Sound Sation MHL-12-12W-RGBW User manual

MHL-12-12W-RGBW
12*12W RGBW (four in one)
LED Fancy Beam Moving Head Light
USER'S MANUAL
Please read this manual carefully and proper take care of this manual.

2
ENGLISH
Dear customer,
First of all thanks far purchasing a SOUNDSATION® product. Our mission
is to satisfy all possible needs of musical instrument and professional audio
users offering a wide range of products using the latest technologies.
We hope you will be satised with this item and, if you want to collaborate, we
are looking for a feedback from you about the operation of the product and
possible improvements to introduce in the next future. Go to our website www.
soundsationmusic.com and send an e-mail with your opinion, this will help
us to build instruments ever closer to customer’s real requirements.
One last thing: read this manual before using the instrument, an incorrect
operation can cause damages to you and to the unit. Take care!
The SOUNDSATION Team

3
ENGLISH
TABLE OF CONTENTS
1. GETTING STARTED .................................................................................................5
1.1 Important Safety Symbols ....................................................................................5
1.2 Important Safety Instructions ...............................................................................5
1.3 Introduction ............................................................................................................7
1.4 Before You Start ....................................................................................................7
2.1 FUNCTION ..............................................................................................................8
2.2 Machine Connection .............................................................................................9
3. REFERENCE ..........................................................................................................10
4. WARRANTY AND SERVICE ..................................................................................12
5. WARNING ..............................................................................................................13

4
ENGLISH

5
ENGLISH
1. GETTING STARTED
1.1 Important Safety Symbols
The symbol is used to indicate that some hazardous live termi-
nals are involved within this apparatus, even under the normal
operating conditions, which may be sufcient to constitute the
risk of electric shock or death.
The symbol is used in the service documentation to indicate
that specic component shall be replaced only by the compo-
nent specied in that documentation for safety reasons.
Protective grounding terminal
Alternating current/voltage
Hazardous live terminal
Denotes the apparatus is turned on
Denotes the apparatus is turned off
WARNING: Describes precautions that should be observed to prevent the
danger of injury or death to the operator.
CAUTION: Describes precautions that should be observed to prevent dan-
ger of the apparatus.
1.2 Important Safety Instructions
fRead these instructions
fKeep these instructions
fHeed all warning
fFollow all instructions
Water / Moisture
This lighting is intended to indoor use only. To prevent risk of re or shock,
do not expose xture to rain or moisture. Make sure there are no ammable,

6
ENGLISH
MHL-12 User’s manual
explosive or corrosive materials surrounded in 10 meters while operating.
Heat
The apparatus should be located away from heat sources such as radiators,
stoves or other appliances that produce heat. Fixture may carry high heat, do
not aim at objective exceeding 2 minutes.
Ventilation
The unit must be installed in a location with adequate ventilation, at least 5m
away from adjacent surfaces. Be sure that no ventilation slots are blocked.
Object and Liquid Entry
Objects do not fall into and liquids are not spilled into the inside of the appara-
tus for safety.
Installation
Always secure xture using a safety chain and carrying handles. Never carry
the xture by its cord.
Power Cord and Plug
Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two poles; a grounding-type plug has two poles and a third
grounding terminal. The third prong is provided for your safety. If the provided
plug does not t into your outlet, refer to an electrician for replacement.
Power Supply
Always make sure that you are connecting to the proper voltage and the line
voltage not higher than stated on the decal or rear panel of the xture. Unplug
this apparatus during lightning storms or when unused for long periods of time.
Fuse
To prevent the risk of re and damaging the unit, please use only of the rec-
ommended fuse type as described in the manual. Before replacing the fuse,
make sure the unit turned off and disconnected from the AC outlet.
Electrical Connection
Always disconnect from the power source before servicing or replacing fuse/
lamp and be sure to replace with same fuse/lamp size and type. Cut off power
before moving, repairing and cleaning the machine. Improper electrical wiring
may invalidate the product warranty.
To avoid electric shock, all xtures must be connected to circuits with a sui-
table ground.
Do not power on and power off the xture in a short time.

7
ENGLISH
MHL-12 User’s manual
DMX connection
When use DMX controller, please make sure that there is no interference
sources (e.g. intercom, high frequency radio waves and radiation source.
Cleaning
Clean only with a dry cloth. Do not use any solvents such as benzol or alcohol.
Servicing
In case of failure or misfunction occurred, stop using the unit immediately.
Never try to repair the unit by yourself. Repairs carried out by unskilled people
can lead to damage or malfunction. Please contact the nearest authorized
technical assistance center. Buy the same spare parts/components from ma-
nufacturer directly.
Any damage that cased by violating this manual is out of insurance, our com-
pany will not take the responsibility.
Warning
Avoid direct eye exposure to the light source while it is on.
1.3 Introduction
Thanks for purchasing our MHL-12-12W-RGBW Fancy Beam Moving Head
Light.
This user manual is made to provide both an overview of the controls, as well
as information on how to use them. In order to help you understand the links
between the various controls, we have gathered in groups according to their
functions.
1.4 Before You Start
1.4.1 UNPACKING
Carefully unpack the box and check the contents to ensure that all parts are
present and in good conditions.
• 1pc xture
• 1pc User Manual
• 1pc Power Cable
If anything damaged during transit, notify the shipper immediately and keep
the packing material for inspection. Again, please save the carton and all

8
ENGLISH
MHL-12 User’s manual
packing materials. If the xture must be returned to manufacturer, it is impor-
tant that the xture be returned in the original manufacturer box and packing.
1.4.2 Getting started
Make sure there is enough space around the unit for proper ventilation and
prevent overheating; do not place the unit on top of hot devices such as
radiators or power ampliers. The console is connected to mains through the
supplied cable. The product meets the required safety standards. Blown fuses
must be replaced with fuses of the same type and specication.
Make sure that all units must be properly grounded. For your safe-
ty, you should never remove any ground connector from electrical
devices or power cables, or make them inoperative.
Our products are subject to a process of continual further development. There-
fore modications to the technical features remain subject to change without
further notice.
2.1 Function
12 pieces multi-angle lens, which can rotate clockwise or counter-clockwise.
When rotating, it shows out fantastic effects: 24 pieces small beam or combine
with a big beam, with the effect of point- shaped which can change to ower
point or combine with a big ower-shaped

9
ENGLISH
MHL-12 User’s manual
2.2 Machine Connection
2.2.1 Cable Connectors
Cables must have a male XLR connector on one end and a female XLR con-
nector on the other end.
DMX use of XLR connectors
1 = Ground / Shield
2 = DMX +
3 = DMX -
INPUT OUTPUT
A word on termination: DMX is a resilient communication protocol, however
errors still occasionally occur. Termination reduces signal errors, and there-
fore best practices include use of a terminator in all circumstances. If you are
experiencing problems with erratic xture behavior, especially over long signal
cable runs, a terminator may help improve performance.
120ohm, 1/4W
resistor
To build your own DMX Terminator: Obtain a 120-ohm, 1/4-watt resistor, and
wire it between pins 2&3 of the last xture. They are also readily available
from specialty retailers.
 Complimentarysignalcablecantransmitssignalsto20unitxtures
atmost.Signalamplierisamusttoconnectmorextures.

10
ENGLISH
MHL-12 User’s manual
3. REFERENCE
16 DMX Channels
DMX Channel Description:
DMX
Channel Function Data Function Description
CH1 Pan 0--255 Pan
CH2 Tilt 0--255 Tilt
CH3 Pan Fine 0--255 Pan ne
CH4 Tilt Fine 0--255 Tilt ne
CH5 Lens Rotation Speed 0--255 Form fast to slow
CH6 Lens Rotation 0--255 Lens rotation
CH7 Dimmer 0--255 Dimmer from dark to bright
CH8 Strobe 0--255 Strobe from slow to fast
CH9 Red 0--255 Red
CH10 Green 0--255 Green
CH11 Blue 0--255 Blue
CH12 White 0--255 White
CH13 Manual Mixing Colors 0--255 Manual mixing colors
CH14 Inside Program 0--255 Inside program
CH15 Inside Program Speed 0--255 Inside program speed from fast to
slow
CH16 Reset 0--255 Renew factory state
SPECIFICATION
Voltage: AC100V-240V
Frequency: 50/60Hz
Power Consumption: 180 W (max at full output)
LED: 12 pieces 12W RGBW LED
Pan: 540° Tilt: 270°

11
ENGLISH
MHL-12 User’s manual
Declare
This product, which is at the factory, performance in good condition, and
completely packed. All users shall strictly comply with the above warnings and
instructions, any damage caused by the misuse is not within our company
guarantee, to ignore operation manual and cause of the failure and problems
which is not in the scope of dealer is responsible for. Thank you for your coop-
eration!
Our company reserves the right to change technical parameters without notice.

12
ENGLISH
MHL-12 User’s manual
4. WARRANTY AND SERVICE
All SOUNDSATION products feature a limited two-year warranty. This two-
year warranty is specic to the date of purchase as shown on your purchase
receipt.
The following cases/components are not covered from the above warranty:
• Any accessories supplied with the product
• Improper use
• Fault due to wear and tear
• Any modication of the product effected by the user or a third party
SOUNDSATION shall satisfy the warranty obligations by remedying any
material or manufacturing faults free of charge at SOUNDSATION’s discretion
either by repair or by exchanging individual parts or the entire appliance. Any
defective parts removed from a product during the course of a warranty claim
shall become the property of SOUNDSATION.
While under warranty period, defective products may be returned to your local
SOUNDSATION dealer together with original proof of purchase. To avoid any
damages in transit, please use the original packaging if available. Alternatively
you can send the product to SOUNDSATION SERVICE CENTER – Via Enzo
Ferrari , 10 – 62017 Porto Recanati - Italy . In order to send a product to ser-
vice center you need an RMA number. Shipping charges have to be covered
by the owner of the product.
For further information please visit www.soundsationmusic.com

13
ENGLISH
MHL-12 User’s manual
5. WARNING
PLEASE READ CAREFULLY – EU and EEA (Norway, Iceland and Liechten-
stein) only
This symbol indicates that this product is not to be disposed of with your
household waste, according to the WEEE Directive (2202/96/EC) and your
national law.
This product should be handed over to a designated collection point, e.g., on
an authorized one-for-one basis when you buy a new similar product or to an
authorized collection site for recycling waste electrical and electronic equip-
ment (WEEE).
Improper handling of this type of waste could have a possible negative impact
on the environment and human health due to potentially hazardous substanc-
es that are generally associated with EEE. At the same time, your cooperation
in the correct disposal of this product will contribute to the effective usage of
natural resources.
For more information about where you can drop off your waste equipment
for recycling, please contact your local city ofce, waste authority, approved
WEEE scheme or your household waste disposal service.
This product is imported in EU by
FRENEXPORT SPA – Via Enzo Ferrari, 10 - 62017 Porto Recanati - Italy
www.soundsationmusic.com
Soundsation® is a registered trademark of FRENEXPORT SPA - Italy

www.soundsationmusic.com
Ver 1.0 - Dec. 2015
