Stagg HEADBANGER10 MK3 User manual

USER MANUAL
HEADBANGER10

MK3
SLI MHW HB10
Table of Contents
1.BEFORE USAGE
This package contains
Unpacking
Introduction
Specifications
Features
2.INSTALLATION
Installation requirements
Power Connection
DMX Serial Data Link
3. OPERATION
Menu Map
Operating Instructions
DMX Channels

1. BEFORE USAGE
This package contains
•1x HeadBanger 10 MK3
•1x Power Cable
•1x User Manual
Unpacking
•Thank you for purchasing this product, it has been thoroughly tested
and has been shipped in perfect operating condition.
•Carefully check the packaging for damage that may have occurred during
shipping.
•If the packaging appears to be damaged, carefully inspect your fixture
for any damage and be sure all equipment necessary to operate the unit has
arrived intact.
•If damage has been found or parts are missing, please contact your vendor or
our customer support number for further instructions.
Introduction
•This fixture can operate in six different operating modes: DMX control, sound
active, automatic, manual setup, infrared remote control or in a Master/Slave
configuration
•This product comes with several built-in programs that can be used while
operating as a single unit or with multiple units linked in a master/slave
configuration
•For best results use fog or special effects smoke to enhance the beam
projection
•Warning! To prevent or reduce the risk of electrical shock or fire, do not

expose this unit to rain or moisture
•Warning! This product may cause severe eye damage. Avoid looking
directly into the light source at all times!
Specifications
•Voltage: AC100V～240V, 50-60Hz
•Power Consumption: 80W
•Light source: 7x 10W RGBW 4 in 1 LED
•Beam angle: 25°
•Max output @1m: 6100 Lux
•PAN 540°, Tilt 270° with 16bit control
•DMX channels: 9 or 14 DMX Channels
•Packing Dimensions: 210x210x140mm
•Net weight: 2,75 Kg
Features
•3PIN XLR DMX in and out
•IEC power in
•4 control modes: DMX512, automatic programs, sound control, master/slave
•LCD display for easy setup
•Indoor operation temperature range: -20°C～+40°C
•Dimmer: 0-100%
•Strobe 0-10Hz
Please Note: Specifications and improvements in the design of this unit and this
manual are subject to change without any prior written notice.
2. INSTALLATION
Installation requirements
•The product can be hung or placed on a solid surface
•If you install the light in a hanging position, always use a suitable mounting
position and a clamp or screw that is strong enough to hold the product
without stress. Always use a safety wire to secure the light.
•Always keep a distance of minimum 0.5 m (1.6 ft.) to all objects or persons
•Installation should always be done by a trained professional.
•Make sure the light always has good ventilation

•It is recommended to always use 110 Ohm DMX cable to prevent data
corruption of your DMX control signal
Power connection
The equipment has an auto-switching power supply that can accommodate a
wide range of input voltages. The only thing necessary to do before powering on
the unit is to make sure the line voltage you are applying is within the range of
accepted voltages. This equipment will accommodate between 100V and 240v
AC 50-60HZ. It is possible to daisy chain the power connection from one fixture
to the next. We recommend not connecting more than 30 fixtures on one 16A
220V socket and not more than 15 fixtures on one 16A 110V socket.
Color
Connection
PIN
Brown
AC live wire
1
Blue
AC zero curve
2
Green/Yellow
AC ground wire
3
DMX Serial Data Link
1. Connect the male 3pin DMX input of the first fixture to the female 3pin DMX
output of the lighting controller using 110 Ohm DMX cable, for example a Stagg
Commandor 10 (skip this step when not using a controller)
2. Connect the output of the first fixture to the input of the next fixture using 110
Ohm DMX cable. Repeat this process until you reach your last fixture. Here it is
recommended to connect a DMX terminator to the output of the last fixture in the
chain.

3. OPERATION
Menu Map
Dxxx
DMXAddress
001-512
MAFA
Slow automatic mode
SLOU
Fast automatic mode
FASt
Master sound mode
MStS
Stand-Alone Control
MStc
Slave mode
SlAu
PAN
PAN normal mode
PAN
PAN reverse mode
rPAN
TIL
TILT normal mode
TIl
TILT reverse mode
rTIl
dIS
Normal display Mode
dIS
Reversed display
rdIS
14CH
14 channels mode
14CH
9 channels mode
9CH
PA54
Max pan rotation 540°
PA54
Max pan rotation 360°
PA36
Max pan rotation 180°
PA18
TI27
Max tilt rotation 270°
TI27
Max tilt rotation 180°
TI18
Max tilt rotation 90°
TI09
REST
Reset device
REST
LOAD
Load factory setting
LOAD

DMX daisy-chain example
Operating Instructions
Take note: All changes made to the unit become active and saved when pressing
the “OK” button. Screen turn automatically off after 5 seconds of inactivity. The
unit will then display the active running mode or the DMX address when DMX
input is detected.
DMX Address Setup
• Press MENU, until “Dxxx” is displayed, then press ENTER
•Change the DMX address by pressing UP or DOWN
•Press ENTER to save the DMX address

Modes Selection
•Press MENU, then UP or DOWN until one of the following mode is displayed,
then press ENTER
oMASL / SLOU: Master automatic slow mode. The HeadBanger
will play automatic sequences with slow movements.
oMAFA / FASt: Master automatic fast mode. The HeadBanger will
play automatic sequences with fast movements.
oMStS: Master sound mode. The HeadBanger will play automatic
sequences controlled by the ambient sound or music.
oMStc: Machine Stand-alone Control. Second automatic mode to
use the HeadBanger as stand-alone machine without any slaves
in the daisy-chain
oSlAu: Slave mode. This unit will follow the “Master” behavior of
the daisy chain.
•Select your desired mode with UP or DOWN and press ENTER to confirm.
Tilt and pan reverse mode
•Press MENU, then UP or DOWN until “Pan” or “TIL” is displayed, then press
ENTER.
•"rPan" or “rTIL”: The unit inverts the pan (horizontal) or tilt (vertical) movement
(up becomes down and left becomes right)
•"Pan" or “TIL”: The unit's PAN movement is run normally.
•Press ENTER to confirm
Display Inversion
•Press MENU, then UP or DOWN until “DISP” or “rDIS” is displayed, then
press ENTER
•By pressing ENTER, the unit's display can be inverted so that when the light
is hung upside-down, the display will still be properly readable by the user.
Channels modes
•Press MENU, then UP or DOWN until “14CH” or “9CH” is displayed, then
press ENTER
•You can choose between 9 or 14 dmx channels modes using the UP or
DOWN buttons, press ENTER to confirm.
9 Channels

Channel
function
1
0-255
Pan
2
0-255
Tilt
3
0-7
8-134
135-239
240-255
None
Dimmer
Strobe
Full on
4
0-255
R
5
0-255
G
6
0-255
B
7
0-255
W
8
0-255
Movements Speed
9
150-200
Reset
14 Channels
Channel
Function
1
0-255
Pan
2
0-255
Pan fine
3
0-255
Tilt
4
0-255
Tilt fine
5
0-255
Movements speed
6
0-7
8-134
135-239
240-255
None
Dimmer
Strobe
Full on
7
0-255
R
8
0-255
G
9
0-255
B
10
0-255
W
11
0-7
8-21
22-34
35-49
Color1
Color2
Color3
Color4

50-63
64-77
78-91
92-105
106-119
120-134
135-147
148-161
162-175
176-189
190-203
204-217
218-231
232-255
Color5
Color6
Color7
Color8
Color9
Color10
Color11
Color12
Color13
Color14
Color15
Color16
Color17
Color Jump change
12
0-255
Speed
13
0-7
8-22
23-37
38-53
54-67
68-82
83-97
98-112
113-127
128-142
143-157
158-172
173-187
188-202
203-217
218-232
233-255
No function
Auto 1
Auto 2
Auto 3
Auto 4
Auto 5
Auto 6
Auto 7
Auto 8
Sound 1
Sound 2
Sound 3
Sound 4
Sound 5
Sound 6
Sound 7
Sound 8
14
150-255
Reset
Max PAN Rotation Setup
•Press MENU, then Up or DOWN until “PAxx“ is displayed, then press ENTER
•You can reduce the maximum horizontal rotation range to 540° (PA54), 360°
(PA36) or 180° (PA18) using the UP or DOWN buttons, press ENTER to
confirm.

Max Tilt Rotation Setup
•Press MENU, then Up or DOWN until “TIxx“ is displayed, then press ENTER
•You can reduce the maximum vertical rotation range to 270° (TI27), 180°
(TI18) or 90° (TI09) using the UP or DOWN buttons, press ENTER to confirm.
.
Reset
•Press MENU, then UP or DOWN until "REST" is displayed, then press
ENTER
•The unit will reboot and perform a self-test program testing all the features
individually.
Reset Factory Settings
•Press MENU, then UP or DOWN until "LOAD" is displayed, then press
ENTER
•The unit will reboot and load factory settings.
