News Gathering
Wide RF bandwidth provides ENG users with
greater potential to find unoccupied
frequencies in congested metropolitan
areas. Direct slot-in makes DWX the ideal
solution along with Sony’s camcorders.
A V-mount attachment is also available to
expand mounting options.
Field Production
Receiver DC operation, and a choice of rack
mounting and portable receivers, for use on
a sound cart, enables high-quality field
production for movies, sports, drama,
reality TV shows and commercials.
Sound Recording
The compact, robust design suits production
with a mixer bag. Three-way powering and
three-parallel audio output from a portable
receiver are features that give great flexibility
to the sound engineer.
The DWX Series steps onto a new stage,
with a wide choice of Sony and third-party capsules
Live Concert
Higher-quality wireless transmission
maintains the sonic integrity of legendary
microphone capsules and subtle overtones
of guitar or bass instruments. Now the DWX®
series assists with frequency coordination
and use with other wireless systems.
Theater Hall
As well as offering large-scale simultaneous
multi-channel operation, the DWX series can
be used with a wide range of popular lavalier
and headset microphones to suit most
theater performances. New Wireless Studio
3.0 helps with complex system integration
and simplifies daily operation.
Broadcast Studio
Stable transmission and advanced
monitor/control functions secure reliable
and safe operation in the broadcast studio,
and users can choose from a variety of
handheld microphone capsules or lavalier
microphones according to their program
production needs.
DWX Series
Digital Wireless Microphone System

Component Products
Handheld Microphone
DWM-02
Digital Wireless Microphone
lHandheld microphone
l1.25”/28 thread pitch
(31.3 mm/pitch 1.0 mm threading)
interchangeable mechanism
lAccepts popular thread-on capsules
CU-C31
Capsule Unit
lCondenser type
lCardioid
l60 Hz - 20 KHz
CU-F31
Capsule Unit
lDynamic type
lSuper cardioid
l60 Hz - 18 KHz
CU-F32
Capsule Unit
lDynamic type
lWide cardioid
l70 Hz - 18 KHz
Transmitter
DWT-B01/E
Digital Wireless Transmitter
lBodypack transmitter
lBandwidth: up to 72 MHz
lOutput power: 50 mW/10 mW/1 mW
lInput level: microphone to line level
lFrequency Code
US model: U14/U30/U42
ECM-77BC
Lavalier Microphone
ECM-FT5
Flat Lavalier Microphone
GC-0.7CP
Guitar Cable
lGC-0.7CP/S: Straight plug
lGC-0.7CP/R: Right-angle plug
DWT-P01/E
Digital Wireless Transmitter
lPlug-on transmitter
lBandwidth: up to 72 MHz
lOutput power: 50 mW/10 mW/1 mW
lInput level: microphone to line level
l+48 V phantom powering
lFrequency Code
US model: U14/U30/U42
Rackmount Receiver
DWR-R02D
Digital Wireless Receiver
l2ch rackmount receiver
lBandwidth: up to 72 MHz
lAC powering: 100 V - 240 V
lDC powering: 12 V
lGND lift function for analog BAL output
RMU-01
Remote Control Unit
lExtension of Cross Remote™ function
lControl of up to 82ch transmitter
lTwo-way powering
AN-01
UHF Antenna
lLog-periodic antenna
lUni-directional
lBuilt-in booster
AN-820
UHF Antenna
lDipole antenna
lHorizontal omni-direction
lBuilt-in booster
Wireless Studio 3.0
lBundled application for PC
lStatus monitor & parameter control
lChannel plan adviser
lRF Chart Grapher / RF Chart Analyzer
Portable Receiver
DWR-S02D
Digital Wireless Receiver
l2ch slot-in receiver
lBandwidth: up to 72 MHz
lFrequency Code
US model: U14/U30/U42
DWA-01D
Digital Wireless Adapter
lSupport V-mount attachment
lHirose 4-pin DC powering
lAnalog and/or digital audio output
DWA-F01D
Digital Wireless Adapter
lTop-panel operation for mixer bag
lThree-way powering
lThree-parallel audio output
LCS-F01D
Soft Carrying Case
lSoft case for DWA-F01D
lShoulder strap is included
lSupport V-mount attachment
lATT function for analog UNBAL output
lXLR and BNC output for AES3 digital output
lFrequency Code
US model: U14/U30/U42
lBandwidth: up to 72 MHz
lOutput power: 50 mW/10 mW/1 mW
lFrequency Code
US model: U14/U30/U42
