Spectrum 22499 User manual

(1) 0118481
60” Worksurface
(1) 057614
Cord Channel
Assembled
Legs
0118503 Page 1 of 3
Assembly Instructions
Important
Before you begin, please make sure all parts and proper quantities
are included. Any parts damaged during shipment must be reported
within 15 days of receipt. To report information regarding damage, to
purchase parts or accessories, or if you have any questions, please
contact us at:
www.spectrumfurniture.com
715-723-6750, 800-235-1262
Thank you for purchasing Spectrum products!
60” ADA Desk With Crank
22499
Phillips
Screwdriver
Tools Required
(4) 026064
1/4-20 x 5/8”
PHMS
1. Assemble Legs
1. Assemble the legs according to the leg
manufacturer instructions. Figure 1.
(4) 041289
1/4-20 x 1-3/4”
PHMS
(2) 043771
1/4-20 x 2”
FHMS painted
(2) 052397
T-supports
(1) 057615
60” chair rail
(1) 0118431
Desk legs-crank
5mm Hex
Wrench
Figure 1

3. Install T-supports
1. Align the T-supports with the worksurface mounting holes
as shown. Figure 3.
2. Tighten screws securely.
0118503 Page 2 of 3
Figure 3
T-Support
T-Support
(2) 1/4-20 x 1-3/4” PHMS
(2) 1/4-20 x 1-3/4” PHMS
Figure 2
Assembled
Legs
Worksurface
2. Attach Legs to Worksurface
1. Place the worksurface top-side down onto a non-abrasive surface.
2. Align the assembled legs with the worksurface mounting holes
and attach with the screws included with the legs. Be sure the
crank is on the bull-nose edge side of the worksurface. Figure 2.
3. Tighten screws securely.
Worksurface

4. Install Cord Channel
1. Align the cord channel mounting holes with the T-legs as shown. Figure 4.
2. Attach with (4) 1/4-20 x 5/8” PHM screws.
3. Tighten securely.
5. Install Chair Rail
1. Attach the chair rail using (2) 1/4-20 x 2” FHM screws. Figure 4.
2. Tighten screws securely.
6. Flip table upright
1. Carefully ip the desk upright-this may take several people.
0118503 Page 3 of 3
925 FIRST AVENUE, CHIPPEWA FALLS, WI 54729 / 800-235-1262 / 715-723-6750 / WWW.SPECTRUMFURNITURE.COM
Figure 4
Chair
Rail
1/4-20 x 2” FHMS
painted
1/4-20 x 2” FHMS
painted
Cord Channel
1/4-20 x 5/8” PHMS
1/4-20 x 5/8” PHMS
