SOMFY INTEO TELIS 1 RTS User manual

www.somfy.com
Operating and installation guide
Telis 1 RTS
Ref. 5054463A

1. Brief introduction to the Telis 1 RTS remote control 3
1.1 What is the Telis 1 RTS for? 3
1.2 A few denitions 3
2. Safety - Important information 4
2.1 Installation and commissioning 4
2.2 Operating 4
2.3 Environment 4
3. Content of the kit and tools required 5
3.1 List of parts 5
3.2 Tools required 5
4. The Telis 1 RTS in detail 6
4.1 Components 6
4.2 Technical data 6
5. Adding a new Telis 1 RTS 6
5.1 Identifying the original control point 6
5.2 One-touch point 8
5.3 Point with Up/STOP/Down buttons 13
5.4 Timer 15
5.5 Situo control point 17
5.6 Telis 1 RTS Telis Soliris RTS remote controls 20
5.7 Telis 4 RTS/Telis 4 Soliris RTS remote controls 22
6. Replacing a lost or broken control point 24
6.1 Sole control point lost or broken 24
6.2 One lost or broken control point amongst others 24
7. Mounting the bracket 24
8. Everyday use of the Telis 1 RTS 25
8.1 Up and Down buttons 25
8.2 My button 25
8.3 Replacing the battery 26
8.4 Maintenance 26
9. Problems with the Telis 1 RTS? 26
Contents
2Copyright © 2008 Somfy SAS. All rights reserved.
Telis 1 RTS

Somfy's expertise delivers satisfaction guaranteed.
Thank you for choosing a Somfy Telis 1 RTS .
Before installing and using the Telis 1 RTS, please read this guide
carefully.
Somfy solutions animate your windows and entrances to bring your
whole house alive. Somfy solutions are designed so that everyone can
enjoy the benets of the products in their home, based on their specic
requirements.
In this guide, the term ‘product’ can include your awning, blind, curtain,
garage door, gate, projection screen, roller shutter.
Well thought-out and easy to use, Somfy solutions are one of life’s little
daily pleasures, making home life more enjoyable.
1. Brief introduction to the Telis 1 RTS remote
control
These instructions describe the installation steps required to make the
best use of the Telis 1 RTS. Advanced installation functions are available
on our website (address on the back cover of these instructions).
1.1 What is the Telis 1 RTS for?
The Telis 1 RTS is a wireless radio remote control compatible only with
products tted with Radio Technology Somfy (RTS):
The Telis 1 RTS is used:
As an individual control to control a single product (eg roller blind)
at a time.
As a group control to command several products at the same time
(eg several roller blinds) (advanced installation function).
1.2 A few denitions
Installation
All of the Radio Technology Somfy products a house is equipped with.
Favourite position
The favourite position is your ideal position for your product in certain
•
•
3
Copyright © 2008 Somfy SAS. All rights reserved.
Telis 1 RTS
3

4Copyright © 2008 Somfy SAS. All rights reserved.
Telis 1 RTS
common situations, for example, your curtains or blinds partially closed
to shield the TV from afternoon sunlight; your awning partially extended
when you are dining beneath it in summer but don’t want to deprive your
houseplants of sunlight
2. Safety - Important information
2.1 Installation and commissioning
Before installing and using the Telis 1 RTS, please read these instruc-
tions carefully, which describe how to install, commission and operate
the Telis 1 RTS.
Never begin installing without rst checking the compatibility of the Telis
1 RTS with the associated equipment and accessories.
Any incorrect use will invalidate the warranty and Somfy’s liability.
2.2 Operating
Somfy recommends that at least one control point is located close to
the product or group of products.
Do not allow children to play with the xed control points. Keep remote
controls out of the reach of children.
Monitor the product (especially roller shutter/awning/garage door/gate)
while it is moving, especially during commissioning of the Telis 1 RTS,
and keep people at a distance until the product is completely closed.
Switch off the circuit breaker corresponding to the roller shutter/awning/
garage door/gate before any maintenance operation in the vicinity of
the product (for example, when cleaning windows near your awning).
Avoid moving the roller shutter/awning if ice has formed in it, unless
the motor is tted with anti-freeze protection.
Do not leave the Telis 1 RTS behind a window in full sunlight as it
cannot withstand temperatures greater than 60°C.
Do not leave the Telis 1 RTS in a car in winter.
Do not immerse or soak the Telis 1 RTS in any liquid.
Only use cleaning products recommended by Somfy.
Frequently check the product (eg awning) to detect any defects in
balance or any signs of wear. Do not use the product if a repair or
adjustment is required
2.3 Environment
Damaged electrical or electronic products, such as used batteries,
-
-
-
-
-
-
-
-
-
-

5
Copyright © 2008 Somfy SAS. All rights reserved.
Telis 1 RTS
should not be disposed of with household waste. Please take them to
a collection point or an approved centre to ensure they are recycled
correctly.
3. Content of the kit and tools required
3.1 List of parts
Before starting installation and commissioning of the Telis 1 RTS,
check that all parts listed in the table below are present in the correct
quantity (Q):
No. Components Q.
1Telis 1 RTS remote control 1
2Mounting pin 1
3 Support 1
4Plug 1
5Screw 1
3.2 Tools required
Phillips screwdriver
Insulated athead electricians
screwdriver
Drill and drill bit
Pencil
-
•
•
•
•
4
3
1
5
2
4
3
1
5
2

6Copyright © 2008 Somfy SAS. All rights reserved.
Telis 1 RTS
4. The Telis 1 RTS in detail
4.1 Components
A. Up button
B. STOP/my button
C. Down button
D. Indicator light
E. PROG button
4.2 Technical data
Dimensions in mm (Height x Width x Depth):
Pure model: 134 x 41 x 21 mm
Lounge, Silver, Patio models: 145 x 49 x 22 mm
Operating temperature: 0°C to + 60°C
Protection rating: Inside use, in a dry room - IP 30 (Pure, Lounge,
Silver Models) ; IP 44 (Patio Model)
Frequency: 433.42 MHz
Range: 20 m through two concrete walls; 200 m in an open area
Battery: 3 V, type CR 2430
5. Adding a new Telis 1 RTS
5.1 Identifying the original control point
5.1.1 Installation recommendations
To add a Telis 1 RTS, use the control point linked to the product
which controls only this product: pressing the Down or Up button only
causes movement of the product to which the new Telis 1 RTS must
be connected.
Caution! If there is no longer a control point linked to the product (all the
control points are broken or have been lost), contact the Somfy assis-
tance service.
N.B.: These instructions only describe the installation procedure for
an additional Telis 1 RTS of the «individual control» type. Refer to the
instructions for advanced functions available on the Internet (address
on the back cover of these instructions) to install a control referred to as
«group control».
On some products, inputs in programming mode and the addition or
deletion of a control point are signalled by a series of beeps emitted
-
-
mysomfy.com
C
B
A
E
D
mysomfy.com
C
B
A
E
D

7
Copyright © 2008 Somfy SAS. All rights reserved.
Telis 1 RTS
by the motor. On other products, this is
signalled by a brief movement of the
product.
Caution: If the product does not emit a
beep or make a brief movement, please
contact the Somfy assistance service.
Place the product in the midway posi-
tion before installing the new Telis 1
RTS so that the movements can be
easily seen.
5.1.2 Original control points
Find the original control point in the list
below and refer to the paragraph given
to add the new Telis 1 RTS:
1) Control point xed to the wall with
a single button, called a One-touch
point, see paragraph 5.2;
2) Control point xed to the wall with
Up/STOP/Down buttons, called a
Point with Up/STOP/Down buttons,
see paragraph 5.3;
3) Programmer type control point,
called a Timer, see paragraph 5.4;
4) Situo control point xed to the wall,
see paragraph 5.5;
5a) Telis 1 RTS remote control, see
paragraph 5.6;
5b) Telis Soliris RTS remote control,
see paragraph 5.6;
6a) Telis 4 RTS remote control, see
paragraph 5.7;
6b) Telis 4 Soliris RTS remote control,
see paragraph 5.7.
-
-
5b
5a
6a 6b
3
2
1
4
5b
5a
6a 6b
3
2
1
4

8Copyright © 2008 Somfy SAS. All rights reserved.
Telis 1 RTS
5.2 One-touch point
Move close to the product to install the
new Telis 1 RTS.
5.2.1 Identifying the model
Check that the original control point
has an elongated button.
Bring the product to the midway
position.
Remove the front cover from the one-
touch point:
One-touch point with a white and grey front
cover
Gently remove the front cover with
a at, pointed tool (such as a at-
head screwdriver) where the white
section and the grey section join.
Lever it, without using force, to
detach the mounting lugs from the
front cover.
One-touch point with a white front cover
Lever the front cover with a at,
pointed tool (such as a athead
screwdriver), without using force,
around the upper section of the
front cover to detach it from its
mounting.
Turn the front cover over to nd out the
model:
If there is a metal plate (a) inscribed
PROG next to the battery: model A.
If there is no metal plate inscribed
PROG next to the battery: model B.
-
-
-
-
-
-
-
-
-
A B

9
Copyright © 2008 Somfy SAS. All rights reserved.
Telis 1 RTS
5.2.2 Adding the Telis 1 RTS
Model A:
Make a contact between the PROG
metal plate (a) on the electrical circuit
and the battery bracket using a
athead screwdriver, until the product
moves briey (or there is a series of
3 beeps): the programming function of
your RTS enabled products is activated
for approximately 2 minutes.
Take the new Telis 1 RTS and turn it
over.
Press the PROG button (E) on the
new Telis 1 RTS briey with the tip of
a pencil: the product will make another
brief movement (or emit a series of
8 beeps) to indicate that the new Telis
1 RTS is stored.
Press the down button on the new Telis
1 RTS:
If the product is lowered, the
Telis 1 RTS is operational.
If the product does not move, contact
the Somfy assistance service.
If the original control point must be
deleted, go to paragraph 5.2.3 "Deleting
an original control point".
If the original control point is to be kept,
ret the front cover:
One-touch point with a white and grey front
cover
Insert the mounting lugs into their
notches on one side of the front
cover.
Press on the other side until it clicks,
to x the front cover in its bracket.
-
-
-
-
-
-
-
-
-
-
EE

10 Copyright © 2008 Somfy SAS. All rights reserved.
Telis 1 RTS
One-touch point with a white front cover
Ret the front cover on its bracket
Model B:
Remove the battery from the original
control point using a plastic object.
Press on the centre section of the one-
touch point button.
Ret the battery in the base of its
bracket (with text legible).
Press the button again until the product
moves briey (or there is a series of
3 beeps): the programming function of
your RTS enabled products is activated
for approximately 2 minutes.
Take the new Telis 1 RTS and turn it
over.
Press the PROG button (E) on the
new Telis 1 RTS briey with the tip of
a pencil: the product will make another
brief movement (or emit a series of
8 beeps) to indicate that the new Telis
1 RTS is stored.
Press the down button on the new Telis
1 RTS:
If the product is lowered, the
Telis 1 RTS is operational.
If the product does not move, contact
the Somfy assistance service.
If the original control point must be
deleted, go to paragraph 5.2.3 "Deleting
an original control point".
If the original control point is to be kept,
ret the front cover:
-
-
-
-
-
-
-
-
-
-
-
-
EE

11
Copyright © 2008 Somfy SAS. All rights reserved.
Telis 1 RTS
One-touch point with a white and grey front
cover
Insert the mounting lugs into their
notches on one side of the front
cover.
Press on the other side until it clicks,
to x the front cover in its bracket.
One-touch point with a white front cover
Ret the front cover on its bracket
5.2.3 Deleting an original control point
(optional)
Recommended: Only follow this proce-
dure if use of the original control point is
no longer required.
Model A:
Wait 5 minutes.
Take the new Telis 1 RTS and turn it
over to access the PROG button (E).
Press the PROG button (E) on the new
Telis 1 RTS with the tip of a pencil until
the product moves briey (or a series
of 3 beeps is emitted): the program-
ming function of your RTS enabled
products is activated for approximately
2 minutes.
On the original control point, make
a contact between the PROG metal
plate (a) on the electrical circuit and the
battery bracket using a athead screw-
driver: the product will move briey (or
emit a series of 8 beeps) to indicate that
the original control point is deleted.
Press the one-touch point button: the
product does not move.
Press the down button on the new Telis
1 RTS:
If the product is lowered, the
Telis 1 RTS is operational.
If the product does not move, contact
-
-
-
-
-
-
-
-
-
-
-
EE

12 Copyright © 2008 Somfy SAS. All rights reserved.
Telis 1 RTS
the Somfy assistance service.
Remove the one-touch point.
Do not dispose of the original control
point with household waste, see para-
graph 2.3.
Model B:
Wait 5 minutes.
Take the new Telis 1 RTS and turn it
over to access the PROG button (E).
Press the PROG button (E) on the new
Telis 1 RTS with the tip of a pencil until
the product moves briey (or a series
of 3 beeps is emitted): the program-
ming function of your RTS enabled
products is activated for approximately
2 minutes.
Remove the battery from the original
control point using a plastic object.
Press on the centre section of the one-
touch point button.
Ret the battery in the base of its hous-
ing (with text legible).
Press the front panel button again:
the product will move briey (or emit a
series of 8 beeps) to indicate that the
original control point is deleted.
Press the one-touch point button: the
product does not move.
Press the down button on the new Telis
1 RTS:
If the product is lowered, the
Telis 1 RTS is operational.
If the product does not move, contact
the Somfy assistance service.
Remove the one-touch point.
Do not dispose of the original control
point with household waste, see para-
graph 2.3.
-
-
-
-
-
-
-
-
-
-
-
-
-
EE

13
Copyright © 2008 Somfy SAS. All rights reserved.
Telis 1 RTS
5.3 Point with Up/STOP/Down
buttons
Move close to the product to install the
Telis 1 RTS.
5.3.1 Checking the compatibility
Bring the product to the midway
position.
Cut off the mains power supply or
detach the battery connected to the
motor (eg for a battery operated roller
blind).
Remove the front cover of the original
control point:
Gently remove the front cover with
a at, pointed tool (such as a at-
head screwdriver) where the white
section and the grey section join.
Lever the front cover, without using
force, to detach the mounting lugs
from the front cover.
Turn the front cover over: the
PROG button is located next to the
battery (b).
Caution! If after removing the front cover,
no PROG button is found, this means
that the control point is not compatible:
the Telis 1 RTS cannot be linked to the
product.
5.3.2 Adding the Telis 1 RTS
Switch the mains power supply back on
or reconnect the battery to the motor.
Press the PROG button (b) on the
original control point until the product
moves briey (or a series of 3 beeps is
emitted): the programming function of
your RTS enabled products is activated
for approximately 2 minutes.
Take the new Telis 1 RTS and turn it
over.
-
-
-
-
-
-
-
-
-
bb
bb

14 Copyright © 2008 Somfy SAS. All rights reserved.
Telis 1 RTS
Press the PROG button (E) on the Telis
1 RTS briey with the tip of a pencil: the
product will make another brief move-
ment (or emit a series of 8 beeps) to
indicate that the new Telis 1 RTS is
stored.
Press the Down button on the new Telis
1 RTS:
If the product is lowered, the
Telis 1 RTS is operational.
If the product does not move, contact
the Somfy assistance service.
If the original control point must be
deleted, go to paragraph 5.3.3 "Deleting
an original control point".
If the original control point is to be kept,
ret the front cover:
Insert the mounting lugs into their
notches on one side of the front
cover.
Press on the other side until it clicks,
to x the front cover in its bracket.
5.3.3 Deleting an original control point
(optional)
Recommended: Only follow this proce-
dure if use of the original control point is
no longer required.
Wait 5 minutes.
Take the new Telis 1 RTS and turn it
over to access the PROG button (E).
Press the PROG button (E) on the new
Telis 1 RTS with the tip of a pencil until
the product moves briey (or a series
of 3 beeps is emitted): the program-
ming function of your RTS enabled
products is activated for approximately
2 minutes.
On the original control point, press the
PROG button (b) briey: the product
will move briey (or emit a series of
-
-
-
-
-
-
-
-
-
-
-
-
EE
EE
bb
14

15
Copyright © 2008 Somfy SAS. All rights reserved.
Telis 1 RTS
8 beeps) to indicate that the original
control point is deleted.
Press the Down button on the origi-
nal control point: the product does not
move.
Press the Down button on the new Telis
1 RTS:
If the product is lowered, the
Telis 1 RTS is operational.
If the product does not move, contact
the Somfy assistance service.
Removing the original control point.
Do not dispose of the original control
point with household waste, see para-
graph 2.3.
5.4 Timer
Move close to the product to install the
Telis 1 RTS.
5.4.1 Checking the compatibility
Bring the product to the midway
position.
Cut off the mains power supply or
detach the battery connected to the
motor (eg for a battery operated roller
blind).
Remove the front cover of the original
control point:
Lever it with a at, pointed tool (such
as a athead screwdriver), with-
out using force, around the upper
section of the front cover to detach
it from its mounting.
The PROG button is located on top
of the screen and is shaped like a
tab (c).
Caution! If after removing the front cover,
no PROG button is found, this means
that the control point is not compatible:
the Telis 1 RTS cannot be linked to the
-
-
-
-
-
-
-
-
-
-
cc

16 Copyright © 2008 Somfy SAS. All rights reserved.
Telis 1 RTS
product.
5.4.2 Adding the Telis 1 RTS
Switch the mains power supply back on
or reconnect the battery to the motor.
Press the tab (c) until the product
moves briey (or there is a series of
3 beeps): the programming function of
your RTS enabled products is activated
for approximately 2 minutes.
Take the new Telis 1 RTS and turn it
over.
Press the PROG button (E) on the
new Telis 1 RTS briey with the tip of
a pencil: the product will make another
brief movement (or emit a series of
8 beeps) to indicate that the new Telis
1 RTS is stored.
Press the Down button on the new Telis
1 RTS:
If the product is lowered, the
Telis 1 RTS is operational.
If the product does not move, contact
the Somfy assistance service.
If the original control point must be
deleted, go to paragraph 5.4.3 "Deleting
an original control point".
If the original control point is to be kept,
ret the front cover:
Insert the front cover on its bracket,
allowing the buttons to come
through their housings.
Press the front until it clicks, to x
the front cover in its bracket.
5.4.3 Deleting an original control point
(optional)
Recommended: Only follow this proce-
dure if use of the original timer is no
longer required.
Wait 5 minutes.
-
-
-
-
-
-
-
-
-
-
-
-
cc
EE

17
Copyright © 2008 Somfy SAS. All rights reserved.
Telis 1 RTS
Take the new Telis 1 RTS and turn it
over to access the PROG button (E).
Press the PROG button (E) on the
Telis 1 RTS with the tip of a pencil until
the product moves briey (or a series
of 3 beeps is emitted): the program-
ming function of your RTS enabled
products is activated for approximately
2 minutes.
On the original timer, briey press the
tab (c): the product will move briey (or
emit a series of 8 beeps) to indicate that
the original control point is deleted.
Press the timer Down button: the prod-
uct does not move.
Press the Down button on the new Telis
1 RTS:
If the product is lowered, the
Telis 1 RTS is operational.
If the product does not move, contact
the Somfy assistance service.
Remove the timer.
Do not dispose of the original control
point with household waste, see para-
graph 2.3.
5.5 Situo control point
Move close to the product to install the
Telis 1 RTS.
5.5.1 Adding the Telis 1 RTS
Bring the product to the midway
position.
Remove the front cover from the Situo:
Gently remove the front cover with
a at, pointed tool (such as a at-
head screwdriver) around the lower
section.
Lever and lift the cover, without
using force, to detach the mounting
lugs from the front cover.
-
-
-
-
-
-
-
-
-
-
-
-
EE
cc

18 Copyright © 2008 Somfy SAS. All rights reserved.
Telis 1 RTS
Turn the front cover over: the
PROG button is located next to the
battery (d).
Press the PROG button (d) on the
Situo until the product moves brie-
y (or a series of 3 beeps is emitted):
the programming function of your
RTS enabled products is activated for
approximately 2 minutes.
Take the new Telis 1 RTS and turn it
over.
Press the PROG button (E) on the
new Telis 1 RTS briey with the tip of
a pencil: the product will make another
brief movement (or emit a series of
8 beeps) to indicate that the new Telis
1 RTS is stored.
Press the Down button on the new Telis
1 RTS:
If the product is lowered, the
Telis 1 RTS is operational.
If the product does not move, contact
the Somfy assistance service.
If the Situo must be deleted, go to
paragraph 5.5.2 "Deleting the original
Situo".
If the Situo is to be kept, ret the front
cover:
Insert the mounting lugs in their
notches at the top.
Press the lower section until it clicks,
to x the front cover in its bracket.
5.5.2 Deleting the original Situo
(optional)
Recommended: Only follow this proce-
dure if use of the original Situo is no
longer required.
Wait 5 minutes.
Take the new Telis 1 RTS and turn it
over to access the PROG button (E).
-
-
-
-
-
-
-
-
-
-
-
-
-
dd
EE
EE

19
Copyright © 2008 Somfy SAS. All rights reserved.
Telis 1 RTS
Press the PROG button (E) on the new
Telis 1 RTS with the tip of a pencil until
the product moves briey (or a series
of 3 beeps is emitted): the program-
ming function of your RTS enabled
products is activated for approximately
2 minutes.
On the Situo, briey press the PROG
button (d): the product will make
another brief movement (or emit a
series of 8 beeps) to indicate that the
Situo is deleted.
Press the Situo Down button: the prod-
uct does not move.
Press the Down button on the new Telis
1 RTS:
If the product is lowered, the
Telis 1 RTS is operational.
If the product does not move, contact
the Somfy assistance service.
Remove the Situo.
Do not dispose of the original control
point with household waste, see para-
graph 2.3.
-
-
-
-
-
-
-
dd

20 Copyright © 2008 Somfy SAS. All rights reserved.
Telis 1 RTS
5.6 Telis 1 RTS Telis Soliris
RTS remote controls
The Telis 1 RTS has 1 indicator light (5a)
and the Telis Soliris RTS has 2 indicator
lights (5b).
If the original remote control has more
than 2 indicator lights, refer to the section
"Telis 4 RTS/Telis 4 Soliris RTS remote
controls".
Move close to the product to install the
Telis 1 RTS.
5.6.1 Adding a new Telis 1 RTS
Bring the product to the midway
position.
Turn the original Telis over: the PROG
button (g) is located on the rear panel.
Press the PROG button (g) with the
tip of a pencil until the product moves
briey (or a series of 3 beeps is emit-
ted): the programming function of your
RTS enabled products is activated for
approximately 2 minutes.
Take the new Telis 1 RTS and turn it
over.
Press the PROG button (E) on the
new Telis 1 RTS briey with the tip of
a pencil: the product will make another
brief movement (or emit a series of
8 beeps) to indicate that the new Telis
1 RTS is stored.
Press the Down button on the new Telis
1 RTS:
If the product is lowered, the
Telis 1 RTS is operational.
If the product does not move, contact
the Somfy assistance service.
If the original Telis must be deleted, go
to paragraph 5.6.2 "Deleting the origi-
nal Telis".
-
-
-
-
-
-
-
-
-
gg
EE
