Sony DWM02/14 User manual

4-179-556-15(1)
Digital Wireless Microphone System Frequency Lists
The following tables show the channels and frequencies that are selectable on your digital wireless microphones, transmitters, and receivers.
For the setting procedures of the channel/frequency on your units, refer to the Operating Instructions supplied with the units.
The group 00 permits the units to operate on any of 47 carrier frequencies in 125-kHz steps of TV channels 14 to 17.
• Simultaneous multi-channel operation is not assured with this group.
• Channels marked with asterisks (*) cannot be used with the wireless remote control function. When using the wireless remote control
function, use channels that are not marked with asterisks.
Frequency unit: MHz
TV1417
Group 00
Notes
TV-14
Channel Frequency Channel Frequency
14 - 01 470.125 14 - 25 473.125
14 - 02 470.250 14 - 26 473.250
14 - 03 470.375 14 - 27 473.375
14 - 04 470.500 14 - 28 473.500
14 - 05 470.625 14 - 29 473.625
14 - 06 470.750 14 - 30 473.750
14 - 07 470.875 14 - 31 473.875
14 - 08 471.000 14 - 32 474.000
14 - 09 471.125 14 - 33 474.125
14 - 10 471.250 14 - 34 474.250
14 - 11 471.375 14 - 35 474.375
14 - 12 471.500 14 - 36 474.500
14 - 13 471.625 14 - 37 474.625
14 - 14 471.750 14 - 38 474.750
14 - 15 471.875 14 - 39 474.875
14 - 16 472.000 14 - 40 475.000
14 - 17 472.125 14 - 41 475.125
14 - 18 472.250 14 - 42 475.250
14 - 19 472.375 14 - 43 475.375
14 - 20 472.500 14 - 44 475.500
14 - 21 472.625 14 - 45 475.625
14 - 22 472.750 14 - 46 475.750
14 - 23 472.875 14 - 47 475.875
14 - 24 473.000
TV-15
Channel Frequency Channel Frequency
15 - 01 476.125 15 - 25 479.125
15 - 02 476.250 15 - 26 479.250
15 - 03 476.375 15 - 27 479.375
15 - 04 476.500 15 - 28 479.500
15 - 05 476.625 15 - 29 479.625
15 - 06 476.750 15 - 30 479.750
15 - 07 476.875 15 - 31 479.875
15 - 08 477.000 15 - 32 480.000
15 - 09 477.125 15 - 33 480.125
15 - 10 477.250 15 - 34 480.250
15 - 11 477.375 15 - 35 480.375
15 - 12 477.500 15 - 36 480.500
15 - 13 477.625 15 - 37 480.625
15 - 14 477.750 15 - 38 480.750
15 - 15 477.875 15 - 39 480.875
15 - 16 478.000 15 - 40 481.000
15 - 17 478.125 15 - 41 481.125
15 - 18 478.250 15 - 42 481.250
15 - 19 478.375 15 - 43 481.375
15 - 20 478.500 15 - 44 481.500
15 - 21 478.625 15 - 45 481.625
15 - 22 478.750 15 - 46 481.750
15 - 23 478.875 15 - 47 481.875
15 - 24 479.000
TV-16
Channel Frequency Channel Frequency
16 - 01 482.125 16 - 25 485.125
16 - 02 482.250 16 - 26 485.250
16 - 03 482.375 16 - 27 485.375
16 - 04 482.500 16 - 28 485.500
16 - 05 482.625 16 - 29 485.625
16 - 06 482.750 16 - 30 485.750
16 - 07 482.875 16 - 31 485.875
16 - 08 483.000 16 - 32 486.000
16 - 09 483.125 16 - 33 486.125
16 - 10 483.250 16 - 34 486.250
16 - 11 483.375 16 - 35 486.375
16 - 12 483.500 16 - 36 486.500
16 - 13 483.625 16 - 37 486.625
16 - 14 483.750 16 - 38 486.750
16 - 15 483.875 16 - 39 486.875
16 - 16 484.000 16 - 40 487.000
16 - 17 484.125 16 - 41 487.125
16 - 18 484.250 16 - 42 487.250
16 - 19 484.375 16 - 43 487.375
16 - 20 484.500 16 - 44 487.500
16 - 21 484.625 16 - 45 487.625
16 - 22 484.750 16 - 46 487.750
16 - 23 484.875 16 - 47 487.875
16 - 24 485.000
TV-17
Channel Frequency Channel Frequency
17 - 01 488.125 17 - 25 491.125
17 - 02 488.250 17 - 26 491.250
17 - 03 488.375 17 - 27 491.375
17 - 04 488.500 17 - 28 491.500
17 - 05* 488.625* 17 - 29 491.625
17 - 06* 488.750* 17 - 30 491.750
17 - 07* 488.875* 17 - 31 491.875
17 - 08* 489.000* 17 - 32 492.000
17 - 09* 489.125* 17 - 33 492.125
17 - 10* 489.250* 17 - 34 492.250
17 - 11* 489.375* 17 - 35 492.375
17 - 12 489.500 17 - 36 492.500
17 - 13 489.625 17 - 37 492.625
17 - 14 489.750 17 - 38 492.750
17 - 15 489.875 17 - 39 492.875
17 - 16 490.000 17 - 40 493.000
17 - 17 490.125 17 - 41 493.125
17 - 18 490.250 17 - 42 493.250
17 - 19 490.375 17 - 43 493.375
17 - 20 490.500 17 - 44 493.500
17 - 21 490.625 17 - 45 493.625
17 - 22 490.750 17 - 46 493.750
17 - 23 490.875 17 - 47 493.875
17 - 24 491.000

Guidance on the use of a multi-channel system using digital wireless system
When building up the system with digital wireless devices only, channel intervals can be fixed. No special calculations are necessary to
avoid intermodulations. Set channel intervals to 375 kHz or more.
When building up a multi-channel system, Sony recommends that one of the following groups is selected to avoid mutual interference
from other Sony wireless microphones/transmitters:
– Groups D1 to D4 are for using 12 channels of transmitting frequencies in one TV channel.
– Groups D5 to D8 are for using 24 channels of transmitting frequencies in two TV channels.
– Group D9 is for using 48 channels of transmitting frequencies in four TV channels.
• The reliability of this channel plan is assured when the RF power output of the transmitter/microphone is 1 mW or 10 mW and distances
of transmitters/microphones are 1 m (3.3 feet) or more.
• When the distances between transmitters and microphones need to be closer than the distances above, use a grouping system for multi-
channel systems that include both digital wireless and analog wireless devices.
• Channels marked with asterisks (*) cannot be used with the wireless remote control function. When using the wireless remote control
function, use channels that are not marked with asterisks.
Frequency unit: MHz
Grouping for digital wireless system
Notes
Group D1
Grouping 12 channels
Channel Frequency
14 - 02 470.250
14 - 06 470.750
14 - 10 471.250
14 - 14 471.750
14 - 18 472.250
14 - 22 472.750
14 - 26 473.250
14 - 30 473.750
14 - 34 474.250
14 - 38 474.750
14 - 42 475.250
14 - 46 475.750
Group D2
Grouping 12 channels
Channel Frequency
15 - 02 476.250
15 - 06 476.750
15 - 10 477.250
15 - 14 477.750
15 - 18 478.250
15 - 22 478.750
15 - 26 479.250
15 - 30 479.750
15 - 34 480.250
15 - 38 480.750
15 - 42 481.250
15 - 46 481.750
Group D3
Grouping 12 channels
Channel Frequency
16 - 02 482.250
16 - 06 482.750
16 - 10 483.250
16 - 14 483.750
16 - 18 484.250
16 - 22 484.750
16 - 26 485.250
16 - 30 485.750
16 - 34 486.250
16 - 38 486.750
16 - 42 487.250
16 - 46 487.750
Group D4
Grouping 12 channels
Channel Frequency
17 - 02 488.250
17 - 06* 488.750*
17 - 10* 489.250*
17 - 14 489.750
17 - 18 490.250
17 - 22 490.750
17 - 26 491.250
17 - 30 491.750
17 - 34 492.250
17 - 38 492.750
17 - 42 493.250
17 - 46 493.750
Group D5
Grouping 24 channels
Channel Frequency
14 - 01 470.125
14 - 05 470.625
14 - 09 471.125
14 - 13 471.625
14 - 17 472.125
14 - 21 472.625
14 - 25 473.125
14 - 29 473.625
14 - 33 474.125
14 - 37 474.625
14 - 41 475.125
14 - 45 475.625
15 - 02 476.250
15 - 06 476.750
15 - 10 477.250
15 - 14 477.750
15 - 18 478.250
15 - 22 478.750
15 - 26 479.250
15 - 30 479.750
15 - 34 480.250
15 - 38 480.750
15 - 42 481.250
15 - 46 481.750
Group D6
Grouping 24 channels
Channel Frequency
16 - 01 482.125
16 - 05 482.625
16 - 09 483.125
16 - 13 483.625
16 - 17 484.125
16 - 21 484.625
16 - 25 485.125
16 - 29 485.625
16 - 33 486.125
16 - 37 486.625
16 - 41 487.125
16 - 45 487.625
17 - 02 488.250
17 - 06* 488.750*
17 - 10* 489.250*
17 - 14 489.750
17 - 18 490.250
17 - 22 490.750
17 - 26 491.250
17 - 30 491.750
17 - 34 492.250
17 - 38 492.750
17 - 42 493.250
17 - 46 493.750

Frequency unit: MHz
Group D7
Grouping 24 channels
Channel Frequency
14 - 01 470.125
14 - 05 470.625
14 - 09 471.125
14 - 13 471.625
14 - 17 472.125
14 - 21 472.625
14 - 25 473.125
14 - 29 473.625
14 - 33 474.125
14 - 37 474.625
14 - 41 475.125
14 - 45 475.625
16 - 02 482.250
16 - 06 482.750
16 - 10 483.250
16 - 14 483.750
16 - 18 484.250
16 - 22 484.750
16 - 26 485.250
16 - 30 485.750
16 - 34 486.250
16 - 38 486.750
16 - 42 487.250
16 - 46 487.750
Group D8
Grouping 24 channels
Channel Frequency
15 - 01 476.125
15 - 05 476.625
15 - 09 477.125
15 - 13 477.625
15 - 17 478.125
15 - 21 478.625
15 - 25 479.125
15 - 29 479.625
15 - 33 480.125
15 - 37 480.625
15 - 41 481.125
15 - 45 481.625
17 - 02 488.250
17 - 06* 488.750*
17 - 10* 489.250*
17 - 14 489.750
17 - 18 490.250
17 - 22 490.750
17 - 26 491.250
17 - 30 491.750
17 - 34 492.250
17 - 38 492.750
17 - 42 493.250
17 - 46 493.750
Group D9
Grouping 48 channels
Channel Frequency
14 - 01 470.125
14 - 05 470.625
14 - 09 471.125
14 - 13 471.625
14 - 17 472.125
14 - 21 472.625
14 - 25 473.125
14 - 29 473.625
14 - 33 474.125
14 - 37 474.625
14 - 41 475.125
14 - 45 475.625
15 - 02 476.250
15 - 06 476.750
15 - 10 477.250
15 - 14 477.750
15 - 18 478.250
15 - 22 478.750
15 - 26 479.250
15 - 30 479.750
15 - 34 480.250
15 - 38 480.750
15 - 42 481.250
15 - 46 481.750
16 - 01 482.125
16 - 05 482.625
16 - 09 483.125
16 - 13 483.625
16 - 17 484.125
16 - 21 484.625
16 - 25 485.125
16 - 29 485.625
16 - 33 486.125
16 - 37 486.625
16 - 41 487.125
16 - 45 487.625
17 - 02 488.250
17 - 06* 488.750*
17 - 10* 489.250*
17 - 14 489.750
17 - 18 490.250
17 - 22 490.750
17 - 26 491.250
17 - 30 491.750
17 - 34 492.250
17 - 38 492.750
17 - 42 493.250
17 - 46 493.750

Guidance on the use of a multi-channel system using digital wireless system with analog wireless system
When building up the system with digital and analog wireless devices, use the conventional analog wireless channel groups. Set the
intervals between a digital channel and an analog channel to 375 kHz or more.
When building up a multi-channel system, Sony recommends that one of the following groups is selected to avoid mutual interference
from other Sony wireless microphones/transmitters:
– Groups 01 to 04 are for using 8 channels of transmitting frequencies in one TV channel.
– Groups 05 to 08 are for using 11 channels of transmitting frequencies in two TV channels.
– Group 09 is for using 16 channels of transmitting frequencies in four TV channels.
• On shaded channels in the tables below, digital wireless microphones cannot be used. The indication of these channels does not appear
in the display of the device.
• The reliability of this channel plan is assured when the RF power output of the transmitter/microphone is 1 mW or 10 mW and distances
of transmitters/microphones are 1 m (3.3 feet) or more.
• When the distances between transmitters and microphones need to be closer than the distances above, use a grouping system for multi-
channel systems that include both digital wireless and analog wireless devices.
• Channels marked with asterisks (*) cannot be used with the wireless remote control function. When using the wireless remote control
function, use channels that are not marked with asterisks.
Frequency unit: MHz
Grouping for digital wireless system with analog wireless system
Notes
Group 01
Grouping 8 channels
Channel Frequency
14 - 01 470.125
14 - 05 470.625
14 - 11 471.375
14 - 25 473.125
14 - 28 473.500
14 - 36 474.500
14 - 41 475.125
14 - 43 475.375
Group 02
Grouping 8 channels
Channel Frequency
15 - 03 476.375
15 - 13 477.625
15 - 18 478.250
15 - 26 479.250
15 - 37 480.625
15 - 40 481.000
15 - 44 481.500
15 - 46 481.750
Group 03
Grouping 8 channels
Channel Frequency
16 - 01 482.125
16 - 05 482.625
16 - 11 483.375
16 - 25 485.125
16 - 28 485.500
16 - 36 486.500
16 - 41 487.125
16 - 43 487.375
Group 04
Grouping 8 channels
Channel Frequency
17 - 03 488.375
17 - 13 489.625
17 - 18 490.250
17 - 26 491.250
17 - 37 492.625
17 - 40 493.000
17 - 44 493.500
17 - 46 493.750
Group 05
Grouping 11 channels
Channel Frequency
14 - 07 470.875
14 - 09 471.125
14 - 12 471.500
14 - 19 472.375
14 - 33 474.125
14 - 37 474.625
15 - 02 476.250
15 - 08 477.000
15 - 24 479.000
15 - 35 480.375
15 - 44 481.500
Group 06
Grouping 11 channels
Channel Frequency
16 - 05 482.625
16 - 14 483.750
16 - 25 485.125
16 - 41 487.125
16 - 47 487.875
17 - 12 489.500
17 - 16 490.000
17 - 30 491.750
17 - 37 492.625
17 - 40 493.000
17 - 42 493.250
Group 07
Grouping 11 channels
Channel Frequency
14 - 03 470.375
14 - 12 471.500
14 - 23 472.875
14 - 39 474.875
14 - 45 475.625
16 - 10 483.250
16 - 14 483.750
16 - 28 485.500
16 - 35 486.375
16 - 38 486.750
16 - 40 487.000
Group 08
Grouping 11 channels
Channel Frequency
15 - 08 477.000
15 - 10 477.250
15 - 13 477.625
15 - 20 478.500
15 - 34 480.250
15 - 38 480.750
17 - 03 488.375
17 - 09* 489.125*
17 - 25 491.125
17 - 36 492.500
17 - 45 493.625
Group 09
Grouping 16 channels
Channel Frequency
14 - 03 470.375
14 - 05 470.625
14 - 08 471.000
14 - 12 471.500
14 - 34 474.250
15 - 01 476.125
15 - 20 478.500
15 - 37 480.625
16 - 02 482.250
16 - 27 485.375
16 - 47 487.875
17 - 11* 489.375*
17 - 22 490.750
17 - 32 492.000
17 - 38 492.750
17 - 46 493.750

The following tables show the channels and frequencies that are selectable on your digital wireless microphones, transmitters, and
receivers.
For the setting procedures of the channel/frequency on your units, refer to the Operating Instructions supplied with the units.
The group 00 permits the units to operate on any of 47 carrier frequencies in 125-kHz steps of TV channels 18 to 21.
Simultaneous multi-channel operation is not assured with this group.
Frequency unit: MHz
TV1821
Group 00
Note
TV-18
Channel Frequency Channel Frequency
18 - 01 494.125 18 - 25 497.125
18 - 02 494.250 18 - 26 497.250
18 - 03 494.375 18 - 27 497.375
18 - 04 494.500 18 - 28 497.500
18 - 05 494.625 18 - 29 497.625
18 - 06 494.750 18 - 30 497.750
18 - 07 494.875 18 - 31 497.875
18 - 08 495.000 18 - 32 498.000
18 - 09 495.125 18 - 33 498.125
18 - 10 495.250 18 - 34 498.250
18 - 11 495.375 18 - 35 498.375
18 - 12 495.500 18 - 36 498.500
18 - 13 495.625 18 - 37 498.625
18 - 14 495.750 18 - 38 498.750
18 - 15 495.875 18 - 39 498.875
18 - 16 496.000 18 - 40 499.000
18 - 17 496.125 18 - 41 499.125
18 - 18 496.250 18 - 42 499.250
18 - 19 496.375 18 - 43 499.375
18 - 20 496.500 18 - 44 499.500
18 - 21 496.625 18 - 45 499.625
18 - 22 496.750 18 - 46 499.750
18 - 23 496.875 18 - 47 499.875
18 - 24 497.000
TV-19
Channel Frequency Channel Frequency
19 - 01 500.125 19 - 25 503.125
19 - 02 500.250 19 - 26 503.250
19 - 03 500.375 19 - 27 503.375
19 - 04 500.500 19 - 28 503.500
19 - 05 500.625 19 - 29 503.625
19 - 06 500.750 19 - 30 503.750
19 - 07 500.875 19 - 31 503.875
19 - 08 501.000 19 - 32 504.000
19 - 09 501.125 19 - 33 504.125
19 - 10 501.250 19 - 34 504.250
19 - 11 501.375 19 - 35 504.375
19 - 12 501.500 19 - 36 504.500
19 - 13 501.625 19 - 37 504.625
19 - 14 501.750 19 - 38 504.750
19 - 15 501.875 19 - 39 504.875
19 - 16 502.000 19 - 40 505.000
19 - 17 502.125 19 - 41 505.125
19 - 18 502.250 19 - 42 505.250
19 - 19 502.375 19 - 43 505.375
19 - 20 502.500 19 - 44 505.500
19 - 21 502.625 19 - 45 505.625
19 - 22 502.750 19 - 46 505.750
19 - 23 502.875 19 - 47 505.875
19 - 24 503.000
TV-20
Channel Frequency Channel Frequency
20 - 01 506.125 20 - 25 509.125
20 - 02 506.250 20 - 26 509.250
20 - 03 506.375 20 - 27 509.375
20 - 04 506.500 20 - 28 509.500
20 - 05 506.625 20 - 29 509.625
20 - 06 506.750 20 - 30 509.750
20 - 07 506.875 20 - 31 509.875
20 - 08 507.000 20 - 32 510.000
20 - 09 507.125 20 - 33 510.125
20 - 10 507.250 20 - 34 510.250
20 - 11 507.375 20 - 35 510.375
20 - 12 507.500 20 - 36 510.500
20 - 13 507.625 20 - 37 510.625
20 - 14 507.750 20 - 38 510.750
20 - 15 507.875 20 - 39 510.875
20 - 16 508.000 20 - 40 511.000
20 - 17 508.125 20 - 41 511.125
20 - 18 508.250 20 - 42 511.250
20 - 19 508.375 20 - 43 511.375
20 - 20 508.500 20 - 44 511.500
20 - 21 508.625 20 - 45 511.625
20 - 22 508.750 20 - 46 511.750
20 - 23 508.875 20 - 47 511.875
20 - 24 509.000
TV-21
Channel Frequency Channel Frequency
21 - 01 512.125 21 - 25 515.125
21 - 02 512.250 21 - 26 515.250
21 - 03 512.375 21 - 27 515.375
21 - 04 512.500 21 - 28 515.500
21 - 05 512.625 21 - 29 515.625
21 - 06 512.750 21 - 30 515.750
21 - 07 512.875 21 - 31 515.875
21 - 08 513.000 21 - 32 516.000
21 - 09 513.125 21 - 33 516.125
21 - 10 513.250 21 - 34 516.250
21 - 11 513.375 21 - 35 516.375
21 - 12 513.500 21 - 36 516.500
21 - 13 513.625 21 - 37 516.625
21 - 14 513.750 21 - 38 516.750
21 - 15 513.875 21 - 39 516.875
21 - 16 514.000 21 - 40 517.000
21 - 17 514.125 21 - 41 517.125
21 - 18 514.250 21 - 42 517.250
21 - 19 514.375 21 - 43 517.375
21 - 20 514.500 21 - 44 517.500
21 - 21 514.625 21 - 45 517.625
21 - 22 514.750 21 - 46 517.750
21 - 23 514.875 21 - 47 517.875
21 - 24 515.000

Guidance on the use of a multi-channel system using digital wireless system
When building up the system with digital wireless devices only, channel intervals can be fixed. No special calculations are necessary to
avoid intermodulations. Set channel intervals to 375 kHz or more.
When building up a multi-channel system, Sony recommends that one of the following groups is selected to avoid mutual interference
from other Sony wireless microphones/transmitters:
– Groups D1 to D4 are for using 12 channels of transmitting frequencies in one TV channel.
– Groups D5 to D8 are for using 24 channels of transmitting frequencies in two TV channels.
– Group D9 is for using 48 channels of transmitting frequencies in four TV channels.
• The reliability of this channel plan is assured when the RF power output of the transmitter/microphone is 1 mW or 10 mW and distances
of transmitters/microphones are 1 m (3.3 feet) or more.
• When the distances between transmitters and microphones need to be closer than the distances above, use a grouping system for multi-
channel systems that include both digital wireless and analog wireless devices.
Frequency unit: MHz
Grouping for digital wireless system
Notes
Group D1
Grouping 12 channels
Channel Frequency
18 - 02 494.250
18 - 06 494.750
18 - 10 495.250
18 - 14 495.750
18 - 18 496.250
18 - 22 496.750
18 - 26 497.250
18 - 30 497.750
18 - 34 498.250
18 - 38 498.750
18 - 42 499.250
18 - 46 499.750
Group D2
Grouping 12 channels
Channel Frequency
19 - 02 500.250
19 - 06 500.750
19 - 10 501.250
19 - 14 501.750
19 - 18 502.250
19 - 22 502.750
19 - 26 503.250
19 - 30 503.750
19 - 34 504.250
19 - 38 504.750
19 - 42 505.250
19 - 46 505.750
Group D3
Grouping 12 channels
Channel Frequency
20 - 02 506.250
20 - 06 506.750
20 - 10 507.250
20 - 14 507.750
20 - 18 508.250
20 - 22 508.750
20 - 26 509.250
20 - 30 509.750
20 - 34 510.250
20 - 38 510.750
20 - 42 511.250
20 - 46 511.750
Group D4
Grouping 12 channels
Channel Frequency
21 - 02 512.250
21 - 06 512.750
21 - 10 513.250
21 - 14 513.750
21 - 18 514.250
21 - 22 514.750
21 - 26 515.250
21 - 30 515.750
21 - 34 516.250
21 - 38 516.750
21 - 42 517.250
21 - 46 517.750
Group D5
Grouping 24 channels
Channel Frequency
18 - 01 494.125
18 - 05 494.625
18 - 09 495.125
18 - 13 495.625
18 - 17 496.125
18 - 21 496.625
18 - 25 497.125
18 - 29 497.625
18 - 33 498.125
18 - 37 498.625
18 - 41 499.125
18 - 45 499.625
19 - 02 500.250
19 - 06 500.750
19 - 10 501.250
19 - 14 501.750
19 - 18 502.250
19 - 22 502.750
19 - 26 503.250
19 - 30 503.750
19 - 34 504.250
19 - 38 504.750
19 - 42 505.250
19 - 46 505.750
Group D6
Grouping 24 channels
Channel Frequency
20 - 01 506.125
20 - 05 506.625
20 - 09 507.125
20 - 13 507.625
20 - 17 508.125
20 - 21 508.625
20 - 25 509.125
20 - 29 509.625
20 - 33 510.125
20 - 37 510.625
20 - 41 511.125
20 - 45 511.625
21 - 02 512.250
21 - 06 512.750
21 - 10 513.250
21 - 14 513.750
21 - 18 514.250
21 - 22 514.750
21 - 26 515.250
21 - 30 515.750
21 - 34 516.250
21 - 38 516.750
21 - 42 517.250
21 - 46 517.750

Frequency unit: MHz
Group D7
Grouping 24 channels
Channel Frequency
18 - 01 494.125
18 - 05 494.625
18 - 09 495.125
18 - 13 495.625
18 - 17 496.125
18 - 21 496.625
18 - 25 497.125
18 - 29 497.625
18 - 33 498.125
18 - 37 498.625
18 - 41 499.125
18 - 45 499.625
20 - 02 506.250
20 - 06 506.750
20 - 10 507.250
20 - 14 507.750
20 - 18 508.250
20 - 22 508.750
20 - 26 509.250
20 - 30 509.750
20 - 34 510.250
20 - 38 510.750
20 - 42 511.250
20 - 46 511.750
Group D8
Grouping 24 channels
Channel Frequency
19 - 01 500.125
19 - 05 500.625
19 - 09 501.125
19 - 13 501.625
19 - 17 502.125
19 - 21 502.625
19 - 25 503.125
19 - 29 503.625
19 - 33 504.125
19 - 37 504.625
19 - 41 505.125
19 - 45 505.625
21 - 02 512.250
21 - 06 512.750
21 - 10 513.250
21 - 14 513.750
21 - 18 514.250
21 - 22 514.750
21 - 26 515.250
21 - 30 515.750
21 - 34 516.250
21 - 38 516.750
21 - 42 517.250
21 - 46 517.750
Group D9
Grouping 48 channels
Channel Frequency
18 - 01 494.125
18 - 05 494.625
18 - 09 495.125
18 - 13 495.625
18 - 17 496.125
18 - 21 496.625
18 - 25 497.125
18 - 29 497.625
18 - 33 498.125
18 - 37 498.625
18 - 41 499.125
18 - 45 499.625
19 - 02 500.250
19 - 06 500.750
19 - 10 501.250
19 - 14 501.750
19 - 18 502.250
19 - 22 502.750
19 - 26 503.250
19 - 30 503.750
19 - 34 504.250
19 - 38 504.750
19 - 42 505.250
19 - 46 505.750
20 - 01 506.125
20 - 05 506.625
20 - 09 507.125
20 - 13 507.625
20 - 17 508.125
20 - 21 508.625
20 - 25 509.125
20 - 29 509.625
20 - 33 510.125
20 - 37 510.625
20 - 41 511.125
20 - 45 511.625
21 - 02 512.250
21 - 06 512.750
21 - 10 513.250
21 - 14 513.750
21 - 18 514.250
21 - 22 514.750
21 - 26 515.250
21 - 30 515.750
21 - 34 516.250
21 - 38 516.750
21 - 42 517.250
21 - 46 517.750

Guidance on the use of a multi-channel system using digital wireless system with analog wireless system
When building up the system with digital and analog wireless devices, use the conventional analog wireless channel groups. Set the
intervals between a digital channel and an analog channel to 375 kHz or more.
When building up a multi-channel system, Sony recommends that one of the following groups is selected to avoid mutual interference
from other Sony wireless microphones/transmitters:
– Groups 01 to 04 are for using 8 channels of transmitting frequencies in one TV channel.
– Groups 05 to 08 are for using 11 channels of transmitting frequencies in two TV channels.
– Group 09 is for using 16 channels of transmitting frequencies in four TV channels.
• On shaded channels in the tables below, digital wireless microphones cannot be used. The indication of these channels does not appear
in the display of the device.
• The reliability of this channel plan is assured when the RF power output of the transmitter/microphone is 1 mW or 10 mW and distances
of transmitters/microphones are 1 m (3.3 feet) or more.
• When the distances between transmitters and microphones need to be closer than the distances above, use a grouping system for multi-
channel systems that include both digital wireless and analog wireless devices.
Frequency unit: MHz
Grouping for digital wireless system with analog wireless system
Notes
Group 01
Grouping 8 channels
Channel Frequency
18 - 01 494.125
18 - 05 494.625
18 - 11 495.375
18 - 25 497.125
18 - 28 497.500
18 - 36 498.500
18 - 41 499.125
18 - 43 499.375
Group 02
Grouping 8 channels
Channel Frequency
19 - 03 500.375
19 - 13 501.625
19 - 18 502.250
19 - 26 503.250
19 - 37 504.625
19 - 40 505.000
19 - 44 505.500
19 - 46 505.750
Group 03
Grouping 8 channels
Channel Frequency
20 - 01 506.125
20 - 05 506.625
20 - 11 507.375
20 - 25 509.125
20 - 28 509.500
20 - 36 510.500
20 - 41 511.125
20 - 43 511.375
Group 04
Grouping 8 channels
Channel Frequency
21 - 03 512.375
21 - 13 513.625
21 - 18 514.250
21 - 26 515.250
21 - 37 516.625
21 - 40 517.000
21 - 44 517.500
21 - 46 517.750
Group 05
Grouping 11 channels
Channel Frequency
18 - 07 494.875
18 - 09 495.125
18 - 12 495.500
18 - 19 496.375
18 - 33 498.125
18 - 37 498.625
19 - 02 500.250
19 - 08 501.000
19 - 24 503.000
19 - 35 504.375
19 - 44 505.500
Group 06
Grouping 11 channels
Channel Frequency
20 - 05 506.625
20 - 14 507.750
20 - 25 509.125
20 - 41 511.125
20 - 47 511.875
21 - 12 513.500
21 - 16 514.000
21 - 30 515.750
21 - 37 516.625
21 - 40 517.000
21 - 42 517.250
Group 07
Grouping 11 channels
Channel Frequency
18 - 03 494.375
18 - 12 495.500
18 - 23 496.875
18 - 39 498.875
18 - 45 499.625
20 - 10 507.250
20 - 14 507.750
20 - 28 509.500
20 - 35 510.375
20 - 38 510.750
20 - 40 511.000
Group 08
Grouping 11 channels
Channel Frequency
19 - 08 501.000
19 - 10 501.250
19 - 13 501.625
19 - 20 502.500
19 - 34 504.250
19 - 38 504.750
21 - 03 512.375
21 - 09 513.125
21 - 25 515.125
21 - 36 516.500
21 - 45 517.625
Group 09
Grouping 16 channels
Channel Frequency
18 - 03 494.375
18 - 05 494.625
18 - 08 495.000
18 - 12 495.500
18 - 34 498.250
19 - 01 500.125
19 - 20 502.500
19 - 37 504.625
20 - 02 506.250
20 - 27 509.375
20 - 47 511.875
21 - 11 513.375
21 - 22 514.750
21 - 32 516.000
21 - 38 516.750
21 - 46 517.750

The following tables show the channels and frequencies that are selectable on your digital wireless microphones, transmitters, and
receivers.
For the setting procedures of the channel/frequency on your units, refer to the Operating Instructions supplied with the units.
The group 00 permits the units to operate on any of 47 carrier frequencies in 125-kHz steps of TV channels 22 to 25.
Simultaneous multi-channel operation is not assured with this group.
Frequency unit: MHz
TV2225
Group 00
Note
TV-22
Channel Frequency Channel Frequency
22 - 01 518.125 22 - 25 521.125
22 - 02 518.250 22 - 26 521.250
22 - 03 518.375 22 - 27 521.375
22 - 04 518.500 22 - 28 521.500
22 - 05 518.625 22 - 29 521.625
22 - 06 518.750 22 - 30 521.750
22 - 07 518.875 22 - 31 521.875
22 - 08 519.000 22 - 32 522.000
22 - 09 519.125 22 - 33 522.125
22 - 10 519.250 22 - 34 522.250
22 - 11 519.375 22 - 35 522.375
22 - 12 519.500 22 - 36 522.500
22 - 13 519.625 22 - 37 522.625
22 - 14 519.750 22 - 38 522.750
22 - 15 519.875 22 - 39 522.875
22 - 16 520.000 22 - 40 523.000
22 - 17 520.125 22 - 41 523.125
22 - 18 520.250 22 - 42 523.250
22 - 19 520.375 22 - 43 523.375
22 - 20 520.500 22 - 44 523.500
22 - 21 520.625 22 - 45 523.625
22 - 22 520.750 22 - 46 523.750
22 - 23 520.875 22 - 47 523.875
22 - 24 521.000
TV-23
Channel Frequency Channel Frequency
23 - 01 524.125 23 - 25 527.125
23 - 02 524.250 23 - 26 527.250
23 - 03 524.375 23 - 27 527.375
23 - 04 524.500 23 - 28 527.500
23 - 05 524.625 23 - 29 527.625
23 - 06 524.750 23 - 30 527.750
23 - 07 524.875 23 - 31 527.875
23 - 08 525.000 23 - 32 528.000
23 - 09 525.125 23 - 33 528.125
23 - 10 525.250 23 - 34 528.250
23 - 11 525.375 23 - 35 528.375
23 - 12 525.500 23 - 36 528.500
23 - 13 525.625 23 - 37 528.625
23 - 14 525.750 23 - 38 528.750
23 - 15 525.875 23 - 39 528.875
23 - 16 526.000 23 - 40 529.000
23 - 17 526.125 23 - 41 529.125
23 - 18 526.250 23 - 42 529.250
23 - 19 526.375 23 - 43 529.375
23 - 20 526.500 23 - 44 529.500
23 - 21 526.625 23 - 45 529.625
23 - 22 526.750 23 - 46 529.750
23 - 23 526.875 23 - 47 529.875
23 - 24 527.000
TV-24
Channel Frequency Channel Frequency
24 - 01 530.125 24 - 25 533.125
24 - 02 530.250 24 - 26 533.250
24 - 03 530.375 24 - 27 533.375
24 - 04 530.500 24 - 28 533.500
24 - 05 530.625 24 - 29 533.625
24 - 06 530.750 24 - 30 533.750
24 - 07 530.875 24 - 31 533.875
24 - 08 531.000 24 - 32 534.000
24 - 09 531.125 24 - 33 534.125
24 - 10 531.250 24 - 34 534.250
24 - 11 531.375 24 - 35 534.375
24 - 12 531.500 24 - 36 534.500
24 - 13 531.625 24 - 37 534.625
24 - 14 531.750 24 - 38 534.750
24 - 15 531.875 24 - 39 534.875
24 - 16 532.000 24 - 40 535.000
24 - 17 532.125 24 - 41 535.125
24 - 18 532.250 24 - 42 535.250
24 - 19 532.375 24 - 43 535.375
24 - 20 532.500 24 - 44 535.500
24 - 21 532.625 24 - 45 535.625
24 - 22 532.750 24 - 46 535.750
24 - 23 532.875 24 - 47 535.875
24 - 24 533.000
TV-25
Channel Frequency Channel Frequency
25 - 01 536.125 25 - 25 539.125
25 - 02 536.250 25 - 26 539.250
25 - 03 536.375 25 - 27 539.375
25 - 04 536.500 25 - 28 539.500
25 - 05 536.625 25 - 29 539.625
25 - 06 536.750 25 - 30 539.750
25 - 07 536.875 25 - 31 539.875
25 - 08 537.000 25 - 32 540.000
25 - 09 537.125 25 - 33 540.125
25 - 10 537.250 25 - 34 540.250
25 - 11 537.375 25 - 35 540.375
25 - 12 537.500 25 - 36 540.500
25 - 13 537.625 25 - 37 540.625
25 - 14 537.750 25 - 38 540.750
25 - 15 537.875 25 - 39 540.875
25 - 16 538.000 25 - 40 541.000
25 - 17 538.125 25 - 41 541.125
25 - 18 538.250 25 - 42 541.250
25 - 19 538.375 25 - 43 541.375
25 - 20 538.500 25 - 44 541.500
25 - 21 538.625 25 - 45 541.625
25 - 22 538.750 25 - 46 541.750
25 - 23 538.875 25 - 47 541.875
25 - 24 539.000

Guidance on the use of a multi-channel system using digital wireless system
When building up the system with digital wireless devices only, channel intervals can be fixed. No special calculations are necessary to
avoid intermodulations. Set channel intervals to 375 kHz or more.
When building up a multi-channel system, Sony recommends that one of the following groups is selected to avoid mutual interference
from other Sony wireless microphones/transmitters:
– Groups D1 to D4 are for using 12 channels of transmitting frequencies in one TV channel.
– Groups D5 to D8 are for using 24 channels of transmitting frequencies in two TV channels.
– Group D9 is for using 48 channels of transmitting frequencies in four TV channels.
• The reliability of this channel plan is assured when the RF power output of the transmitter/microphone is 1 mW or 10 mW and distances
of transmitters/microphones are 1 m (3.3 feet) or more.
• When the distances between transmitters and microphones need to be closer than the distances above, use a grouping system for multi-
channel systems that include both digital wireless and analog wireless devices.
Frequency unit: MHz
Grouping for digital wireless system
Notes
Group D1
Grouping 12 channels
Channel Frequency
22 - 02 518.250
22 - 06 518.750
22 - 10 519.250
22 - 14 519.750
22 - 18 520.250
22 - 22 520.750
22 - 26 521.250
22 - 30 521.750
22 - 34 522.250
22 - 38 522.750
22 - 42 523.250
22 - 46 523.750
Group D2
Grouping 12 channels
Channel Frequency
23 - 02 524.250
23 - 06 524.750
23 - 10 525.250
23 - 14 525.750
23 - 18 526.250
23 - 22 526.750
23 - 26 527.250
23 - 30 527.750
23 - 34 528.250
23 - 38 528.750
23 - 42 529.250
23 - 46 529.750
Group D3
Grouping 12 channels
Channel Frequency
24 - 02 530.250
24 - 06 530.750
24 - 10 531.250
24 - 14 531.750
24 - 18 532.250
24 - 22 532.750
24 - 26 533.250
24 - 30 533.750
24 - 34 534.250
24 - 38 534.750
24 - 42 535.250
24 - 46 535.750
Group D4
Grouping 12 channels
Channel Frequency
25 - 02 536.250
25 - 06 536.750
25 - 10 537.250
25 - 14 537.750
25 - 18 538.250
25 - 22 538.750
25 - 26 539.250
25 - 30 539.750
25 - 34 540.250
25 - 38 540.750
25 - 42 541.250
25 - 46 541.750
Group D5
Grouping 24 channels
Channel Frequency
22 - 01 518.125
22 - 05 518.625
22 - 09 519.125
22 - 13 519.625
22 - 17 520.125
22 - 21 520.625
22 - 25 521.125
22 - 29 521.625
22 - 33 522.125
22 - 37 522.625
22 - 41 523.125
22 - 45 523.625
23 - 02 524.250
23 - 06 524.750
23 - 10 525.250
23 - 14 525.750
23 - 18 526.250
23 - 22 526.750
23 - 26 527.250
23 - 30 527.750
23 - 34 528.250
23 - 38 528.750
23 - 42 529.250
23 - 46 529.750
Group D6
Grouping 24 channels
Channel Frequency
24 - 01 530.125
24 - 05 530.625
24 - 09 531.125
24 - 13 531.625
24 - 17 532.125
24 - 21 532.625
24 - 25 533.125
24 - 29 533.625
24 - 33 534.125
24 - 37 534.625
24 - 41 535.125
24 - 45 535.625
25 - 02 536.250
25 - 06 536.750
25 - 10 537.250
25 - 14 537.750
25 - 18 538.250
25 - 22 538.750
25 - 26 539.250
25 - 30 539.750
25 - 34 540.250
25 - 38 540.750
25 - 42 541.250
25 - 46 541.750
