Sonoma X-BASE OTTOMAN WITH BUILT IN TRAY User manual

PART LIST QUANTITY
A
1
B
1
C
2
D
1
E
2
F
4
SAVE THESE INSTRUCTIONS
SONOMA X-BASE OTTOMAN WITH BUILT IN TRAY ASSEMBLY INSTRUCTIONS
ASSEMBLE ON A FLAT, PROTECTED SURFACE.
FIGURE
DESCRIPTION
OTTOMAN SEAT & TRAY
METAL FRAME
X-BASE LEGS
LEG SUPPORT BAR
LARGE BOLTS
SMALL BOLTS
Page 1/4

PART LIST QUANTITY
G
1
H
4
ALLEN WRENCH
TRIANGLE SOFT STICKERS
ASSEMBLY INSTRUCTIONS (CONTINUED)
FOR MISSING OR INCORRECT PARTS/HARDWARE, CONTACT THE MANUFACTURER'S CUSTOMER SERVICE DIRECTLY AT
[email protected]
REFER TO LAST PAGE FOR ADDITIONAL CUSTOMER SERVICE DETAILS.
FIGURE
DESCRIPTION
Page 2/4

ASSEMBLY INSTRUCTIONS (CONTINUED)
STEP 2
1. PLACE METAL FRAME (B) ON TOP OF X-BASE
LEGS.
2. ALIGN METAL FRAME (B) WITH HOLES ON TOP
OF X-BASE LEGS (C). CONNECT METAL FRAME (B)
TO X-BASE LEGS (C) USING SMALL BOLTS (F) AND
ALLEN WRENCH (G).
3. TIGHTEN ALL BOLTS ON UNIT.
STEP 1
1. ON A FLAT PROTECTED SURFACE CONNECT X-
BASE LEG (C) AND SUPPORT BAR (D) WITH LARGE
BOLT (E) USING ALLEN WRENCH (G). DO NOT
TIGHTEN COMPLETELY.
2. REPEAT WITH OTHER X BASE LEG (C).
Page 3/4

CARE AND CLEANING
SPOT CLEAN WITH A DAMP, CLEAN CLOTH AS NEEDED. DO NOT RUB.
INTENDED FOR INDOOR USE ONLY.
AVOID SOAKING AND SUN EXPOSURE TO PREVENT CRACKING.
ASSEMBLY INSTRUCTIONS (CONTINUED)
WEIGHT LIMIT
250 LBS
KEEP AWAY FROM HEAT SOURCES LIKE HEATERS.
STEP 3
A. APPLY SOFT TRIANGLE STICKERS (H) ON
CORNERS TO COVER SMALL BOLTS (F), TO PREVENT
DAMAGE TO TRAY TOP WHEN NOT IN USE.
STEP 4
PUT OTTOMAN SEAT & TRAY (A) ON TOP OF
METAL FRAME (B).
ASSEMBLY IS COMPLETE.
Page 4/4
