FORTY6 Slim-Line Built-In
DIRECTVENT LOG SET KIT
PART: LGS46BI
INSTALLATION MANUAL
ONLY FOR USE ON SÓLAS MODEL: 46NBICZ
WARNING
This log set kit shall be installed by a qualified service agency in
accordance with the manufacturer’s instructions and all applicable
codes and requirements of the Authority Having Jurisdiction. If
the information in these instructions is not followed exactly, a fire,
explosion or production of carbon monoxide may result causing
property damage, personal injury or loss of life. The qualified
service agency is responsible for the proper installation of this kit.
The installation is not proper and complete until the operation of the
converted appliance is checked as specified in the manufacturer’s
instructions supplied with the kit.
NOT FOR USE WITH VENT-FREE OR OUTDOOR FIREPLACES
SÓLAS BIRCH LOG SET KIT
INSTALLER: Leave this manual with appliance | CONSUMER: Retain this manual for future reference

SÓLAS CONTEMPORARY FIRE
2
KIT CONTENTS:
 4 CERAMIC LOGS  1 lb. 3oz. LAVA ROCK
 5 CERAMIC ROCKS
LOG SET INSTALLATION
SÓLAS BIRCH LOG SET

solasfires.com 3
LOG SET INSTALLATION
STEP 1
Install the 3-rock cluster on the 2 pins located just right
of the pilot. (Figure 1)
STEP 2
Install the center birch log by placing the left side of the
log on the locating pin left of the pilot. The right side of
the log will rest on top of the 3-rock cluster, rotate the
log so it gently touches the rear enamel panel of the
firebox. (Figure 2)
STEP 3
Install the second, smaller, 3-rock cluster on the
pin located right of 3-rock cluster installed during
step #1. Once the 3-rock cluster is sitting on the pin,
rotate clockwise until the lower left rock touches the
rear edge of the burner. (Figure 3)
STEP 4
Install the right-hand birch log by placing the left side
of the log on the 3-rock cluster installed in previous
step. A groove on the underside of the log which
engages with the leading edge of the burner. The right
side of the log will rest against the right enamel panel
within the firebox. (Figure 4)
INTALLATION OF BIRCH LOG SET
Figure 1
Figure 2
Figure 3
Figure 4

SÓLAS CONTEMPORARY FIRE
4
LOG SET INSTALLATION
STEP 5
Install the single rock on the 2 pins located on
the far left of the burner top. The log-locating
tab on top of the rock should be toward the
back of the burner. (Figure 5)
STEP 6
Between the rock installed during Step 5 and
the center birch log are 4 pins located in close
proximity to each other. Place the first of the 2
individual rocks on the left set of pins. Look for
a gap between the front of the rock and the
leading edge of the burner, if the rock
overhangs the front of the burner the incorrect
rock has been used. (Figure 6)
STEP 7
Place the second of the 2 individual rocks on the
right set of pins as shown in Figure 7. The
second rock should overhang the back of the
burner. The second rock will overhang the rear
of the burner, nearly contacting the rear enamel
panel.
STEP 8
Between the rock installed during step #4 and
the pair of rocks installed during steps #5 and
#6, are 2 pins. The “Y” shaped log has 2 holes
on its underside that correspond with these 2
pins. The right side of the log will rest on the pair
of logs as shown in Figure 8.
Figure 5
Figure 6
Figure 7
Figure 8

solasfires.com 5
LOG SET INSTALLATION
STEP 9
Evenly distribute the included 1lb and 3oz of Lava
Rock on the exposed burner top. Cover the burner top
completely but do not compress or “pack” the lava rock
tightly. Pay special attention to tight and hard to reach
areas when placing the media on the burner. It is ok if
small amounts of lava rock are lost over the edge of the
burner. (Figures 9 & 10)
STEP 10
Using the log-locating tab on the single rock on the left
side of the burner, rest the small birch log on the rock
and “Y” shaped log while aligning it with the leading
edge of the burner as shown in Figure 11.
Installation of the Birch Log Set is now complete, refer to the FORTY6 Installation and
Operation Manual for instructions on final assembly and lighting of the appliance.
Figure 9
Figure 10
Figure 11
