Specac Quest ATR GS10800 Series User manual

Quick Start Guide For Quest ATR
Accessory P/N GS10800 Series
This Quick Start Guide is intended to help you through the steps required for the correct first time installation and
alignment of the Quest ATR Accessory into your IR spectrometer system. This guide is a supplement to the
Instruction Manual provided for the accessory itself where more detailed information can e found.
Step 1 – Install t e Benc mark™ Baseplate into your spectrometer
The Benchmark™ aseplate supplied allows the Quest ATR Accessory to e
positioned correctly in the sample compartment of your specific spectrometer.
Please consult the relevant page of the Benchmark™ Baseplate Installation Guide
instruction manual (2I-549-000-7) if you need more information.
Step 2 – Fit t e Quest ATR Accessory (Optical Unit) to t e Baseplate
The Quest ATR Accessory can now e fitted onto the aseplate.
The Optical Unit is placed over the aseplate support pillars and
the central front Fixing Thum screw tightened into the central pillar.
Step 3 – Fit t e ATR Crystal Puck to t e Optical Unit
The Quest ATR accessory is normally supplied with the ATR Crystal Puck already in place
on the Optical Unit. Release the pressure tower and remove any packing material on the
diamond.
Top View of Crystal Puck Underside View of Crystal Puck
If the puck has not already een fitted, then place it on the optical unit as shown. Take
care that the Notc on the underside of the Crystal Puck locates with the small pin on the
top and to the front of the Optical Unit. The Crystal Puck is held in position y three magnet
catches around the top aperture of the Optical Unit.
Notc
Fixi
ng
T umbscrew

Step 4 – Remove t e Front Cover
Use the 3.0mm all driver (supplied) to undo the two captive screws shown and pull
the top of the cover forward to remove it.
Front Cover Plate Removed
Step 5 – Alignment Procedure
With the spectrometer in its energy monitoring mode, use the 2.5mm all driver (supplied) to adjust the alignment
screws in the following sequence (the screws are identified in the diagram opposite). Rotate each screw in turn (one
at a time) to o tain the maximum energy level.
Screw sequence 1, 2, 3, 4, 5, 6.
Do not adjust any ot er screws
If the energy has increased significantly after these
adjustments, repeat them again in the same order. This will
ensure that the accessory is in its optimum alignment.
Remem er, this alignment process only has to e done
once when first setting up the accessory in the spectrometer
– so it is worth spending a small amount of time now in
order to get the est performance from it in the future.
Step 6 – Replace t e Front Cover
Once aligned, the front cover can e replaced to maintain a sta le environment inside the accessory. To fit the purge
ellows or a dry air supply to purge the accessory, refer to page 18 of the Quest ATR Accessory instruction manual.
Step 7 – It’s Ready to Use!
For safety information and detailed instructions on getting the est from your Quest ATR Accessory please refer to
the Quest ATR Accessory instruction manual 2I-10800-6 supplied.
Specac Ltd
River House, 97 Cray Avenue,
Orpington
Kent BR5 4HE
Tel: [phone]
Fax: [phone]
www.specac.com
QS-10800-6
Captive
Screws
1
2
5
4
6
3
