Solplanet ASW S-G2 Series User manual

UM0023_ASW1000-6000-S-G2_EN_V01_1122 1
Solplanst inverter Table of Contents
1 Notes on this Manual...........................................................................................................................................4
1.1 General Notes ..............................................................................................................................................4
1.2 Area of validity.............................................................................................................................................4
1.3 Target group.................................................................................................................................................4
1.4 Symbols used in this manual ......................................................................................................................5
2 Safety ....................................................................................................................................................................6
2.1 Intended use ................................................................................................................................................6
2.2 Important safety information .....................................................................................................................6
2.3 Symbols on the label ...................................................................................................................................8
3 Unpacking .............................................................................................................................................................9
3.1 Scope of delivery .........................................................................................................................................9
4 Mounting ............................................................................................................................................................11
4.1 Ambient conditions ...................................................................................................................................11
4.2 Selecting the mounting location...............................................................................................................12
4.3 Mounting the inverter with the wall bracket ..........................................................................................14
5 Electrical Connection .........................................................................................................................................16
5.1 Safety.......................................................................................................................................................16
5.2 System layout of units without integrated DC switch ............................................................................17
5.3 Overview of the connection area .............................................................................................................18
5.4 Second protective grounding connection................................................................................................18
5.5 AC connection............................................................................................................................................19
5.5.1 Conditions for the AC connection ...................................................................................................19
5.5.2 Grid connection ................................................................................................................................20

2 UM0023_ASW1000-6000-S-G2_EN_V01_1122
5.5.3 Residual current protection.............................................................................................................23
5.5.4 Overvoltage category .......................................................................................................................23
5.5.5 Grounding conductor monitoring ...................................................................................................24
5.5.6 Rating of miniature circuit-breaker.................................................................................................24
5.6 DC Connection ...........................................................................................................................................24
5.6.1 Requirements for the DC Connection .............................................................................................24
5.6.2 Assembling the DC connectors........................................................................................................25
5.6.3 Disassembling the DC connectors ...................................................................................................27
5.6.4 Connecting the PV array ..................................................................................................................28
5.7 Communication equipment connection ..................................................................................................29
5.7.1 RS485 cable connection ...................................................................................................................30
5.7.2 Smart meter cable connection ........................................................................................................31
5.7.3 WiFi/4G stick connection .................................................................................................................32
6 Communication..................................................................................................................................................32
6.1 System monitoring via WLAN/4G.............................................................................................................33
6.2 Active power control with Smart meter ..................................................................................................34
6.3 Inverter demand response modes (DRED) ..............................................................................................34
6.4 Communication with third-party devices ................................................................................................36
7 Commissioning ...................................................................................................................................................37
7.1 Electrical checks.........................................................................................................................................37
7.2 Mechanical checks.....................................................................................................................................38
7.3 Start-Up ......................................................................................................................................................38
8 Operation............................................................................................................................................................39
8.1 Overview of the panel ...............................................................................................................................39
8.1.1 LEDs ...................................................................................................................................................40
9 Disconnecting the Inverter from Voltage Sources...........................................................................................41
10 Technical Data..................................................................................................................................................42

UM0023_ASW1000-6000-S-G2_EN_V01_1122 3
10.1 DC input data ...........................................................................................................................................42
10.2 AC output data.........................................................................................................................................45
10.3 General data ............................................................................................................................................47
10.4 Safety regulations....................................................................................................................................48
10.5 Tools and torque .....................................................................................................................................50
11 Troubleshooting...............................................................................................................................................51
12 Maintenance ....................................................................................................................................................52
12.1 Cleaning the contacts of the DC switch .................................................................................................53
12.2 Cleaning the heat sink .............................................................................................................................53
13 Recycling and disposal.....................................................................................................................................53
14 EU Declaration of Conformity .........................................................................................................................53
15 Warranty...........................................................................................................................................................54
16 Contact .............................................................................................................................................................55

4 UM0023_ASW1000-6000-S-G2_EN_V01_1122
1 Notes on this Manual
1.1 General Notes
Solplanet inverter is a transformerless solar inverter with two independent MPP trackers. It converts the
direct current (DC) from a photovoltaic (PV) array to grid-compliant alternating current (AC) and feeds it
into the grid.
1.2 Area of validity
This manual describes the mounting, installation, commissioning and maintenance of the following
inverters:
ASW1000-S-G2
ASW1500-S-G2
ASW2000-S-G2
ASW2500-S-G2
ASW3000-S-G2
ASW3680-S-G2
ASW4000-S-G2
ASW5000-S-G2
ASW6000-S-G2
Observe all documentation that accompanies the inverter. Keep them in a convenient place and available
at all times.
1.3 Target group
This manual is for qualified electricians only, who must perform the tasks exactly as described.
All persons installing inverters must be trained and experienced in general safety which must be observed
when working on electrical equipment. Installation personnel should also be familiar with local
requirements, rules and regulations.
Qualified persons must have the following skills:
•Knowledge of how an inverter works and is operated
•Training in how to deal with the dangers and risks associated with installing, repairing and using
electrical devices and installations
•Training in the installation and commissioning of electrical devices

UM0023_ASW1000-6000-S-G2_EN_V01_1122 5
•Knowledge of all applicable laws, standards and directives
•Knowledge of and compliance with this document and all safety information
1.4 Symbols used in this manual
Safety instructions will be highlighted with the following symbols:
DANGER indicates a hazardous situation which, if not be avoided, will result in death or serious
injury.
CAUTION indicates a hazardous situation which, if not be avoided, can result in minor or moderate
injury.
NOTICE indicates a situation which, if not be avoided, can result in property damage.
INFORMATION that is important for a specific topic or goal, but is not safety-relevant.
WARNING indicates a hazardous situation which, if not be avoided, can result in death or serious
injury.

6 UM0023_ASW1000-6000-S-G2_EN_V01_1122
2 Safety
2.1 Intended use
1. The inverter converts the direct current from PV array into grid-compliant alternating current.
2. The inverter is suitable for indoor and outdoor use.
3. The inverter must only be operated with PV arrays (PV modules and cabling) of protection class II, in
accordance with IEC 61730, application class A. Do not connect any sources of energy other than PV
modules to the inverter.
4. PV modules with a high capacitance to ground must only be used if their coupling capacitance is less
than 1.0μF.
5. When the PV modules are exposed to sunlight, a DC voltage is supplied to the inverter.
6. When designing the PV system, ensure that the values comply with the permitted operating range of
all components at all times.
7. The product must only be used in countries for which it is approved or released by AISWEI and the
grid operator.
8. Use this product only in accordance with the information provided in this documentation and with
the locally applicable standards and directives. Any other application may cause personal injury or
property damage.
9. The type label must remain permanently attached to the product.
2.2 Important safety information
Danger to life due to electric shock when live components or cables are touched
•All work on the inverter must only be carried out by qualified personnel who have read and fully
understood all safety information contained in this manual.
•Do not open the product.
•Children must be supervised to ensure that they do not play with this device.

UM0023_ASW1000-6000-S-G2_EN_V01_1122 7
Danger to life due to high voltages of the PV array
When exposed to sunlight, the PV array generates dangerous DC voltage which is present in the DC
conductors and the live components of the inverter. Touching the DC conductors or the live
components can lead to lethal electric shocks. If you disconnect the DC connectors from the inverter
under load, an electric arc may occur leading to electric shock and burns.
•Do not touch non-insulated cable ends.
•Do not touch the DC conductors.
•Do not touch any live components of the inverter.
•Have the inverter mounted, installed and commissioned only by qualified persons with the
appropriate skills.
•If an error occurs, have it rectified by qualified persons only.
•Prior to performing any work on the inverter, disconnect it from all voltage sources as described
in this document(see Section 9 "Disconnecting the Inverter from Voltage Sources").
Risk of injury due to electric shock
Touching an ungrounded PV module or array frame can cause a lethal electric shock.
•connect and ground the PV modules, array frame and electrically conductive surfaces so that
there is continuous conduction.
Risk of burns due to hot enclosure parts
Some parts of the enclosure can get hot during operation.
•During operation, do not touch any parts other than the enclosure lid of the inverter.

8 UM0023_ASW1000-6000-S-G2_EN_V01_1122
2.3 Symbols on the label
Symbol
Explanation
Beware of a danger zone
This symbol indicates that the product mus be additionally grounded if additional
grounding or equipotential bonding is required at the installation site.
Beware of high voltage and operating current
The inverter operates at high voltage and current. Work on the inverter must only be
carried out by skilled and authorized electricians.
Beware of hot surfaces
The inverter can get hot during operation. Avoid contact during operation.
WEEE designation
Do not dispose of the product together with the household waste but in accordance
with the disposal regulations for electronic waste applicable at the installation site.
CE marking
The product complies with the requirements of the applicable EU directives.
Certification mark
The product has been tested by TUV and got the quality certification mark.
RCM Mark
The product complies with the requirements of the applicable Australian standards.
Capacitors discharge
Before opening the covers, the inverter must be disconnected from the grid and PV
Damage to the inverter due to electrostatic discharge
Internal components of the inverter can be irreparably damaged by electrostatic discharge.
•Ground yourself before touching any component.

UM0023_ASW1000-6000-S-G2_EN_V01_1122 9
array. Wait at least 5 minutes to allow the energy storage capacitors to fully discharge.
Observe the documentation
Observe all documentation supplied with the product
3 Unpacking
3.1 Scope of delivery

10 UM0023_ASW1000-6000-S-G2_EN_V01_1122
Object
Description
Quantity
A
Inverter
1 piece
B
Wall mounting bracket
1 piece
C
Wall anchors and hexagon bolts (2×)
M5 screw (2×)
1 set
D
DC connector
2 pairs
E
AC Plug connector
1 piece
F
WiFi stick
1 piece
G
RS 485 COM plug（Optional）
2 pieces
H
Documentation
1 set
I
Smart meter terminal（Optional）
1 piece
A
B
C
D
E
F
G
H
I
Carefully check all components. If anything is missing, contact your dealer.
3.2 Checking for transport damage
Thoroughly inspect the packaging upon delivery. If you detect any damage to the packaging which
indicates the inverter may have been damaged, informthe responsible shipping company immediately. We
will be glad to assist you if required.

UM0023_ASW1000-6000-S-G2_EN_V01_1122 11
4 Mounting
4.1 Ambient conditions
1. Be sure the inverter is installed out of the reach of children.
2. Mount the inverter in areas where it cannot be touched inadvertently.
3. Ensure good access to the inverter for installation and possible service.
4. Make sure that heat can dissipate, observe the following minimum clearance to walls, other
inverters, or objects:
5. The ambient temperature is recommended below 40°C to ensure optimal operation.
6. Recommend to mount the inverter under the shaded site of the building or mount an awning above
the inverter.
7. Avoid exposing the inverter to direct sunlight, rain and snow to ensure optimal operation and extend
service life.
Direction
Min. clearance（mm）
above
500
below
500
sides
300

12 UM0023_ASW1000-6000-S-G2_EN_V01_1122
8. The mounting method, location and surface must be suitable for the inverter's weight and
dimensions.
9. If mounted in a residential area, we recommend mounting the inverter on a solid surface.
Plasterboard and similar materials are not recommended due to audible vibrations when in use.
10. Do not put any objects on the inverter.
11. Do not cover the inverter.
4.2 Selecting the mounting location
Danger to life due to fire or explosion
•Do not mount the inverter on flammable construction materials.
•Do not mount the inverter in areas where flammable materials are stored.
•Do not mount the inverter in areas where there is a risk of explosion.

UM0023_ASW1000-6000-S-G2_EN_V01_1122 13
1. Mount the inverter vertically or tilted backward by a maximum of 15°.
2. Never mount the inverter tilted forward or sideways.
3. Never mount the inverter horizontally.
4. Mount the inverter at eye level to make it easy to operate and to read the display.
5. The electrical connection area must point downwards.

14 UM0023_ASW1000-6000-S-G2_EN_V01_1122
4.3 Mounting the inverter with the wall bracket
Mounting procedures:
1. Use the wall bracket as a drilling template and mark the positions of the drill holes. Drill 2 holes with a
10 mm drill. The holes must be about 70 mm deep. Keep the drill vertical to the wall, and hold the drill
steady to avoid tilted holes.
2. After drilling holes in the wall, place three screw anchors into the holes, then attach the wall mounting
bracket to the wall using the self-tapping screws delivered with the inverter.
Risk of injury due to the weight of the inverter
••When mounting, be careful that the inverter weighs approx.:18.5kg.
Risk of injury due to the inverter falls down
••Before inserting the wall anchors, measure the depth and distance of the holes.
••If the measured values do not meet the hole requirements, redrill holes.

UM0023_ASW1000-6000-S-G2_EN_V01_1122 15
3. Position and hang the inverter onto the wall bracket ensuring the two studs located on the outer ribs of
the inverter are slotted into the respective slots in the wall bracket.
4. Check both sides of the heat sink to ensure that it is securely in place. insert one screw M5x12 each into
the lower screw hole on both sides of the inverter anchorage bracket respectively and tighten them.
If a second protective conductor is required in installation site, ground the inverter and secure it so that it
cannot drop from the housing (see section
5.4 “Second protective grounding connection”).
Dismante the inverter in reverse order.

16 UM0023_ASW1000-6000-S-G2_EN_V01_1122
5 Electrical Connection
5.1 Safety
Danger to life due to high voltages of the PV array
When exposed to sunlight, the PV array generates dangerous DC voltage which is present in the DC
conductors and the live components of the inverter. Touching the DC conductors or the live
components can lead to lethal electric shocks. If you disconnect the DC connectors from the inverter
under load, an electric arc may occur leading to electric shock and burns.
•Do not touch non-insulated cable ends.
•Do not touch the DC conductors.
•Do not touch any live components of the inverter.
•Have the inverter mounted, installed and commissioned only by qualified persons with the
appropriate skills.
•If an error occurs, have it rectified by qualified persons only.
•Prior to performing any work on the inverter, disconnect it from all voltage sources as
described in this document(see Section 9 "Disconnecting the Inverter from Voltage Sources").
Risk of injury due to electric shock
•The inverter must be installed only by trained and authorized electricians.
•All electrical installations must be done in accordance with the National Wiring Rules
standards and all locally applicable standards and directives.

UM0023_ASW1000-6000-S-G2_EN_V01_1122 17
5.2 System layout of units without integrated DC switch
Local standards or codes may require that PV systems are fitted with an external DC switch on the DC side.
The DC switch must be able to safely disconnect the open-circuit voltage of the PV array plus a safety
reserve of 20%.
Install a DC switch to each PV string to isolate the DC side of the inverter. We recommend the following
electrical connection:
DC BOX
(optional) AC BOX
DC INPUT AC OUTPUT
To Grid
TO grounding electrode
+
-
+
+
-
-
PE
L N PE
INVERTER
+
-
Second
grounding
+ -
+-
LPE N
Damage to the inverter due to electrostatic discharge
Touching electronic components can cause damage to or destroy the inverter through electrostatic
discharge.
•Ground yourself before touching any component.

18 UM0023_ASW1000-6000-S-G2_EN_V01_1122
5.3 Overview of the connection area
Object
Description
A
DC SWITCH: switch on or off for PV-load.
B
DC input: plug-in connector to connect the strings.
C
COM: Network port with protective cap.
D
Connector for meter.
E
WiFi: transmit and Wi-Fi signal.
F
Connection point for an additional grounding.
G
AC OUTPUT: plug-in connector, connect the grid.
5.4 Second protective grounding connection
In case of operation on a Delta-IT Grid type, in order to ensure safety compliance in accordance with
IEC 62109, the following step should be taken:
The second protective earth/ground conductor, with a diameter of at least 10 mm2and be made from
copper , should be connected to the designated earth point on the inverter.

UM0023_ASW1000-6000-S-G2_EN_V01_1122 19
Procedure:
1. Insert the grounding conductor into the suitable terminal lug and crimp the contact.
2. Align the terminal lug with the grounding conductor on the screw.
3. Tighten it firmly into the housing (screwdriver type: PH2, torque: 2.5 Nm).
Information on grounding components:
Object
Description
M5 screw
Screwdriver type: PH2, torque: 2.5Nm
Bootlace ferrule
Customer provided, type: M5
Grounding cable
Copper conductor cross-section: 6-16mm2
5.5 AC connection
5.5.1 Conditions for the AC connection
Cable Requirements
Danger to life due to high voltages in the inverter
•Before establishing the electrical connection, ensure that the miniature circuit-breaker is
switched off and cannot be reactivated.
