SOLTEK NF4-754RL User manual

4
Contents Contents
Contents
Chapter 1 Specification ............................................. 7
1-1 NF4-754RL Mainboard Layout..............................................8
1-2 Mainboard Specification Table ..............................................9
1-3 Chipset System Block iagram........................................... 10
1-4 Mainboard Specifications and Features .............................11
1-4.1 CPU Socket ................................................................................... 11
1-4.2 System Chipset ............................................................................. 11
1-4.3 Memory ......................................................................................... 11
1-4.4 BIOS ............................................................................................... 11
1-4.5 PCI Express Interface................................................................. 12
1-4.6 AC’97 Audio Codec on board .................................................... 12
1-4.7 Advanced System Power Management .................................... 12
1-4.8 SATA RAI Interface ................................................................. 12
1-4.9 Multi-I/O Functions .................................................................... 13
1-4.10 10/100Mb RTL8201CL PHYceiver on board ....................... 13
1-4.11 Hardware Monitor integrated ................................................. 13
1-4.12 Form Factor................................................................................ 13
Chapter 2 Hardware Setup ..................................... 14
2-1 CPU Installation with Socket 754 ....................................... 15
2-2 Memory Installation ............................................................. 16
2-3 PCI Express Slot Installation .............................................. 16
2-4 I E Connector Installation ................................................. 17
2-5 SATA / RAI Connectors..................................................... 18
2-6 Floppy rive Installation ..................................................... 19
2-7 ATX Power Supply Installation .......................................... 20
2-8 Jumper Setting ....................................................................... 21
2-8.0 How to tackle the Jumpers: ....................................................... 22
2-8.1 JBAT1: Clear CMOS .................................................................. 22
2-8.2 JKB1 & J1: Keyboard/Mouse Wake-up .................................. 23
2-9 Other Connectors Configuration........................................ 24
2-9.1 On-board FAN Connectors ........................................................ 24
2-9.2 USB Ports and USB Pin-headers .............................................. 25

5
Contents Contents
2-9.3. Back Panel Connectors.............................................................. 26
2-9.4 PS/2 Mouse , PS/2 Keyboard and SP IF-out port ................ 26
2-9.5 RJ45 Connector ........................................................................... 27
2-9.6 C -ROM Audio Connectors (C _In)...................................... 27
2-9.7 IMM Powered-on Warning LE and Thermal etector ..28
2-9.8 JAU 1: External Audio Connector ......................................... 28
2-9.9 Complex Pin-header (Front Panel Connectors)..................... 29
Chapter 3 Software Setup ....................................... 30
3-1 To Open up the Support C ................................................ 31
3-2 To Install irectX9 ................................................................ 32
3-3 To Install “nVI IA nForce4 All-in-1 river” .................. 33
3-4 To Verify 8-channel Audio Configuration ......................... 34
3-5 To Install Hardware Monitor Utility.................................. 35
3-5.1 Installation ................................................................................... 35
3-5.2 Verification .................................................................................. 36
3-6 To Install USB 2.0 river for Windows 2000 or XP ........ 37
3-7 RAI river Installation ..................................................... 37
Chapter 4 BIOS Setup............................................. 38
4-1 About BIOS Setup ................................................................. 39
4-2 To Run BIOS Setup ............................................................... 39
4-3 About CMOS .......................................................................... 39
4-4 The POST ( Power On Self Test ) ....................................... 39
4-5 To Update BIOS ..................................................................... 40
4-6 BIOS SETUP --- CMOS Setup Utility................................ 43
4-6.1 CMOS Setup Utility .................................................................... 43
4-6.2 Standard CMOS Setup ............................................................... 45
4-6.3 Advanced BIOS Features ........................................................... 48
4-6.4 Advanced Chipset Features ....................................................... 51
4-6.5 Integrated Peripherals................................................................ 53
4-6.6 Power Management Setup ......................................................... 58
4-6.7 PnP / PCI Configuration ............................................................ 61
4-6.8 Smart oc Anti-Burn Shield....................................................... 63
4-6.9 Frequency/Voltage Control ........................................................ 64
4-6.10 Load Optimized efaults ......................................................... 65
4-6.11 Set Supervisor / User Password .............................................. 66
4-6.12 Save & Exit Setup...................................................................... 67
4-6.13 Exit Without Saving .................................................................. 67

6
Contents Contents
Chapter 5 nVI IA RAI Setup ............................. 69
5-0 About isk Array................................................................... 70
5-0-1 isk Array Interpretation.......................................................... 70
5-0-2 isk Array Member .................................................................... 70
5-0-3 isk Array Types Supported by nForce4-4X (CK804)......... 70
5-1. Set up I E RAI H s and SATA RAI H s ........... 71
5-2. Enable I E SATA function in System BIOS ................... 72
5-3. Enter the NVRAI BIOS .................................................... 73
5-4. Configure the RAI Setup.................................................. 74
5-5. Finish the RAI Setup ........................................................ 75
5-6 Install Win 2K/XP and nForce4-4X RAI river ........... 77

7
SL-NF4-754RL Chapter 1 Specification
Topics included in this chapter are:
1-1 Mainboard Layout
1-2 Specification Table
1-3 Chipset System Block Diagram
1-4 Mainboard Specifications and Features
Introduction
Chapter 1 Specification
** If any difference is found between this manual and the Main-
board you are using, please look up the ERRATA/U DATE Slip
enclosed inside for the correction or updated information, or
else contact the Mainboard Dealer or visit our Web Site for the
latest manual update.
This mainboard features an integration of the powerful processors
AMD Athlon 64 754 and the system chipset nVidia nForce4 K804,
with which the whole system performance supports HyperTransport Bus
up to 800MHz.
nForce4 K804 supports on-board AMD processor to provides the
P I Express interface up to x16 for various P I Express cards (including
the P I Express-x16 Graphics card).
In addition, nForce4 K804 also supports the LP Super I/O, P I
interface (including 8-channel A ’97 Audio interface, and LAN interface),
USB 2.0 interface, ATA 133/100/66 data transfer rate, and Serial ATA /
RAID interface. This chapter is to introduce to users every advanced
function of this high performance integration.

8
SL-NF4-754RL Chapter 1 Specification
1-1 NF4-754RL Mainboard Layout
S/PDIF
Out
+12V Power
PW1
FAN3
ATX1
ATX Power onnector
USB5
1
RJ45
PS/2 Keyboard
OM1
USB Port
USB Port
Line in
(on top)
Line Out / Front Speaker Out
Side Speaker Out
Line In
(on top)
enter / Subwoofer Out
Rear
(on top)
Speaker
Mic In
83627HF
Winbond
BIOS
Li
Battery
IDE2
P I1
DDR 400/333MHz
FD1
P IE1 (P I Express-x1)
P IX1 (P I Express -x16)
NJ1
SATA4
JBAT1
1
DIMM2
AL
850
1
JAUD1
DIMM1
Socket 754
IDE1
SATA1
SATA3
SATA2
USB4
1
USB3
1
P I2
AL 850
P IE2 (P I Express-x1)
P IE3 (P I Express-x1)
1
HD IR PWR
SPK RST
PLED
FAN2
FAN1
PS/2
Mouse
USB Port
USB Port
JKB1
1
LPT1
J1
1
nVidia
nForce 4
K804
RTL
8201 L
PHY
RT2
LED1
onnector
D-IN
1

9
SL-NF4-754RL Chapter 1 Specification
1-2 Mainboard Specification Table
NF4-754RL Specifications and Features
P I Express-x16
Supported by Athlon 64 PU for DDR 400/333
SDRAM, up to 2GB in 2 DIMM slots
Winbond W83627HF
1 P I Express-x16 slot; 3 P I Express-x1 slots
A ’97 Audio 2.3 compliant, 8-channel audio;
1xS/PDIF-out;
2 ATA 133/100/66 IDE onnectors
2 P I Master slots on board
10 USB V2.0, 1 FDD port, 1 OM port, 1 LPT,1
IrDA, 1 PS/2 K/B, 1 PS/2 Mouse, 1 SPDIF-out
PS/2 Keyboard/ Mouse Wake up;
Not integrated on board
PU
System
hipset
Graphics
Interface
Memory
I/O hip
P I Express
Audio
IDE Interface
VGA
P I Slots
I/O onnectors
Other ommon
Feature
Serial ATA/RAID
Interface
RT8201 L PHY supporting 10/100Mb LANNetwork
4SATA / SATA RAID connectors supported by
nForce4 K804
Socket 754 for AMD Athlon 64 PUs
nVidia nForce4 K804, supporting up to
800MHz Hyper Transport (200MHz x 4)
Suspend to RAM mode (STR) supported;

10
SL-NF4-754RL Chapter 1 Specification
1-3 Chipset System Block Diagram
pçÅâÉí=TRQ=H=åsfaf^=åcçêÅÉQ=`hUMQ=aá~Öê~ã
==================çå=kcQJTRQoi
Socket 754
AMD Athlon64
System
Memory
DDR 400/333
nVIDIA
nForce4-4X
(CK804)
1P IE-x16
CI Express
ATA 133/100/66
4 IDE
Devices
4 SATA RAID
ports
SATA/RAID
USB Bus V2.0
10 USB
Ports
CI Bus
RTL8201CL HY
8-channel
Audio output
L C Super I/O
AL 850
2 P I Slots
Keyboard
Mouse
Serial / IR
Parallel
Floppy Disk
BIOS
Controller
RJ45 10/100base-T LAN
Hyper Transport 800MHz
SPDIF-out port
Graphics
3P IE-x1

11
SL-NF4-754RL Chapter 1 Specification
1-4 Mainboard Specifications and Features
1-4.1 C U Socket
PU Socket 754 on board, supporting AMD Athlon 64 processors, imple-
menting up to 800MHz Hyper Transport Speed (System Bus) designed
to be capable of operating up to 2000MT/s with a resulting bandwidth
of up to 8 Gbytes/s and integrated Memory ontroller supporting DDR
400/333MHz SDRAM.
1-4.2 System Chipset
Single hip nForce4-4X ( K804):
• Supporting 800MHz Hyper Transport Bus
• Supporting P I Express up to x16 interface for P I Express device
cards ( including Graphics card)
• Supporting LP Super I/O, P I interface (including 8-channel Audio
interface, and LAN interface), ATA133 interface, USB V2.0 interface,
as well as SATA/SATA RAID interface
1-4.3 Memory
2DDR DIMM 184-pin slots on board for non-E DDR 400/333
SDRAMs:
• Installation of mixed volumes yet same type of DDR SDRAM mod-
ules supported .
1-4.4 BIOS
Flash Memory for easy upgrade, and supporting various hardware con-
figuration during booting system (See hapter 4 BIOS Setup):
• Standard MOS Features (Times, Date, Hard Disk Type etc.)
• Advanced BIOS Features (Virus Protection, Boot Sequence etc.
• Advanced hipset Features (AT lock, DRAM Timing etc.)
• Power Management Features (Sleep timer, Suspend Timer etc.)
• PNP/P I onfigurations (IRQ Settings, Latency Timers etc.)
• Integrated Peripherals (Onboard IO,IRQ, DMA Assign. etc.)
• SmartDoc Anti-Burn Shield ( PU/System Temp.,Fan speed etc.)
• Frequency/Voltage ( PU clock, Voltage of PU, DIMM, AGP etc.)

12
SL-NF4-754RL Chapter 1 Specification
1-4.6 AC’97 Audio Codec on board
A ’97 Audio odec Realtek AL 850 on board
• Supporting 8-channel display of P M audio output
• 8 channel audio consists of Front-Out, Surround-Out, enter-Out,
Surround-Back-Out, Mic-In, Line-In, and Front-Mic-In for complete
surround sound effect
• SPDIF Out connector integrated in Back Panel supported by
nForce- K804 for digital format output.
• A ’97 Audio odec Driver enclosed in Support D for user’s
installation.
1-4.7 Advanced System ower Management
Advanced onfiguration and Power Interface incorporated in BIOS for
reducing power consumption :
• A PI 1.0 compliant (Advanced onfiguration and Power Interface)
• APM V1.2 compliant (Legacy Power Management)
• A PI Suspend function supported
• PS/2 Keyboard & Mouse Wake-up
• STR (Suspend to RAM) mode supported
• Real Time lock (RT ) with date alarm, month alarm, and century
field
1-4.5 CI Express Interface
1P I Express-x16 slot integrated, supporting:
• a raw bit-rate of 2.5 Gb.s on the data pins, resulting in a real band-
width per pair of 250MB/s.
• Enhanced Addressing Machanism
• P IE Graphics / LAN card etc. (not supporting AGP card)
3 P I Express-x1 slots integrated supporting P IE LAN card etc.
1-4.8 SATA RAID Interface
Serial ATA RAID Interface supported by nForce4-4X:
• Supporting 4 Serial ATA/RAID connectors for 4 SATA Hard Disks with
150Mb/s transfer rate
• Serial ATA RAID Drivers enclosed in Support D for user’s installa-
tion
• Supporting RAID 0,1, 0+1 configuration

13
SL-NF4-754RL Chapter 1 Specification
1-4.11 Hardware Monitor integrated
• Hardware Monitor integrated, providing monitoring functions on hard-
ware voltage, temperatures and fan speeds.
• Utility Software Soltek Hardware Monitor for displaying monitor sta-
tus is enclosed in Support D for user’s installation.
1-4.12 Form Factor
• ATX Form Factor, ATX Power Supply
• Mainboard size: 305mm x 220mm
• PS/2 Keyboard and PS/2 Mouse
• UARTs (Universal Asynchronous Receiver / Transmitter):
-- 1 serial port ( OM1) on board.
1-4.9 Multi-I/O Functions
• IDE ontroller, supporting:
-- 2 ATA 133 / 100 / 66 IDE connectors supporting up to 4 IDE devices
• Dedicated IR Functions:
-- 1x5 IR connector dedicated to IR function with Infrared-IrDA (HPSIR)
and ASK (Amplitude Shift Keyed) IR
• Multi-mode parallel data transfer:
-- Standard mode, high speed mode E P and enhanced mode EPP
• Floppy Drive onnector:
-- 1 FDD connector supporting 2 floppy drives with drive swap support
• Universal Serial Bus Transfer Mode:
-- USB V2.0 compliant, 480 Mb/s USB Bus, supporting Windows 98 and
later operating systems; USB drivers provided in Support D for installation
-- 4 built-in USB connectors and 3 more USB pin-headers which require 3
optional USB cables to provide 6 more USB ports
1-4.10 10/100Mb RTL8201CL HYceiver on board
RTL8201 L on board:
• Supporting 10/100Mb data transfer
• Supporting Wake On LAN function through the on-board RJ45 LAN
onnector

14
SL-NF4-754RL Chapter 2 Hardware Setup
Chapter 2 Hardware Setup
1. We recommend to install your PU before any other components.
For detailed installation instructions of processor, you can also refer
to the pamphlet enclosed in your PU package.
2. Installing a cooling fan with a good heatsink is a must for proper heat
dissipation for your PU. Get ready an appropriate fan with heatsink
for proper installation. Improper fan and installation will damage your
PU.
3. In case PU Vcore, PU clock or Frequency Ratio is adjustable on
board, please follow the instructions described in the User Manual
for proper setup. Incorrect setting will cause damage to your PU.
The following topics are included in this chapter:
To Get Things Ready for Hardware Setup !
2-1 CPU Installation with Socket 754 ....................................... 15
2-2 Memory Installation ............................................................. 16
2-3 PCI Express Slot Installation .............................................. 16
2-4 I E Connector Installation ................................................. 17
2-5 SATA / RAI Connectors ..................................................... 18
2-6 Floppy rive Installation ..................................................... 19
2-7 ATX Power Supply Installation .......................................... 20
2-8 Jumper Setting ....................................................................... 21
2-8.0 How to tackle the Jumpers: ....................................................... 22
2-8.1 JBAT1: Clear CMOS .................................................................. 22
2-8.2 JKB1 & J1: Keyboard/Mouse Wake-up .................................. 23
2-9 Other Connectors Configuration........................................ 24

15
SL-NF4-754RL Chapter 2 Hardware Setup
2-1 C U Installation with Socket 754
This series is built with PU Socket 754 supporting the AMD PUs
Athlon 64:
1. Socket 754 supported by a
cooling Fan Base.
2. Pull up the lever to
release socket lock.
Socket 754
Socket 754 Lever
in 1 position
3. Insert PU into Socket 754,
PU Pin1 to Socket Pin1.
ull up Lever
C U in 1 to Socket in 1. ull down Lever to fix C U.
5. Install cooling fan into Fan Base.
4. Pull down Lever to fix PU
to Socket 754
Cooling Fan Latch
Cooling Fan
Latch Connect Fan ower
connector to Mainboard
C U Fan ower connector.
(Attention: This C U Fan
connector is only an
example for illustration.)

16
SL-NF4-754RL Chapter 2 Hardware Setup
S/PDIF
Out
+12V Power
PW1
FAN3
ATX1
ATX Power onnector
USB5
1
RJ45
PS/2 Keyboard
OM1
USB Port
USB Port
Line in
(on top)
Line Out / Front Speaker Out
Side Speaker Out
Line In
(on top)
enter / Subwoofer Out
Rear
(on top)
Speaker
Mic In
83627HF
Winbond
BIOS
Li
Battery
IDE2
P I1
DDR 400/333MHz
FD1
P IE1 (P I Express-x1)
P IX1 (P I Express -x16)
NJ1
SATA4
JBAT1
1
DIMM2
AL
850
1
JAUD1
DIMM1
Socket 754
IDE1
SATA 1
SATA3
SATA2
USB4
1
USB3
1
P I2
AL 850
P IE2 (P I Express-x1)
P IE3 (P I Express-x1)
1
HD IR PWR
SPK RST
PLED
FAN2
FAN1
PS/2
Mouse
USB Port
USB Port
JKB1
1
LPT1
J1
1
nVidia
nForce 4
K804
RTL
8201 L
PHY
RT2
LED1
onnector
D-IN
1
2-3 CI Express Slot Installation
1 CIE-x16 Slot
3 CIE-x1 slots
1) P I Express-x16 Slot is built on board for P I Express Graphics
card application, supporting a raw bit-rate of 2.5Gb/s on the data
pins. It does not support AGP 1X/2X/4X/8X card.
2) 3 P IE-x1 slots are also supported by nForce4-4X, compliant with
P I Express Base Specification, Revision 1.0a for P I Express cards
(including LAN).
DRAM Key osition Voltage Key osition
2-2 Memory Installation
• Make sure to unplug your Power Supply before adding or removing
memory module. Failure to do so may cause severe damage to both
your mainboard and the memory module.
• Pay attention to the orientation of the DIMM slots. Forcing a DIMM in
a socket improperly will damage the memory module and slot.
• Make sure you have the right type of memory module for your
mainboard.
Slot Rib
(2.5V Voltage Key) DDR Notch
184-Pin DIMM Notch Key Definition
Module Latch
DIMM1
DIMM2

17
SL-NF4-754RL Chapter 2 Hardware Setup
S/PDIF
Out
+12V Power
PW1
FAN3
ATX1
ATX Power onnector
USB5
1
RJ45
PS/2 Keyboard
OM1
USB Port
USB Port
Line in
(on top)
Line Out / Front Speaker Out
Side Speaker Out
Line In
(on top)
enter / Subwoofer Out
Rear
(on top)
Speaker
Mic In
83627HF
Winbond
BIOS
Li
Battery
IDE2
P I1
DDR 400/333MHz
FD1
P IE1 (P I Express-x1)
P IX1 (P I Express -x16)
NJ1
SATA 4
JBAT1
1
DIMM2
AL
850
1
JAUD1
DIMM1
Socket 754
IDE1
SATA 1
SATA 3
SATA 2
USB4
1
USB3
1
P I2
AL 850
P IE2 (P I Express-x1)
P IE3 (P I Express-x1)
1
HD IR PWR
SPK RST
PLED
FAN2
FAN1
PS/2
Mouse
USB Port
USB Port
JKB1
1
LPT1
J1
1
nVidia
nForce 4
K804
RTL
8201 L
PHY
RT2
LED1
onnector
D-IN
1
2-4 IDE Connector Installation
1. To install IDE onnector, you may connect the blue connector of IDE
cable to the primary (IDE1) or secondary (IDE2) connector on board,
and then connect the gray connector to your slave device and the
black connector to your master device. If you install two hard disks,
you must configure the second drive to slave mode by setting its
jumpers correctly. Please refer to your hard disk documentation for
the jumper settings.
ATA IDE connectors:
Orient the red line on the IDE
Flat able to Pin1.
Pin 1 (to Red Line of
IDE cable)
IDE1
IDE2
Gray connector
Blue connector
Black connector
Red line
(To Mainboard)
(To Slave device)
(To Master Device)
IDE Flat Cable
80-conductor
cable
2. IDE1 and IDE2 are also supported by nForce4-4x to set up IDE RAID
system with 2 to 4 IDE Hard disks.

18
SL-NF4-754RL Chapter 2 Hardware Setup
S/PDIF
Out
+12V Power
PW1
FAN3
ATX1
ATX Power onnector
USB5
1
RJ45
PS/2 Keyboard
OM1
USB Port
USB Port
Line in
(on top)
Line Out / Front Speaker Out
Side Speaker Out
Line In
(on top)
enter / Subwoofer Out
Rear
(on top)
Speaker
Mic In
83627HF
Winbond
BIOS
Li
Battery
IDE2
P I1
DDR 400/333MHz
FD1
P IE1 (P I Express-x1)
P IX1 (P I Express -x16)
NJ1
SATA 4
JBAT1
1
DIMM2
AL
850
1
JAUD1
DIMM1
Socket 754
IDE1
SATA 1
SATA 3
SATA 2
USB4
1
USB3
1
P I2
AL 850
P IE2 (P I Express-x1)
P IE3 (P I Express-x1)
1
HD IR PWR
SPK RST
PLED
FAN2
FAN1
PS/2
Mouse
USB Port
USB Port
JKB1
1
LPT1
J1
1
nVidia
nForce 4
K804
RTL
8201 L
PHY
RT2
LED1
onnector
D-IN
1
Serial ATA Hard Disk
2-5 SATA / RAID Connectors
Serial ATA Cable
Serial ATA ower Cable
To ower Supply
SATA ower Connectors
(optional)
Serial ATA Connectors
4 SATA Connectors supported by
nForce4-4X for 4 SATA / RAID Hard
Disks setup.
4 Serial ATA connectors for 4 SATA/RAID Hard Disks are supported by
nForce4-4X chipset. Please see hapter 5 Disk Array Installation for
detailed RAID installaion.
(optional)
SATA1
SATA2
SATA3
SATA4

19
SL-NF4-754RL Chapter 2 Hardware Setup
S/PDIF
Out
+12V Power
PW1
FAN3
ATX1
ATX Power onnector
USB5
1
RJ45
PS/2 Keyboard
OM1
USB Port
USB Port
Line in
(on top)
Line Out / Front Speaker Out
Side Speaker Out
Line In
(on top)
enter / Subwoofer Out
Rear
(on top)
Speaker
Mic In
83627HF
Winbond
BIOS
Li
Battery
IDE2
P I1
DDR 400/333MHz
FD1
P IE1 (P I Express-x1)
P IX1 (P I Express -x16)
NJ1
SATA 4
JBAT1
1
DIMM2
AL
850
1
JAUD1
DIMM1
Socket 754
IDE1
SATA 1
SATA 3
SATA 2
USB4
1
USB3
1
P I2
AL 850
P IE2 (P I Express-x1)
P IE3 (P I Express-x1)
1
HD IR PWR
SPK RST
PLED
FAN2
FAN1
PS/2
Mouse
USB Port
USB Port
JKB1
1
LPT1
J1
1
nVidia
nForce 4
K804
RTL
8201 L
PHY
RT2
LED1
onnector
D-IN
1
To install Floppy Drive, you should connect the end of Floppy Drive
cable with single connector to the board, and connect the other end
with two connectors to the floppy drives.
2-6 Floppy Drive Installation
Floppy Drive onnector:
Pin 1 (to Red Line)
FDD Cable
To 1st Floppy Drive To Mainboard
To 2nd Floppy Drive
Red line
Signal Swap End
Orient the red line of the
Floppy Flat able to Pin1.

20
SL-NF4-754RL Chapter 2 Hardware Setup
S/PDIF
Out
+12V Power
PW1
FAN3
ATX1
ATX Power onnector
USB5
1
RJ45
PS/2 Keyboard
OM1
USB Port
USB Port
Line in
(on top)
Line Out / Front Speaker Out
Side Speaker Out
Line In
(on top)
enter / Subwoofer Out
Rear
(on top)
Speaker
Mic In
83627HF
Winbond
BIOS
Li
Battery
IDE2
P I1
DDR 400/333MHz
FD1
P IE1 (P I Express-x1)
P IX1 (P I Express -x16)
NJ1
SATA 4
JBAT1
1
DIMM2
AL
850
1
JAUD1
DIMM1
Socket 754
IDE1
SATA 1
SATA 3
SATA 2
USB4
1
USB3
1
P I2
AL 850
P IE2 (P I Express-x1)
P IE3 (P I Express-x1)
1
HD IR PWR
SPK RST
PLED
FAN2
FAN1
PS/2
Mouse
USB Port
USB Port
JKB1
1
LPT1
J1
1
nVidia
nForce 4
K804
RTL
8201 L
PHY
RT2
LED1
onnector
D-IN
1
2-7 ATX ower Supply Installation
ATX V2.03 Power Supply is strongly recommended for mainboard run-
ning with this mainboard.
To set up Power Supply on this mainboard:
1. onnect the on-board Main Power onnector (20-pin) to the Main
Power onnector (20-pin) of an ATX Power Supply which can be of
the latest version 2.03 model, and then connect the square-shaped
+12V Power onnector on board to the square-shaped +12V Power
onnector of the Power Supply.
Warning: Both the Main Power onnector and the +12V Power
onnector should be connected to Power Supply; otherwise, the
system may either not start or be damaged.
2. This ATX Power Supply should be able to provide at least 720mA/
+5V standby power for Wake On Lan function.
Main Power
onnector
+12V
5SB
WR OK
GND
GND
GND
GND
GND
GND
+5V
+5V
-5V
+5V
+5V
+3.3V
+3.3V +3.3V
S ON#
Pin1 Pin11
-12V
GND
+12V Power onnector
GND
+12V
3
GND
+12V
2
4
1

21
SL-NF4-754RL Chapter 2 Hardware Setup
S/PDIF
Out
+12V Power
PW1
FAN3
ATX 1
ATX Power onnector
USB5
1
RJ45
PS/2 Keyboard
OM1
USB Port
USB Port
Line in
(on top)
Line Out / Front Speaker Out
Side Speaker Out
Line In
(on top)
enter / Subwoofer Out
Rear
(on top)
Speaker
Mic In
83627HF
Winbond
BIOS
Li
Battery
IDE2
P I1
DDR 400/333MHz
FD1
P IE1 (P I Express-x1)
P IX1 (P I Express -x16)
NJ1
SATA4
JBAT1
1
DIMM2
AL
850
1
JAUD1
DIMM1
Socket 754
IDE1
SATA1
SATA3
SATA2
USB4
1
USB3
1
P I2
AL 850
P IE2 (P I Express-x1)
P IE3 (P I Express-x1)
1
HD IR PWR
SPK RST
PLED
FAN2
FAN1
PS/2
Mouse
USB Port
USB Port
JKB1
1
LPT1
J1
1
nVidia
nForce 4
K804
RTL
8201 L
PHY
RT2
LED1
onnector
D-IN
1
The following diagrams show the locations and settings of jumper blocks
on the mainboard.
JBAT1:
1-2 closed (default)
To hold data
1
1
2-3 closed
To clear MOS
Clear CMOS
2-8 Jumper Setting
1
1
JKB1 & J1:
JKB1 1-2 closed
JKB1 2-3 closed
KB/Mouse Wakeup
1
Enabled
J1 1-2 closed
1
J1 2-3 closed
Disabled (default)

22
SL-NF4-754RL Chapter 2 Hardware Setup
1 13313
Jumper with
in 2-3 closed Jumper with all pins open Jumper with in 1-2 closed
If a pin-header (of 2 or more pins) is
designed in such a way that its pins
can be closed or linked together to
set up a specific function, this header
is called a jumper in this manual.
A 3-pin Jumper
The conductor inside the cap
links two header-pins together.
• A Jumper is usually but not necessarily given a “JpX” legend.
Jp X
• Do not remove any jumper cap when power is on. Always
make sure the power is off before changing any jumper
settings. Otherwise, mainboard could be damaged.
2-8.0 How to tackle the Jumpers:
• In the Jumper setting diagram, all jumper pins covered with
black marks stand for closed pins with jumper cap.
123 A 2-pin
Jumper
ap
When you have problem with rebooting your system, you can clear
MOS data and restore it to default value. To clear MOS with Jumper
JBAT1, please follow the steps below:
1. Power off system.
2. Set JBAT1 to Pin 2-3 closed.
3. After 2 or 3 seconds, return the JBAT1 setting to Pin1-2 closed.
4. MOS data are restored to default. Remember never clear MOS
when system power is on.
2-8.1 JBAT1: Clear CMOS
JBAT1:
1-2 closed (default)
To hold data
1
1
2-3 closed
To clear MOS
Clear CMOS

23
SL-NF4-754RL Chapter 2 Hardware Setup
2-8.2 JKB1 & J1: Keyboard/Mouse Wake-up
1
1
JKB1 & J1:
JKB1 1-2 closed
JKB1 2-3 closed
KB/Mouse Wakeup
1
Enabled
J1 1-2 closed
1
J1 2-3 closed
Disabled (default)
JKB1 with J1 is design on board for the “ Wake up system from sus-
pend mode” function with the PS/2 keyboard/mouse. Yet user should
still enter “BIOS Setup” to choose the Wake-up/Power-on mode.
