SOMFY Animeo IB+ User manual

Power
Connector type Quick operation spring-loaded connectors
Number 2 doubled connections (main and through)
Recommended cable
section
Min : 3 x 1.5 mm²
Max : 3 x 2.5 mm²
Dry contact local control
Connector type Quick operation spring-loaded connectors
Number 4
Recommended cable
section
Min : 3 x 0.8 mm²
Max : 3 x 2.5 mm²
Maximum cable length 100m
Control bus
Connector type Quick operation detachable spring-loaded
connectors
Number 2: doubled connections (main and through)
Recommended cable
section
Min : 4 x 0.8 mm² twisted where possible
Max : 4 x 1.5 mm² twisted where possible
Maximum cable length 1000m
Maximum supported
devices per bus line 100
1860085PN
ANIMEO IB+ MOTOR CONTROLLER 4DC SM
SM Surface mounting version
Accessories:
Animeo 24 VDC/4.5A Power supply (1860093)
Somfy RTS plug-in card (PN 1860105)
Somfy EnOcean plug-in card (PN 1860220)
Functional description
Motor controller for individual or group control of up to 4 Somfy
24V DC standard motors. The Animeo IB+ control bus manages up
to 100 motor controllers per zone, extending the capabilities of
the solar shading management system to the requirements of the
building as to the daylight management strategy and the end user
visual and thermal comfort.
In addition to the network capabilities, this controller can also be
operated locally via a standard hardwired wall switch (dry contact)
or a wireless operated local switch thanks to the range of plug-in
cards available.
outputs
Motor outputs
Conector type Quick operation spring-loaded connectors
Number 4
Supported motors 24V DC standard Somfy motors
Max. number of motors 4
Recommended cable
section
Min : 4 x 0.75 mm²
Max : 4 x 2.5 mm²
Maximum cable length 20m
inputs
quick installation and set up

Reset / Prog
Ext.
IB
24 V DC
Power
–
C
1-4
–+ +
IB+ In IB+ Out
1860085
Somfy
animeo IB+
4 DC 2A Motor Controller WM 24 VDC
M4
0.25
2
12
Junction
box
M
C
1-4
C
M1 M2 M3 M4
C C CA B
Local push button
Motor 1
Local push button
Motor 2
Local push button
Motor 3
Local push button
Motor 4
Motor 24
V DC
Motor 4
+ UP Down
+ UP Down
+ UP Down + UP Down UP
Down
M3
0.25
2
12
Junction
box
M
Motor 24 V DC
Motor 3
UP Down
M2
0.25
2
12
Junction
box
M
Motor 24 V DC
Motor 2
UP Down
M1
0.25
2
12
Junction
box
M
Motor 24 V DC
Motor 1
UP Down
Ext.
12 12 12 12
adhesive area
for
ID label
a n
im
e o I D
-
N o
.
-- ++
1860093
Somfy
animeo
Power Supply DC
Power
24 V DC
Power
AC Input: 220
V - 240 V ~50/60 Hz / 0.75 A
DC Output: 24
V = 2.5 A (100 %), 4.5 A (ED 50 %)
NN LL
mains
mains
230 V
50 Hz
L
1
N
P
E
J
un
ct
i
o
n
b
ox
Group
control
C
UP
Down
IB+
Somfy Ltd.Somfy capital 20.000.000. RCS Boneville 303.970.230 ©SOMFY.COM 28/06/13. All pictures from Somfy.
tecHnical speciFications
ANIMEO IB+ MOTOR CONTROLLER 4DC SM
Supply voltage 21.5-28 V DC
Stand-by current (IEC 62301) 50mA @ 24V DC
Stand-by power (IEC 62301) 300mW @ 24V DC
Max. motor current consumption 4x2.3A @ 24V DC
Supply voltage of group control inputs SELV, 16 DC=
Supply voltage of local control inputs SELV, 16 DC=
Terminals Spring loaded connectors
Inputs/outputs protection Short-circuit
Running time per output Max. 5 minutes
Operating temperature 0°C to 45°C
Relative humidity 85%
Enclosure material CC-ABS polycarbonate
Enclosure dimensions 180 x 255 x 63mm
Degree of protection IP 20
Protection class III
Conformity CE by EN 60730-1
This motor controller is an electronic opera-
ted, independently mounted device
Class A control function
Type 1 action
Pollution degree: 2
Type X attachement
Ball hardness test temperature: 75°C / EMC Emission test UDC =24V DC IDC= 9A (EN 55022 Class B Em.)
