SPRT POS901 User manual

POS901
Professional Kitchen Printer
User sManual
Ver1.00）
PDFcreated withpdfFactorytrialversion www.pdffactory.com

Content
Introduction...................................................................................................14
Chapter1Featureand Performance.............................................................14
1.1Print Performance.............................................................................14
1.2Print Paper........................................................................................15
1.3Print Font..........................................................................................15
1.4Interface............................................................................................15
1.5Print ControlCommands..................................................................15
1.6PowerSupply....................................................................................16
1.7OperationEnvironment.....................................................................16
Chapter2OperationSpecification.................................................................17
2.1PrinterAppearance..................................................................................17
2.2PaperInstallation.....................................................................................17
2.2.1PaperLoading......................................................................................17
2.2.2SolutiontoPaperJam..........................................................................19
2.3Interface..................................................................................................20
2.3.1SerialInterface.....................................................................................20
2.3.2Ethernet Interface.................................................................................20
2.3.3USB Interface.......................................................................................21
2.3.4CashDrawerInterface.........................................................................21
2.4ButtonsandIndicators.............................................................................21
2.5Self-test...................................................................................................23
2.6Otherworkingmodeofprinter.................................................................23
2.6.1HexadecimalPrinting...........................................................................24
2.6.2Printerparameterssetting....................................................................24
2.6.3EnteringSoftwareUpgradingMode.....................................................24
2.6.4RecoveringDefault IPAddress.............................................................25
2.7Wall-mounted Installation........................................................................25
AppendixA. ParametersSetting...................................................................27
PDFcreated withpdfFactorytrialversion www.pdffactory.com

Introduction
POS901 printerisonenewtype professionalforkitchen, whichhasthedust,
waterandinsectprooffunction.Itfeaturesinfastprinting-speed,low
printing-noise,highreliabilityand ribbon needless,whichavoidthe vexation of
regularmaintenance.
POS901printer:smallinoutlinedimension,simpleoperationandflexible
installingmethod.Usercan choosetheinstallingmethodaccordingtotheir
ownrequests.
Chapter1 Feature and Performance
1.1PrintPerformance
●Print method: direct line thermal
●Print paperwidth:79.5±0.5mm
●Print density: 8dots/mm, 576 dots/line
●Print speed: approx.180mm sec.
●Reliability
(1)Printingheadlife:100km
Usingcondition:
＊Whenprinting12 ×24 ANKcharacters,print50 lineseachtime,
intermittentprint repeatedly
＊Eachdot-line printing atthe sametimeshouldnotexceed 25%;Ineach
characterline,ononesamedot vertical,printingrepeatedlyshouldnotexceed
11times
＊Usespecifiedthermalpaper
Warning
ThisisaclassAproduct. Inthedomesticenvironment, this
productmaycauseradiointerference, inwhichcasetheuser
maybe requiredtotakeadaptablemeasures.
PDFcreated withpdfFactorytrialversion www.pdffactory.com

（2）Cutterlife: 500,000 cuts
Usingcondition:less than 30 cuts/minute
●Validprint width: 72mm
●Paperfeedingspeed: approx170mm/s
1.2PrintPaper
●Thermalpaperroll model:TF50KS－E（Japanpaperco.ltd）
AF50KS-E (JUJOTHERMAL)
●Thermalpaperroll:Width－－－ 79.5±0.5mm
OuterDiameter －－－ 80mm（max.）
InnerDiameter－－－ 13mm（min.）
Thickness －－－ 0.06mm～0.08mm
1.3PrintFont
●ANK CharacterSet
12×24 dots，1.5（W）×3.00（H）mm
●Chinese:
24×24 dots，3.00（W）×3.00（H）mm.
1.4Interface
●RS－232CSerialInterface：
DB-9socket(female),supportsXON/XOFF and TR/DSRprotocols.
Baudrate:1200,2400,4800,9600,19200,38400,57600,115200bps
adjustable。
Datastructure: 1initialbit +(7or8)databits+1stopbit.
Paritychecking: no parityorodd, even parityoptional.
●Ethernet Interface：
StandardEthernetRJ45interface.
●USB Interface：
StandardUSB interface
●CashDrawerControl
DC24V，1A，6-pinRJ-11socket.
1.5PrintControl Commands
●Characterprintcommands:supportdouble-widthand double-heightprinting
ofmanyANKcodepages,user-definedcharacterand Chinesecharacters.The
PDFcreated withpdfFactorytrialversion www.pdffactory.com

characterlinespacingisadjustable.
●Graphics printcommands: support printingdifferent densitybit-mapgraphics
and downloaded bit-map graphics.
●1-dimensionbarcodeprintcommands:supportUPC-A，UPC-E，EAN-13，
EAN-8，CODE39，ITF25，CODEBAR，CODE93，CODE128barcode printing.
●2-dimensionbarcodeprintcommands:supportPF417,QRCODE,
DARAMATRIXtwo-dimension barcodeprinting.
1.6PowerSupply
●Voltage:AC100V～240V
●Current: 2A
●Frequency: 47～63HZ
1.7Operation Environment
●Operationtemperature: 0～50;
Relativeoperation humidity: 10～80％
●Storagetemperature: -20～60;
Relativestoragehumidity: 10～90
1.8OutlineDimension
●156（L）mm×163（W）mm×211（H）mm
PDFcreated withpdfFactorytrialversion www.pdffactory.com

Chapter2 OperationSpecification
2.1PrinterAppearance
2.2PaperInstallation
2.2.1PaperLoading
POS901 printeruse80mmwidththermalpaperroll.Thermalpaperloading
PDFcreated withpdfFactorytrialversion www.pdffactory.com

stepsareasbelow:
1.Press theOpen doorbuttonandopenthepapercasecover.Asthebelow
picture,
Picture2.2
2.Takeoutthe usedpaperroll,putthepaperaxleintothenewpaperroll.As
showed inthebelowpicture(Picture2.3).Plspayattentiontothedirection of
paper, asshowed inthebelowpicture(Picture2.4)
Picture2.3Picture2.4
3.Pull outsomeinchpaperfromthepaperroll andputthepaperroll andthe
paperaxletogetherintothe slidewayofpapercase,asshowed inPicture2.5.
Then closethe papercasecover, asshowed inthePicture2.6.
Picture2.5
PDFcreated withpdfFactorytrialversion www.pdffactory.com

Picture2.6
4.Tearofftheextrapaper, asshowed inPicture2.7.
Picture2.7
1.Payattentiontothe direction of loadingpaper, makethe
printingsurfacefacetothe printinghead.
2.Pleasedon’tfeedordrawthepaperforwardsor
backwardswithhands.
3.Keep clean oftheprintinghead,avoidtoinfluencethe
printingquality.
2.2.2Solution toPaperJam
If cutterjam,press theopendoorbutton and openthe papercasecover,
takeoutthejammedpaper.Afterloadingthe paperagain,closethe paper
casecover.Then the cutterwill returntothe normalpositionautomatically.
！Caution!
PDFcreated withpdfFactorytrialversion www.pdffactory.com

2.3Interface
2.3.1SerialInterface
TheserialinterfaceofPOS901 printeriscompatiblewithRS-232C,supporting
DTR/DSRand XON/XOFF handshakingprotocols.ThesocketisDB-9female
socket, asshowed inPicture2.8,
6
9
1
5
Picture2.8
Pin
No.Signal NameSignal
Source
Description
2 TXD Printer Printertransmitscontrolcode X-ON/X-OFFand
datatohost
3RXD Host Printerreceivesdatafromhost
4 DSR HostThissignalmeanswhetherthehostcan receive
dataornot. “SPACE”meansthehostcanreceive
data; “MARK”meansthe hostcannotreceive
data.
5 GND —— SignalGround
6DTRPrinter Thissignalmeanswhethertheprinterisbusyor
not. “SPACE”meansthe printerisreadytoreceive
data; “MARK”meanstheprinteristoobusyto
receivedata.
8 RTSPrinter ThesamewithDTRsignal(Pin6).
2.3.2EthernetInterface
TheEthernetinterfacesocketforPOS901 isstandardJR45socket, which
adaptswith10M/100MandFull-duplexorHalf-duplexmode.
Protocolsupports:Ethernet802.3protocol;Upperlayerprotocolsincluding
TCP, ICMP, IP, ARP, HTTP.
PDFcreated withpdfFactorytrialversion www.pdffactory.com

2.3.3USBInterface
TheUSBinterfacesocketforPOS901isstandardUSB-Bsocket,whichabides
byprintertype protocolorvirtualserialinterfacetype protocol.The kindof
protocolwhichisused duringthe printerworking printertype orvirtualserial
interfacetype, canbeset upbysettingsoftwar.
2.3.4CashDrawerInterface
ThecashdrawerinterfaceofPOS901adoptsRJ-116-pinsocket,as
Picture2.9shows:
Picture2.9Cash Drawer Interface
Thepinassignment isasbelow：
PinNo.SignalDirection
1ChassisGround ——
2Cashdrawerdriversignal1Out
3Cashdraweron/offstatussignalIn
4+24V DC ——
5Cashdrawerdriversignal2 Out
6Signalground ——
2.4Buttonsand Indicators
Therearetwobuttons,oneinnerbuzzerand threeindicatorsonPOS901
printer.
【MODE】Self-testbutton.Press thebuttonovertwosecondstoprintthe
self-test of printer.
【FEED】Paper-feeding button.Thefunctionstatuson/offofthisbuttoncan
be setbyprintcommand.Duringthe fuction ofthisbutton ison,paperfeeds
intotheprinterwhen the【FEED】buttonispressed;whilepaperstopsfeeding
intothe printerwhen thebuttonisloosen.
BUZZER isused toindicatetheerrorstatusand papercutting. Thefunction of
buzzercan besettoerroralarm,papercuttingindicatingorbothavailable
PDFcreated withpdfFactorytrialversion www.pdffactory.com

throughthesettingofprintcommand.Errorstatustype issamewithERROR
indicator.
GreenPOWERindicator ispowerindicator.When POWERindicatorislight, it
meansthe printerison.
RedPAPEROUTindicator ispaperstatusindicator. Indicatorlightmeansthe
printerisout ofpaper.
RedERRORindicator iserrorstatusindicator.When theprinterisinnormal
workingstatus,redERRORindicatorisoff.Iftheindicatorflickers,itis
abnormalstatusalarm;whilethe indicatorispersistantlighting,itmeansthe
papercasecoverisopen when the printerisnotprinting.
If the ERRORindicatorflickersandthebuzzersound, itmeansthereiserrorin
printer.
Accordingtothedifferentflickertype,thedifferenterrortypesareasbelow,
1.Non-recoverableerror,thetimesofindicatorflickeringand buzzersounding
meanthe errortype, then persistentlighting.
2.Recoverableerror,thetimesofindicatorflickeringandbuzzersounding
meanthe errortype, then persistentindicator-off.
3.Auto-recoverableerror,the indicatorflickersand the buzzersounds
persistently.
4.Paperout, PAPEROUTindicatorlightsand the buzzersoundspersistently.
When thepapercasecoverisopen,whetherthepaperisout ornotwill not
be tested, but just testingwhetherthereispaperinprinter.
Thedetailsareasbelow,
a.Non-recoverableerror,theindicatorflickersseveraltimes,then
persistentlighting.The timesofflickeringmeanstheerrortype,
ERROR Type ERROR Description ERROR Indicator
Flickering Type
LED Flikers once：Internalmemory
reading and writing error
LED Flikers twice：over-voltage
LED Flikers three times：
under-voltage
LED Flikers fourtimes: CPU
execution error(wrong address)
LED Flikers five times: UIBerror
LED Flikers sixtimes: FLASH
writing error
LED Flikers seven times: parameter
writing error
Non-recoverable
error
LEDFlikers eight times:
Temperature testing circuiterror
PDFcreated withpdfFactorytrialversion www.pdffactory.com

b.Recoverableerror,indicatorflickersconstantly,thenpersistentoffforone
period.
ERROR Type ERROR Description ERROR IndicatorFlickering
Type
Recoverable
error LED Flikers once：Cutter
position error
c.Auto-recoverableerror,indicatorflickersconstantly,includingprintinghead
over-heat errorand uppercasecoveropening errorduringprinting.
2.5Self-test
Theself-testwill testwhetherthe printerisworkingnormally.Ifthe printercan
printthe self-testreceiptcorrectly,itmeansthe printerisinnormalcondition
excepttheinterfacewiththe host;otherwise,theprinterwill needtobe
repaired.
Theself-testwill printout: Softwareversion,Manufacturername,Printermodel,
Interfacetype and parameter,Defaultvalue ofeachparameter,96 characters
inASCII code,Defaultcodepagecontent(Language issettoEnglish)or
Chinesecharacterlibraryname(Languageisset toChinese), Barcode type.
Theself-testmethod:Aftertheprinterispoweron andinstandbystatus,hold
down【MODE】button over2seconds.At thistime,the printerwill printself-test
receipt.
2.6Otherworking modeofprinter
Besidesthe normalprintingmode,therearealsootherworkingmodesof
printer hexadecimalprinting,parameterssetting,softwareupgrading,default
IPaddress recovering,etc.Themethod of enteringotherworkingmodesisas
below:
When the printerisoff,openpapercasecoverfirstly,holddown 【FEED】
button and turnonthe printerpower.Then press 【FEED】button.The timesof
pressing【FEED】buttonwilldecide theworkingmode the printerwill enterinto.
Theflickeringtimesofred PAPEROUTindicatorwill showthe timesof
pressing【FEED】button.Closethe papercasecoverand the printerentersinto
the relatedworkingmode.
ERROR Type ERROR Description ERROR IndicatorFlickering
Type
Auto-recoverable
error
LED Flickers constantly: printing head
over-heat; uppercase coveropening error
during printing
PDFcreated withpdfFactorytrialversion www.pdffactory.com

2.6.1HexadecimalPrinting
Turnontheprinteraccordingtothe stepsbelow, it will enterintothemodelof
HexadecimalPrinting.
1.Openthepapercasecover
2.Holddown【FEED】button, turnonthepower
3.Closethepapercasecover
HexadecimalDump
Toterminatehexadecimaldump,
Press FEEDbutton three times.
Theabovemeansthatthe printerenteredintohexadecimalprintingmode.
Underthismode,all thereceived datawill be printed outinhexadecimal
numbers.Pressing【FEED】buttononce, thepaperfeedingone line.When
3timesarefinished, theprinterwill print “*** Completed ***”.The printerquit
hexadecimalprintingmode.
2.6.2Printerparameterssetting
Thisfunction isusedtoset somesimpleparametersofprinter.
Themethod ofentering intothe parameterssettingisasbelow,
When the printerisoff,openpapercasecoverfirstly,holddown 【FEED】
button andturnontheprinterpower.Afterthe statusindicatorand PAPER
OUTindicatorflickeralternately,loosen 【FEED】button.Thenpress【FEED】
button twiceand closethepapercasecover.Theprinterentersinto
parameterssettingmode,printsoutthefirstsettingavailableitemandits
currentvalue.Beforclosingpapercasecover,theflickeringtimesofPAPER
outindicatormeansthetimesofpressing【FEED】button.Aboutthedetailed
settingmethod,plscheck AppendixA.
Themethod ofquit theparameterssetting: Open the papercasecoverfirstly
and holddown【FEED】button.Thenclosethe papercasecoverand loosen
【FEED】button.SavethesettedparametersandquitParametersSetting
Mode.Enteringintonormalworkingmode.
If theprinterispoweredoffdirectly, thesettedparameterscan not be saved.
2.6.3Entering SoftwareUpgrading Mode
Thesoftwareofthisprintercanbe upgradedonline.ByEthernetinterface,the
printercanbe upgradedthroughwebsitesoftwarewhen theprinterisinnormal
workingmodeorupgradingmode.IfbyUSB interface,the printermustbe
upgraded throughspecialupgradingsoftwarewhen the printerisinupgrading
mode.The specialupgradingsoftwarecan bedownloadedfromourcompany
website.
Themethodofupgradingthroughwebsitesoftwareand web page:InputIP
address inthe addressbarofbrowserand operateaccordingtothe indications
on web page.Ifenteringupgradingmodethroughquick method,plsusethe
PDFcreated withpdfFactorytrialversion www.pdffactory.com

defaultIPaddress ofprinter(192.168.1.114);otherwise,plsusethe normal
workingIPaddress(Printed IPaddress on self-test receipt).
Themethodofentering upgradingmode:
When the printerisoff,openpapercasecoverfirstly,holddown 【FEED】
button andturnontheprinterpower.Afterthe statusindicatorand PAPER
OUTindicatorflickeralternately,loosen 【FEED】button.Then press 【FEED】
button fivetimesandclosethe papercasecover.Theprinterentersinto
SoftwareUpgradingMode.Inthiscase, the indicatorflickersonceasecond.
Themethodofquick entering:Whenthe printerisoff, openpapercasecover
firstly,holddown 【FEED】button and turnon theprinterpower.Then loosen
【FEED】button quickly.The printerentersintoSoftwareUpgrading Mode.In
thiscase, theindicatorflickersonceasecond.
Caution: thesoftwarecan be upgradedonline onlythroughEthernetorUSB
interface.
2.6.4Recovering DefaultIP Address
Ifthe IPaddress of printerisset tobeinvalidIPaddress, the printerwill be not
abletonormallyworkingthroughEthernet interface. Inthiscase, itwill need to
recoverdefaultIPaddress.
ThemethodofrecoveringdefaultIPaddress:When theprinterisoff,open
papercasecoverfirstly,holddown 【FEED】button and turnon the printer
power.Afterthestatusindicatorand PAPEROUTindicatorflickeralternately,
loosen 【FEED】button.Thenpress 【FEED】button fourtimesandclosethe
papercasecover.Theprinterwill print out thedefault IPaddress parameters.
2.7Wall-mounted Installation
1.Install twowall-mounted bucklestothe back side ofprinerbyscrews,as
showed inPicture2.10,
Picture2.10
2.Install the wall-mountedboardtothewallbyscrews.And hangthe printer
PDFcreated withpdfFactorytrialversion www.pdffactory.com

withbucklestothe wall-mountedboard.Asshowed inPicture2.11,
Picture2.11
PDFcreated withpdfFactorytrialversion www.pdffactory.com

AppendixA.Parameters Setting
Thisappendixisthe methodtosetprinterdefaultparameters
throughbuttons:
Setting instruction:Choosesetting item through “Papercasecover”
button.Whenpress “Papercasecover”buttononce,thesetting
itemsgoestothe nextand the printer printsoutthe currentvalue of
thistime.Choosethevalue ofsettingitemthrough【FEED】button.
Whenpress【FEED】buttononce,thesettingvalue goestothe next.
Primarysettings：
Paper casecoverPapercasecoverPaper casecoverPaper case cover
buttonbutton button button
paper casepaper casecover
coverbuttonbutton
paper case cover button
Baudrate
FEED FEED FEED
FEEDFEED
FEED FEED FEED
Language
FEED FEED
FEED
Font:
FEED
FEED
Density:
FEED FEED
FEED
Baudrate Density BuzzerFontLanguage
Blackmark
USBTypeChoosing
9600 576003840019200
4800 11520012002400
China English
China-BIG5
12×24 9×17
Medium
High Low
PDFcreated withpdfFactorytrialversion www.pdffactory.com

Buzzer:
FEED FEED FEED
FEED
Black Mark:
FEED
FEED
USBTypeChoosing:
FEED
FEED
OFF CutON
ErrorON ALLON
Off On
PrinterType VirtualSerial
Interface Type
PDFcreated withpdfFactorytrialversion www.pdffactory.com
