SOMFY 1860333 User manual

SDN 0-10V Interface
Part Number: 1860333

2
SDN 0-10V Interface
The SDN 0-10V Interface control is a device that will accept industry standard 0-10V input and convert it to a Somfy Digital
Network™ (SDN) signal. The SDN signal will drive a Somfy RS485 motor to a percentage of opening or closing based
upon the 0-10V input level and the setting of the reverse push button.
• No configuration or programming required.
• Reverse operation by pressing and holding the reverse button for 1 second.
• One control can drive up to 20 SDN tubular motors.
• Provides 45 SDN Bus Power units
0-10V INPUT DEFAULT POSITION REVERSED POSITION
0V FULLY OPENED FULLY CLOSED
1V (-0.1V/+0.8V) 11% CLOSED 11% OPEN
2V (-0.1V/+0.8V) 22% CLOSED 22% OPEN
3V (-0.1V/+0.8V) 33% CLOSED 33% OPEN
4V (-0.1V/+0.8V) 44% CLOSED 44% OPEN
5V (-0.1V/+0.8V) 55% CLOSED 55% OPEN
6V (-0.1V/+0.8V) 66% CLOSED 66% OPEN
7V (-0.1V/+0.8V) 77% CLOSED 77% OPEN
8V (-0.1V/+0.8V) 88% CLOSED 88% OPEN
9V (-0.1V/+0.8V) FULLY CLOSED FULLY OPENED
1. Verify that the limits of the RS485 motor are set and the power to the motor is applied.
2. Verify that the SDN 0-10V Interface is OFF, then connect the motor data cable and the 0-10V input according to Figure 1.
Do not connect the +24V power supply at this time.
*NOTE* VERIFY THE POLARTIY OF THE 0-10V POSITIVE (+) VIOLET AND NEGATIVE (-) GREY INPUTS BEFORE
APPLYING POWER.
3. Connect the +24V power supply to the 0-10V Control. Then verify that the Bus Power Supply LED on the Bus Out jack is
solid green. Also verify that the Bus Activity LED on the Bus Out port turns on for 2 seconds and then turns off.
4. Turn on the SDN 0-10V Interface and verify that the motor responds accordingly to various input levels.
If reverse operation of the motor is desired:
• Drive the motor to the fully opened or the fully closed limit
• Then press and hold the reverse button for 1 second
• Verify that the motor moves to the opposite limit
SETUP

3
SDN 0-10V Interface
SDN RS485 Tubular motors
(Sonesse® ULTRA 50 RS485 example shown)
+24V
Power
Supply
0-10V
Input
Motor Data Cable*
* use Black Data Cable
(see ordering information)
(violet)
(grey)
Sonesse® ULTRA 50 RS485 (AC)
Sonesse® ULTRA 50 RS485 (DC) Motor Pigtail Weidmueller Connectors
Weidmueller Connectors
SDN Low-voltage motor cable
Cat5 Cable with RJ45 End
24V DC
120V AC
60 HZ
ELEMENT FUNCTION
1Reverse Button Reverse shade position percentage
2Power Input (5.5 mm female barrel connector) Supply 24V DC power to device
30-10V Input (screw clamp connector) Input from control system
4SDN Bus Power and Data Output (female RJ45) Output for power and data
LED Indicators
LABEL ELEMENT COLOR FUNCTION ON FUNCTION OFF
PBus Power Green Power No Power
AA (activity) Green Data No Data
PA
Top Side
Back Side
1
Front Side
2 3 4
FIGURE 1. CONNECTION INFORMATION
Notes:
For single motor operation, motor data cable connects directly to the SDN Bus Out port.
This example shows the Data Hub while the Data Hub Mini and Power Panel for SDN are also compatible.
The diagram shown below is meant for illustrative purposes to show the connections from product to product. This
device could be used in other configurations than shown below. For specification information on individual products,
see related product information. Follow all SDN wiring standards for distance limitations.
CONNECTION DIAGRAM
CONNECTIONS & INDICATORS

4
SDN 0-10V Interface
P-0029
Line-voltage (AC):
• Sonesse® ULTRA 50 RS485 (AC)
• LT50 RS485 (AC)
MOTOR COMPATIBILITY
© Copyright 5/2018 SOMFY SYSTEMS, LLC.
ORDERING INFORMATION
DESCRIPTION PART NUMBER
SDN 0-10V Interface (w/ +24V power supply) 1860333
Data Hub 1870262
SDN Mini Data Hub 1870277
Line-voltage RS485 Motor Data Cables
2.5 .: 9018541
8 .: 9018542
12 .: 9018543
24 .: 9018544
Low voltage RS485 Motor Accessories
24V DC 1.66A Wall Mount Plug-in Transformer 1822209
Power Panel for SDN 1870259
SDN Low-voltage Motor Power and Data Cable 9020126/9020127
(Plenum Rated) (from Liberty AV)
Weidmuller Connector (5 pin) 9020743
Sonesse® 30 DC RS485 Cable Data and Power Pigtail 9020261
Sonesse® Ultra 50 DC RS485 Cable Data and Power Pigtail 9020004
FIGURE 2. MOTOR DATA CABLE CONNECTIONS
4 Not Connected*
Power Out**
1 + RS485
2 - RS485
3 Not Connected
8 GND
7 Not Connected
6 Not Connected
5 Not Connected
1 + RS485
2 - RS485
4 GND
3 Not Connected*
Power Out**
Motor Data Cable
BLACK DATA CABLE (without power out)
4 Cond. 26AWG modular cable with RJ9 on one end
and RJ45 other end
MOTOR DATA CABLE INFORMATION
Low-voltage (DC):
• Sonesse® ULTRA 50 RS485 (DC)
• Sonesse® 30 RS485 (DC)
9020126 - Non-plenum Rated
Orange = SDN RS485 (-)
Orange/white = SDN RS485 (+)
Red = power (+)
Black = power (-)
Brown = groundSDN RS485
Silver = Drain
Data and Power Cable
24V DC / SDN Control
5 conductor cable
Somfy SDN Low-voltage Motor Cable
9020127 - Plenum Rated
Sonesse® ULTRA 50 RS485
Data and Power Pigtail
Sonesse® 30 RS485 Data and
Power Pigtail
Low-Voltage (DC)
Weidmuller Connects
to Network
JST to Motor
Line-Voltage (AC)
Weidmuller Connector (5 pin) SDN Low-voltage Motor
Power and Data Cable
9020127 - Plenum Rated
9020126 - Non-plenum Rated
For more information visit: https://www.somfysystems.com/products/1860333/sdn-0-10v-interface
