01/ Safety Instructions
WARNING
Please keep this User Guide for future consultation. If you sell the unit to another user, be
sure that they also receive this instruction manual.
Important:
Damages caused by the disregard of this user manual are not subject to warranty. The dealer
will not accept liability for any resulting defects or problems.
Unpack and check carefully to ensure that there is no transportation damage before
using the unit.
This product is suitable for wet locations. Do not immerse in water.
DO install and operate by qualified operator.
DO NOT allow children to operate the fixture.
Use safety chain when fixing the unit. Handle the unit by carrying its base instead of
head only.
The unit must be installed in a location with adequate ventilation, at least 50cm from
adjacent surfaces.
Be sure that no ventilation slots is blocked, otherwise the unit will be overheated.
Before operation, ensure that you are connecting this product to the proper voltage in
accordance with the specifications in this manual or on the product’s specification label.
It’s important to ground the yellow/green conductor to earth in order to avoid electric
shock.
Minimum ambient temperature TA: 0℃. Maximum ambient temperature TA: 40℃. Do
not operate this product at a lower or higher temperature.
DO NOT connect the device to any dimmer pack.
Keep flammable materials away from the fixture while operating to avoid fire hazard.
Make sure the power cord is not crimped or damaged; replace it immediately if damaged.
Unit’s surface temperature may reach up to 65 ℃. DO NOT touch the housing
bare-handed during its operation.
Avoid any flammable liquids, water or metal from entering the unit. Once it happens, cut
Please read the instruction carefully which includes important information
about the installation, usage and maintenance.

- 3 -
off the mains power immediately.
DO NOT operate in a dirty or dusty environment. DO clean the fixture regularly.
DO NOT touch any wire during operation as there might be a hazard of electric shock.
Avoid entanglement of the power cord with other wires.
The minimum distance to objects/surface must be more than 0.5 meters.
In the event of serious operating problem, stop using the unit immediately.
Never turn on and off the unit time after time.
The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly
damaged.
DO NOT open the housing as there are no user serviceable parts inside.
DO NOT attempt to operate this unit if it becomes damaged. DO NOT attempt any
repairs yourself. Repairs carried out by unskilled people can lead to damage or
malfunction. Please contact the nearest authorized technical assistance center if needed.
Disconnect this product from its power source before servicing.
DO use the original packaging if the device is to be transported.
Avoid direct eye exposure to the light source while the product is on.
DO NOT operate this product if you see damage on the housing, shields, or cables. Have
the damaged parts replaced by an authorized technician at once.

- 4 -
01/ Consignes de sécurité
ATTENTION
Veuillez conserver ce guide de l'utilisateur pour une consultation future. Si vous vendez
l'appareil à un autre utilisateur, assurez-vous qu'il reçoive également ce manuel
d'instructions.
Important:
Les dommages causés par le non-respect de ce manuel d'utilisation ne sont pas couverts par la
garantie. Le revendeur n'acceptera aucune responsabilité pour les défauts ou problèmes qui en
résultent.
Déballez et vérifiez soigneusement qu'il n'y a pas de dommages dus au transport avant
d'utiliser l'appareil.
Ce produit convient aux endroits humides. Ne pas immerger dans l’eau.
L’installation et la mise en fonctionnement doit être effectué par un opérateur qualifié.
NE PAS permettre aux enfants d'utiliser l'appareil.
Utilisez une chaîne de sécurité lors de la fixation de l'unité. Manipulez l'appareil en
portant sa base au lieu de la tête uniquement.
L'unité doit être installée dans un endroit avec une ventilation adéquate, à au moins
50cm des surfaces adjacentes.
Assurez-vous qu'aucune fente d'aération du luminaire n'est obstruée, sinon il risque de
surchauffer.
Avant toute utilisation, assurez-vous que vous connectez ce luminaire à la tension
appropriée conformément aux spécifications que vous trouverez dans ce manuel ou sur
l'étiquette des spécifications collée sur la base du luminaire.
Il est important de relier le file jaune/vert à la terre afin d'éviter tout choc électrique.
Température ambiante minimale TA: 0℃. Température ambiante maximale TA: 40℃.
N'utilisez pas ce luminaire à des températures inférieures ou supérieures.
NE PAS connecter le luminaire à un pack de gradateurs.
Gardez les matériaux inflammables à l'écart du luminaire pendant le fonctionnement
pour éviter tout risque d'incendie.
Veuillez lire attentivement les instructions qui contiennent des informations
importantes sur l'installation, l'utilisation et l'entretien.

- 5 -
Assurez-vous que le cordon d'alimentation n'est pas pincé ou endommagé; remplacez-le
immédiatement s'il est endommagé.
La température de surface de l'unité peut atteindre 65℃. NE PAS toucher les capots à
mains nues pendant son fonctionnement.
Évitez que des liquides inflammables, de l'eau ou du métal ne pénètrent dans l'appareil. Si
cela se produit, coupez immédiatement l'alimentation secteur.
NE PAS utiliser le luminaire dans un environnement sale ou poussiéreux. Cette appareil
doit être nettoyer régulièrement.
NE touchez AUCUN file pendant le fonctionnement car il pourrait y avoir un risque de
choc électrique.
Évitez l'enchevêtrement du cordon d'alimentation avec d'autres fils.
La distance minimale de projection sur des objets ou sur des surfaces doit être supérieure
à 0.5 mètres.
En cas de problème de fonctionnement grave, arrêtez immédiatement d'utiliser l'appareil.
N'allumez et n'éteignez jamais ce luminaire à maintes reprises.
Le boîtier, les lentilles ou le filtre ultraviolet doivent être remplacés s'ils sont visiblement
endommagés.
NE PAS ouvrir le boîtier car il ne contient aucune pièce réparable par l'utilisateur.
NE PAS mettre ce luminaire en fonctionnement s'il est endommagé. N'effectuez pas de
réparations vous-même. Les réparations ne doivent être effectuées par des personnes
non qualifiées, cela peut entraîner des dommages ou des dysfonctionnements. Veuillez
contacter le centre d'assistance technique agréé le plus proche si nécessaire.
Débranchez ce produit du secteur avant de procéder à l'entretien.
Utiliser l'emballage d'origine si l'appareil doit être transporté.
Évitez une exposition directe des yeux à la source lumineuse lorsque le produit est
allumé.
N'utilisez PAS ce produit si vous constatez des dommages sur le boîtier, les blindages ou
les câbles. Faites remplacer immédiatement les pièces endommagées par un technicien
agréé.

- 6 -
02/ Technical Specifications
Power Voltage
100-240V~ 50/60Hz
Power Consumption
420W
Light Source
672x0.5W RGB LED
112x3W CW LED
Beam Angle
101° (RGB)
108° (CW)
Field Angle
149° (RGB)
152° (CW)
Dimmer/Strobe
0-100% smooth dimming; High output strobe effect
Control
DMX Channel
7/15/21/39/112/17/33/65/68/117/70
Channels
Control Mode
DMX512
RDM
Art-Net
sACN
Firmware Upgrade
Firmware Upgrade via DMX link
Construction
Display
OLED display
Data In/Out
5-pin IP XLR (3-pin IP XLR is optional)
RJ45 Connector
Power In/Out
Waterproof Power Connector in/out
Protection Rating
IP66
Description for power cord set should be used: Listed 5-15P or 6-15P plug molded with
SJTW flexible cord with rating: 300V, 105°C, VW-1, 16AWGx3C, molded with attachment
plug and cord connector model SAC3FX with rating 250VAC, 16A by "Ningbo Haishu
District Seetronic Electronic Co Ltd ". The length of power cord shall be at least 914mm (lt
is to be measured from the face of the attachment plug to the face of the Cord Connector).
Features
32 RGB LED zones can be controlled individually
16 CW LED zones can be controlled individually
Outstanding color mixing effect
Independent frost effect
Multiple fixtures can be split-jointed with tool-free junction buckle

- 7 -
2 x fixed clamps for 50mm truss (version with fixed clamps)
Dimensions
1000x192x237mm
(version with fixed clamps)
39.4"x7.6"x9.3"in
1000x90x124mm
(version without fixed clamps)
39.4"x3.5"x4.9"in
Weight
8.5kgs
(version with fixed clamps)
18.7lbs
7.5kgs
(version without fixed clamps)
16.5lbs
Version with fixed clamps:
Version without fixed clamps:
Photometric Diagram:

- 8 -
03/ Control Panel
1. Display
To show the various menus and the selected function
2. Buttons
MENU
To enter into move backward or leave the menu
UP
To go backward to move up in the menu
DOWN
To go forward to move down in the menu
ENTER
To perform the desired functions
3. POWER IN
To connect to supply power
4. DMX IN
For DMX512 link, use 5-pin XLR cable to link the unit and DMX
controller to input DMX signal (3-pin XLR cable is optional)
5. ETHERNET
Transfers fixture’s information to a main controller
6. POWER OUT
To connect to the next fixture
7. DMX OUT
For DMX512 link, use 5-pin XLR cable to link the next units to output
DMX signal (3-pin XLR cable is optional)

- 9 -
04/ Fixture Installation
DO install and operate by qualified operator. Fixture(s) should be installed in areas
outside walking paths, seating areas, or away from areas were unauthorized personnel
might reach the fixture by hand. NEVER stand directly below the fixture(s) when rigging,
removing or servicing.
Always ensure that the unit is firmly fixed to avoid vibration and slipping off during
operation. Ensure that the trussing or area of installation must be able to hold 10 times
the weight without any deformation. Always attach a safety cable that can hold at least
12 times the weight of the fixture whenever installing this fixture in a suspended
environment to ensure that the fixture will not fall if the clamp fails.
This fixture is fully operational in three different mounting positions: hanging on trussing,
mounted sideways on trussing, or fix on a flat level surface (such as the ground or a wall).
Always use and install the supplied safety cable as a safety measure to prevent accidental
damage and/or injury in the event the clamp fails.

- 10 -
Hanging the fixture:
Fix the fixture on a flat level surface (such as the ground or a wall):
1. Drill four expansion screw holes (for M12 expansion screws) on a flat level surface (such as
the ground or a wall) according to the size shown in Figure ①.
2. As shown in Figure ②, unscrew the washers and nuts of the expansion screws, and insert
the expansion screw tubes and screws into the drilled screw holes.
3. As shown in Figure ③, align the holes on the brackets of the fixture with the four screws,
then put the washers and nuts of the expansion screws in turn and tighten them with a
wrench.
4. After tightening the nuts, check whether the fixture is installed firmly, then adjust the
fixture to the required angle through the bracket knob.

- 11 -
Splicing multiple fixtures:
Introduction:
Steps for splicing the fixtures:
1. Press the reset button and the lock catch will pop up automatically.

- 12 -
2. Lift the bolt up and rotate it for 90 degrees, then release your hand.
3. Align and splice two fixtures. Lift the bolt up and rotate it for 90 degrees, then release your
hand and the bolt will be automatically inserted into the positioning point to lock the two
fixtures. Finally, check whether the bolt is locked in place.

- 13 -
Steps for installing the omega brackets to the fixture:

- 14 -
05/ How To Set The Unit
5.1 Main Functions
To access the control menus, press the [MENU] button.
Navigate the menu structure, using the [ENTER], [UP] and [DOWN] buttons.
To select a menu option or to confirm a selection, press the [ENTER] button.
To return to a higher level in the menu structure without making a change, press the
[MENU] button, or wait 30 seconds.
The main functions are shown below:
MENU
SUBMENU
OPTIONS
DMX Settings
DMX Address
1-506 (7 CH)
(Default=1)
1-498 (15 CH)
1-492 (21 CH)
1-474 (39 CH)
1-401 (112 CH)
1-496 (17 CH)
1-480 (33 CH)
1-448 (65 CH)
1-445 (68 CH)
1-396 (117 CH)
1-443 (70 CH)
Channel Mode
7 CH
15 CH
21 CH
39 CH
112 CH
17 CH
33 CH
65 CH
68 CH
117 CH
70 CH
The screen will be automatically locked if there is no operation for a long time, and can
be unlocked by long-pressing the [MENU] button.

- 15 -
MENU
SUBMENU
OPTIONS
No DMX Status
Hold
Blackout
Manual
View DMX Value
Connect Option
Auto
DMX
Art-Net
sACN
Network
IP Address
XXX.XXX.XXX.XXX
Subnet Mask
XXX.XXX.XXX.XXX
Art-Net Settings
Net
0-127
(Default=0)
Sub-Net
0-15
(Default =0)
Universe
0-15
(Default =0)
sACN Settings
sACN Universe
1-32000
(Default =1)
sACN Priority
0-200
(Default =100)
Fixture Settings
Dimmer Curve
Linear
Square Law
Inv SQ Law
S Curve
Dimmer Speed
Fast
Smooth
White Balance
Red 1
125-255
Green 1
125-255
Blue 1
125-255
Red 2
125-255
Green 2
125-255
Blue 2
125-255
Invert Pixel Order
Disable
Enable
Display Settings
Display Invert
No
Yes
Temperature Unit
°C
°F
Language
English
Chinese

- 16 -
MENU
SUBMENU
OPTIONS
Fixture Test
Auto Test
Manual Mode
Red
0-255
Green
0-255
Blue
0-255
White
0-255
Dimmer
0-255
Dimmer Fine
0-255
Duration
0-255
Rate
0-255
Frost
0-255
Information
Fixture Use Hour
LED Use Hour
Total LED Hour
LED On Hour
LED Hours Reset
Password=050
Temperature
Current
Max temp
LED 1
LED 2
Fan State
LED_Fan_1
LED_Fan_2
Firmware Version
RDM UID
Error Logs
Fixture Errors
Reset Error Log
No
Yes
Password=050
Special Functions
Factory Restore
No
Yes

- 17 -
DMX Settings
Enter the control menu and select DMX Settings, press ENTER. Use the UP/DOWN button
to select DMX Address, Channel Mode, No DMX Status, View DMX Value, Connect Option,
Network, Art-Net Settings or sACN Settings.
DMX Address
Channel Mode
Select Channel Mode, press ENTER.
Use UP/DOWN button to select between 7 CH, 15 CH, 21 CH, 39 CH,
112 CH, 17 CH, 33 CH, 65 CH, 68 CH, 117 CH and 70 CH, confirm your
selection with ENTER.
To exit the menu, press MENU, or wait 30 seconds.
Select DMX Address, press ENTER.
Use UP/DOWN button to select an address, confirm your selection with
ENTER.
CHANNEL MODE
DMX ADDRESS
7 CH
1-506
15 CH
1-498
21 CH
1-492
39 CH
1-474
112 CH
1-401
17 CH
1-496
33 CH
1-480
65 CH
1-448
68 CH
1-445
117 CH
1-396
70 CH
1-443
To exit the menu, press MENU, or wait 30 seconds.

- 18 -
No DMX Status
View DMX Value
Connect Option
Network
Art-Net Settings
Select Art-Net Settings, press ENTER.
Use UP/DOWN button to select Net, Sub-Net or Universe, confirm your
selection with ENTER.
To exit the menu, press MENU, or wait 30 seconds.
Select Network, press ENTER.
Use UP/DOWN button to select IP Address or Subnet Mask, confirm
your selection with ENTER.
To exit the menu, press MENU, or wait 30 seconds.
Select Connect Option, press ENTER.
Use UP/DOWN button to select Auto, DMX, Art-Net or sACN, confirm
your selection with ENTER.
To exit the menu, press MENU, or wait 30 seconds.
Select View DMX Value, press ENTER.
Use UP/DOWN button to select the desired DMX channel, for which the
value is to be displayed.
To exit the menu, press MENU, or wait 30 seconds.
Select No DMX Status, press ENTER.
Use UP/DOWN button to select one of the following status:
Hold (The device continues to operate in the current mode with the last
active DMX values until the signal returns)
Blackout (Fixture blacks out if DMX signal stops)
Manual (The device accepts the DMX value stored in the ‘Manual Mode’
menu)
Confirm your selection with ENTER.
To exit the menu, press MENU, or wait 30 seconds.

- 19 -
sACN Settings
Fixture Settings
Enter the control menu and select Fixture Settings, press ENTER. Use the UP/DOWN button
to select Dimmer Curve, Dimmer Speed, White Balance or Invert Pixel Order.
Dimmer Curve
Dimmer Speed
Select Dimmer Speed, press ENTER.
Use UP/DOWN button to select Fast or Smooth, confirm your selection
with ENTER.
To exit the menu, press MENU, or wait 30 seconds.
Select Dimmer Curve, press ENTER.
Use UP/DOWN button to select Linear, Square Law, Inv SQ Law or S
Curve, confirm your selection with ENTER.
To exit the menu, press MENU, or wait 30 seconds.
Select sACN Settings, press ENTER.
Use UP/DOWN button to select sACN Universe or sACN Priority,
confirm your selection with ENTER.
To exit the menu, press MENU, or wait 30 seconds.
