ONE6
CORNER KIT
PART: CK161
INSTALLATION MANUAL
ONLY FOR USE ON SÓLAS MODELS: SL16N, SL16P
NOTE: A 12" straight section of Direct Vent Pipe will be required to
complete the corner installation.
SÓLAS ONE6 CORNER KIT
INSTALLER: Leave this manual with appliance | CONSUMER: Retain this manual for future reference
When installing the SÓLAS-ONE6 Wall-Mount with Corner Install Kit, you will need to refer
to both this manual and the Installation & Operation’s Manual supplied with the fireplace.

SÓLAS CONTEMPORARY FIRE
2
1. Remove the 3 phillips screws from the top and
bottom corner pieces as shown in photo.
2. Remove the diagonal mounting plate as shown
in Figure 2. Lift up on the diagonal mounting
plate to disengage.
3. Once the location is determined for the corner
installation, use the wall panel as a template and
mark the location of the 9 mounting holes. Decide
which wall the vent and gas inlet will penetrate
and mark the locations of
the vent outlet hole and
gas inlet hole. Cut the
vent outlet hole and gas
inlet hole (refer to page
18 of the SÓLAS ONE6
Installation & Operation’s
Manual). Pre-drill the 9
lag bolt holes with a ⁄”
diameter drill. Be sure that
there is solid wood at each
mounting location. If not,
the wall will need to be
reconstructed to provide the support.
4. Attach the inner and outer telescoping vent pass
through heat-shields
to the wall plate as
shown in Figure 3
& 4. The vent pass
through heat-shields
are to be installed
where the vent
passes through the
first adjacent wall
to the left or right of
the corner install kit
CORNER KIT INSTALLATION
SÓLAS ONE6 CORNER KIT
KIT CONTENTS:
 1 Assembled Corner Kit
 1 45˚ Vent Starter Pipe
 1 Bag of Hardware
Remove (3) Screws
Top & Bottom
Figure 2
Figure 3
Figure 4

solasfires.com 3
CORNER KIT INSTALLATION
5. Attach the wall plate to the wall with the pass through
heat-shields in place, and fasten to the wall using the
9 lag bolts provided. See Figure 5.
Note: The four longer 2 ⁄" lag bolts are to be used on
the diagonal mounting holes, and the five shorter lag
bolts are for use on the flat mounting holes.
6. Having secured the wall plate to the wall, fit the
diagonal mounting plate as shown in Figure 6. Please
ensure that all (4) mounting pins are fully engaged in
the (4) keyway slots.
7. Attach the mounting plate (that came with your fireplace)
to the corner wall mount unit and fasten in place with (4)
lock nuts and washers. See Figure 7.
8. Fit the custom 45˚ vent starter pipe and gasket supplied
with the Corner Kit to the SÓLAS ONE6 Fireplace
BEFORE mounting the fireplace to the wall mount.
Mount the unit on the wall mount and complete the
installation as described in the Installation & Operation’s
Manual supplied with the fireplace.
Once the installation is complete, fit the top and bottom
corner cover plates to the wall mounting unit using the
screws provided (that were removed in Step 1).
Figure 8
Figure 9
Figure 5
Use (4) Longer
Lag Bolts here
45° Vent Starter Pipe
Gasket
Use
Shorter
Lag Bolts
here
Figure 6
Figure 7

THANK YOU FOR CHOOSING
RECORD YOUR PRODUCT INFORMATION
Model #: ________________________ Serial Number: ______________________________
Dte Purchsed: __________________ Date Installed: _______________________________
