SPX OTC 1505A User manual

© SPX Corporation
Sheet No.
Issue Date: Rev. A 2-6-01
1507594 1 Jack Handle
2507593 1 Power Unit
3507595 1 Saddle
4507596 1 Rear Wheel (set of two)
5507597 1 Front Wheel (set of two)
6507598 1 Foot Pedal Return Spring
7507599 1 Lift Arm Return Spring (set of two)
8507600 1 Foot Pedal
Replacement Parts
507592 1 Seal Kit (not shown)
Parts List &
Operating Instructions
for: 1505A
Form No. 106562
Service Jack
Max. Capacity: 5 Tons
1 of 2
Item Part No.
No. No. Req'd Description
SPX Corporation
655 Eisenhower Drive
Owatonna, MN 55060-0995 USA
Phone: [phone]
Tech. Serv.: [phone]
Fax: [phone]
Order Entry: [phone]
Fax: [phone]
International Sales: [phone]
Fax: [phone]
WARNING: To prevent personal injury and damage to equipment,
•
Read, understand, and follow all instructions and safety precautions.
•
Before using the service jack to lift a vehicle, refer to the vehicle service manual for recommended lifting
surfaces on the vehicle chassis.
•
Wear eye protection that meets ANSI Z87.1 and OSHA standards.
•
Inspect the jack before each use; do not use the jack if it's damaged, altered, or in poor condition.
•
Use the jack for lifting purposes; use approved safety stands to support the axles before working on the
vehicle.
•
Never exceed the rated lifting capacity of the jack.
•
Use the jack on a hard, level surface. The jack must be free to roll without any obstructions while lifting or
lowering the vehicle. The wheels of the vehicle must be in the straight-ahead position, and the hand brake
must be released.
•
Center the axle on the jack saddle. Off-center loads can damage seals and cause jack failure.
•
Lift only dead weight. Do not move the jack while it is supporting a vehicle.
•
Stay clear of lifted loads. Use approved safety stands to support the axles before making repairs.
•
Do not adjust the safety valve.
•
Lower the jack slowly and carefully while watching the position of the jack saddle.
•
Use only approved hydraulic fluid (Chevron AW Hydraulic Oil MV or equivalent). The use of alcohol, hydraulic brake fluid,
or transmission oil could damage seals and result in jack failure.
Safety Precautions
This guide cannot cover every situation, so always do the job with safety first.
2
3
7
4
6
1
5
8
Parts List
7

Parts List & Operating Instructions Form No. 106562, Sheet 1 of 2, Back
Setup
ll
ll
l
ll
ll
l
ll
ll
l
Notch A
Notch B
Notch C
Assemble the Handle
1. Loosen the bolt on the handle socket.
2. Insert the handle.
3. Tighten the bolt.
Bleed Air from the Service Jack
Air can accumulate within a hydraulic system during shipment or after
prolongeduse.Thisentrappedaircausesthejacktorespondslowlyorfeel
"spongy." To remove the air:
1. Open the release valve by moving the control lever toward Notch C.
2. Pump the jack handle six full strokes.
3. Close the release valve by moving the control lever toward Notch A.
4. Pump the jack handle or foot pedal until the lift arm is fully extended.
5. Lowerthelift armby moving thecontrol levertowardnotch C.Ifthe jack
does not immediately respond, repeat Steps 2-4.
Operating Instructions
(Refer to Figure 1)
Control Lever in Notch “A”: Pumping action of handle or foot pedal will raise lift arm.
Control Lever in Notch “B”: Handle is locked; foot pedal will still raise lift arm.
Control Lever in Notch “C”: Releases lift arm.
Lifting Operation
1. Move the control lever to Notch A or B. (Refer to control lever positions listed above.)
2. Position the jack under the vehicle. Important: Use the vehicle manufacturer's recommended lifting points on the chassis.
3. Pump the jack handle or the foot pedal until the saddle touches the vehicle. Check the placement of the saddle lugs. Finish lifting
the vehicle.
4. Place approved safety stands under the vehicle at points that will provide stable support. Before working on the vehicle, SLOWLY
lower the vehicle onto the safety stands.
Lowering Operation
1. SLOWLY move the control lever to Notch C.
Figure 1
ll
ll
l
Control
Lever
Preventive Maintenance
Important:Dirtis thegreatestsinglecauseof failureinhydraulicunits.
Keep the service jack clean and well lubricated to prevent foreign
matter from entering the system. If the jack has been exposed to rain,
snow, sand, or grit, it must be cleaned before it is used.
1. Store the jack in a well-protected area where it will not be exposed to
corrosive vapors, abrasive dust, or any other harmful elements.
2. Refer to Figure 2, and regularly (at least once per month) lubricate the
moving parts shown.
3. Add grease to upper arm grease nipple (shown) every three months.
Figure 2
Grease Nipple

© SPX Corporation
Sheet No.
Issue Date: Rev. A 2-6-01
Parts List & Operating Instructions Form No. 106562
Troubleshooting Guide
Repair procedures must be performed in a dirt-free environment by qualified personnel who are familiar with this equipment.
Jack does not lift 1. Release valve is open. 1. Close release valve.
2. Low/no oil in reservoir. 2. Fill with oil and bleed system.
3. Air-locked system. 3. Bleed system.
4. Load is above capacity of jack. 4. Use correct equipment.
5. Delivery valve and/or bypass 5. Clean to remove dirt or foreign
valve not working correctly. matter. Replace oil.
6. Packing worn out or defective. 6. Install Seal Kit No. 507592.
Jack lifts only partially 1. Too much or not enough oil. 1. Check oil level.
Jack advances slowly 1. Pump not working correctly. 1. Install Seal Kit No. 507592, or replace
power unit.
2. Leaking seals. 2. Install Seal Kit No. 507592.
Jack lifts load, but doesn't hold 1. Cylinder packing is leaking. 1. Install Seal Kit No. 507592.
2. Valve not working correctly 2. Inspect valves. Clean and
(suction, delivery, release, or repair seat surfaces.
bypass).
3. Air-locked system. 3. Bleed system.
Jack leaks oil 1. Worn or damaged seals. 1. Install Seal Kit No. 507592.
Jack will not retract 1. Release valve is closed. 1. Open or clean release valve.
Jack retracts slowly 1. Cylinder damaged internally. 1. Send jack to OTC authorized
service center for repair.
2. Link section is binding. 2. Lubricate link section.
Trouble Cause Solution
2 of 2
a. Cracked or damaged housing e. Malfunctioning swivel heads or adjusting screws
b. Excessive wear, bending, or other damage f. Loose hardware
c. Leaking hydraulic fluid g. Modified or altered equipment
d. Scored or damaged piston rod
Preventive Maintenance contd.
4. Replace the oil in the reservoir at least once per year. To check the oil level, place the service jack on level ground and lower the
lift arm completely. Remove the filler plug located under the top shroud. The oil level should be within 3/8" of the filler plug hole. If
necessary, add approved anti-wear hydraulic jack oil, and install the filler plug again. Important: The use of alcohol, hydraulic
brake fluid, detergent motor oil, or transmission oil could damage the seals and result in jack failure.
5. Inspect the jack before each use. Take corrective action if any of the following problems are found:
