIONS OF YOUR AREA
With Emission control now in e󰀨ect diesel fuel specication type and sulfur content % (ppm) used must be in
compliant with all applicable emission regulations for the area in which the engine is operated.
Use of diesel fuel with sulfur content less than 0.10% (1000 ppm) is strongly recommended.
If high sulfur fuel is used, change oil and oil lters twice as often.
DO NOT USE Fuels that have sulfur content greater than 1.0% (10000 ppm).
Diesel fuels specied in EN 590 or ASTM D975 are recommended.
Since KUBOTA diesel engines of less than 56kW (75 hp) utilize EPA Tire 4 and Interim Tier 4 Standards, the
use of low sulfur fuel or ultra low sulfur fuel is mandatory for these engines, when operated in US EPA regu-
lated areas. Therefore, use No.2-D S500 or S15 diesel fuel as a alternative toe No. 2-D for ambient tempera-
tures below -10°C (14° F).

5
Service
MAINTENANCE
ENGINE OIL
With strict emission control regulations now in e󰀨ect, the CF-4
and CG-4 engine oils have been developed for use with low
sulfur fuels, for On-Highway vehicle engines. When Non-
Road engines run on high sulfur fuel, it is advisable to use a
"CF or better" classication engine oil with Total Base Num-
ber (a minimum TBN of 10 is recommended).
Check the engine oil before starting or more than 5 minutes
after stopping the engine. If oil level is low, remove oil ller
plug and add new oil to the prescribed level. Do not overll.
Engine oil should be MIL-L2104C or have properties of API Classications CD grades or higher. Change the
type of Engine oil according to the ambient temperature.
Starting Temperature Range Anticipated Before Next Oil Change
HYDRAULIC OIL
1. Use SAE 10W-40 API Service SJ or higher motor oil.
2. For proper warranty, change oil the rst 50 hours and then every 500 hours or annually, which ever is
rst.
3. Oil level should be 2-2½" (5-6.4cm) from top of the tank when uid is cold. Do not overll.
4. After changing oil, run the machine for a few minutes. Check oil level and for leaks.
5. Always use extreme caution when lling hydraulic oil tank or checking level to keep system free of con-
taminants. Check and service more frequently when operating in extremely cold, hot or dusty conditions.
6. If the natural color of the uid has become black or smells burnt, it is possible that an overheating prob-
lem exists.
7. If uid becomes milky, water contamination may be a problem.
8. If either of the above conditions happen, change oil immediately after uid is cool and nd the cause.
Take uid level readings when the system is cold.
9. In extreme temperatures you can use straight weight oil. We recommend SAE 30W API Service SG
when hot (above 90°F (33°C)) and SAE 10W API Service SJ or higher when cold (below 32°F (0°C)
ambient temperature. Use either motor oil or hydraulic oil, but do not mix.
10. Oil being added to the system must be the same as what is already in the tank. Mark the tank ll area
as to which type you put in.
TIRE PRESSURE
Caution must be used when inating a low tire to recommended pressure. Over inating can cause tires to
explode. Front tires should be 20 psi (1.4bar) and rear tires should be 30 psi (2.0bar). Improper ination will
reduce tire life considerably.

6
Service
MAINTENANCE
BATTERY
Batteries normally produce explosive gases which can cause personal injury. Do not allow ames, sparks or
any ignited object to come near the battery. When charging or working near battery, always shield your eyes
and always provide proper ventilation.
Battery cable should be disconnected before using “Fast Charge”.
Charge battery at 15 amps for 10 minutes or 7 amps for 30 minutes. Do not exceed the recommended
charging rate. If electrolyte starts boiling over, decrease charging.
Always remove grounded (-) battery clamp rst and replace it last. Avoid hazards by:
1. Filling batteries in well-ventilated areas.
2. Wear eye protection and rubber gloves.
3. Avoid breathing fumes when electrolyte is added.
4. Avoid spilling or dripping electrolyte.
Battery Electrolyte is an acidic solution and should be handled with care. If electrolyte is
splashed on any part of your body, ush all contact areas immediately with liberal amounts
of water. Get medical attention immediately.
Use of booster battery and jumper cables. Particular care should be used when connecting a
booster battery. Use proper polarity in order to prevent sparks.
TO JUMP START (NEGATIVE GROUNDED BATTERY):
1. Shield eyes.
2. Connect ends of one cable to positive (+) termi-
nals of each battery, rst (A) then (B).
3. Connect one end of other cable to negative (-)
terminal of "good" battery (C).
4. Connect other end of cable (D) to engine block
on unit being started (NOT to negative (-) termi-
nal of battery)
To prevent damage to other electrical components on
unit being started, make certain that engine is at idle
speed before disconnecting jumper cables.
WHEEL CREEP
WHEEL CREEP
"Creep" is when the engine is running and hydrostatic transmission is in neutral,
but due to inadequate alignment, wheels still move. Do the following procedure
to stop this motion.
1. Lift up and support machine so rear wheels are o󰀨 the ground and can
turn freely.
2. In the engine compartment, the hydrostatic pump is on the right side. The
shift arm (D) is on top of the pump The idler arm (B) has a bearing that
rides in the vee of the shift arm. Loosen bolt (A).
3. With engine running, move bearing (B) so it centers on the shift arm (D)
and 'wheel creep' stops.
4. Tighten all fasteners and test by using foot pedal linkage to see that
'creep' is removed.
5. Turn engine o󰀨 and lower machine.

7
Service
ADJUSTMENTS
SPRAY PUMP WITH BELT
Located to the right of the engine. The belt should have approximately 1/2" (13mm) of deection in the center
of the top strand.
SAFETY INTERLOCK SWITCH
To adjust the interlock switch on the back hydrostatic pump loosen the set screw on the front half of the
switch, with the ignition switch OFF. With a continuity tester connected across the switch, it should light with
the shift arm centered. Move the shift arm to the right or left and the light should go o󰀨. By turning the back
half of the switch clockwise it will reduce the amount of travel on the shift arm that is required for the light to
remain on. The light must be on ONLY with the shift arm centered.
MASTER BOOM SWITCH (FOOT SWITCH)
The master boom switch, located on the left oorboard is used to override the master switch on the computer
console of the spray systems. By pushing down it will turn on/o󰀨 the booms. For the 440 System the Master
Switch on the computer must be o󰀨 for the master boom control switch to work.
GROUND SPEED CONTROL (FOOT SWITCH)
The ground speed control does not work the same as an automotive type cruise. The ground speed control is
located on the center oorboard and is used to lock forward speed.
TO ENGAGE:
1. Flip rocker switch ‘On’ (green light).
2. Obtain desired speed with foot pedal.
3. Step on foot switch to lock speed.
4. Push foot switch again to disengage.
SPEED CALIBRATION NUMBERS
The speed calibration numbers for the Spray Star 3182 is 612.
SPRAY BOSS CONTROL (ORANGE)
Engages and disengages speed boss. Forward is engage and all the way back is disengage. When the lever
is engaged it sets a stop for the accelerator. The accelerator pedal must be used to maintain this speed. To
adjust speed use the knob on the end of the lever, counter clockwise increases speed and clockwise decreas-
es speed. Disengage the lever and you will have full accelerator pedal range.
BRAKE RELEASE
Run machine at half-throttle minimum, prior to operating
traction pedal. This will ensure proper brake release.
To disengage the brake, assemble t he disengage cover
with the dimple center protruding inward. This will release the
brake shaft. Re-assemble the disengage cover back to its
original way.
TAN K AGITATION
The valve to turn on and o󰀨 the tank agitation is located on the front of the
seat panel, drivers right hand side.Turn valve handle down to turn on and
turn back up to shut o󰀨.

8
Service
SERVICE CHART
Before servicing or making adjustments to the machine, stop engine, block wheels and
remove key from ignition.
Follow all procedures and ONLY use parts prescribed by the manufacturer. Read the engine
manual before maintenance.
The suggested maintenance checklist is not o󰀨ered as a replacement for the manufacturer’s engine manual
but as a supplement. You must adhere to the guidelines established by the manufacturer for warranty cover-
age. In adverse conditions such as dirt, mud or extreme temperatures, maintenance should be more frequent.
Duplicate this page for routine use

9
Service
SERVICE CHART

10
Service
STORAGE
To prevent damage from freezing, pour window washer uid into spray systems tank and
operate pump to circulate mix through gun and hose back to tank. Open boom control to
circulate through rest of spray system.
1. Clean the exterior surfaces of the engine.
2. Change the oil and lter while the engine is still warm from operation.
3. Drain coolant from the radiator. Open cock at the bottom of the radiator, and remove the pressure cap
to drain water completely. Leave the cock open. Hang a not written "No Water" on the pressure cap.
Since water freezes when temperature drops below 0°C (32° F) it is important that no water is left in the
machine.
4. Remove battery from the engine, adjust the electrolyte level, and recharge it. Store battery in a dry dark
place.
5. Store machine in a clean, dry place.
XTENDED STORAGE
1. Check for any damaged parts or missing decals. Replace as needed.
2. Drain crankcase completely and rell with recommended engine oil or equivalent.
3. Lubricate all grease points.
4. Check coolant protection and level.
5. Clean exterior surface of engine.
6. Seal all openings in engine and accessories with non-hygroscopic material. Mask o󰀨 all areas to be
used for electrical contact.
7. Tape all openings and make sure all surfaces are dry. Then spray all taped openings, all engine acces-
sories including ignition wiring, and all exterior surfaces of engine with Insulation Compound.
8. Disconnect, remove and clean battery. Check electrolyte level. Charge the battery and store in a cool
dry place (NOT directly on cement).
9. Put blocks or stands under the machine to take weight o󰀨 tires.
AFTER STORAGE
1. Check for any damaged parts or missing decals. Replace as needed.
2. Lubricate all grease points.
3. Clean exterior surface of engine.
4. Remove all tape and obstructions from exterior engine surfaces.
5. Charge and replace battery.
6. Check tire pressure.
7. Remove blocks or supports from under the machine.
8. Check engine oil level and coolant level and lubricate all grease points.
9. Fill fuel tank.
10. Check belt tension.
11. Run engine approximately 5 minutes before putting the engine under load.

11
Service
NOTES

12
Service
WIRING DIAGRAM
REF# PART# DESCRIPTION QUANTITY
1 77-223 Timer 1
30-042-06 Relay 1
2 50-359 Warning Light 3
3 10-556 Speedometer 1
4 12-017 Hour Meter 1
5 14-292 Seat Switch 1
6 13-488 Ignition Switch 1
7 32-014 Lights 2
8 15-725 Mount Panel End 1
15-727 Rocker, No Light 1
15-782 Non-Lighted Switch 1
9 15-729 Mount Panel Middle 1
15-726 Lighted Switch 1
15-732 Rocker, Green 1
10 15-729 Mount Panel Middle 1
15-726 Lighted Switch 1
15-731 Rocker, Amber 1
11 15-729 Mount Panel Middle 1
15-727 Rocker, No Light 1
15-728 Centering Switch, Momentary, On-O󰀨-On 1
12 15-725 Mount Panel End 1
15-727 Rocker, No Light 1
15-728 Centering Switch, Momentary, On-O󰀨-On 1
Color Code Chart
Bl Blue
Br Brown
Y Yellow
G Green
O Orange
R Red
B Black
P Purple
W White

13
Service
WIRING DIAGRAM
REF# PART# DESCRIPTION QUANTITY
13 77-207 Buzzer 1
14 16-998 Hypro Pump 1
15 18-372 3-Way ball Valve 1
16 33-480 Pressure Switch 1
17 33-271 Buss Bar 1
33-272 Fuse, 15 AMP 1
33-273 Fuse, 30 AMP 2
18 33-509 Cruise Foot Switch 1
19 30-107 Wire Harness Battery ground to Fuse 1
20 33-084 Magnetic Coil 1
21 48-147 Ground Battery Cable 1
22 33-216 Battery 1
23 30-106 Wire Harness Battery to Fuse 1
24 76-326 Battery Cable 1
25 30-104 Manual Hand Brake 1
26 16-883 Speed Sensor 1
27 12-003 Park Brake Toggle Switch 1
30-143 Toggle Switch Guard 1
28 31-071 Speedometer Wire 1
29 30-130 Fuel Pump 1
30 20-693 Circuit Breaker, 50amp 1
NA 30-148 Main Wire Harness 1
NA 30-149 Engine Wire Harness 1

14
Diagrams
HYDRAULIC DIAGRAM
Use dielectric grease on all electrical connections.
Letter Code Chart
C Center
I Inside
O Outside
T Top
B Bottom

15
Diagrams
HYDRAULIC DIAGRAM PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 30-156 Hydraulic Hose 1
2 30-091 Hydraulic Hose 1
3 15-301 Orbitrol 1
4 30-094 Hydraulic Hose 2
5 15-839 Hydraulic Cylinder 1
14-531 Seal Kit 1
18-171 3/8Seal Loc Adapter 2
6 30-025 Oil Tank 1
13-747 Filler Breather 1
13-586-03 Neck 1
7 8833-9 Suction Hose 1
18-222 Hose Clamp 2
8 8833-17 Suction Hose 1
18-222 Hose Clamp 2
9 30-093 Hydraulic Hose 1
10 76-197 Gear Pump 1
11 30-102 Eaton Closed Loop Pump 1
12 18-405 Run Tee 1
13 30-086 Hydraulic Hose 1
14 30-085 Hydraulic Hose 1
15 30-090 Hydraulic Hose 2
16 30-087 Hydraulic Hose 2
17 30-099 Wheel Drive 2
18 30-100 Hydraulic Release Brakes 2
19 30-101 Eaton Wheel Motors 2
20 30-089 Hydraulic Hose 4
21 30-103 Hot Oil Shuttle Manifold 1
22 18-395 Union Tee 1
23 30-088 Hydraulic Hose 1
24 60-215 Oil Filter Assembly 1
60-334 Replacement Element 1
25 8833-41 Suction Hose 1
18-222 Hose Clamp 2
26 30-105 Oil to Air Heat Exchanger 1
27 18-308 Swivel Tee 1
28 30-194 Brake Manifold w/ Relief 1
30-104-01 Cartridge Valve 1
30-104-02 Coil 1
29 8917-15.5 Suction Hose 1
18-040 Hose Clamp 2
30 8833-24 Suction Hose 1
18-222 Hose Clamp 2

16
Parts
BODY & FRAME DRAWING

Parts
17
BODY & FRAME PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 30-110 Accessory Mount Bracket 1
HB-516-18-175 Bolt
5/16 - 18 x 13/44
HW-516 Washer
5/16 4
HNFL-516-18 Flange Lock Nut 5/16 - 18 4
2 17-615 Boom Carrier 2
HB-12-13-150 Bolt,
1/2- 13 x 11/24
HNFL-12-13 Flange Lock Nut, 1/2- 13 4
3 16-557 Square Cap 2
4 30-095 318 Gallon Tank (Fiberglass) 1
25-372 Decal, Smithco 4" Star 1
30-016 Decal, Spray Star 3180 2
5 16-953 16" Hinged Lid Well 1
16-953-01 Gasket for Lid 1
16-169 Strainer Basket 1
6 14-365 Air Gap Filler 1
7 31-063 Roll Bar 1
8 30-308 Engine Cover (Fiberglass) 1
9 27-055 Flush Hinge 2
HSM 10-32-100 Machine Screw #10-32-100 12
HNFL-10-32 Flange Whiz Lock Nut # 10 - 32 12
10 14-270 Seat 2
14-292 Seat Switch 2
14-800 Seat Rail Set 2
HSP-1260-340-250 Seat Spacer 8
11 76-198-03 Seat Belt 2
12 13-718 15" Steering Wheel 1
13-726 Center Cap 1
27-077 Decal, Smithco Round 1
13 32-014 Headlight 2
14 31-044 Nose Cone (Fiberglass) 1
50-400 Grommet 1
15 30-250 Main Frame 1
16 43-124 Turf Tread Tire and Wheel 2
43-123-01 Tire 2
43-058-01 Wheel 2
HNL-12-20 Lug Nut, 1/2- 20 14
17 76-443 Handle 3
18 31-045 Seat (Fiberglass) 1
19 30-262 12 Gallon Fuel Tank 1
20 30-286 Fuel Cap 1
21 30-048 Tire and Wheel(assembled) 2
30-048-01 Tire 2
30-048-02 Wheel 2
HNL-12-20 Lug Nut, 1/2- 20 14
22 30-099 Wheel Drive 2

18
Parts
NOSE CONE DRAWING
