Stanley EL User manual

i am growth.
we are Stanley.
Stanley EL Electronic Lock

Topics
Product Description
Standalone
Wireless
Hardware Installation
Software Configuration
Product Support
Technical Training
2

Product Description
Standalone Wireless
3

No software to install
All programming at lock
Upgradeable to wireless
Proximity reader only
Visual / Audible feedback
Standalone - Overview
Standalone
EL Series Lockset Specifications
4

Standalone - Application
Medium usage areas
No audit trail
1-12 door applications
Recommended <200 users
Interior applications only
Tubular / Cylindrical doors only
All programming at reader
5

Front
General Electronic Specifications
Reader Technology –Proximity only
1000 Users (recommend <200 for standalone
application
125 kHz Credential compatibility
4 AA Batteries
Visual/Audible indicators
Warranty –1 year
Wireless Only
Communication Interface –802.15.4 (2.4GHz)
AES 128-bit Encryption
500 Audits stored at lock
Standalone - Specifications
Back
6

Stand Alone - Installation & Configuration
Installation Video
www.elserieselectroniclock.com
Standalone Installation Documentation
QEL200 Lockset Template
QEL200 Thin Door Shim Kit
QEL200 Lockset Installation Instructions
Standalone Configuration Documentation
QEL200 Series Quick Start Guide
QEL200 Series User Guide
7

Server based software
Web browser interface
Wireless survey kit
Wireless gateway
Wireless card added to reader
Data stored at reader
Proximity reader only
Wireless - Overview
Wireless
8

Wireless - Product Application
Medium usage areas
Audit trail
Gateway can communicate with up to
64 locks
1000 users per lock
Interior applications
9

Power - PoE (IEEE 802.3 af) or 24 VDC (AC/DC adaptor sold
separately)-only one cable
LAN Communication Interface –Ethernet TCP/IP (IEEE
802.3)
Wireless Communication Interface–IEEE 802.15.4
Configuration Interface –Web Based Portal
AES 128-bit Encryption
Warranty –1 year
Wireless - Gateway
10

Operating System - Windows Server 2008 R2, Windows 7
Professional
Hardware Requirements –32 Doors or less
CPU-2GHz
Memory-2GB
Hard Drive-50GB
Hardware Requirements –128 Doors or less
CPU-2 GHz Dual Core
Memory-4GB
Hard Drive-100GB
NOTE: Home or Starter versions of Windows are NOT
supported as they do not include the required components
System Requirements - Computer Specifications
11

IIS (Internet Information Services) –Installed and
configured by Intelli-M software
Message Queuing –Installed and configured by Intelli-M
software
SQL Server 2008 R2 –Installed by Intelli-M software if not
currently installed on access control server. SQL Server 2008
R2 Express is provided with software
SQL Reporting Services –Installed by Intelli-M software if
needed
Firewall exceptions configured by Intelli-M software
Required ports:80,443,18776,18777,18779
System Requirements - Software
12

It is recommended that a site survey be conducted prior to
the installation of wireless gateways
Building construction may interfere with wireless signal
reception between the gateway and the locksets
Equipment or machinery may interfere with wireless signal
reception between the gateway and the locksets
A survey is the only method to precisely determine the
quantity and placement of the wireless gateways and their
antennae
System Requirement - Site Survey
13

Tools
Scepter-simulates gateway antennae location to ensure
signal reception
Emulator-simulates EL Lock on the specific door locations
Product Installation - Survey Kit
Scepter Emulator
14

Survey Kit Contents:
Scepter assembly with monitor
1 AC/DC adapter power supply
4 Preconfigured locksets (Emulators)
4 Battery holders
Pelican case
System Requirement - Site Survey
Scepter Emulator
15

Site Plan
Make sure all tools are charged
Create a site plan with dimensions and
distances
Hang all emulators at required door
locations
Emulators should be placed on the interior
side of the door
Stand with scepter to determine maximum
signal strength for the each emulator –
adjust location(s) for number of emulators
Scepter location determines final antennae
placement
Coordinate network drop(s) for gateways
with customer
Product Installation-Survey Process
QEL Survey Quick Start Guide
16

Download Intelli-M software
https://s3.amazonaws.com/StanleyELP/Downloads/Setup.exe
Conduct survey
Coordinate network drops based on site survey
Configure access control server computer
Install Intelli-M access control software on server
Install gateways in predetermined locations
Install gateway antennas based on survey
Configure gateways
Confirm gateway communication with server
Install or Upgrade readers to wireless
Attach readers to gateway
Installation - Checklist
17

Gateway Installation and Configuration
QEL Gateway installation documentation
QEL Gateway configuration video
Reader installation and upgrade to wireless video
www.elserieselectroniclock.com
The listed links below will take you to the installation
documentation and to hardware installation
demonstration videos
Hardware Installation
18

Intelli-M Hardware
Configuration Steps
Zones
Doors
Schedules
Groups
Rules
Intelli-M Administration
People
Events
Reports
Hardware Control
Software Configuration - Checklist
19

Dentist Office Zone:
2 doors into the Dentist’s
office
Closet Zone:
1 door into the supply closet
Surgery Room Zone:
1 door into surgery
A door occupies a physical space, and its border
areas are called Zones. When applying privileges
to a door you’re granting access to a zone
Zones
